Ultrative UTT?205 User manual

www.ultrative.com
UltrativeCommunication







UTT‐205IPSmart
VoIPPhoneUserManual







U
Ul lt tr ra at ti iv ve e H HK K C CO O. ., , L LT TD D 

www.ultrative.com
UltrativeCommunication

INDEX
INDEX................................................................................................................................................2
1.GettingStarted..............................................................................................................................4
About.........................................................................................................................................4
FeatureHighlights.....................................................................................................................4
2.SetupthePhone...........................................................................................................................4
3.PhoneUserInterface.....................................................................................................................6
3.1HardwareComponentInstructions.....................................................................................6
3.2PhoneScreenDisplayFeatures...........................................................................................8
3.3BasicNetworkSettings........................................................................................................9
3.4SIPAccountSettings..........................................................................................................10
3.5BasicFeatures....................................................................................................................11
3.5.1MakingaCall..........................................................................................................11
3.5.2AnonymousCall......................................................................................................11
3.5.3Redial......................................................................................................................12
3.5.4CallLog...................................................................................................................12
3.5.5MakingCallstoContact..........................................................................................12
3.5.6Multi‐linestoAnswertheCall................................................................................13
3.5.7Auto‐Answer..........................................................................................................13
3.5.8EndingaCall...........................................................................................................13
3.5.9UsingHoldandRecover(SwitchCallingLine)........................................................14
3.5.10TransferringCalls..................................................................................................14
3.5.11UsingMute...........................................................................................................15
3.5.12DoNotDisturb.....................................................................................................15
3.5.133‐wayConference.................................................................................................16
3.5.14VoiceMail.............................................................................................................16
3.6AdvancedSettings.............................................................................................................17
3.6.1Usingthephonebook............................................................................................17
3.6.2UsingCallLogs........................................................................................................20
3.6.3Peer‐to‐Peer...........................................................................................................20
3.7KeypadSetting...................................................................................................................20
3.7.1LanguageSetting....................................................................................................21
3.7.2Message.................................................................................................................21
3.7.3Time&Date...........................................................................................................21
3.7.4RingTon eandVolumeSetting...............................................................................22
3.7.5SearchingPhoneBook............................................................................................22
3.7.6CannotSettheFeatureswithKeypad....................................................................23
4.WEBUserInterface.....................................................................................................................23
MainInterface‐PhoneStatus..................................................................................................23
4.1NetWork...........................................................................................................................24
4.1.1LANPort.................................................................................................................24
4.1.2PCPort....................................................................................................................26

www.ultrative.com
UltrativeCommunication

4.1.3Advanced................................................................................................................27
5SIPAccount...................................................................................................................................28
5.1Basic...................................................................................................................................28
5.2Call.....................................................................................................................................29
5.3Security..............................................................................................................................30
6PhoneSetting...............................................................................................................................31
6.1Basic..................................................................................................................................31
6.1.1TimeSettings..........................................................................................................32
6.1.2Call..........................................................................................................................33
6.1.3VoIPCallForward...................................................................................................34
6.1.4QoS.........................................................................................................................35
6.2Advanced...........................................................................................................................35
6.2.0Audio.....................................................................................................................35
6.3LineKeys....................................................................................................................37
6.4FunctionKeys............................................................................................................38
6.5SoftKey.....................................................................................................................38
6.6DialPlan.....................................................................................................................39
6.7IPStrategy.................................................................................................................40
7PhoneBook..................................................................................................................................40
7.1Group................................................................................................................................40
7.2Contact..............................................................................................................................41
7.3LDAP..................................................................................................................................
41
7.4BanList..............................................................................................................................42
8PhoneMaintenance.....................................................................................................................43
8.1Basic..................................................................................................................................43
8.1.1HTTPUpgrade.........................................................................................................43
8.1.2FTPUpgrade...........................................................................................................44
8.1.3TFTPUpgrade.........................................................................................................45
8.1.4DefaultSetting........................................................................................................46
8.1.5Reboot....................................................................................................................46
8.2Advanced...........................................................................................................................47
8.2.1Log..........................................................................................................................47
8.2.2AutoProvision
........................................................................................................47
9Password......................................................................................................................................49
10WEBOtherSettingsorInformation‐Appendix.........................................................................49
10.1WEBUser.........................................................................................................................49
10.2Multi‐Language...............................................................................................................49
10.3NoteTips.........................................................................................................................50






