TurboTronic TT-AF3D User manual

INSTRUCTION MANUAL
DIGITAL AIR FRYER
TT-AF3D
www.zline-world.com
EN

Thank you for choosing TurboAir Fryer Digital Air Fryer by TurboTronic®.
Enjoy easy home cooking, produces nutritious healthy food in a convenient and consistent fashion.
This air fryer lets you cook your favourite foods with little to no oil. same great taste. Thanks to
Rapid air technology there is no need to add oil to prepare fried foods. This technique uses the hot
360° air circulating with speed and precision to make healthier versions of your favourite fried
foods. with a temperature range of 30°C –200°C, the fryer allows you to prepare a variety of
dishes from crispy fries to juicy wings with little to no oil, Up to 80% less fat.
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY. READ ALL INSTRUCTIONS.
When using electrical appliance, basic safety precautions should always be followed, including
the following:
Read this user manual carefully, before you use the appliance, and keep it safely for future reference
Danger
- Always put the ingredients to be fried in the fry pot, to prevent them from coming into contact with
the heating elements.
- Do not cover the air inlet and the air outlet openings in the sides and bottom of the appliance.
- Do not fill the fry pot with oil as this may cause a fire hazard.
- To protect against electrical shock do not immerse cord, plugs, or the appliance in water or other
liquid. Do not rinse it under the tap.
Warning
- Check if the voltage indicated on the appliance corresponds to the local mains voltage before you
connect the appliance.
- Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or
has been damaged in any manner.
- Return appliance to the nearest authorized service facility for examination, repair, or adjustment.
- This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
- Keep the appliance and its cord out of reach of children less than 8 years.
- Close supervision is necessary when any appliance is used by or near children.
- Keep the mains cord away from hot surfaces. Do not let cord hang over edge of table or counter,
or touch hot surfaces.
- Only connect the appliance to an earthed wall socket. Always make sure that the plug is inserted

into the wall socket properly. To disconnect, turn any control to “off”, then remove plug from wall
outlet.
- Always place and use the appliance on a dry, stable, level and horizontal surface. Do not place
on or near a hot gas or electric burner, or in a heated oven.
- This appliance is not intended to be operated by means of an external timer or a separate
remote-control system.
- Do not place the appliance against a wall or against other appliances. Leave at least 10cm free
space on the back and sides and 10cm free space above the appliance. Do not place anything on
top of the appliance.
- Do not use appliance for other than intended use.
- During hot air frying, hot steam is released through the air outlet openings. Keep your hands and
face at a safe distance from the steam and from the air outlet openings. Also be careful of hot
steam and air when you remove the fry pot from the appliance.
- The accessible surfaces may become hot during use. Do not touch hot surfaces. Use handles or
knobs.
- The air fryer accessories become hot when you use them in the air fryer. Be careful when you
handle them.
Caution
- This appliance is intended for normal household use only. It is not intended for use in
environments such as staff kitchens of shops, offices, farms or other work environments. Nor is it
intended to be used by clients in hotels, motels, bed and breakfasts and other residential
environments. Do not use outdoors.
- Do not place any food or other items on the heating element. If a piece of food falls onto the
heating element when the appliance is operating, switch off the appliance and remove the piece of
food with a fork or similar utensil immediately.
- Do not use accessories and kitchen utensils other than those recommended by the manufacturer
with this appliance. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
- Always return the appliance to a service center authorized by seller for examination or repair. Do
not attempt to repair the appliance yourself, otherwise the guarantee becomes invalid.
- This appliance is designed to be used at ambient temperatures between 5°C and 40°C.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30 minutes before you handle or clean it.
- Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking
off parts.
- Empty the fry pot after each batch, especially when you fry fatty or marinated foods. Be careful
because the fry pot becomes hot during use.
- Make sure the ingredients prepared in this appliance come out golden yellow instead of dark or
brown. Remove burnt remnants. Do not fry fresh potatoes at a temperature above 180°C (to
minimize the production of acrylamide).
Extension Cord
a) A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or
tripping over a longer cord.

b) Longer extension cords are available and may be used if care is exercised in their use.
c) If a longer extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance;
2) The cord should be arranged so that it will not drape over the countertop or tabletop where it can
be pulled on by children or tripped over unintentionally; and
3) If the appliance is of the grounded type, the cord set or extension cord should be a grounding-
type 3-wire cord.
SAVE THESE INSTRUCTION
Rating
Item Number
TT-AF3D
Voltage
220-240V
Power
1200W
Capacity of fry pot
3L
GENERAL DESCRIPTION
1 Touch panel / display
2 Fry pot
3 Rack (put into pot)
DISPLAY AND FUNCTIONS
1
3
2
Cooking time indication light
Temperature indication light
8 functions lights
Key to decrease the time or temperature
Key to increase the time or temperature
Menu key, to choose function
Display, shows time and
temperature alternately
Key to set cooking time or temperature
Start key

