UNINEX KOOLZONE SAC-3000 User manual

UNINEX INTERNATIONAL
5780 SMITHWAY STREET COMMERCE, CA 90040
T. 800-864-3288 / 323-890-9246 / F. 323-890-9249
KOOLZONE
MOBILE SPOT COOLER
THANK YOU FOR PURCHASING THE KOOLZONE MOBILE SPOT COOLER.
PLEASE READ THE INSTRUCTIONS BEFORE USING.
AND PLEASE KEEP THESE INSTRUCTIONS FOR REFERENCE.
QUICK GUIDE FOR SAC-3000

MANUAL - COLD AIR DUCT / HEAT-REMOVAL DUCT FITTING
PARTS OF THE MACHINE
UNINEX.COM 800.864.3288 CONTACT US FOR PURCHASE OR RENTAL (Click Here)
INSTALLATION
1. Installation of the curved duct: Please make the convex part of the curved duct point to the concave part
of the bending base and insert it, then turn the duct in counterclockwise to lock.
2. Installation of the cooling duct: Slide the fringe of cooling duct to the slot of curve duct,
then turn the cooling duct clockwise to lock. Please make sure the joint is connected well before use.
3. Installation of the heat-removal duct and socket: The heat-removal duct socket uses 4 ST4×12 bolts to x on the heat vent.
When heat-removal duct insertion heat-removal duct socket, please note reliably.
When inserting the heat-removal duct, please note the heat-removal mouth recess.
Heat-Removal Duct
Heat-Removal Duct Socket
Cold Air Duct
Duct Elbow
Duct Cap
Choice Switch
Drain Tank (5L)
Particle Filter Pull it out
High
Low
Off
Power
Insertion
Heat Vent
Heat-Removal
Duct
Cooling Duct
Recess
Convex Part
Duct Elbow
Cold Wind Export
Black Line
Insert into
the Entrance
*After the insertion,
rotates 180
Drain Hose
Heat-Removal
Duct Socket

TURN THE SPOT COOLER ON/
DIRECTION ADJUSTMENT
DRAIN TANK / DIRECT DRAIN
IMPORTANT - KEEP DISTANCE
Heating Outlet
Direction above 80cm
Air Outlet
Direction above 30cm
Cooling Outlet
Direction above 30cm
UNINEX.COM 800.864.3288 CONTACT US FOR PURCHASE OR RENTAL (Click Here)
200º
High
Low
Off
Power
Extraction Drain Tank
Red Water Line
Base Hole
Draining Water Mouth
Drain Tank
Extraction
Drain Mouth
16
⏀

UNINEX.COM 800.864.3288 CONTACT US FOR PURCHASE OR RENTAL (Click Here)
KOOLZONE MANUFACTURER’S
RECOMMENDATIONS
1. USE A DEDICATED OUTLET. DO NOT SHARE AN OUTLET WITH OTHER DEVICES.
SHARING AN OUTLET MAY CAUSE A POWER CUT.
2. USING AN EXTENSION CORD IS NOT RECOMMENDED.
IF AN EXTENSION CORD IS NEEDED, USE 12 AWG OR THICKER GAUGE.
3. DO NOT BLOCK THE HEAT EXHAUST OUTLET.
(DO NOT PLACE SAC1800 TOO CLOSE TO THE WALL.)
IT MAY BLOCK THE HEAT OUTLET AND CAUSE THE SPOT COOLER TO
STOP WORKING PROPERLY.
4. FOR OPTIMUM PERFORMANCE, USE ONLY UP TO A MAXIMUM OF
12 FT OF HEAT/COOL EXTENSION DUCT.
12
AWG
MAX
12FT

PLEASE NOTE
UNINEX.COM 800.864.3288 CONTACT US FOR PURCHASE OR RENTAL (Click Here)
OPTIMUM OPERATING TEMPERATURE RANGE FOR
KOOLZONE MOBILE SPOT A/C COOLER
IS FROM 64 - 104° FAHRENHEIT.
PROPER USAGE OF THIS UNIT, AT THE COOLING DUCT,
WILL REDUCE THE AMBIENT TEMPERATURE
BETWEEN 10 - 15° FAHRENHEIT.

MAKE LIFE SIMPLE AND MORE CONVENIENT
WITH UNINEX
EXCLUSIVELY DISTRIBUTED BY:
UNINEX INTERNATIONAL
5780 SMITHWAY STREET COMMERCE, CA 90040
T. 800-864-3288 / 323-890-9246 / F. 323-890-9249
MANUFACTURE:
NAKATOMI CO.,LTD.
6445-2, TAKAI, TAKAYAMA, KAMITAKAI, NAGANO, JAPAN