www.ultrative.com
UltrativeCommunication


1.GettingStarted
About
ULTRATIVEUTT‐205isacompactofficeIPphonewithrichfeatures.Ithas128*64
HDgraphicLCDupto4‐linedisplay;italsohasHDSoundQuality,uniqueartdesign,
demountablebrackettoprovidemulti‐angle,4softkeys,andfriendlyuserinterfacet
osatisfyusers'scommunicationneeds.
FeatureHighlights
a) Multi‐Language
TheLCDdisplaysupportsMulti‐Language.
b) HDVoice
Specialvoiceprocessingtechnology,high‐fidelityvoicequality,HDencoding,HD
Handset,ensureclear,realisticsmoothcommunication.
c) SeniorCallingAbility
2lineswithdoublecolor(GREEN&RED)LEDs,Synchronouslycontrolormanage2calls,
Callqueue,Switchbetweenlines.Multi‐partiesconference,calltransfer.
d) AllkindsofPhoneBook
ItsupportsXMLPersonalPhoneBook\LDAP\EnterprisePhoneBooketc.Thisfeature
satisfiescustomer'sphonebookrequirements.
e) SupportHTTP\TFTP\FTP\Auto‐Provision.
f) SupportPOE(Remark:UTT‐205‐P)andPowerAdapter.
g) 2‐angleadjustablebracket.
h) Support9programmablekeys.

2.SetupthePhone
a) PackingList:
Checkthepackinglistbeforeinstallation,ifyoufindanythingmissing,contactyoursystem
administrator.
z1*UTT‐205IPPhone
z1*Handset
z1*HandsetCord
z1*EthernetCable

www.ultrative.com
UltrativeCommunication

z1*PhoneBracket
z1*QuickSetupGuide
b) PhoneInstallation:
Thissectionintroduceshowtoinstallthephonewiththecomponentsinthepackinglist:
zAttachtheBracket
zConnecttheHandsetandoptionalHeadset
zConnecttheNetworkandPower

AttachtheBracket
Pleasefollowasbelowpicturestoattachthebracket.


ConnecttheHandsetandoptionalHeadset

NOTE: Headset port & PSTN port is option. The Back light of LCD also is option.

ConnecttheNetworkandPower
Youhavetwooptionsforpowersupply.Yoursystemadministratorwilladviseyouwhichoneto
use.
‐ACpoweradapter
‐POE(PoweroverEthernet)IEEE802.3af
NOTES：PleasemakesureyourphonesupportPOEfeature.Youcancheckthelabelonthe
backofthephone,forexample"Model:UTT‐205‐PNRev:2.1.0",thePmeansitsupport
POEfeature.

www.ultrative.com
UltrativeCommunication


Note:IfPOEworks,thephonedoesn'tneedtoconnecttotheACpoweradapter.Makesure
theEthernetcableandswitch/hubisPOEcompliant.

3.PhoneUserInterface
3.1HardwareComponentInstructions
ThemainhardwarecomponentsoftheUTT‐205IPPhonearetheLCDscreenandthe
keypad.



HardwarecomponentinstructionsoftheUTT‐205IPPhoneare:

