Tyco Fire Product Star SG300 User manual

High Pressure Sprinklers
Quick and Standard Response
Model SG300
GENERAL DESCRIPTION
The Star Model SG300 Sprinklers are automatic sprin-
klers of the frangible bulb type. Their maximum service
pressure rating of 300 psi (20,7 bar) makes them an ex-
cellent choice for systems that otherwise would require
the use of pressure control valves to reduce the static
pressure to 165 psi (11,4 bar) as required by NFPA stand-
ards, when conventional 175 psi (12,1 bar) maximum
pressure rated sprinklers are utilized. One of the most
common applications for the SG300 Sprinklers is fire pro-
tection systems for high rise buildings.
WARNINGS
The Model SG300 Sprinklers described herein must be in-
stalled and maintained in compliance with this document,
as well as with the applicable standards of the National
Fire Protection Association, in addition to the standards
of any other authorities having jurisdiction. Failure to do
so may impair the integrity of these devices.
The owner is responsible for maintaining their fire protec-
tion system and devices in proper operating condition.
The installing contractor or sprinkler manufacturer should
be contacted relative to any questions.
OPERATION
The glass bulb contains a fluid which expands when ex-
posed to heat. When the rated temperature is reached,
the fluid expands sufficiently to shatter the glass bulb,
which then allows the sprinkler to activate and flow water.
TECHNICAL DATA
Approvals
UL and ULC Listed.
(Refer to the Data Sheets referenced in Table A for 175
psi rated Model SG Sprinkler approvals which also apply
to the UL and ULC Listed SG300 Sprinklers.)
Maximum Working Pressure
300 psi (20,7 bar)
Discharge Coefficient
K=4.2GPM/psi
1/2 (60,5 LPM/bar1/2)
K=5.6GPM/psi
1/2 (80,6 LPM/bar1/2)
Temperature Ratings
Quick Response: 135°F/57°C, 155°F/68°C, 175°F/79°C,
200°F/93°C, and 286°F/141°C
Standard Response: 135°F/57°C, 155°F/68°C,
175°F/79°C, 200°F/93°C, 286°F/141°C, and 360°F/182°C
Finishes
White Polyester, Chrome Plated, Natural Brass
(Colors other than white are available on request.)
FIGURE 1
K-FACTOR=4.2 (60,5)
MODEL SG300 UPRIGHT AND PENDENT
(Quick Response or Standard Response)
FIGURE 2
K-FACTOR=5.6 (80,6)
MODEL SG300 UPRIGHT AND PENDENT
(Quick Response or Standard Response)
FIGURE 3
K-FACTOR=4.2 (60,5)
MODEL SG300 HORIZONTAL SIDEWALL
(Standard Response)
FIGURE 4
K-FACTOR=5.6 (80,6)
MODEL SG300 EC 3HORIZONTAL SIDEWALL
(Quick Response)
1/2" NPT
UPRIGHT PENDENT
2-1/8"
REF.
(54.0 mm)
1/2" NPT
U
PRI
G
HT PENDENT
2-1/8"
REF.
(54.0 mm)
2-1/8"
REF.
(54.0 mm)
HORIZONTAL
SIDEWALL
1/2" NPT
2-3/16"
REF.
(55,7 mm)
HORIZONTAL
SIDEWALL
1/2" NPT
Customer Service/Sales: Tel: [phone] • Fax: [phone]
Technical Services: Tel: [phone] • Fax: [phone]
1-1.2.62
TYCO FIRE PRODUCTS
OBSOLETE

