General
Description
Exposure (Outside) Protection Sprin-
klers are utilized to provide protection
from exposure fires on the outside of
buildings . The Issue A and B Window
Type Exposure Protection Sprinklers
areintendedforsprayingwateronwin-
dowglazing at prescibed spacings and
sprinkler locations at a minimum dis-
charge pressure of 7 psi (0,48 bar).
The smaller orifice Issue A Sprinklers
are normally used where exposure is
lightor moderate,theareaofcoverage
is small, or where one horizontal line
of window sprinklers is installed at
each floor. The larger orifice Issue B
Sprinklers are normally used where
exposure is severe, or where one hori-
zontal line of sprinklers is used to pro-
tect windows at more than one floor
level.
Itis recommendedthattheend userbe
consulted with respect tothe suitability
of the materials of construction and
finish for any given corrosive environ-
ment. The effects of ambient tempera-
ture, concentration of chemicals, and
gas/chemical velocity, should be con-
sidered, at a minimum, along with the
corrosive nature to which the sprin-
klers may be exposed.
The Issue A and B Window Type Ex-
posure Protection Sprinklers are a re-
designation for the Gem Issue A and
B.
WARNINGS
The Issue A and B Window Type Ex-
posure Protection Sprinklers de-
scribed herein must be installed and
maintained in compliance with this
document, as well as with the applica-
ble standards of the National Fire Pro-
tection Association, in addition to the
standards ofany other authorities hav-
ing jurisdiction. Failure to do so may
impair the performance of these de-
vices..
The owner is responsible for maintain-
ing their fire protection system and de-
vices in proper operating condition.
The installing contractor or sprinkler
manufacturer should be contacted
with any questions.
Page 1 of 4 TFP835
APRIL, 2006
Issue A and B
Exposure Protection Sprinklers,
Window Type
Technical Services: Tel: [phone] / Fax: [phone]
IMPORTANT
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cautions
with respect to handling and instal-
lation of sprinkler systems and com-
ponents. Improper handling and in-
stallation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation. TABLE A
ISSUE A AND B WINDOW TYPE EXPOSURE PROTECTION SPRINKLERS
ORIFICE SIZES AND K-FACTORS
1/4"
3/8"
5/16" 2.62
4.08
1.83
58,73
37,72
26,33
(LPM / bar)
ISO/SI
(GPM / psi)
NFPA
ORIFICE
SIZE
K-FACTOR
TYPE
NOZZLE
ISSUE A
1/2"
3/4"
5/8" 8.64
12.39
5.76
178,39
124,39
82,93
ISSUE B
THREAD
3/4"
3/4"
1/2"
1/2"
1/2"
1/2"
SIZE
(NPT)

Technical
Data
Approvals
The Issue A and B Window Type Ex-
posure Protection Sprinklers are UL
Listed and FM Approved.
Maximum Working Pressure
175 psi (12,1 bar).
Discharge Coefficient
See Table A.
Thread Connection
See Table A.
Physical Characteristics
Body . . . . . . . . . . . . . Bronze
Design
Criteria
Nozzle Placement. Exposure Protec-
tion Sprinkler Systems must be de-
signed, installed, and calculated in ac-
cordance with NFPA 13. Figures 2 and
3 provide nominal spray patterns.
Main Pipeline Strainers. The use of a
main pipeline strainer per NFPA 13 is
required for sprinklers having a nomi-
nal K-factor less than 2.8 (40,3).
Installation
Issue A and B Window Type Exposure
Protection Window Sprinklers must be
installed in accordance with the follow-
ing instructions:
NOTE
A leak tight 1/2 inch NPTsprinkler joint
should be obtained with a torque of 7
to 14 ft.lbs. (9,5 to 19,0 Nm). A maxi-
mum of 21 ft. lbs. (28,5 Nm) of torque
may be used to install sprinklers with
1/2 NPT connections. A leak tight 3/4
inch NPT nozzle joint should be ob-
tained with a torque of 10 to 20 ft.lbs.
(13,4 to 26,8 Nm). A maximum of 30 ft.
lbs. (40,7 Nm) of torque may be used
to install sprinklers with 3/4 NPT con-
nections. Higher levels of torque may
distort the sprinkler inlet and cause
leakage or impairment of the sprin-
klers.