www.ultrative.com
UltrativeCommunication

ITEMDESCRIPTION
1LCDScreenDisplayedinformationaboutcalls,messages,softkeys,time,dateand
otherrelevantdata:
•Callinformation—callerID,callduration
•Icons(e.g.)
•Missedcallsorsecondincomingcaller'sinformation
•Timeanddate
2LineKeyRed,flashing:Incomingcall
Red,steady:Pickupbutnotoncommunication
Green,steady:Oncommunication
Green,flashing:Onhold
Lightoff:Idle
NOTE:Lightyellowsteady:Undertheidlestatus,thelightwillon
when:MissedCall,Transfer,DND,Message,Mute,SIP‐Unregistered.
3SoftKeyLabelsautomaticallytoidentitytheircontext‐sensitivefeatures
4Navigation
Key&VolumeKey
Intheidlestatus,pressUPorDOWNkeycancheckthecalllog:
UP:Openthe"AllCONTACTLOG",DOWN:Openthe"MISSEDCALL",
RIGHTandLEFTcancheckotherlist,like"RECEIVEDCALL\DAILCALL".
Intheidleortalkingstatus,pressRIGHTorLEFTkeycanadjustthe
volume.
5Mute&CKeyCancelsactionsorrejectsanincomingcall,andtheotherfeature:
Intheidle:Openthe"PhoneStatus".
Diagnosis:Pressandhold3secondtoopen"HardwareDiagnosis".
MUTE:"MUTE"featureisenabledifyoupressitwhiletheconversation
makingonthephone.
6RedialKeyDial the latest number.
7Programmable
Key
Intheidlestatus,pressandhold3swillenterprogrammablefunction,
thedefaultpasswordisempty:
Line1&2:pressandholdcanquicklyenteraccountsetting.Ifyou
wantsetittoanotherfunction,youneedtologinintowebsiteto
changeit.
NavigationkeyUP&DOWN,Redialkeypressandholdcanquickly
enterprogrammablekeysettingfunction,theycanchangeto
Redial\DND\PersonalPhonebook\EnterprisePhonebook\LDAP
\Directory\SpeedDial\CallHistory\ReceivedCalls\DialedCalls\Main
Menu\NewMessage\ForwardedCalls\ViewStatus\Enable/DisableSIP
Account\Default.
NOTE：MUTE&Ckeyisn’tsupportprogrammablefunction.
8SpeakerKeyTog g lesthehands‐freespeakerphonemode.Pressandholdcan
changetoheadsetmode
9MICHighsensitivepickupMic.
10KeypadProvidesthedigits,lettersandspecialcharactersincontext‐sensitive
applications.

www.ultrative.com
UltrativeCommunication

11SpeakerHDspeaker.

3.2PhoneScreenDisplayFeatures
Ifthephonehassuccessfullystartedupandafterusing,theidleLCDdisplaywillshow
informationasbelow:
 
ITEMDESCRIPTION
1TIME&DATETIME&DATEdisplayinthemiddleofthescreen.
2Auto‐AnswericonEnablethisfeature,itwilldisplay"AA"atthetoprightcorner.
3MissedCallMissedCallundertheTIMEinthemiddleofscreen
4LineStatusTherearefourstatusasbelow:
a.:Disconnectthenetwork
b.:Accountfailedtoregister
c.:Accountsuccessfullyregistered
d.:AccountsuccessfullyregisteredandDNDfeatureisenabled.
TheDNDiconalsowilldisplayatthetoprightcorner.
5SoftKeyAreaLabelsautomaticallytoidentitytheircontext‐sensitivefeatures
6ScreenTopIconTheScreenTop Iconfromlefttorightis:
:HandsetHandonstatus
:SpeakerHandonstatus
:HeadsetHandonstatus
:CallMUTE
:MissedCall
:CallForward
:TextMessage

www.ultrative.com
UltrativeCommunication

:KeypadLock
:Networkisunavailable

3.3BasicNetworkSettings
ThephonesupportsThreeModesofNetworkSetting.IncludePPPoE\StaticIP\DHCP.
DHCPSetting
FeatureOperatingSteps
DHCPPressMENU>SystemSettings>AdvancedSettings>Password(Defaultis
Empty)>Network>LANPort
zPressLANPorttologinintothemenu
zSelect"DHCP"mode
zPress"Enter"key
zSettheDNS\webport\telnetport
zPress"Save"keytomakeitwork
zTips"Networkischanged,pressOKreboot"

StaticIPSetting
FeatureOperatingSteps
StaticIP PressMENU>SystemSettings>AdvancedSettings>Password(Defaultis
Empty)>Network>LANPort
zPressLANPorttologinintothemenu
zSelect"Static"mode
zPress"Enter"key
zSettheIP\Mask\GW\DNS\webport\telnetport
zPress"Save"keytomakeitwork
zTips"Networkischanged,pressOKreboot"

