Unisto Manta User manual

Unisto Manta
User guide
EP-0016A-500Ac-en

2Manufacturer’s
address
Unisto AG
Seestrasse 7
CH-9326 Horn
Switzerland
Tel. [phone]
Fax [phone]
www.unisto.com

3
Table of contents
Unisto Manta user guide
EP-0016A-500Ac-en
2 Manufacturer’s address
3 Table of contents
4 Package content
6 Product overview
8 Preparation
1 1 Positioning and fitting instructions
1 4 Fitting instructions for various lock types
1 8 Special applications
1 9 Added security
2 0 Usage instructions
2 2 The event memory
2 3 Device functions
2 8 Maintenance
2 9 FCC Rules
Warning
3 0 Warranty
3 1 Recommended assembly/Recommended cleaning

4Package
content
1 Standard packaging
2 Unisto Manta
Electronic seal
3 Gasket rear
4 Security hasp
5 Mudflap
6 User guide
7 Fixing kit
including Allen Key size 2
Unisto Manta
User guide
Ref. AA 39 E
6 7

5
Package
content
1
2
3
4
5

6Product
overview
Manta front view
1 Display
for seal number,
date and time
2 IrDA Interface
3 Select button/
Back track button
4 Display button
5 Locking handle
in open position
6 Locking screw
to prevent
“false openings”
7 Reinforcer plate
with cable retention
slider
12
3 4
5
6
7

7
Product
overview
Manta rear view
8 Product label
9 fixing points
8
9
9

8Preparation
Manta Hasp Fitting –
fixed end
One end of the wire hasp must be per-
manently fixed into the reinforcer plate
of Unisto Manta. First remove the two locking screws on the
left and right side of the locking handle.
Then turn the locking handle either to the
left or right.
Release the socket head screw in the rein-
forcement plate with the Allen key.
Remove the screw and slide over the retain-
ing cover to give space for the wire hasp.
Place one end of the wire hasp into the open
cavity as shown above.
1
2
3
4

9
Preparation
Manta Hasp Fitting –
fixed end (cont.)
Pull the hasp downward.
Slide the retaining cover over the inserted
hasp.
Secure the position of the retaining cover
with the socket head screw.
5
6
7

10 Preparation
Manta
Preferred opening
You may choose from the opening posi-
tion on either the right or left side.
Hasp fixed end
on the right side
Hasp fixed end
on the left side
1
2
1
2

11
Positioning
and fitting
instructions
Important fixing details
BEFORE drilling holes
Please make sure that the end position
of the hasp is:
- tight enough to prevent movement
of the door handle whilst ensuring
that the movement of the handle
and the door(s) are not impaired in
any way.
Position and fix the Unisto Manta
vertical.
1) Feed the lose end of the security hasp
through the door latch and insert into the
open cavity of the Unisto Manta.
2) Position the Unisto Manta and make sure
the door latch cannot be opened.
3) Mark the requested position on the door.
Use rear gasket as drilling template.
Ensure the word “FRONT” faces away from
the vehicle door. Carefully mark the two drill
holes on top and bottom.
12

12 Fitting
instructions
Use a 6 mm bit (1 /4”) to drill the holes in the
doors (or shutter).
Screw the two 6 mm stud bolts into the
threaded holes of Unisto Manta by hand.
HAND TIGHTEN ONLY!
Slip the rubber gasket over the studs.
Slip the mudflap over the studs as shown
above.
3
4
5
6

13
Fitting
instructions
Introduce the studs into the prepared holes.
Attach the washers and nuts (from the inside
of the doors).
DO NOT OVERTIGHTEN THE NUTS!
Check how much of the stud bolts are pro-
truding on the inside of the door and remove
excess with a hacksaw.
Once the excess is removed, it is advisable to
remove any sharp edges with a file.
7
8
9

14 Fitting
instructions
for various
lock types
The diagrams shown here are only in-
tended as a guide;
door/locking mechanisms vary from
vehicle to vehicle.
Container locks
Barn door
Roller shutter
Staple door latches
Fix the Unisto Manta to the “door”
placed to open first.

15
Fitting
instructions
for various
lock types
Henderson/TODCO
Type latches

16 Fitting
instructions
for various
lock types
Whiting Type Catches
Note for Whiting type catches:
With some types of catch it is necessary
to mount the Unisto Manta slightly to
the left of the handle (see diagram), to
make sure the door cannot be opened.

17
Fitting
instructions
for various
lock types
Whiting Type Catches
Note for handles (Whiting 77 Type):
The Unisto Manta must be mounted in
a suitable position, where it does not
hinder the travel of the handle.

18 Special
applications
Certain applications (e.g. curtain side
trailers) may require a special length
hasp. The hasp has to be fed through
each buckle in the side curtain, then
the hasp ends can be introduced into
the cavities of the Unisto Manta as de-
scribed before.
Alternatively, the hasp loop can be used
in conjunction with TIR cables. The TIR
cable terminals must first be flattened
slightly with a hammer or pliers.
The free end of the hasp is then thread-
ed through the 7 mm openings of the
TIR cable and then introduced into the
cavity of the Unisto Manta as described
in the general fitting instructions.

19
Added security
Padlock (6 mm shank)
Optional for added security.

20 Usage
instructions
Before departure (1-4)
When the vehicle is loaded and the door(s)
closed, feed the end of the wire hasp through
the door latch...
...and insert into the open cavity of the Unisto
Manta.
Pull down on the hasp and secure by closing
the locking handle (see diagrams in installa-
tion instructions).
Press the DISPLAY button, a random seal
number appears in the display for 3 seconds.
Note the displayed (4-digit) seal number in
the vehicle’s transport documents.
1
2
3
4