BEFORE FIRST USE
1 Remove all packaging material.
2 Remove any stickers or labels from the appliance.
3 Thoroughly clean the appliance before first use. (See 'Cleaning ')
PREPARING FOR USE
1 Place the appliance on a stable, horizontal, level and heat-resistant surface.
Note: Do not put anything on top or on the sides of the appliance. This could disrupt the airflow and
influence the frying result.
Caution: Do not place the appliance on non-heat-resistant surfaces.
2 Place the rack in the fry pot.
Caution: Do not fill the pot with oil or any other liquid.
USING THE APPLIANCE
This is an air fryer that works on hot air. Do not fill the fry pot with oil or frying fat.
1 Put the plug in the wall socket.
2 Carefully pull the fry pot out of the air fryer, ensure the rack is inside the pot.
3 Put the ingredients into the fry pot, on the rack.
Note: The air fryer can prepare a large range of ingredients. Refer to the food table (see 'Food
table') for the right quantities and preparation time.
Note: Do not overfill the fry pot or exceed the amount indicated in the food table (see 'Food table'),
as this could affect the quality of the end result.
Note: If you want to prepare different ingredients at the same time, make sure you check the
preparation time required for the different ingredients before you start to prepare them
simultaneously.
4 Slide the fry pot back into the air fryer.
Caution: Do not touch the pot during cooking and short time after use, as it gets very hot,
only can hold the pot by the handle.
function
Default temperature
Temp range
Default time
Time range
chips
200℃
65-200℃
15 Mins
1-90 Mins
wings
185℃
65-200℃
20 Mins
1-90 Mins
chicken legs
200℃
65-200℃
30 Mins
1-90 Mins
fish
165℃
65-200℃
15 Mins
1-90 Mins
steak
200℃
65-200℃
15 Mins
1-90 Mins
cake
160℃
65-200℃
25 Mins
1-90 Mins
pizza
180℃
65-200℃
15 Mins
1-90 Mins
defrost
60℃
30-80℃
20 Mins
1-90 Mins

5 Touch the start key to switch on the machine.
6 Touch the MENU key to choose the function you need. Display will show the default cooking time
and temperature. If need, touch the TIME/TEMPERATURE key then touch + or –to adjust the
cooking time. Then touch the TIME/TEMPERATURE key again you can adjust the temperature.
Note: Add 3 minutes to the preparation time when the appliance is cold. If you want, you can also
let the appliance preheat first without any ingredients inside.
7 Touch the START key to start cooking. The machine will start to count down and the display will
shows the remaining cooking time.
8 Some ingredients require shaking halfway through the preparation time. To shake the
ingredients, pull the pot out of the appliance by the handle and shake it. Then slide the pot back
into the fryer.
Caution: Do not touch the pot during shaking as it’s very hot.
Note: Excess oil from the ingredients is collected on the bottom of the fry pot
Note: When pull out the pot, machine will shut down, pull back the pot, it will continue on cooking.
9 When you hear the beep, the cooking is finished.
Note: If you prepare several batches of fatty ingredients (e.g. drumsticks, sausages or hamburgers)
make sure you remove excess oil with a kitchen paper towel from rack and the bottom of fry pot
after each batch. Be careful as they gets very hot during use.
Note: You can also switch off the appliance manually. To do this, touch the START key .
10 Pull the fry pot out of the appliance and place it on a heat-resistant surface.
11 Check if the ingredients are ready. If the ingredients are not ready yet, simply put the pot back
into the appliance to re-start and set the cooking time to a few minutes.
Note: After hot air frying, the fry pot, the rack, the housing and the ingredients are hot. Depending
on the type of ingredients in the fry pot. Steam may escape from it. This is normal.
12 Empty the fry pot into a bowl or onto a plate.
Tip: To remove large or fragile ingredients, use a pair of tongs to lift the ingredients out of the fry
pot.
When a batch of ingredients is ready, the air fryer is instantly ready for preparing another batch.
FOOD TABLE
This table below will help you to select the basic settings for the ingredients.
Note: Keep in mind that these settings are indications. As ingredients differ in origin, size, shape as
well as brand, we cannot guarantee the best setting for your ingredients.
Note: Add 3 minutes to the preparation time when you start frying while the Hot-air fryer is still cold.
Amount
(g)
Time
(min.)
Temperature
(℃)
Remark
Potato & fries