PPPoESetting
FeatureOperatingSteps
PPPoE PressMENU>SystemSettings>AdvancedSettings>Password(Defaultis
Empty)>Network>LANPort
zPressLANPorttologinintothemenu
zSelect"PPPoE"mode
zPress"Enter"key
zSettheUserName\Password\webport\telnetport
zPress"Save"keytomakeitwork
zTips"Networkischanged,pressOKreboot"


www.ultrative.com
UltrativeCommunication

3.4SIPAccountSettings
UTT‐205IPphonemakescallsbasedonsipaccounts,ItcansupportSingleaccountor
Multi‐account,EachaccountcanbeconfiguredtothedifferentSIPserver.
Ifyouwantto…Then...
CreateanSIPaccount‐‐1)Select“Systemsetting”>“Advancedsetting”；
‐‐2)Enterthepasswordrequired（Thedefaultisempty)；
‐‐3)Select“SIP”>“Accountsip”；
‐‐4)Selectoneoftheaccountyouwanttosetting,youcanconfigure
thefollowingparameters
‐Enableaccount*:SelectEnable
‐Numberoflines:Defaultis2
‐Description:descriptionofthisaccount
‐DisplayName:Thenamedisplayedonthescreen
‐Authenticationuser:theAuthenticatedusersarematchedwith
theSIPserver.(ThedefaultWiththesameaccount)
‐Account*:theaccountmatcheswiththeSIPserver.(extension
number)
‐Userpassword*:theuserpasswordmatcheswiththeSIPserver
‐SIPServer*:TheprimarySIPserver,allcallsthroughthisserver
‐OutBoundServer:TheoutboundSIPserver
‐STUNType:Enable/DisableSTUNfeature
‐STUN:InputSTUNURL
‐AutoAnswer:Enable/Disablethisaccountautoanswerfeature
*Note:Whenyoufinishthesetting,youcanpressSavetomakeit
work,andthenyoucanseethestatusiconintheLCDidle.
Theparameterswiththe*markmustbeset.
Disablesipaccount‐‐1)Select“Systemsetting”>“Advancedsetting”；
‐‐2)Enterthepasswordrequired（Thedefaultisempty)；
‐‐3)Select“SIP”>“Accountsip”；

www.ultrative.com
UltrativeCommunication

‐‐4)Select“Enableaccount”>“Disable”；
‐‐5)Select“Save”tosavessettings
3.5BasicFeatures
3.5.1MakingaCall
HerearesomeeasywaystoplaceacallonULTRATIVEIPPhone:
Ifyouwantto...Then…
Placeacallusing
thehandset
Pickupthehandset‐‐1)Youcanheardialtone;
‐‐2)Enteranumber；
‐‐3)Press#button(default)，
‐orwait5s(default),thenitsendthe
numberautomatically.
Placeacallusinga
speakerphone
PressSpeakerbutton
Placeacallusinga
headset
Putonyourheadset,
Pressandholdthespeaker
buttontoactiveHeadset
feature,andthendoas
usingspeakerphone

3.5.2AnonymousCall
Youcanuseanonymouscallfeaturetoblocktheidentityandphonenumberfromshowingupto
thecalledpartywhenyoucallsomeone.E.g,youwanttocalltoconsultsomeoftheservices,but
youdon'twanttobeharassed.
EnableAnonymousCall

PressMENU>FunctionSetting>Anonymous
‐‐PressEnterbutton,
‐YoucanselectwhichAccountwanttouse,enable/disablethis
featureandenable/disablerejectanonymous


www.ultrative.com
UltrativeCommunication

3.5.3Redial
Toredialthelastplacedcallfromyourphone
Redial‐‐PressREDIALbuttontodialthelastnumber
‐orpressNavigationbutton‐Left>“Dialednumber”,selecta
number,andpress

3.5.4CallLog
Dialfromacalllog‐‐1)PressMENUbutton>“Callhistory”,youcanselect"AllCalls",
“Missedcalls”,“Receivedcalls”and“Dialednumbers”,
‐orpressNavigationUP/DOWNbutton(inidlestatus)>select"All
Calls"(up)“Missedcalls”(down),leftandrightcanselect“Dialed
numbers”or“Receivedcalls”
‐‐2)Thenpressbutton.
NOTE:Youalsocanpressthe"log"tologinthismenuwheninthe
idle.

