Ultra-Fab ULTRA POWER TWIN II-30 User manual

ULTRAPOWERTWINII-30 P/N39-941705
ULTRAPOWERTWINII-22 P/N39-941707
REV12/2013
APPLICATION
TheprimarypurposeofyourPowerTwinIIistoprovide
rocksolidstabilizationformaximumcomfortwhile
usingyourRVinaparkedposition.Toobtainthis
desiredendresultandeliminatethepossibilityof
damagetoyourRVorthePowerTwinII,itisvery
importanttofollowthesestep‐by‐stepinstructions.
IMPORTANT:DONOTOPERATETHEPOWERTWINII
BEFOREREADINGTHEOPERATINGINSTRUCTIONS.
ThePowerTwinIIwillassistyouinfinalliftingand
leveling,basedonthePowerTwinIIPowerCurveGraph
whichshowspoundsofliftinrelationtotheground
clearancefromthebottomoftheframe.
BymeasuringthegroundclearanceonyourRVyoucan
determinethemaximumamountofliftyourPower
TwinIIwillprovideforfinalleveling.
NOTE:THEPOUNDSOFLIFTINCREASESASTHE
DISTANCE,FROMGROUNDTOFRAME,INCREASES.
SAFETYANDDAMAGEWARNING
CAUTION:ALWAYSFOLLOWTHESE
INSTALLATIONANDOPERATING
INSTRUCTIONSTOPREVENTDAMAGETO
YOURRVANDTOPREVENTPERSONAL
INJURY.
INSTALLATION
ThePowerTwinII‐30doesnotcomeassembled.
Pleasefollowallofthestepsoftheseinstructions.The
PowerTwinII‐22ispre‐assembled,sopleaseskipto
Step3.
❶ Attachmountingplate(#2)tomainassembly
channel(#1)usingfour(4)M8‐1.25x25mmcarriage
bolts(#14)andfour(4)M8x1.25NYLOCKnuts
(#15).Makesurethemountingplateissquareto
themainchannelassemblybeforetighteningthe
nuts.
❷ Attachthetwo(2)armsupportbraces(#13)
tothemountingplate(#2)usingtwo(2)
M12‐1.75x30mmhexheadbolts(#16)andtwo(2)
M12x1.75NYLOCKnuts(#17).
Placetheplasticwasher(#11)betweenthearm
andthemountingbracket.Attachtheotherend
ofthearmsupportbracestothelegassembly(#8)
usingone(1)M12‐1.75x100mmhexheadbolt(#18)
andone(1)M12x1.75NYLOCKnut(#17)byplacing
thelegspacer(#10)insidethelegassemblyand
pushingtheboltthroughtheonesideoftheleg,
throughthespacerandoutoftheothersideofthe
legchannel.
Besuretoplacetheplasticwasher(#11)between
thearmandthelegbracebeforepushingthebolt
throughthehole.
Tightenallboltsandnutsuntilsnug.Donotover
tightenasthesearepivotpoints.
REPEATsteps1and2forthesecondlegassembly
(39‐841700PTII‐30).
INSTALLATION/OPERATION

