Unitech Ms810 Installation and operation manual

MS810 Laser Scanner

Product Reference Guide

Rev. A

This manual explains how to install, operate and maintain the Unitech MS810 Laser

Scanner.

No part of this publication may be reproduced or used in any form, or by any

electrical or mechanical means, without permission in writing from the manufacturer.

This includes electronic or mechanical means, such as photocopying, recording, or

information storage and retrieval systems. The material in this manual is subject to

change without notice.

All product names mentioned in this manual may be trademarks or registered

trademarks of their respective companies and are hereby acknowledged.

FCC Compliance

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the instructions manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference

in which case the user will be required to correct the interference at his own expense.

Changes or modications not expressly approved by the party responsible for

compliance could void the user‘s authority to operate the equipment.

Warranty

No warranty of any kind is made in regard to this material, including, but not limited

to, implied warranties of merchantability or tness for any particular purpose. We are

not liable for any errors contained herein or for incidental or consequential damages

in connection with furnishing, performance or use of this material. We shall be under

no liability in respect of any defect arising from fair wear and tear, willful damage,

negligence, abnormal working conditions, failure to follow the instructions and

warnings, or misuse or alteration or repair of the products without written approval.

About This Manual

Preface

Support

Unitech’s professional support team is available to quickly answer your questions

or technical-related issues. Should an equipment problem occur, please contact the

Unitech regional service representatives nearest you. Visit the websites, listed below,

for complete contact information:

UTC (China) http://www.ute.com.cn

UTT (Taipei, Taiwan) http://www.unitech.com.tw

APAC (Taipei, Taiwan) http://www.unitech-adc.com

UTJ (Japan) http://www.unitech-japan.co.jp

UTA (USA, Canada) http://www. ute.com

UTA (Latin America) http://www.latin.ute.com

UTI (Europe) http://www.unitech-europe.nl

Chapter 4

Bar Code Symbologies

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Symbologies On/Off - 1

Code 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Code 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Symbologies On/Off - 2

Code 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Code 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Codabar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Interleaved 2 of 5..............................................18

Industrial2of5...............................................19

Symbologies On/Off - 3

MSI ........................................................20

UPC/EAN ...................................................20

Symbologies Setup - 1

Code 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Code 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Symbologies Setup - 2

Code 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Code 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Codabar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Symbologies Setup - 3

Codabar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Interleaved 2 of 5..............................................25

Industrial2of5...............................................26

Symbologies Setup - 4

MSI ........................................................27

UPC/EAN ...................................................27

Symbologies Setup - 5 ..........................................29

Symbologies Setup - 6

UPC/EAN ...................................................31

Edit Setup Bar Codes ...........................................32

Macro/Special Keys Setup Bar Codes..............................34

Termination String Setup Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Chapter 5

Factory Default Settings

Scanner Timing/Default .........................................37

Chapter 6

Troubleshooting

Possible Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Other Product Questions ........................................40

Preface

About This Manual

FCC Compliance ................................................2

Warranty .......................................................2

Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 1

Introduction

Introducing the MS810 ...........................................6

A Tour of the MS810 .............................................7

Laser Scan Engine Specications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Decode Zone ...................................................9

Chapter 2

Installation

USB Cable Connection ..........................................10

PS2 (K/B) Cable Connection .....................................11

Operating the MS810. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Chapter 3

Bar Code Setup Menu

Multi-Interface Functions - 1

OutputMode.................................................13

Buzzer/LED ..................................................13

Image ......................................................13

Code ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Multi-Interface Functions - 2

Reading Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

PC Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Transmit Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Language ...................................................16

Table of Contents

Introducing the MS810

The Unitech MS810 1D laser bar code scanner combines the best scanning

performance and value. The device provides an accurate, easy, and fast method of

data entry and data storage for computerized information systems. It is easy to install

and does not require software or drivers to operate.

All the operating parameters are programmed by the bar code programming menu

and stored in non-volatile RAM which can retain the settings after power is turned off.

The MS810 is a powerful and reliable handheld scanner without compromise. It is

compatible with USB and K/B interfaces, and numerous congurations.