3.5.5MakingCallstoContact
YoucanalsodialacontactfromthePersonalPhoneBook.
PlacingCallsto
Contacts

‐‐1)PressMENUbutton>“PhoneBook”,youcanselect"Personal
PhoneBook",“EnterprisePhoneBook”,“LDAP”and“BlackList”,
‐orpressNavigationUP/DOWNbutton(inidlestatus)>selectthe
desiredcontact.
‐‐2)Thenpressbutton.
NOTE:Youalsocanpressthe"DIR"tologinthismenuwheninthe
idle.


www.ultrative.com
UltrativeCommunication

3.5.6Multi‐linestoAnswertheCall
Multi‐linestoAnswer
theCall
‐‐1)AnotherLinebuttonisRed andflashing,LightstripisRed
andflashing;
‐‐2)Presstheflashing Linebuttontoanswer(atthistime,the
originalcallwillbehold.)

3.5.7Auto‐Answer
Youcansetthephoneandletitauto‐answerthecomingcall.
Auto‐Answerthe
ComingCall
‐‐1)EnabletheAuto‐Answerfeature.
‐‐2)Auto‐AnswermodeyoucansetintheMENU>FunctionSetting>
AutoAnswer>Device
zSpeaker
zHandset
zHeadset
WhenyouusetheHandsetmode,atthistimeyouneedtohandsup
thehandsetandthenitcanworkatthisstatus.
‐‐3)FilterGroups
Auto‐answerthecomingcallinthisspecialgroups.

3.5.8EndingaCall
Toendacall,hangup.Herearesomemoredetails.NOTE:Pressandholdthespeakerkeycan
changetoHandsetfeature.
Hangupwhileusingthe
Handset
‐‐Returnthehandsettoitscradle,
‐orpressEnd
Hangupwhileusingthe‐‐PressSpeakerbutton,

www.ultrative.com
UltrativeCommunication

Speakerphone‐orpressLinebuttonfortheappropriateline,
‐orpressEnd
Hangupwhileusingthe
Headset
‐‐PressHandsetbutton,（Donotkeeptheheadsetmode),
‐orpressEnd(keeptheheadsetmode)
Hanguponecall,but
preserveanothercallon
theotherline
‐‐PressEnd,
‐orrefertotheabovethreemethods
3.5.9UsingHoldandRecover(SwitchCallingLine)
Youcanholdandresumecalls.Youcantakeacallinonelineatanytime,andtheotherlines
wouldbehold.Asaresultofthat,youcanswitchdifferentcallinglineonourphone.Note:Ifthe
phoneisn’thavetheholdbutton,Pleaseusingthesoftkey.
Ifyouwantto...Then...
Putacallonhold‐‐PressHOLDbutton,
‐orpresssoftkey
Holdalineandswitchto
anotherline
PressanotherLinebuttonfortheappropriateline
Resumeacalloncurrent
line
‐‐PressLinebutton,

Releaseacallondifferent
line
Selectthelinewanttoreleasehold,presstheline,sorecovery;
NOTES
•EngagingtheHoldfeaturetypicallygeneratesmusicorabeepingtone.
•AheldcallisindicatedbytheYellow‐greenandflashingLinebuttonorHoldintheLCD.
3.5.10TransferringCalls
Transferredirectsaconnectedcall.Thetargetisthenumbertowhichyouwanttotransferthe
call.
Talktothetransfer
recipientbefore
‐‐1)PressTRANSFERbuttonorpressXFER;
‐‐2)Enternumber;

www.ultrative.com
UltrativeCommunication

transferringacall
(consulttransfer)
‐‐3)press“#”（default),
‐orpress  thentransferthecall,
‐orwaitfiveseconds(default)thentransferthecall
Transferredtoidle
linesorother
numberswithout
talkingtothetransfer
recipient
(Blindtransfer)
‐‐1)PressTRANSFERbuttonorXFER；
‐‐2)Press;
‐‐3)Enternumber;
‐‐4)Press“#”（default)
‐orpress,thentransferthecall;
‐orwaitfiveseconds(default)thentransferthecall
Blindtransfertothe
heldline
‐‐1)PressTRANSFERbuttonorpressXFER;
‐‐2)PresstheLinebuttonofheldline
3.5.11UsingMute
WithMuteenabled,youcanhearotherpartiesonacallbuttheycannothearyou.Youcanuse
muteinconjunctionwiththehandset,speakerphone,oraheadset。
Tog gle MuteonPressCbutton,thenthescreentopandleftwillhaveaMUTE
icon 
Tog gle MuteoffPressCbuttonagain,thenthebuttonlightoff
3.5.12DoNotDisturb
YoucanusetheDoNotDisturb(DND)featuretoblockincomingcallsonyourphonewithabusy
tone（Canalsobesettotheirvoicemailorotherextensionnumbers,etc.).
EnableglobalDND‐‐1)PressDND;
‐‐2)Allenabledlineonthephonewouldchangestostatus.and
theiconis.
EnableDNDona
singleline
PressMENUbutton>“Functionsetting”>“DND”>(selectline)
“Enable”
DisableDND‐‐GlobalDNDenabled,presstodisableglobalDND;
‐‐LineDNDenabled,presstwice,

