TurboTronic airchefPro TT-AF190 User manual

INSTRUCTION MANUAL
DIGITAL AIR FRYER
TT-AF190
EN

Thank you for choosing AirChef Pro Digital Air Fryer by TurboTronic®.
Enjoy easy home cooking, produces nutritious healthy food in a convenient
and consistent fashion. This air fryer lets you cook your favorite foods with
little to no oil. same great taste. Thanks to Rapid air technology there is no
need to add oil to prepare fried foods. This technique uses the hot 360° air
circulating with speed and precision to make healthier versions of your
favorite fried foods. with a temperature range of 40°C –200°C, the fryer
allows you to prepare a variety of dishes from crispy fries to juicy wings
with little to no oil, up to 80% less fat.
PRODUCT SIZE
270*350*323mm
N.W: 4.65KG
PACKAGE SIZE
390*315*363mm
G.W: 5.75KG
ELECTRICAL AND ENVIRONMENTAL PARAMETERS
ITEM
SPECIFICATION
1
Working voltage and frequency
220-240V,50Hz~
2
Stand by power
<1W
3
Rated voltage and power
220-240V/1600W
4
Motor
230V,50Hz
5
Max working humidity
RH95%
6
Working ambient temperature range
0°C-100°C
7
Storage ambient temperature range
-5 °C-100°C
TECHNICAL SPECIFICATION
NAME
SPECIFICATION
Temperature adjust range
40°C-200°C
Time adjust range
1~60min/
Time control error
±2%
Temperature accuracy error
±5%

IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY. READ ALL INSTRUCTIONS.
When using electrical appliance, basic safety precautions should
always be followed, including the following:
Read this user manual carefully, before you use the appliance, and keep it
safely for future reference.
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. READ ALL INSTRUCTIONS.
2. Do not touch hot surfaces. Use handles or knobs. Use oven mitts or
potholders.
3. To protect against electric shock do not immerse cord, plugs, or
appliance in water or other liquid.
4. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
5. Children should be supervised to ensure that they do not play with
the appliance.
6. Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts, and before cleaning the
appliance.
7. Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Bring it to a qualified technician for examination, repair or electrical or
mechanical adjustment.
8. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
11. Do not place on or near a hot gas or electric burner, or in a
heated oven.
12. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
13. Always attach plug to appliance first, then plug cord into the
wall outlet. To disconnect, turn any control to “off” , then remove

plug from wall outlet.
14. Do not use appliance for other than intended use.
15. Make sure the crisping tray is in place before adding food to
be air fried.
16. Make sure the frying basket is locked securely into the front of
the Air Fryer, while the Air Fryer is in operation.
WARNING: The Air Fryer will not operate unless frying basket is
fully closed.
CAUTION: After hot air frying, extreme caution must be used
when handling the hot frying basket, crisping tray, and cooked foods.
ADDITIONAL IMPORTANT SAFEGUARDS
CAUTION HOT SURFACES:This appliance generates heat and
escaping steam during use. Proper precautions must be taken to
prevent the risk of burns, fires, or other injury to persons or damage to
property.
CAUTION: This appliance is hot during operation and retains heat for
some time after turning OFF. Always use oven mitts when handling hot
materials and allow metal parts to cool before cleaning. Do not place
anything on top of the appliance while it is operating or while it is hot.
1. All users of this appliance must read and understand this instruction
manual before operating or cleaning this appliance.
2. The cord to this appliance should be plugged into a 220V AC
electrical outlet only.
3. If this appliance begins to malfunction during use, pull the frying
basket drawer out of the body. Then remove plug from wall outlet. Do
not use or attempt to repair the malfunctioning appliance.
4. Do not leave this appliance unattended during use.
5. Do not immerse power cord in any liquid. If the power cord to this
appliance is damaged, it must be replaced by contacting Consumer
Service.
6. Keep the cord out of reach from children and infants to avoid the
risk of electric shock and choking.
7. Place the Air Fryer on a flat, heat-resistant work area.

