TurboTronic XL airchef TT-AF12D User manual

1
EN
INSTRUCTION MANUAL
DIGITAL AIR FRYER
TT-AF12D
www.zline-world.com
®

2
Thank you for buying XL airchef - Digital air fryer by TurboTronic®.
You will now be able to cook a wide assortment of food in a healthier manner –
with little or no oil!
The air fryer uses hot air, in combination with high-speed air circulation, and a top
grill to prepare your dishes quickly and easily. The ingredients are heated from all
sides, at once, and there is no need to add oil in most cases.
General description
A: Tray
B: Basket
C: Basket handle
D: Air inlet
E: Control panel
F: Vent windows
G: Power cord

3
A: Pre-heat
B: Temperature plus/minus
C: French fries
D: meat
E: Time/Temperature
F: Drumsticks
G: Steak
H: Time plus/minus
I: PAUSE
J: START
K: Vegetables
L: Chicken
M: fish
N: Shrimp
O: Cake
Important
Read this user manual carefully, before you use the appliance, and keep it safely for future
reference.
Danger
- Never immerse the housing, which contains electrical components and the heating
elements, in water nor rinse it under the tap.
- Do not let any water or other liquid enter the appliance –to prevent electric shock.
- Always put the ingredients to be fried in the tray, to prevent it from coming into contact
with the heating elements.
- Do not cover the air inlet and the air exhaust openings while the appliance is operating.
- Do not fill the basket with oil as this may cause a fire hazard.
- Never touch the inside of the appliance while it is operating.
- Check whether the voltage indicated on the appliance corresponds to the local mains
voltage in your country before you connect the appliance.
- Do not use the appliance if the plug, the power cord or the appliance itself is damaged.
- If the power cord is damaged, you must have it replaced at a service center authorized
by similarly qualified persons in order to avoid a hazard.
- This appliance is not suitable for children or for people who are either physically or
mentally handicapped or who lack experience and knowledge. Should you want anyone

4
else to use the appliance, that person should be properly guided on its use.
- Keep the appliance and its mains cord out of the reach of children when the appliance is
switched on or is cooling down.
- Keep the mains cord away from hot surfaces.
- Do not plug in the appliance or operate the control panel with wet hands.
- Only connect the appliance to an earthed wall socket. Always make sure that the plug is
inserted into the wall socket properly.
- Never connect this appliance to an external timer switch.
- Do not place the appliance on or near combustible materials such as a tablecloth or
curtains.
- Do not place the appliance against a wall or against other appliances. Leave at least 10cm
free space at the back and sides and 10cm free space above the appliance. Do not place
anything on top of the appliance.
- Do not use the appliance for any purpose other than described in this manual.
- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through the air exhaust openings. Keep your
hands and face at a safe distance from the steam and from the air exhaust openings.
Also be careful of hot steam and hot air when you remove the basket from the appliance.
- The surface below the appliance may become hot during use.
- Immediately unplug the appliance if you see dark smoke coming out of the appliance.
Wait for the smoke emission to stop before you remove the basket from the appliance.
Caution
- Place the appliance on a horizontal, level and stable surface.
- This appliance is intended for normal household use only. It is not intended for use in
environments such as staff kitchens, offices, farms or other work environments. Nor is it
intended to be used by clients in hotels or other similar environments.
- If the appliance is used improperly or if it is not used according to the instructions in the
user manual, the warranty becomes invalid and seller refuses any liability for any
damage that may be caused.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30 minutes before you handle or clean it.
- Remove burnt remnants.
Before first use
1. Remove all packing material.
2. Remove any stickers or labels from the appliance –other than the rating label.
3. Thoroughly clean the tray, and basket, with hot water and some liquid washing soap
using a non-abrasive sponge.

