Uniden BT112APT User manual

Also included in this package:
Extra ear cushions
BT112 Bluetooth®
Headset User’s Guide
Questions? Problems? Get help on the web at www.uniden.com
or call our Customer Service line at 800-292-2294.
DC Head
USB Cable
AC Head

2
Getting to Know the Headset
CAUTION! Using the headset at high volume can cause permanent
hearing loss. To reduce the risk of hearing damage, use the
minimum volume level necessary (see Avoid Hearing Damage
section).
Volume
button
Power
port
Multifunction
button
Earhook
ring
Ear
cushion
LED
Microphone
What the buttons do
Press and release the button to activate the function. Do not press the buttons
quickly.

3
Button To do this... Do this...
Multifunction
Button (MFB)
Power on headset Press and hold for 3 seconds.
Get into pairing mode Press and hold for 5 seconds.
Power o headset Press and hold for 4 seconds
Refer to later sections in this manual for specic operational functions.
VOL
Increase volume on a call Press and release VOL side button.
Decrease volume on
a call
Press and release VOL side button until the volume
level cycles through increasing the volume and
returns to the lowest volume level.
NOTE: Only the headset can adjust the volume.
What the LED means
The BT112 has a single blue LED. It blinks or stays on according to the
current action or headset status.
If the LED... It means...
Blinks 3 times The device is powering up.
Blinks 4 times The device is powering down.

4
If the LED... It means...
Blinks twice every 5 seconds The device is in connectable mode.
Blinks once every 6 seconds The device is in connected mode.
Blinks 3 times every 5 seconds The device is in an active call.
Is on The device is in pairing mode.
The device is charging.
Is o Charging is complete.
Setting Up Your Headset
Charge the battery
Before using your headset, charge the battery for at least 2 hours.
Charging the battery completely (and keeping it charged) will help
you get the longest possible talk and standby time out of the battery.

5
Use ONLY the power adapter supplied with the headset! Using any other adapter could
damage your headset, create a re hazard, or cause a risk of electric shock.
1. Connect the adapter to the power connector on the top of the headset,
then plug it into a standard 120 volt AC (regular indoor) power outlet.
The blue LED remains on while the headset is charging.
2. Charging is complete when the blue LED turns o.
The headset beeps every 30 seconds when the battery is low. The headset
may power o if it is not charged within 30 minutes.
Pair the headset to your Bluetooth phone
Pairing is like “introducing” two Bluetooth devices and giving them
permission to connect to each other.
NOTE: The headset goes into Pairing mode automatically the rst time you use it.
1. Make sure the headset is powered o and the power adapter is not
connected (you can’t use the headset while it’s charging).
2. Press and hold MFB for 5 seconds until the blue LED is steady on, then
release it. The headset is in pairing mode and should be visible to other
Bluetooth devices.

6
3. On your phone, start a search for Bluetooth headsets or handsfree
devices. (This process may take several seconds, and it will be dierent
for each phone; see your phone’s manual for detailed instructions.)
4. Your phone should discover a device called BT112 or Headset. If your
phone asks if you want to pair with this device, answer yes.
5. When your phone prompts you for a PIN code or password to pair with
the BT112, enter 0000.
6. When the headset is paired, the LED begins ashing once in 6-second
intervals. Your phone might display a conrmation message, also.
7. Your phone might ask if you want to change the headset’s name;
generally, you should only change the name if you have more than one
BT112 headset that you use with this phone.
Connecting to your phone
Most phones connect to the headset as soon as you pair it; if yours won’t,
then turn the headset o and back on. If the headset still won’t connect,
check your phone’s owner’s manual for additional Bluetooth information.
Once the headset is paired:

7
• Whenever you turn the headset on, it will automatically try to connect
to whatever device it was connected to last.
• If the headset loses the connection (e.g., if your phone is out of range), it
reconnects automatically if the phone is back in range within 1 minute.
After 1 minute, you must press MFB to manually reconnect to the phone.
• If the headset loses connection to the phone during a call, the call is
automatically forwarded to the phone. However, the phone setting
determines if the phone will keep the forwarded call or drop it.
Using Your Headset
Put your headset on
Insert the ear cushion, then wrap the
earhook behind your ear.
Everyone’s ear has a sweet spot, a
particular angle of the speaker where
the audio comes in loud and clear.
Take a few minutes to move the headset around until you nd the best
angle for the ear cushion.