www.ultrative.com
UltrativeCommunication

‐orpressMENUbutton>“Functionsetting”>“DND”>(selectline)
“Disable”
3.5.133‐wayConference
Youcanenableathree‐partyconference,duringtheconversationthreephonepartiescan
communicatewitheveryparty.
Ifyouwantto...Then...
Invitethetransfer
recipientintoa
conferenceina
transferring
‐‐1)Whenthetransferrecipientanswerthecall,pressCONFERCENCE
buttonor"CONF"onyourphone;
‐‐2)Thentheheldone,transferrecipientandyouwillbeintoa
conference,andtheLCDwilldisplaystatus.
Invitethethirdparty
intoaconferenceina
activecall
‐‐1)Press"CONFERENCE"buttonor"CONF"inanactivecall;
‐‐2)Enterthethirdpartynumber；
‐‐3)Afterconnectedthethirdparty,press"CONFERENCE"buttonor
"CONF"again
establishaconference
withheldline
‐‐1)whenonephonelineisholdingonandtheotherlineisbusy;
‐‐2)Press"CONFERENCE"button,
‐orPress"CONF"Softkey
‐‐3)Presstheheldline'sprogrammablebutton,the3‐wayConference
isenable.
3.5.14VoiceMail
YoucansetVoiceMailfunctioninMenu>Message.
VoiceMail‐‐1)Dialthevoicemailnumber,e.g*97
‐‐2)EntertheUserPassword
‐‐3)Itwillloginintothevoicemailserver.YouneedtofollowtheIVRto
doit.


www.ultrative.com
UltrativeCommunication

3.6AdvancedSettings
3.6.1Usingthephonebook
EnterprisePhoneBook
SearchtheContacts
fromEnterprise
PhoneBook
‐‐1)PressDIRintheidlestatus,
‐orpress"MENU"button>“Phonebook”>“EnterprisePhone
Book”,
‐‐2)Select“EnterprisePhoneBook”,press"OK"button;
‐‐3)Press"Find"andinputthenamewhoyouwanttosearch.
CalltheContact
fromEnterprise
PhoneBook
‐‐1)Press"DIR"intheidle,
‐orpress"MENU"button>“Phonebook”>“EnterprisePhone
Book”,
‐‐2)Select“EnterprisePhoneBook”,press"OK"button;
‐‐3)Press"Find"andinputthenamewhoyouwanttosearch.
‐‐4)Whenyousearchtheperson,youcandialit.

PersonalPhoneBook
AddContacts‐‐1)PressPhoneBook,
‐orpress"MENU"button>“Phonebook”>“Personalphone
book>ViewAll”,
‐orpress"OK"button>“Phonebook”>“Personalphone
book>ViewAll”;
‐‐2)Select“Addcontact”,press"OK"button;
‐‐3)Usethenavigationkeystoselectcontent,press"OK"buttontoset
andmodify:
‐Name:setthenameofcontact,