5
Note: Youcan also clean these parts in the dishwasher.
4. Wipe the inside and outside of the appliance with a moist cloth.
Preparing for use
1. Place the appliance on a stable, horizontal and level surface that is also heat resistant.
2. Place the tray in the basket properly.
Do not fill the basket with oil or any other liquid.
Do not put anything on top of the appliance. This disrupts the airflow and affects the
air-frying result.
Using the appliance
1. Power on
Plug in, there is BEEPS sounds. Light up. 1 seconds will be back to standby mode:
all light will be off expect .
2. Menu selection/Temperature/Time
Plug in, it is at the standby mode. press , default temperature and default time
of the Program are 180°C, 15 min respectively, at that time you can adjust the
time and temperature freely by using Time +/- and Temperature +/- button.
You can also press any function icon to cook different food. When press the function icon,
the lights flickered, then press unit start to work. Every function have its own default
time and temperature (As shown in the table). Customer can adjust the time and
temperature freely by using Time +/- and Temperature +/- button.
(1). The temperature control range is 50-200°C, every click on the + / - temperature will
increase or reduce 10°C. At 200°C, ，press the "+", will loop back to a temperature of
50°C, press the "-" at 50°C temperature will cycle back to 200°C. In the process of
temperature control, temperature digital display will flicker on the screen (not
flashing during working), after flickering 3 times, the temperature has been done
of setting;
(2). The adjusting time range is 1 to 60 mins. every click on the + / - time will
increase or reduce 1 min. At 60 min if you press "+", the time will cycle back to
01 min,. At 01 min , if you press "-", the temperature will cycle back to 60 min.

6
In the process of time control, time digital display will flicker on the screen (not
flashing during working), after flickering 3 times, the time has been done of
setting.
3. Start, pause/stop
After select function ,set the right time and right temperature, press , the
start to flicker, after BEEPS sounds, machine start to work. During the
machine working, press , after BEEPS sounds, machine stop working,
stop flickering. during the machine working, press , after BEEPS, machine
stop working, and machine back to standby mode.
Noted:
(1). During working, you can take basket out, stop working, and you can check
cooking result or add more food, machine continue to work on the program if
pull in the basket.
(2). Power cut or unplug during working, machine stop working, all light off,
machine continue to work on the program when power on or plug in again.
3,during work, five red lights flicker on by one all the time.
4. End of program
Heating element stop working when working time is done ,show 00 min, motor
continues to work, buzzer warning. motor continues to work 1 min, cooling
machine, then machine enter the standby mode.
Menu table
program logistics
menu
Default
time(min)
Default temperature（
°C ）
function
pre-heat
3
180
French fries
18
200
Meat
12
200
drumsticks
20
200

7
steak
12
180
cake
25
160
shrimp
8
180
fish
10
180
chicken
30
200
vegetables
10
160
Caution: Do not touch the pan during and about 30mins after use, as it gets very hot.
Only hold the pan by the handle.
Operation step
1. Put the mains plug in an earthed wall socket.
2. Put the ingredients into the tray and put tray in basket
3. put the basket in the right position. Choose function from menu and press
START/PAUSE to start cooking.
4. screen display
It will show temperature and time. Temperature is the setting temperature and time is
remain working time
The function we have selected is flicker
5.Some ingredients require shaking halfway through the preparation time (see section
'Settings' in this chapter). To shake the ingredients, pull the basket out of the appliance by
the handle and shake it. Then slide the basket back into the air fryer.
6.When you hear the timer bell, the set preparation time has elapsed. Pull the pan out of
the appliance and place it on a heat-resistant surface.
7.Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide the basket back into the appliance and
cook it extra minutes
After hot air frying, the basket and the ingredients are hot. Depending on the type of
ingredients in the air fryer, steam may escape form the basket.
9. Emptythe trayinto a bowl or ontoaplate.
Tip: Toremove large or fragile ingredients, use a pair of tongs to lift the ingredients out of
the tray.
10.When a batch of ingredients is ready, the air fryer is instantly ready for preparing
another batch.