ULTRAPOWERTWINII-30 P/N39-941705
ULTRAPOWERTWINII-22 P/N39-941707
REV12/2013
2
❸ Measuretheoutsidewidthofthemainframe
channelofyourRV.Layoutthetwo(2)Power
Twinlegassemblies(seefigureinthissection
below)andadjusttheinsidedistancebetweenthe
two(2)mountingplatestothesameastheoutside
dimensionofyourRVframe.
Taketheconnectingbracket(#34)andpositionit
overthetwo(2)sidebysidemainchannels(#1)
andboltbyusingeight(8)M8‐1.25x25mmhex
headbolts(#37)withtheM8flatwashers(#36)
andM8x1.25NYLOCKnuts(#35).
Donottightenatthistime.
❹ AttachthePowerTwinassemblytotheframe
byusingtheholesprovidedinthemountingplate
(#2)and(6eachside)⅜”***hexheadboltsand
nutsor⅜”selfdrilling***hexheadscrews.
DONOTuseanyfastenerssmallerthan¼”
diameter.
❺ Tofinishassembly,gobackandtightenthe
eight(8)boltsandnutsattheconnectingbracket
(#34).
❻ Nextstepistowiretheswitchestoourmotor
assembliesandconnecttothe12‐voltpower
supply.
NOTE:Insomeinstallations,toachievethe
maximumstabilizationyourequire,itmaybe
necessarytosupporttheconnectingbrackettothe
frameofyourRV.Wedonotsupplythebrackets
astherearemanydifferentconfigurationsofcross
membersandinmostinstallationsitisnot
necessary.
***hardwarenotincluded
MOTORINSTALLATION
❶ Attacheachofthemotorandgearbox
assemblies(#22)tothePowerTwinIIwiththefour
(4)M6‐1.0x110mmhexbolts(#24)makingsurethe
gasket(#27)isbetweenthemotorcoverandthe
gearbox.
NOTE:Makesurethatthewirescomeoutofthe
bottomsideofthemotorcover(towardsthe
groundwheninstalled).
REPEATthisstepforthesecondmotorandgear
boxassembly.
❷ Theswitchesmaybemountedatanydesired
location,butapreferredlocationwouldbeina
protectedenvironment,suchasastorage
compartmentorswitchboxnearthejacks.THE
GOAL:Tobechild‐proofaswellasweather‐proof.
❸ CAUTION:Toavoidshortcircuits,remove
thefuses(#28)fromthefuseholders(#29)until
thewiringiscomplete.Use10gauge(supplied)
wiresfortheinstall.Usingasmallergaugewire
willvoidthewarranty.Joinallwireconnections
withsolderconnectionsorcrimptypeconnection.
DONOTusewirenutsastheytendtoloosenand
falloff.
❹ ConnecttheGREENwiretothenegative
terminalofthebattery,orsecurelygroundittothe
frame(acleanandpaint‐freearea).
❺ ConnecttheWHITEwiretothepositive
terminalofthebattery,orthenearestpositive
terminalblock.Makesuretoinstallthefuse
holders(#29)onthisWHITEwire,oneoneach
switch.Ifrunningmorethan15feetofwireto
accessthebattery,usealargerwire,suchas6
gaugewire.Thiswillassuremaximum
performance.Voltagedropisaconcernonlong
spans.
❻ ConnecttheBLACKwirefromthemotorto
theBLACKwireoftheswitch.ConnecttheRED
wirefromthemotortotheREDwireoftheswitch
(oneachmotor).

ULTRAPOWERTWINII-30 P/N39-941705
ULTRAPOWERTWINII-22 P/N39-941707
REV12/2013
❼ Replacethefuse(#28)andtestthePower
TwinII,onelegatatime.Checktoseethatthe
switchesarewiredinalogicalrelationship(UP
positionontheswitchwillraisethejackleg,DOWN
positionlowerthejackleg).
EMERGENCYHANDLE
USAGE/MANUALOPERATION
❶ Removethefusesfromthefuseholders.
❷ Removethefour(4)bolts(ITEM#24)holding
themotorinplace.
❸ Placethepinnedcollardriveonthehandle
overtheslottedcollarandturnthecrankthe
appropriatedirectiontoeitherextendthePower
TwinIIlegorretractit.
INSTRUCTIONSFORUSE
TRAVELTRAILEROR5
TH
WHEELS
❶ ChockyourwheelsandlevelyourRVfrom
fronttobackbyusingyourtonguejackorlanding
gear.
❷ Usingalevel,determinewhichsideofourRV
isthelowestandextendthejack(s)onthatside
untilyourRVislevel.
❸ Extendthejack(s)ontheoppositesideofthe
RVuntiltheytouchthegroundfirmly.YourRVis
nowinitsmoststableposition.
❹ Youcanretractallofthejacks
simultaneously.
CLASSCMOTORHOMES
❶ Setyourbrakes.
❷ ExtendthejackonthelowsideofyourClass
Cmotorhomeuntiltherearislevel.
❸ Extendtheoppositesideuntilittouchesthe
groundfirmly.YourRVisnowinitsmoststable
position.
CAUTION:
ALWAYSRETRACTPOWERTWINII
BEFOREDEPARTING.
LUBRICATION
Eachmotor/gearassemblyshouldbere‐greasedonce
peryearthroughthegreasefittingonthegearbox.
WARNING:DONOTUSEpneumatic‐poweredlube
equipmentasitcandamagethelevelerunit.Use
hand‐operatedgreasegunonly.
Twopumpsofchassislubeonceperyearisallthat
shouldberequired.DONOToverfillthegearboxwith
chassislubeasitcouldpushintothemotorcausing
damagetothemotor.