8
If you can’t nd your sweet spot or if the cushion doesn’t t comfortably
in your ear, change it to one of the other sizes that came with the headset.
Pull the cushion o gently and snap a new one on.
Wearing the headset on your left ear
If you want to wear the headset on your left ear, slide
the earhook o and turn it over.
Flip the hook over so it faces
the other direction.
Slide it back on headset and back into place.
Available Features
After the headset is connected, you can:

9
To do this... Do this...
Make a call
Make a call from your mobile phone as usual; your phone
should automatically send the call to the headset. If it
doesn’t, press and hold MFB for 2 seconds to manually send
the call to the headset.
Answer a call While the call is ringing, press MFB.
Hang up Press and release MFB.
Transfer call from
headset to phone/
from phone to
headset
During a call, press and hold MFB for 2 seconds. The headset
sends the call to your phone.
Reject an incoming
call
Press and hold MFB for 2 seconds; when you hear a beep,
release the button.
Redial the last
number
With the phone in standby, press MFB; the headset
automatically dials the last number dialed from the phone.
Adjust the volume
Press the VOL button. There are 6 volume levels that cycle as
you press the VOL button. When the highest level is reached,
the volume level cycles back down to the lowest.

10
Activate voice dialing
With the phone in standby, press and hold MFB for 2 seconds then release.
When you hear a beep, start using your phone’s voice commands. (Your
phone must support voice dialing, and all commands must be pre-
programmed.)
To deactivate voice dialing, press and hold MFB for 2 seconds until you hear
a beep.
Troubleshooting and Maintenance
If you have problems with the headset, see the suggestions in the table
below. If these suggestions don’t help, contact customer support (see the
cover for contact information).
If... Try...
The headset won’t
turn on. -Charging the battery completely.

11
If... Try...
The headset won’t pair
with my phone.
-Making sure your phone is in pairing mode. Check your
phone’s manual for instructions on Bluetooth device
pairing.
-Turning the headset o. Wait at least 10 seconds, then
try again. (See page 5.)
-Making sure your phone supports the Bluetooth
headset or Hands Free Prole.
The headset paired
with my phone, but
I can’t hear anything
through it.
-Making sure the call connected and is still active.
-Making sure the phone transferred the call to the
headset. Press and hold MFB for two seconds to transfer
the call.
The headset keeps
beeping, and I don’t
know why.
-Charging the battery; the battery may be getting low.
The beep sequence will continue every 30 seconds
until you charge the battery.
I can hear the caller,
but the audio is very
weak or soft.
-Turning the speaker volume up.
-Moving closer to your phone Adjusting the ear cushion
to nd your “sweet spot” (see Using Your Headset
section).

12
Reset the Headset
Make sure the headset is not connected to any mobile phones. Push and
hold MFB + VOL for 4 seconds. When reset is successful, the LED blinks 5
times and all mobile phone links are deleted.
General Information
• You cannot use the headset while it is recharging.
• Bluetooth wireless devices have a maximum range of 30 feet (10 m);
the actual range will vary depending on current conditions (obstacles,
battery power, interference, etc.).
• The headset can be connected only to devices that support the
Bluetooth headset or hands-free prole. This product is not compatible
with standard cordless phones.
Battery life
With average use, the battery should provide about 5 hours of talk time
and 100 hours (4 days) days of standby time. A battery that is new or left
unused for long periods of time can have reduced capacity the rst few
times it is used. For maximum battery life, keep your battery charged.

13
• When the battery only has enough charge for about 30 minutes of talk
time, the headset triggers a low battery alert: you’ll hear a periodic beep.
• When the battery no longer has enough charge to operate the headset,
the headset will power o; you won’t be able to turn it back on until you
charge the battery.
Noise or Static on the Headset
The most common cause of noise or static on any wireless device is
interference. Bluetooth devices operate in the ISM band (2.402 GHz ~ 2.480
GHz); any equipment operating in this frequency range might interfere
with the headset. Some common sources of interference in this range are:
• Equipment that uses microwaves, especially microwave ovens
• Wireless LAN equipment or WiFi connections
• Other Bluetooth devices or computers
• Certain cordless telephones
• Certain medical equipment and appliances
If you have problems with static during calls, look for one of these
interference sources. Try moving away from the suspected source.

14
If the noise continues, there may be interference on your phone itself, and
any noise in the phone’s connection will come through on the headset,
too. Transfer the call to your phone and see if the audio quality improves. If
it doesn’t, check around for things that might interfere with your phone.
Safety and Handling Information
For maximum product life, do not drop, throw, or crush the headset. Do
not expose it to humidity, dust, or temperatures above 125˚ F.
Cleaning the headset
• If necessary, remove the ear cushion and earhook. Dampen a lint-free
cloth with water or a cleaner specically designed for electronics, and
gently wipe the headset clean.
• Do not expose this product to liquid (water, alcohol, etc.) or submerse in
liquid for any reason.
Avoiding hearing damage
Using any headset or earbud at too high a volume can cause permanent
hearing damage. To reduce the risk of hearing damage:

15
• Set the volume at the minimum level needed to hear in the current
environment. If possible, use your headset in quiet surroundings or try
to move to an area with less background noise before adjusting the
volume.
• Start with the volume at its lowest setting, then gradually increase it
until you can hear. When the headset has reached its maximum level,
you will hear a beep. Press VOL again and the headset will take the lowest
volume level.
• When you turn the headset o, it keeps the volume level at the last used
level.
• If someone next to you can hear the other end of the call through your
headset or if your ears hurt or ring when you hang up, the volume is too
high.
• The longer your ears are exposed to noise, the greater the risk of
damage. Limit calls at higher volumes (or other exposure to loud noise).
• For more information on protecting your hearing, visit the WISE EARS®
website (www.nidcd.nih.gov/health/wise/) or consult an audiologist.