8
Note: When using the Health Fryer for the first time, a slight smoke or odour may
be emitted. This is normal and will soon subside. Ensure that there is sufficient
ventilation around the Health Fryer.
Settings
Except the preset menu, you also can use this air fryer to make other foods by setting the
time and temperature. This table below helps you to select the basic settings for the
ingredients you want to prepare.
Note: Keep in mind that these settings are only for reference. As ingredients differ in
origin, size, shape as well as brand, we cannot guarantee the best setting for your
ingredients.
5
Because the Rapid Air Technology instantly reheats the air inside the appliance,pulling the
basket briefly out of the appliance during hot air frying barely disturbs process.
Tips:
- Smaller ingredients usually require a slightly shorter preparation time than larger
ingredients.
- A larger amount of ingredients only requires a slightly longer preparation time, a smaller
amount of ingredients only requires a slightly shorter preparation time.
- Shaking smaller ingredients halfway throughthe preparation time optimized the end
result and can help prevent unevenly fried ingredients.
- You can coat fresh potatoes with a little oil for a crispy result. Fry your ingredients in the
air fryer within a few minutes after you have added the oil.
- Do not prepare extremely greasy ingredients such as sausages in the air fryer.
- Snacks that can be prepared in an oven can also be prepared in the air fryer.
- The optimal amount for preparing crispy fries is 500 grams.
- Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also
requires a shorter preparation time than home-made dough.
- You can also use the air fryer to reheat ingredients by setting the temperature to 150°C
and the timer to about 10 minutes.

9
Time
(min.)
Temperature (°C)
Shake
Extra information
Potatoes & fries
Thin frozen fries
12-16
200
Shake
Thickfrozen fries
12-20
200
Shake
Home-made fries
(8x8mm)
18-25
180
Shake
add1/2 tbsp of oil
Home-made
potato wedges
18-22
180
Shake
add1/2 tbsp of oil
Home-made
potato cubes
12-18
200
Shake
add1/2 tbsp of oil
Rösti
15-18
180
Potato gratin
18-22
180
Meat & Poultry
Steak
8-12
180
Pork chops
10-14
180
Hamburger
7-14
180
Sausage roll
13-15
200
Drumsticks
18-22
180
Chicken breast
10-15
180
Snacks
Spring rolls
8-10
200
Shake
Use oven-ready
Frozen chicken
Nuggets
6-10
200
Shake
Use oven-ready
Frozen fish
fingers
6-10
200
Use oven-ready
Frozen Bread-
crumbed cheese
snacks
10
200
Use oven-ready

10
Stuffed
vegetables
10
160
Use oven-ready
Note: Add 3 minutes to the preparation time before you start frying if the appliance is
cold.

11
Making home-made fries
For the best results, we advise to use pre-baked fries. If you want to make home-made fries,
follow the steps below:
1. Peel the potatoes and cut them into sticks.
2. Soak the potato sticks in a bowl of water for at least 30 minutes, take them out and
dry them with kitchen paper.
3. Pour 1/2 tablespoon of olive oil in a bowl, put the sticks on top and mix until the sticks
are coated with oil.
4. Remove the sticks from the bowl with your fingers or a kitchen utensil so that excess oil
stays behind in the bowl. Put the sticks in the tray.
Note: Do not tilt the bowl to put all the sticks in the tray in one go, to prevent excess oil from
collecting at the bottom of the basket.
5. Fry the potato sticks according to the instructions in this chapter.
Cleaning
Clean the appliance after every use.
The basket, tray and the inside of the appliance have a non-stick coating. Do not use metal
kitchen utensils or abrasive cleaning materials to clean them, as this may damage the non-
stick coating.
1. Remove the mains plug from the wall socket and let the appliance cool down.
Note: Remove the basket to let the air fryer cool down more quickly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the basket and tray with hot water, some washing liquid soap and a non-abrasive
sponge.
You can use a washing liquid to remove any remaining dirt.
Note: The basket and tray are dishwasher-proof.
Tip: If dirt is stuck to the tray, or at the bottom of the basket, fill the basket with hot water
and with some washing liquid soap. Put the tray in the basket and let the basket and the tray
soak for approximately 10 minutes.
1. Clean the inside of the appliance with hot water and a non-abrasive sponge.
2. Clean the heating element with a cleaning brush to remove any food residues.
Storage
1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.