8. Do not obstruct the air outlet or air inlets on the back and sides of
the Air Fryer with any objects. Avoid escaping steam from the air outlet
during air frying.
9. Keep appliance at least 4 inches away from walls or other objects
during operation.
10. Always use the frying basket handle to open frying basket drawer.
11. Never move a hot Air Fryer or an Air Fryer containing hot food.
Allow to cool before moving.
12. Do not clean with metal scouring pads. Pieces can break off the
pad and touch electrical parts, creating a risk of electric shock.
13. Use extreme caution when removing tray or disposing of hot
grease.
WARNING: After air frying, make sure to place the frying basket
drawer on a flat, heat-resistant surface.
WARNING: Over-filling the frying basket may damage the Air
Fryer and could result in serious personal injury.
Indicates to read and review instructions to understand operation and use of
product.
Indicates the presence of a hazard that can cause personal injury, death or
substantial
property damage if the warning included with this symbol is ignored.
Take care to avoid contact with hot surface. Always use hand protection to
avoid burns.
For indoor and household use only.
NOTES ON THE PLUG
This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug will fit in a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Do not modify
the plug in any way.

NOTES ON THE CORD
A. A short power-supply cord (or detachable power-supply cord) is to
be provided to reduce the risk resulting from becoming entangled in or
tripping over a longer cord.
B. Longer detachable power-supply cords or extension cords are
available and may be used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used:
1. The marked electrical rating of the cord or extension cord should be
at least as great as the electrical rating of the appliance;
2. If the appliance is of the grounded type, the extension cord should
be a grounding-type3-wire cord.
3. The longer cord should be arranged so that it does not drape over
the countertop or table top where it can be pulled on by children or
tripped over unintentionally.
PARTS & ACCESSORLES
1. Control panel
2. Main body
3. Air inlet
4. Non-Stick coating frying rack
5. Basket cover
6. Handle cover
7. Non-stick coating frying tray

INSTRUCTIONS
ITEM
ICON
OPERATION INSTRUCTION
1
After the machine is powered on, press the button““,
in the standby state, click this button to enter the function
selection state, the default DIY menu is in the state of
being selected; in the non-standby state, click this button
to enter the standby state.
2
Press this icon enter the state, the corresponding LED
screen flashes, turn the dial to set the time. After the
setting is completed, do not operate within 5 seconds or
press the icon again to confirm the setting is completed.
The time icon turns into a constant light display. Rotation
in 1-minute steps.
3
Press this icon enter the state, the corresponding LED
screen flashes, turn the dial to set the temperature. After
the setting is completed, do not operate within 5 seconds
or press the icon again to confirm the setting is
completed. The temp icon turns into a constant light
display. Rotation in 1-degrees centigrade steps.
4
When the power is on and you press the "ON/OFF" Icon,
the Fries menu is selected by default, and the Fries menu
icon flashes. The user can directly press the "Start"
button to enter the working state.

5
When the power is on, press the "ON/OFF" icon and the
machine will enter the setting state. Press this menu at
this time, the menu icon flashing display. Directly press
the "Start" button to enter the Bread mode.
6
When the power is on, press the "ON/OFF" Icon and the
machine will enter the setting state. Press this menu at
this time, the menu Icon flashing display. Directly press
the "Start" button to enter the Vegetable mode.
7
When the power is on, press the "ON/OFF" icon and the
machine will enter the setting state. Press this menu at
this time, the menu icon flashing display. Directly press
the "Start" button to enter the Steak mode.
8
When the power is on, press the "ON/OFF" icon and the
machine will enter the setting state. Press this menu at
this time, the menu icon flashing display. Directly press
the "Start" button to enter the Drumstick mode.
9
When the power is on, press the "ON/OFF" icon and the
machine will enter the setting state. Press this menu at
this time, the menu icon flashing display. Directly press
the "Start" button to enter the Fish mode.
10
When the power is on, press the "ON/OFF" icon and the
machine will enter the setting state. Press this menu at
this time, the menu icon flashing display. Directly press
the "Start" button to enter the Shrimp mode.
11
When the power is on, press the "ON/OFF" icon and the
machine will enter the setting state. Press this menu at
this time, the menu icon flashing display. Directly press
the "Start" button to enter the Thaw mode.
12
Menu selection button, in the function selection state,
click this button, in the 8 preset menus, from left to right
cycle to select the corresponding menu.