Step 1. With pipe thread sealant ap-
plied to the pipe threads, hand tighten
the sprinkler into the sprinkler fitting.
Step 2. Tighten the sprinkler into the
sprinkler fitting using an adjustable
crescent wrench. With reference to
Figure 1 the adjustable crescent
wrench is to be applied to wrenchflats.
Page2of4 TFP835
FIGURE 1
ISSUE A AND B WINDOW TYPE EXPOSURE PROTECTION SPRINKLERS
NOMINAL DIMENSIONS
ISSUE A — 1/4, 5/16, and 3/8 INCH ORIFICE
ISSUE B — 1/2 and 5/8 INCH ORIFICE
ISSUE B — 3/4 INCH ORIFICE
FLATS
25/32"
(19,8 mm)
ACROSS
WRENCH
NOMINAL MAKE-IN
7/16" (11,1 mm)
(36,5 mm)
1-7/16"
ORIFICE SIZE
STAMPED ON
1/2" NPT
WRENCH
FLAT
25/32"
(19,8 mm)
1-11/16"
(42,9 mm)
2-7/8"
(73,0 mm) (47,6 mm)
1-3/16"
(69,9 mm)
2-3/4"
7/16"
(11,1 mm)
NOMINAL
MAKE-IN
1/2"
NPT
ORIFICE SIZE
INDICATED ON
DEFLE
C
T
O
R
ACROSS WRENCH
FLATS
1-1/8" (28,6 mm)
1/2"
ORIFICE
ONLY
(77,8 mm)
3-1/16"
ORIFICE SIZE
INDICATED ON
WREN
C
H FLAT
(82,6 mm)
3-1/4"
NOMINAL
MAKE-IN
(12,7 mm)
1/2"
(47,6 mm)
1-3/16"
3/4"
NPT
FLATS
1-3/8" (34,9 mm)
ACROSS WRENCH
ORIFICE
5/8" or 3/4"

Care and
Maintenance
The Issue A and B Window Type Ex-
posure Protection Sprinklers must be
maintained and serviced in accord-
ance with the following instructions:
NOTE
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system that
itcontrols,permissiontoshutdownthe
affectedfireprotectionsystemmustbe
obtained from the proper authorities
and all personnel who may be affected
by this action must be notified.
Issue A and B Window Type Exposure
Protection Sprinklers must never be
painted, plated, coated or altered in
any way after leaving the factory; oth-
erwise, the spray performance may be
impaired.
Care must be exercised to avoid dam-
age to the sprinklers - before, during,
and after installation. Sprinkler dam-
aged by dropping, striking, wrench
twist/slippage, or the like, must be re-
placed.
Frequent visual inspections are rec-
ommendedtobeinitiallyperformedfor
nozzles installed in potentially corro-
sive atmospheres to verify theintegrity
of the materials of constructionas they
may be affected by the corrosive con-
ditions present for a given installation.
Thereafter, annual inspections per
NFPA 25 are required.
Exposure protection systems for the
outside of buildings require regularly
scheduled care and maintenance by
trained personnel. In addition to in-
specting sprinklers for proper spray
performance during water flow trip
tests of the system, it isrecommended
that sprinklers be periodically in-
spected for loading/obstructions, or
other evidence of impaired protection.
The inspections should be scheduled
weekly or as frequently as may be
necessary, and corrective action must
be taken to ensure that the sprinkler
will perform as intended in the event of
a fire.
The owner is responsible for the in-
spection, testing, and maintenance of
their exposure protection system and
devices in compliance with this docu-
ment, as well as with the applicable
standards of the National Fire Protec-
tion Association (e.g., NFPA 25), in
addition to the standards of any other
authorities having jurisdiction. The in-
stalling contractor or sprinkler manu-
TFP835 Page 3 of 4
FIGURE 2
ISSUE A WINDOW TYPE EXPOSURE PROTECTION SPRINKLERS
NOMINAL DISCHARGE PATTERNS
Provided for reference only. Refer to NFPA 13 for the required distance to
window as a function of window width.