16
Important Safety Instructions
Uniden America Corporation DOES NOT represent this product to be waterproof. To
reduce the risk of re, electrical shock, or damage to the product, DO NOT expose this
product to rain or moisture.
When using the headset, always follow basic safety precautions to reduce
the risk of re, electric shock and injury to persons, including the following:
• Do not turn on the car with the headset plugged into the car charger.
Only connect the car charger to the headset after the car has been
turned on.
• Do not use this product near water, for example, near a bath tub,
wash bowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.
• Use only the power cord and batteries indicated in this manual. Do not
expose the battery (or the device) to ames or dispose of it in a re: the
battery may explode. Check with local authorities for possible battery
disposal instructions.
• Do not disassemble, modify, or attempt to repair any component of this
product.

17
• Check the laws and regulations on the use of mobile phones and hands-
free equipment in the areas where you drive. Always give full attention
to driving and pull o the road and park before making or answering a
call if driving conditions require.
• Do not allow children to play with your headset since it contains small
parts that could become detached and create a choking hazard.
• Turn o your headset when pumping gas, handling ammable
materials, or in any area with a risk of explosion. In rare occurrences, this
product could generate sparks which can cause an explosion or re.
Follow all warning notices in your immediate area!
SAVE THESE INSTRUCTIONS!
FCC Notice
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation. Privacy of
communications may not be ensured when using this product.
To insure the safety of users, the FCC has established criteria for the amount of radio frequency energy
various products may produce depending on their intended usage. This product has been tested
and found to comply with the FCC’s exposure criteria. For body worn operation, the FCC RF exposure

18
guidelines were also met when used with the Uniden accessories supplied or designed for this
product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines and
should be avoided.
Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following
two conditions: (1)This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE: Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
End users must follow the specic operating instructions for satisfying RF exposure compliance.
To maintain compliance with IC RF exposure compliance requirements, please follow operation
instruction as documented in this manual.
Lithium-polymer battery information
This device contains a lithium-polymer battery. The headset and battery must be recycled or disposed
of properly. Contact your local waste management oce for information on battery recycling or
disposal.
Two-Year Limited Warranty
Important: Evidence of original purchase is required for warranty service.

19
WARRANTOR: UNIDEN AMERICA CORPORATION (“Uniden”)
ELEMENTS OFWARRANTY: Uniden warrants, for two years, to the original retail owner, this Uniden
Product to be free from defects in materials and craftsmanship with only the limitations or exclusions
set out below.
WARRANTY DURATION: This warranty to the original user shall terminate and be of no further eect
24 months after the date of original retail sale. The warranty is invalid if the Product is a) damaged
or not maintained as reasonable or necessary, b) modied, altered, or used as part of any conversion
kits, subassemblies, or any congurations not sold by Uniden, c) improperly installed, d) serviced
or repaired by someone other than an authorized Uniden service center for a defect or malfunction
covered by this warranty, e) used in any conjunction with equipment or parts or as part of any system
not manufactured by Uniden, or f) installed or programmed by anyone other than as detailed by the
owner’s manual for this product.
STATEMENT OF REMEDY: In the event that the product does not conform to this warranty at any time
while this warranty is in eect, warrantor will either, at its option, repair or replace the defective unit
and return it to you without charge for parts, service, or any other cost (except shipping and handling)
incurred by warrantor or its representatives in connection with the performance of this warranty.
Warrantor, at its option, may replace the unit with a new or refurbished unit.
THE LIMITED WARRANTY SET FORTH ABOVE IS THE SOLE AND ENTIRE WARRANTY PERTAINING TO THE
PRODUCT AND IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES OF ANY NATURE WHATSOEVER,
WHETHER EXPRESS, IMPLIED OR ARISING BY OPERATION OF LAW, INCLUDING, BUT NOT LIMITED TO

20
ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THIS
WARRANTY DOES NOT COVER OR PROVIDE FOR THE REIMBURSEMENT OR PAYMENT OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES. Some states do not allow this exclusion or limitation of incidental or
consequential damages so the above limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you specic legal rights, and you may also have other rights
which vary from state to state. This warranty is void outside the United States of America and Canada.
PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: If, after following the instructions in the
owner’s manual you are certain that the Product is defective, pack the Product carefully (preferably in
its original packaging). The Product should include all parts and accessories originally packaged with
the Product. Include evidence of original purchase and a note describing the defect that has caused
you to return it. The Product should be shipped freight prepaid, by traceable means, to warrantor at:
Uniden America Service
4700 Amon Carter Blvd.
Fort Worth, TX 76155