DESIGN CRITERIA
The Model SG300 Sprinklers are to be utilized for the
same applications as intended for the 175 psi (12,1 bar)
counterparts described in the cross referenced Star Data
Sheets indicated in Table A. Recessed versions of the
Model SG300 having up to a maximum temperature rat-
ing of 200°F/93°C are obtained by utilizing the #2085 Re-
cessed Escutcheon as described in the applicable cross
referenced Star Data Sheets.
INSTALLATION
Installation of the Model SG300 Sprinklers is to be the
same as the 175 psi (12,1 bar) counterparts described in
the cross referenced Star Data Sheets indicated in Table
A.
CARE AND MAINTENANCE
The Model SG300 Sprinklers must be maintained and
serviced in accordance with the following instructions:
NOTE
Before closing a fire protection system main control valve
for maintenance work on the fire protection system which
it controls, permission to shut down the affected fire pro-
tection systems must be obtained from the proper authori-
ties and all personnel who may be affected by this action
must be notified.
Absence of an escutcheon, which is used to cover a clear-
ance hole, may delay the time to sprinkler operation in a
fire situation.
Sprinklers which are found to be leaking or exhibiting vis-
ible signs of corrosion must be replaced.
Automatic sprinklers must never be shipped or stored
where their temperature will exceed 100°F/38°C and they
must never be painted, plated, coated, or otherwise al-
tered after leaving the factory. Modified sprinklers must
be replaced. Sprinklers that have been exposed to corro-
sive products of combustion, but have not operated,
should be replaced if they cannot be completely cleaned
by wiping the sprinkler with a cloth or by brushing it with a
soft bristle brush.
Care must be exercised to avoid damage to the sprinklers
— before, during, and after installation. Sprinklers dam-
aged by dropping, striking, wrench twist/slippage or the
like, must be replaced. Also, replace any sprinkler that
has a cracked bulb or that has lost liquid from its bulb
(ref. Installation Section Note).
The owner is responsible for the inspection, testing, and
maintenance of their fire protection system and devices in
compliance with this document, as well as with the appli-
cable standards of the National Fire Protection Associa-
tion (e.g., NFPA 25), in addition to the standards of any
other authorities having jurisdiction. The installing contrac-
tor or sprinkler manufacturer should be contacted relative
to any questions.
It is recommended that automatic sprinkler systems be in-
spected, tested, and maintained by a qualified Inspection
Service.
STAR SPRINKLER
Page 2 1-1.2.62
SIN* K-Factor Response Deflector Data Sheet***
S2945 4.2 QR Upright 1-1.2.11
S2946 4.2 QR Pendent 1-1.2.11
S2946 4.2 QR Rec. Pendent** 1-1.2.11
S2950 5.6 QR Upright 1-1.2.21
S2951 5.6 QR Pendent 1-1.2.21
S2951 5.6 QR Rec. Pendent** 1-1.2.21
S2978 5.6 QR EC HSW 1-1.2.31
S2978 5.6 QR Rec.EC HSW** 1-1.2.31
S2855 4.2 SR Upright 1-1.2.10
S2856 4.2 SR Pendent 1-1.2.10
S2856 4.2 SR Rec. Pendent** 1-1.2.10
S2857 4.2 SR HSW 1-1.3.10
S2857 4.2 SR Rec. HSW** 1-1.3.10
S2850 5.6 SR Upright 1-1.2.20
S2851 5.6 SR Pendent 1-1.2.20
S2851 5.6 SR Rec. Pendent** 1-1.2.20
* Sprinkler Identification Number for 300 psi sprinklers.
** Utilizes #2085 Recessed Escutcheon.
*** Data sheet number for comparible 175 psi sprinkler.
TABLE A
CROSS REFERENCE STAR DATA SHEETS
(Use for applicable Design, Installation,
Maintenance and Service Information)
OBSOLETE

LIMITED WARRANTY
Products manufactured by Tyco Fire Products are war-
ranted solely to the original Buyer for ten (10) years
against defects in material and workmanship when paid
for and properly installed and maintained under normal
use and service. This warranty will expire ten (10) years
from date of shipment by Tyco Fire Products. No warranty
is given for products or components manufactured by
companies not affiliated by ownership with Tyco Fire Prod-
ucts or for products and components which have been
subject to misuse, improper installation, corrosion, or
which have not been installed, maintained, modified or re-
paired in accordance with applicable Standards of the Na-
tional Fire Protection Association, and/or the standards of
any other Authorities Having Jurisdiction. Materials found
by Tyco Fire Products to be defective shall be either re-
paired or replaced, at Tyco Fire Products’ sole option.
Tyco Fire Products neither assumes, nor authorizes any
person to assume for it, any other obligation in connec-
tion with the sale of products or parts of products. Tyco
Fire Products shall not be responsible for sprinkler sys-
tem design errors or inaccurate or incomplete information
supplied by Buyer or Buyer’s representatives.
IN NO EVENT SHALL TYCO FIRE PRODUCTS BE LI-
ABLE, IN CONTRACT, TORT, STRICT LIABILITY OR UN-
DER ANY OTHER LEGAL THEORY, FOR INCIDENTAL,
INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES,
INCLUDING BUT NOT LIMITED TO LABOR CHARGES,
REGARDLESS OF WHETHER TYCO FIRE PRODUCTS
WAS INFORMED ABOUT THE POSSIBILITY OF SUCH
DAMAGES, AND IN NO EVENT SHALL TYCO FIRE
PRODUCTS’ LIABILITY EXCEED AN AMOUNT EQUAL
TO THE SALES PRICE.
THE FOREGOING WARRANTY IS MADE IN LIEU OF
ANY AND ALL OTHER WARRANTIES EXPRESS OR IM-
PLIED, INCLUDING WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE.
ORDERING PROCEDURE
Please Specify:
Quick Response:
4.2 K-Factor Model SG300 QR Upright Sprinkler
(#2945)
4.2 K-Factor Model SG300 QR Pendent Sprinkler
(#2946)
5.6 K-Factor Model SG300 QR Upright Sprinkler
(#2950)
5.6 K-Factor Model SG300 QR Pendent Sprinkler
(#2951)
5.6 K-Factor Model SG300 QR-EC HSW Sprinkler
(#2978)
Standard Response:
4.2 K-Factor Model SG300 SR Upright Sprinkler
(#2855)
4.2 K-Factor Model SG300 SR Pendent Sprinkler
(#2856)
4.2 K-Factor Model SG300 SR HSW Sprinkler
(2857)
5.6 K-Factor Model SG300 SR Upright Sprinkler
(#2850)
5.6 K-Factor Model SG300 SR Pendent Sprinkler
(#2851)
Refer to Price List for for complete listing of Part Num-
bers with respect to temperature ratings, etc.
STAR SPRINKLER
1-1.2.62 Page 3
OBSOLETE

STAR SPRINKLER
Page 4 1-1.2.62
7071 S. 13th Street • Suite 103
Oak Creek, WI 53154
www.starsprinkler.com
PRINTED IN U.S.A. 3-01