ULTRAPOWERTWINII-30 P/N39-941705
ULTRAPOWERTWINII-22 P/N39-941707
REV12/2013

ULTRAPOWERTWINII-30 P/N39-941705
ULTRAPOWERTWINII-22 P/N39-941707
REV12/2013
T
TH
HR
RE
EE
E‐
‐Y
YE
EA
AR
R
L
LI
IM
MI
IT
TE
ED
D
W
WA
AR
RR
RA
AN
NT
TY
Y
DELUXE5
TH
WHEELLANDINGGEAR,ULTRASWAYCONTROL,WEIGHT
DISTRIBUTIONHITCH,BALLMOUNTS,HITCHBALLS,ODYSSEY3000/4000
TONGUEJACKS,POWERTWINIISTABILIZERS,THEELIMINATORSTABILIZER,
LEVELINGBLOCKSANDMANUALTONGUEJACKS
THEMANUFACTURERNAMEDBELOWMAKESTHEFOLLOWING
WARRANTYWITHRESPECTTOTHEABOVEULTRA‐FABPRODUCTS
1. ThisWarrantyismadeonlytothefirstPurchaser(hereinaftercalledthe“OriginalPurchaser”)whoacquiresthisproductfortheirown
use.
2. ThisWarrantywillbeineffectforthreeyearsfromthedateofpurchasebytheOriginalPurchaser.ItissuggestedthattheOriginal
Purchaserretainacopyofthedatedbillofsaleasproofofthedateofpurchase.
3. ThisWarrantycoversonlyspecifiedpartswhichshallbefreefromdefectsinmaterialandworkmanshipundernormaluse.This
Warrantydoesnotcoverconditionsunrelatedtothematerialandworkmanshipoftheproduct.Suchunrelatedconditionsinclude,but
arenotlimitedto(a)faultyinstallationandanydamageresultingfromsuch;(b)theneedfornormalmaintenanceandanydamage
resultingfromthefailuretoprovidesuchmaintenance;(c)failuretofollowManufacturer’sinstructionsforuseofthisproduct,and(d)
anyaccidentto,ormisuseof,anypartofthisproductandanyalterationbyanyoneotherthantheManufactureroritsauthorized
representative.
4. InordertoobtainthebenefitsofthisWarranty,youshouldreturntheproductwhichyoufinddefectivetotheManufacturernamed
belowduringtheperiodthatthisWarrantyisineffect.AllchargesincurredindeliveryoftheproducttotheManufacturer,andin
pickingitupaftertheWarrantyservicehasbeencompleted,mustbepaidbytheOriginalPurchaser.
5. Anyitemreturnedinthemannerdescribedinparagraph4willbeexaminedbytheManufacturer.Ifitisfoundthatthereturneditem
wasdefectiveinmaterialorworkmanship,theManufacturerwillrepairitwithoutchargeformaterialandlabor.
6. Ultra‐Fabwillpayfreightonreplacementpartsduringthefirst90daysofownershipbytheOriginalPurchaser.
7. TheManufacturerdoesnotauthorizeanypersonorcompanytocreateanyWarrantyobligationorliabilityontheirbehalf.
8. INNOEVENTSHALLTHEMANUFACTURERBELIABLEFORINCIDENTALORCONSEQUENTIALDAMAGES.SOMESTATESDONOTALLOW
THEEXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGESSOTHEABOVELIMITATIONOREXCLUSIONMAYNOT
APPLYTOYOU.
9. ANYIMPLIEDWARRANTY,INCLUDINGTHEIMPLIEDWARRANTYOFMERCHANTABILITYANDFITNESSFORANYPURPOSE,ISLIMITEDTO
THEDURATIONOFTHISLIMITEDWARRANTY.SOMESTATESDONOTALLOWLIMITATIONSONHOWLONGANIMPLIEDWARRANTY
LASTS,SOTHEABOVELIMITATIONMAYNOTAPPLYTOYOU.
10. THISWARRANTYGIVESYOUSPECIFICLEGALRIGHTS,ANDYOUMAYALSOHAVEOTHERRIGHTSWHICHVARYFR0MSTATETOSTATE.
57985SR19S.,Elkhart,IN46517
Tel:(574)294‐7571Fax:(574)294‐4980
www.ultra‐fab.com
