U-Line MAGLINER H-1054 User manual

PAGE 1 OF 2 1214 IH-1054
πH-1054
MAGLINER®ALUMINUM
STANDARD HAND TRUCK
WITH SOLID RUBBER WHEELS
1-800-295-5510
uline.com
PARTS
13
7
6
5
8
3
14
15
12
16
4
12
7
8
65
13
11
10
9
9
2
REF. QTY. DESCRIPTION
1 1 Handle
2 4 1/4"-20 x 1⁄" - Pan Head Bolt
3 4 1/4" - Locknut
4 1 Frame w/ Black Caps
5 2 Cotter Pin
6 2 Thin Washer
7 2 Wheel
8 2 Thick Washer
9 2 Pin Coil Spring/Roll Pin
10 1Axle
11 1 Right Hand (RH) Wheel Bracket
12 1 Left Hand (LH) Wheel Bracket
13 4 5/16" - Locknut
14 2Side Channel Reinforcement
15 4 5/16"-18 x 2⁄" - Hex Head Bolt
16 1Nose Plate
Includes additional hardware not required for assembly.
TOOLS NEEDED
1/2" Combination Wrench
or Socket Wrench
7/16" Combination Wrench
or Socket Wrench
#3 Phillips Screwdriver
PliersHammer

PAGE 2 OF 2 1214 IH-1054
ATTACH NOSE PLATE, WHEEL BRACKETS AND AXLE
1. Position side channel reinforcements against bottom
frame rail. (See Figure 1a) Slide nose plate into
channel on side channel reinforcement, keeping
bolt holes aligned. (See Figure 1)
2. Insert four 5/16"-18 x 2⁄" - hex head bolts through the
nose plate, side channel reinforcements and frame.
(See Figure 1)
3. Slide the right hand wheel bracket over the bolts on
the outside of the frame leg and secure with two
5/16" locknuts but DO NOT tighten. (See Figure 1)
4. Lay hand truck on front so nose plate faces
downwards. (See Figure 2)
5. Use a hammer to tap in first roll pin into the axle.
6. Insert the axle (the end with the roll pin in place)
through the lower axle hole in the wheel bracket.
(See Figure 2a) Rotate axle until roll pin "locks" into
position in the wheel bracket.
7. Position and attach the left hand wheel bracket
sliding it over the axle to the outside of the frame
leg and secure with two 5/16" locknuts but DO NOT
tighten. (See Figure 2)
8. Use a hammer to tap in second roll pin into the axle.
ATTACH WHEELS
1. Slide a thick washer onto each end of the axle. Slide
a wheel onto each end of the axle. Slide a thin
washer on each end of the axle. (See Figure 3)
2. Insert a cotter pin through the holes in each end
of the axle. Bend cotter pins using pliers to secure
wheels. Wheels should spin freely. (See Figure 3)
ATTACH HANDLE
1. Slide handle into the top rails of frame. Align holes
in handle and frame. Insert four 1/4"-20 x 1⁄" - pan
head bolts through the frame and handle and
secure with four 1/4" locknuts. (See Figure 4)
2. Tighten all locknuts.
ASSEMBLY
Frame
Side Channel
Reinforcements
Figure 1
Figure 1a
Roll Pin
Axle
Figure 2
Figure 2a
Figure 3
Figure 4