EACH SQUARE
= 1 SQ. FT.
WEL DEFINED
OUTLINE
(180 mm)
5/16" & 3/8"
ORIFICE SPRINKLER
1/4"
ELEVATION
ORIFICE
1/4" & 5/16"
ORIFICE PLAN
1/2"
LITTLE
FINE SPRAY
ORIFICE
SURFACE
GLAZING
SHOWN AT
7"
FLOWING
PRESSURE
(2,1 BAR)
30 PSI
FIGURE 3
ISSUE B WINDOW TYPE EXPOSURE PROTECTION SPRINKLERS
NOMINAL DISCHARGE PATTERNS
Provided for reference only. Refer to NFPA 13 for the required distance
to window as a function of window width.
SHOWN AT
(2,1 BAR)
PRESSURE
FLOWING
ORIFICE
1/2"5/8"3/4" ORIFICEORIFICE WEL DEFINED
SPRINKLER
ELEVATION OUTLINE
GLAZING
SURFACE
ORIFICE
1/2"5/8"3/4" ORIFICEORIFICE
30 PSI
EACH SQUARE
FINE SPRAY
PLAN LITTLE (215 mm)
8-1/2"
= 1 SQ. FT.

facturer should be contacted relative
to any questions.
It is recommended that exposure pro-
tection systems for the outside of
buildings be inspected, tested, and
maintained by a qualified Inspection
Service in accordance with local re-
quirements and/or national codes.
Limited
Warranty
Products manufactured by Tyco Fire &
Building Products (TFBP) are war-
ranted solely to the original Buyer for
ten (10) years against defects in mate-
rial and workmanship when paid for
and properly installed and maintained
under normal use and service. This
warranty will expire ten (10) years
from date of shipment by TFBP. No
warranty is given for products or com-
ponents manufactured by companies
not affiliated by ownership with TFBP
or for products and components which
havebeensubjecttomisuse,improper
installation,corrosion, or which have
not been installed, maintained, modi-
fied or repaired in accordance with ap-
plicable Standards of the National Fire
Protection Association, and/or the
standards of any other Authorities
Having Jurisdiction. Materials found
by TFBP to be defective shall be either
repaired or replaced, at TFBP’s sole
option. TFBP neither assumes, nor
authorizesanypersontoassumeforit,
any other obligation in connection with
the sale of products or parts of prod-
ucts.TFBP shall notberesponsiblefor
sprinkler system design errors or inac-
curate or incomplete information sup-
plied by Buyer or Buyer’s repre-
sentatives.
In no event shall TFBP be liable, in
contract, tort, strict liability or under
any other legal theory, for incidental,
indirect,specialor consequentialdam-
ages, including but not limited to labor
charges, regardless of whether TFBP
was informed about the possibility of
such damages, and in no event shall
TFBP’s liability exceed an amount
equal to the sales price.
Theforegoingwarrantyismadeinlieu
of any and all other warranties, ex-
press or implied, including warranties
ofmerchantabilityand fitnessforapar-
ticular purpose.
This limited warranty sets forth the ex-
clusive remedy for claims based on
failure of or defect in products, materi-
als or components, whether the claim
is made in contract, tort, strict liability
or any other legal theory.
This warranty will apply to the full ex-
tent permitted by law. The invalidity, in
whole or part, of any portion of this
warranty will not affect the remainder.
Ordering
Procedure
Whenplacinganorder,indicatethefull
product name and P/N.
Contact your local distributor for avail-
ability.
Window Type Exposure Protection
Sprinklers:
Specify: Issue (A or B) Window Type
Exposure Protection Sprinkler with
(specify finish and material), P/N (Ref.
Table B).
Page4of4 TFP835
TYCO FIRE & BUILDING PRODUCTS, 451 North Cannon Avenue, Lansdale, Pennsylvania 19446
P/N 49 — XXX — X — XXX
ORIFICE
SIZE
1
TABLE B
PART NUMBER SELECTION
NATURAL FINISH BRONZE
200 A
201 B
001
002
003
1/4"
5/16"
3/8"
004 1/2"
005 5/8"
006 3/4"
FINISH
& MATERIAL
ISSUE
