Unisto e-Guard User manual

Unistoe‐Guard Manual
www.unisto.com
Scopeofdelivery
Eachpackagecontains:
Unisto e‐Guard
MetalCradle
Hasp(mountedandcalibrated,500mm)
Fixing‐Set
2Screws
2ringsand2nuts
Positioningandfittinginstructions
1
3
2
A
B
Usethecradleto
determinethecorrect
placeofdrillingthe2
holesinthe
trailerdoor.Cutoff
theremaininglength
oftheboltsafter
mountinginsidethe
trailer.Firstmount
thebackofthecradle
1
A B
(onescrew)tothedoor,insertthee‐Guardandthenmountthe
Litandplacethesecondscrew.Important:DonotmounttheUnisto
e‐Guardupsidedowntopreventextradirtaccumulatinginthecable
mechanism.
B2
3 A
CableReplacement
Thecablecanbereplacedbyremovingtheplastic“bridge”andthe
pinwithasmallscrewdriver.Nowthemetallockplateandthe
cablecanberemovedfromthehousing.Attention:Calibrationis
necessarywhenreinsertinga cable.
AA
A
B
B
C
C
D
D
LowBattery
A
Lowbattery:
Lowbatteryreportinfirmware.Calculate
batterycapacityused.80%isthelimitto
showalowbatteryalert.
Thecustomershouldatleastbeabletouse
thesealfor3monthsafterthefirstlow
batterywarning.Thisdependsontheamount
ofopening
Indicationlowbattery:
Blinkredledevery6secondandwith
everyactivationoftheSeal.Blinkanumber
oftimesandshowtext“lobat “.
A
Warnings
ApplyanduseUnisto e‐Guardasdescribedinthismanual.
Donottrytorechargebattery,orexposetoheatabove100C,riskforfire,
explosionandsevereburnhazard.
Wrongconnectionofthebatterypackconnectorwillruintheelectronics!
Moistinthebatterycompartmentcouldruintheelectronics!
Aqualifiedpersononlyshouldreplacethebattery,thecableanddothe
intialisation!
Donotpressurewash.
Donotdrillholesorhammertheproduct.
Onlycertifiedoriginalcablescanbeused.
OnlythespecialbatterypackfromUnisto canbeused.
Battery
•LI/SOCI2Lithium Xtra Tadiran ,3,6volt,
temprange–55to+85C
•ULrecognitionunderfileMH12827.
•Electricalcomponents:highquality,PCBencapsulated
inepoxy
•Workingtemperaturesfrom–30to+70C
1

Batterychange
B
Howitworks
1
23
45
WhentheUnisto e‐Guardismountedonatrailerdoor,closethesealby
pressingtheleftsideofthemetalbar,placethecableendanda
random4digitnumberisgenerated.Writedownthe4digitunique
sealingnumberonthefreightdocumentationandclosethelitofthe
metalcradle.Thenumberdisappearsautomatically;toseeitagain,
presstheroundbutton.
12
3
4
5
6
8
79
Liftcoveratpointofarrival.Presstheroundbuttontocheckifthe
displaystillshowsthesamenumberasgeneratedatthestartingpoint.
Openthesealbypressingtheleftsideofthemetalbar,movethecable
endoutofthehousing.Whenthesealisopen,oPEn – sealingnumber‐
oPEn appearsonthedisplay.
67
8
9
B
Unscrewthe4boltsbyusingaTorx number8.Openthecoverand
removetherubberrings(1largeand4smallones).Takeoutthebattery
packbycarefullypullingthewiretounplugthebatterypack.Plug‐inthe
newbatterypackand reassemblethecoverinreverseorder.
CableCalibration
FirstremovethecablecompletelyPressthebuttonuntilCALappears
onthedisplay.NowpressbuttonOPENappears.Pressbuttonagain.Two
differentrandomlygenerated5‐digitcodeappearinthedisplay.CLOSE
appears.
A
A B
B
C
C
Nowthetwoendsofthecablecanbeplacedintothehousing.Press
button.Twodifferentrandomlygenerated5‐digitcodeappearinthe
display.ThenDONEappears.Afterthatpressthebutton.Ifthedisplay
showsa4‐digitsealnumber,thecalibrationprocessisfinished.
Oneendhastofixedtothehousingbyplacingbackthemetallockplate
andfixitwiththepinandthebridge.
Atthetimeofdeliverythecableisalreadymountedandcalibrated.
Thisprocessisonlynecessarywhenreplacingacable.
H
H
K
J
JK
L
L
X
X
Initialoperation
Whentheunitisstartedup,SLEEP appearson
thedisplay.Toactivatethedeviceyouhaveto
pressthebutton5timeswithin2seconds.
AfterthatthedisplayshowsStArt forashort
time.Nowthesealisreadyandcreatessealing
numbers.