Frozen French fries
300-500
15-20
200
Shake during cooking
Fresh French fries
300-500
20-30
180
Shake during cooking
Potato gratin
300-600
20-30
200
Shake during cooking
Meat & Poultry
Steak
100-500
10-20
200
Turn over during cooking
Pork chops
100-500
10-20
200
Turn over during cooking
Hamburger
100-500
10-15
180
Sausage roll
100-500
10-15
200
Chicken wings/drumsticks
100-500
15-25
200
Turn over during cooking
Chicken breast
100-500
15-20
200
Turn over during cooking
Snacks
Spring rolls
100-500
8-15
200
Use oven-ready. Turn over
during cooking
Frozen chicken nuggets
100-500
8-15
200
Use oven-ready. Turn over
during cooking
Frozen fish fingers
100-500
8-15
200
Use oven-ready. Turn over
during cooking
Frozen bread crumbed
cheese snacks
100-500
8-15
200
Use oven-ready. Turn over
during cooking
Stuffed vegetables
100-500
8-15
160
Baking
Cake
400
20-25
160
Use baking tin
Quiche
500
20-25
180
Use baking tin/oven dish
Muffins
400
15-20
160
Use baking tin
Sweet snacks
500
15-20
160
Use baking tin/oven dish
Tips
- A smaller amount of food requires a slightly shorter preparation time, a larger amount of food
needs a slightly longer preparation time.
- It is recommended not to fill the fry pot of the air fryer beyond ¾ of its capacity. The maximum
amount of ingredients that can be prepared depends on the kind of food you want to prepare.
- Shaking smaller ingredients halfway through the preparation time optimizes the end result and
can help prevent unevenly fried ingredients.
- Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also requires a
shorter preparation time than home-made dough.
- Place a baking tin or oven dish in the air fryer pot if you want to bake a cake or quiche or if you
want to fry fragile ingredients or filled ingredients
- You can also use the air fryer to reheat ingredients. To reheat ingredients, set the temperature to
150℃for up to 10 minutes.
- It is suggested to wait some minutes to cool down the machine when you need to start another
cooking after the 1st cooking. Keep heating not more than 1 hour.
- If you use oven-ready snacks, do not add oil because they are usually pre-fried and become
golden brown and crispy when prepared in the air fryer.
- If you use oven-ready snacks and they do not become crispy and stay pale, please check the
following:

a. The amount of ingredients: Put smaller batches of ingredients in the fry pot. Cover the bottom of
the fry pot with just one layer. Smaller batches are fried more evenly.
b. The preparation time: If you have not preheated the appliance before you put in the snacks,
make sure you add 3 minutes extra to the preparation time when you set the timer.
c. Most snacks need the preparation time indicated for the oven to become fully cooked.
d. If your croquettes or snacks burst when you prepare them in the air fryer, choose a shorter
preparation time.
CLEANING
Warning: Let the fry pot, rack and the inside of the appliance cool down completely before you
start cleaning. The pot and the rack are with non-stick coating. Do not use metal kitchen
utensils or abrasive cleaning materials to clean them, as this may damage the coating.
Clean the appliance after every use. Remove oil and fat from the bottom of the fry pot after every
use to prevent smoke.
1 Switch off the machine, remove the plug from the wall socket and let the appliance cool down for
15 minutes.
Tip: Remove the fry pot to let the air fryer cool down more quickly.
2 Wipe the outside of the appliance with a moist cloth.
3 Clean the fry pot and rack with hot water, some washing-up liquid and a non-abrasive sponge.
Note: The fry pot and rack are dishwasher-proof.
Tip: If food residues are stuck to the fry pot or rack, you can soak them in hot water with washing-
up liquid for 10 to 15 minutes. Soaking will loosen the food residues and will make it easier to
remove them. The quality of your washing-up liquid determines how easy it is to remove food
residues and grease. Make sure you use a washing-up liquid that can dissolve oil and grease. If
there are grease stains on the fry pot or rack and you have not been able to remove them with hot
water and washing-up liquid, use a liquid degreaser.
Tip: You can use a degreasing liquid to remove any remaining dirt.
4 Clean the inside of the appliance with hot water and a non-abrasive sponge.
Any other servicing should be performed by an authorized service representative.
STORAGE
1 Unplug the appliance and let it cool down.
2 Make sure all parts are clean and dry before you store the appliance.
ENVIRONMENT
Do not throw away the appliance with the normal household waste when it is exhausted, but hand
it in at an official collection point for recycling. By doing this, you help to preserve the environment.