BEFORE USING FOR THE FIRST TIME
1. Remove all packing material and labels from the inside and
outside of the air fryer. Check that there is no packaging underneath
and around the frying basket.
2. Your air fryer is shipped with the frying
basket locked inside the air fryer body. Firmly
grasp the frying basket handle to open frying
basket and place on a flat, clean work area.
3. Wash air frying basket and crisping tray in
hot, soapy water.
Do not immerse the air fryer body in water.
Wipe the air fryer body with a damp cloth.
Dry all parts thoroughly.
To ensure the crisping tray fits snugly into
the frying basket drawer, there are 4 rubber
tips attached to make sure all 4 rubber tips
are in place. If they become separated from
the tray, simply slide onto the tabs as shown. (See fig 2.)
CARE & CLEANING INSTRUCTIONS
WARNING! Allow the Air fryer to cool fully before cleaning.
1. Unplug the Air Fryer. Remove frying basket. Make sure the frying
basket and crisping tray have cooled completely before cleaning. Use the
center hole of the crisping tray to lift crisping tray up and out of the frying
basket.
13
Start & Stop & Cancel button, in the function selection
state, click this button, the corresponding menu starts to
enter the working state. In the working state, click this
button, enter the pause state, long press to return to the
initial function selection state
14
Custom menu button, in the function selection state, click
this button to select the DIY menu. You can set with any
time and temp. you want and keep it as memory function.

2. Wash the frying basket and crisping tray in hot soapy water. Do not use
metal kitchen utensils or abrasive cleansers or cleaning products as this
may damage the nonstick coating.
3. The frying basket and crisping tray are dishwasher-safe. For best
results, place in the top rack of your dishwasher to clean.
4. Wipe the air fryer body with a soft, non-abrasive damp cloth to clean.
STORING INSTRUCTIONS
1. Make sure the air fryer is unplugged and all parts are clean and dry
before storing.
2. Never store the air fryer while it is hot or wet.
3. Store the air fryer in its box or in a clean, dry place.
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE), requires that old
household electrical appliances must not be disposed of in
the normal unsorted municipal waste stream. Old
appliances must be collected separately in order to optimize
the recovery and recycling of the materials they contain, and reduce the
impact on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance, it must be separately
collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
LIMITED WARRANTY
Limited Warranty applies to purchases made from authorized retailers of
TurboTronic®.
TurboTronic®Warranty coverage applies to the original owner and to the
original product only and is not transferable.
TurboTronic®warrants that the unit shall be free from defects in material
and workmanship. Limited Warranty apply only when it is used under normal
household conditions and maintained according to the requirements outlined
in the Owner’s Guide, subject to the following conditions and exclusions:

ANY WARRANTY OR AFTER PURCHASE SERVICE, SHOULD BE
WITH A THIRD-PARTY COMPANY, FROM WHICH YOU PURCHASED
THE PRODUCT. TURBOTRONIC® PROVIDES THE WARRANTY ONLY
TO OUR THIRD-PARTY SUPPLIERS. SINCE THIS PRODUCT IS NOT
PURCHASED DIRECTLY FROM TURBOTRONIC®BUT THROUGH ONE
OF OUR THIRD-PARTY SUPPLIERS, ANY ISSUE AFTER THE
PURCHASE, CUSTOMER SERVICE OR RECEIVING THE WARRANTY
SHOULD BE ONLY / DIRECTLY THROUGH THE THIRD-PARTY
SUPPLIERS FROM WHICH YOU PURCHASED THE PRODUCT.
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in
TurboTronic® sole discretion, will be repaired or replaced
2. TurboTronic® reserves the right to replace the unit with one of equal or
greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids,
cups, blades, blender bases, removable pots, racks, pans, etc.), which
require regular maintenance and/or replacement to ensure the proper
functioning of your unit, are not covered by this warranty.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform
required maintenance (e.g., failure to keep the well of the motor base
clear of food spills and other debris), or damage due to mishandling in
transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®.
These defects include damages caused in the process of shipping,
altering, or repairing the TurboTronic® product (or any of its parts) when
the repair is performed by a repair person not authorized by
TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the
specifications contained herein are subject to change without notice.
TurboTronic®and Z-Line®are registered trademarks of
Z-GLOBAL B.V.B.A ®.
PRINTED IN PRC