www.ultrative.com
UltrativeCommunication

‐OfficeNumber:SettingthecontactOfficeNumber
‐MobilePhoneNumber:SettingthecontactMobilePhone
Number
‐OthersNumber:SettingthecontactOthersNumber
‐SIPAccount:SettingthecontactcallSIPaccount
‐Group:thecontactsbedividedintodifferentuser’sgroups
‐‐4)Press"Save"softkeytocomplete
Addgroup‐‐1)Press"DIR"softkey,
‐orpress"MENU"button>“Phonebook”>“Personalphonebook>View
All”,
‐orpress"OK"button>“Phonebook”>“Personalphone
book>ViewAll”;
‐‐2)Selectthe“addgroup”thenpressOKbutton;
‐‐3)Usethenavigationkeystoselectcontent,pressOKbuttontoset
andmodify:
‐Groupname:nameofthegroup
‐‐4)Press"Save"softkeytocomplete
Modifygroup‐‐1)Press"DIR"softkey,
‐orpress"MENU"button>“Phonebook”>“Personalphone
book>ViewAll”,
‐orpress"OK"button>“Phonebook”>“Personalphone
book>ViewAll”;
‐‐2)Selectthe“Modifygroup”thenpress"OK"button;
‐‐3)Selectthegroupyouwanttomodify,pressthe"OK"buttonto
setandmodify,press"Save"tosavethechange
Deletegroup‐‐1)Press"DIR"softkey,
‐orpress"MENU"button>“Phonebook”>“Personalphone
book>ViewAll”,
‐orpress"OK"button>“Phonebook”>“Personalphone

www.ultrative.com
UltrativeCommunication

book>ViewAll”;
‐‐2)Selectthe“Deletegroup”button；
‐‐3)Selectagroupyouwanttodelete,pressOKbutton

LDAP
SearchtheContacts
fromLDAP
‐‐1)Press"DIR"intheidle,
‐orpress"MENU"button>“Phonebook”>“LDAP”,
‐‐2)Select“LDAP”,press"OK"button;
‐‐3)Press"Find"andinputthenameornumberwhoyouwanttofind
searchfromtheLDAPserver.
CalltheContact
fromLDAP
‐‐1)Press"DIR"intheidle,
‐orpress"MENU"button>“Phonebook”>“LDAP”,
‐‐2)Select“LDAP”,press"OK"button;
‐‐3)Press"Find"andinputthenameornumberwhoyouwanttofind
fromtheLDAPserver.
‐‐4)Whenyousearchtheperson,youcandialit.

BlackList
AddtheContacts ‐‐1)Press"DIR"intheidle,
‐orpress"MENU"button>“Phonebook”>“BlackList”,
‐‐2)Select“BlackList”,press"OK"button;
‐‐3)Press"Add"andinputthename\officenumber\mobile
number\othernumber\SIPaccountwhowhatyouwanttoaddinto
theBlackList.
ViewtheContact
fromBlackList
‐‐1)Press"DIR"intheidle,
‐orpress"MENU"or"OK"button>“Phonebook”>“BlackList”,

www.ultrative.com
UltrativeCommunication

‐‐2)Select“BlackList”,press"OK"button;
‐‐3)Press"RUN"toviewsomeonewhowhatyouwanttofind.
‐‐4)Ifyouwanttomoveorchangeit,youcanfollowtheRUNtodo.
3.6.2UsingCallLogs
Yourphonemaintainsrecordsofyourmissed,placed,andreceivedcalls.
Viewcalllogs‐‐1)Press"MENU"or"LOG"button>“AllCall”>“MissedCalls”,
“ReceivedCalls”,or“Dialednumbers”
‐‐2)Usethenavigationkeystoviewthecallrecordinformation.
Delete/SaveCall
Logs
‐‐1)LoginintotheCallLogs
‐‐2)UsethenavigationkeystoviewthecallrecordorselectDELkey.
‐‐3)UsethenavigationkeystoviewthecallrecordorselectSavekey.
3.6.3Peer‐to‐Peer
Whenallofthephoneaccountsweredisableornotregister.itwillbeshowthismodeintheidle.
Itcanusebywhenthenewworkstationisn'thaveSIPserver.
Peer‐to‐Peer Disableallofaccountsornotregister.
MakeCallwith
Peer‐to‐Peer
‐‐1）PressMENUbutton>SystemSetting>AdvancedSetting>SIP
Account；
‐‐2）Disableallofaccountsorun‐register；
‐‐3）Turnbackthephoneidle,youcancallsomeoneuseIPaddress.

3.7KeypadSetting
ULTRATIVEseriesIPPhonecanthroughtwowaysconfigurationit,oneissettinginMENU,and
anotherissettinginwebsite.HerejustdescriptioninMENU.
NOTES:WhenyouwanttoinputtheIPaddresslike".",itwasreplacedbythe"*".
