U-Line H-3879 User manual

PAGE 1 OF 2 0514 IH-3879
πH-3879
4-way slatwall tower
1-800-295-5510
uline.com
PARTS
ASSEMBLY
TOOLS NEEDED
Phillips Screwdriver Rubber Mallet (Optional)
KICK BASE ASSEMBLY
1. Install camlock pins into the predrilled holes in kick
base boards using screwdriver. (See Figure 1)
2. Install camlocks into large holes in kick base boards
by tapping them into position with rubber mallet.
(See Figure 2)
NOTE: Ensure the hole in the side of the
camlock always faces outward.
3. Arrange kick base boards to form a square so that
each corner has camlock pins set into the camlocks
of the adjacent board. (See Figure 3)
4. Connect camlocks and pins by inserting screwdriver
into the top hole of the camlock and turning
clockwise. (See Figure 4)
NOTE: Tilt screwdriver at an angle while twisting
to better lock the camlocks.
Confirmat Screw x 12 Camlock Pin x 12 Pan Head Screw x 16
Dowel Pin x 4 Screw Cap x 12Camlock x 12
Caster x 4
Wing Panel x 4Spinner Base Top x 1Kick Base Board x 4
Figure 1
Figure 2
Figure 3 Figure 4
Allen Wrench (Included)
Camlock Pin
Camlock

PAGE 2 OF 2 0514 IH-3879
π CHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
ASSEMBLY CONTINUED
SPINNEr bASE ASSEMbLY
1. Set spinner base top with underside facing up on a
protected surface.
2. Install camlock pins into predrilled holes of the spinner
base using screwdriver. (See Figure 1)
3. Set the kick base onto the spinner base so the
camlocks and camlock pins match up, and tighten
camlocks. (See Figure 5)
NOTE: If you do not want the spinner base to
rotate, install a screw through the bottom base
panel into the top base panel, taking care
not to puncture through the surface of the
top base panel. This will stabilize the spinner
component of the base unit.
CASTErS INSTALLATION (OPTIONAL)
1. Position the casters onto each of the four corners of
kick base assembly. (See Figure 6)
2. Using four pan head screws per caster, attach the
casters through the predrilled holes on the inside
corners of the kick base. (See Figure 6)
NOTE: Install all screws before the final
tightening to allow for easier alignment of
casters.
4-wAY DISPLAY PANELS INSTALLATION
1. Flip spinner base top right side up.
2. Install four wooden dowel pins into the pre-drilled
holes on the base top.
NOTE: Two people are recommeded for steps 3
through 5.
3. Install two panels onto the dowel pins so that they are
perpendicular to each other. Locate the holes on the
bottom of the panels and set them onto the dowel pins.
4. Attach panels together by installing confirmat screws
into predrilled holes using Allen wrench. (See Figure 9)
NOTE: Do not fully tighten screws until all the
panels are in place. Once wing panels are in
place, tighten screws completely.
5. Install remaining panels in the same manner.
6. To cover the exposed screw heads, peel the
decorative screw caps to expose the sticky back,
and carefully center and cover the screw heads.
Figure 5
Figure 6
Figure 7
Figure 8 Figure 9
Dowel Pin