.
TROUBLESHOOTING
This chapter summarizes the most common problems you could encounter with the appliance.
Problem
Possible cause
Solution
The air fryer does not
work
The appliance is not
plugged in.
Put the mains plug in an earthed wall socket.
You have not start
cooking
Press START key to start cooking after
choosing the function
You have not put the fry
pot into the machine
There is a micro switch in machine, no
working if without pot. Just slide in the fry pot
then ok.
Several appliances are
connected to one socket.
Try a different socket and check the fuses.
The air fryer has a power of 1200W.
The outside of the
appliance becomes
hot during use.
The outside of the
appliance becomes hot
because the heat inside
radiates to the outside
walls.
This is normal. The fry pot, rack and the inside
of the fryer will always become hot when the
appliance is switched on to ensure the food is
properly cooked. The fry pot and rack are
always too hot to touch. But the handles,
panel that you need to touch during use will
still stay cool enough to touch.
The ingredients fried
with the air fryer are
not done.
The amount of
ingredients in the fry pot
is too big.
Put smaller batches of ingredients in the fry
pot. Smaller batches are fried more evenly.
The set temperature is
too low.
Adjust the temperature to the required
temperature setting (see ‘food table’).
The preparation time is
too short.
Adjust the cooking time to the required
preparation time (see ‘food table’).
The ingredients are
fried unevenly in the
air fryer.
Certain types of
ingredients need to be
shaken halfway through
the preparation time.
Ingredients that lie on top of or across each
other (e.g. fries) need to be shaken halfway
through the preparation time. See ‘food table’.
Fried snacks are not
crispy when they
come out of the air
fryer.
You used a type of
snacks meant to be
prepared in a traditional
deep fryer.
Use oven snacks or lightly brush some oil onto
the snacks for a crispier result.
I cannot slide the pot
into the appliance
properly.
There are too much
ingredients in the pot.
Do not fill the pot beyond ¾ of its capacity.
White smoke comes
out of the appliance.
You are preparing
greasy ingredients.
When you fry greasy ingredients in the air
fryer, a large amount of oil will leak into the
pot. The oil produces white smoke and the fry
pot may heat up more than usual. This does
not effect the appliance or the end result.
The fry pot still contains
White smoke is caused by grease heating up

grease residues from
previous use.
in the pot . make sure you clean the pan
properly after each use.
Fresh fries are fried
unevenly in the air
fryer.
You did not use the right
potato type.
Use fresh potatoes and make sure they stay
firm during frying.
You did not rinse the
potato sticks properly
before you fried them.
Rinse the potato sticks properly to remove
starch from the outside of the sticks.
Fresh fries are not
crispy when they
come out of the air
fryer.
The crispiness of the
fries depends on the
amount of oil and water
in the fries.
Make sure you dry the potato sticks properly
before you add the oil.
Cut the potato sticks smaller for a crispier
result.
Add slightly more oil for a crispier result.
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE), requires that old household electrical appliances must not be disposed of in
the normal unsorted municipal waste stream. Old appliances must be collected
separately in order to optimize the recovery and recycling of the materials they
contain, and reduce the impact on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you
dispose of the appliance, it must be separately collected.
Consumers should contact their local authority or retailer for information concerning the correct
disposal of their old appliance.
LIMITED WARRANTY
Limited Warranty applies to purchases made from authorized retailers of TurboTronic®.
TurboTronic® Warranty coverage applies to the original owner and to the original product only and
is not transferable.
TurboTronic® warrants that the unit shall be free from defects in material and workmanship. Limited
Warranty apply only when it is used under normal household conditions and maintained according
to the requirements outlined in the Owner’s Guide, subject to the following
conditions and exclusions:
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in TurboTronic® sole discretion,
will be repaired or replaced
2. TurboTronic® reserves the right to replace the unit with one of equal or greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids, cups, blades, blender
bases, removable pots, racks, pans, etc.), which require regular maintenance and/or replacement to
ensure the proper functioning of your unit, are not covered by this warranty.

2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform required maintenance
(e.g., failure to keep the well of the motor base clear of food spills and other debris), or damage due
to mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®. These defects include
damages caused in the process of shipping, altering, or repairing the TurboTronic® product (or any
of its parts) when the repair is performed by a repair person not authorized by TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the specifications contained herein are
subject to change without notice.
TurboTronic® and Z-Line® are registered trademarks of Z-GLOBAL B.V.B.A®.
PRINTED IN PRC