12
Troubleshooting
Problem
Possible cause
Solution
The air fryer does
not work
The appliance is not
plugged into the mains.
Put the mains plug in an earthed
wall socket.
Youhave not set the timer.
Turn the timer knob to the required
Preparation time to switch on the
appliance.
The ingredients
fried with the
air fryer are not
done.
The amount of the
ingredients in the tray is too
much.
Put smaller batches of ingredients in
the tray. Smaller batches are fried
moreevenly.
The set temperature is too
low.
Turn the temperature control knob to
the required temperature setting
(see section 'Settings').
The preparation time is too
short.
Turn the timer knob to the required
preparation time (see section
'Settings').
The ingredients
are fried unevenly
in
the air fryer.
Certain types of the
ingredients need to be
shaken halfway through the
preparation time.
Ingredients that lie on top of or
across each other (e.g. fries) need
to be shaken halfway through the
preparation time (see section
'Settings').
Fried snacks arenot
crispy when they
come out of the air
fryer
You used a type of snacks
meant to be prepared in a
traditional deep fryer.
Use oven snacks or lightly brush
some oil onto the snacks for a
crispier result.
I cannot slidethe
panintothe
applianceproperly.
There is too much food in
the tray.
Do not fill the tray beyond the Max
amount indicated in the table on the
earlier page.
The tray is not placed in the
pancorrectly.
Push the tray down into the pan until
you hear a click.
Whitesmokecomes
out of the appliance
Youare preparing greasy
ingredients.
Pay attention that the temperature
is well-controlled to be under 180℃,
when you fry greasyingredients in
the air fryer.

13
Problem
Possible cause
Solution
The pan still contains
greasy residues from
previous use.
White smoke is caused by grease
heating up in the pan. Make sure
you clean the pan properly after
each use.
Freshpotatofries
arefriedunevenly
in theairfryer.
Youdid not soak the potato
sticks properly before you
fried them.
Soak the potato sticks in a bowl of
water for at least 30 minutes; take
them out and dry them with kitchen
paper.
Youdid not use the right
potato type.
Use fresh potatoes and make sure
they stay firm duringfrying.
Freshpotatofries
arenot crispy
when theycome
out of theairfryer.
The crispiness of the fries
depends on the amount of oil
and water in the fries.
Make sure you dry the potato sticks
properly before you coatthem withoil.
Cut the potato into thinner sticks for
a crispier result.
Add slightly more oil for a crispier
result.
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal
unsorted municipal waste stream. Old appliances must be
collected separately in order to optimize the recovery and
recycling of the materials they contain, and reduce the impact
on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance, it must be separately
collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.

14
LIMITED WARRANTY
Limited Warranty applies to purchases made from authorized retailers of
TurboTronic®.
TurboTronic®Warranty coverage applies to the original owner and to the original
product only and is not transferable.
TurboTronic®warrants that the unit shall be free from defects in material and
workmanship. Limited Warranty apply only when it is used under normal
household conditions and maintained according to the requirements outlined in
the Owner’s Guide, subject to the following
conditions and exclusions:
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in
TurboTronic®sole discretion, will be repaired or replaced
2. TurboTronic®reserves the right to replace the unit with one of equal or greater
value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids, cups,
blades, blender bases, removable pots, racks, pans, etc.), which require regular
maintenance and/or replacement to ensure the proper functioning of your unit,
are not covered by this warranty.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform
required maintenance (e.g., failure to keep the well of the motor base clear of
food spills and other debris), or damage due to mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®. These
defects include damages caused in the process of shipping, altering, or repairing
the TurboTronic®product (or any of its parts) when the repair is performed by a
repair person not authorized by TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the specifications
contained herein are subject to change without notice.
TurboTronic®and Z-Line®are registered trademarks of Z-GLOBAL B.V.B.A®.
PRINTED IN PRC