Introduction

Chapter 1

A Tour of the MS810

The following section describes the main components and features of the MR810.

No. Component Description

1. LED (Blue/Red) LED light indicates a proper decode.

2. Speaker Speaker beeps to indicate a proper decode.

3. Handle Ergonomic handle allows for an easy grip.

4. Trigger Trigger device allows for manual scanning.

5. Exit Window A scratch-resistant surface for high-quality

scans.

NOTE: When a barcode is successfully decoded, the blue LED light on the back of

the scanner will turn on and off, and the scanner will beep once. If the barcode is

not successfully read, the LED will show red and the beep will not sound.

Laser Scan Engine Specications

Performance

Light Source: 650 nm (+10/-5 nm) Laser Diode, 1mW (peak)

Depth of Field (40 mils): Up to 420 mm Min.

Scan Speed: 80 scans/sec

Max Resolution: 0.1mm (4mils) - Code 39

Print Contrast: 45% or more

Scan Angle: 38º

Reading Indicator: Blue/Red LED, Audible Beep

Interface: USB, PS/2

Symbologies: UPC/EAN/JAN, Code 39, Codabar, ITF 2/5,

Code 128, Code 11, Code 93, MSI

Electrical Characteristics

Input Voltage: 5 VDC ± 0.5V

Current - Operating: 60mA

Regulation: FCC Class A & CE & IEC60825 Class II,

CDRH: Class II

Physical Characteristics

Dimensions (L x W x H): 93mm x 61mm x 182mm

Weight: 130 g +/- 5 g (without cable)

Case Material: Rubber & ABS Plastic

Environmental Characteristics

Operating Temperature: 0ºC to 50ºC (32ºF to 122ºF)

Storage Temperature: -20ºC to 60ºC (-4ºF to 140ºF)

Operating Humidity: 10% to 85% relative humidity, non-condensing

Storage Humidity: 5% to 95% relative humidity, non-condensing

Light Level: Up to 36000 Lux

Shock: 1.5m drop onto concrete

Decode Zone

The Decode Zone is based on Symbol’s Standard Code 39 PCS=0.9 lable in a 600 lux

environment.

NOTE: Do not hold the scanner directly over a barcode at 90˚. Scanning light

bounces directly back into the scanner from the barcode label is known as

specular reection which will create a “dead zone” where decoding is difcult.

Practice a few times to nd what range of angles works best.

USB Cable Connection

Insert the plug on the free end of the USB Communications Cable into any open USB

port on the host as described below.

Reset Conguration to Defaults

If you are unsure of the scanner

conguration or have scanned the

incorrect codes, please scan the “Reset

Conguration to Defaults” barcode.

This will reset the scanner to its factory

defaults settings in USB interface.

Installation

Chapter 2

PS/2 (K/B) Cable Connection

Reset Conguration to Defaults

If you are unsure of the scanner

conguration or have scanned the

incorrect codes, please scan the “Reset

Conguration to Defaults” barcode.

This will reset the scanner to its factory

defaults settings in PS/2 interface.

To Operate the MS810

1. Be sure that Host computer is turned OFF.

2. Ensure that all connections are secure.

3. Turn on your host computer and operate the scanner in Notepad, Word or your

preferred software.

4. Aim the scanner at a barcode, ensure that the scanner is in trigger mode (default),

and press the trigger.

5. On successful decode, the blue LED light will turn on and off. The scanner will beep

once.

Maintenance

Cleaning the scan window is the only maintenance required. A dirty window may

affect scanning accuracy. Wipe the scanner window gently with a lens tissue or other

material suitable for cleaning optical material. Do not spray water or other cleaning

liquids directly onto the window.

Bar Code Setup Menu

Chapter 3

Multi-Interface Functions - 1

OUTPUT FIRMWARE VERSION

RESET CONFIGURATION TO

DEFAULTS

0A 0B

OUTPUT MODE – KEYBOARD / USB OUTPUT MODE OUTPUT MODE – KEYBOARD / USB

000600 000600

GOOD READ BEEP TONE – NONE BUZZER / LED GOOD READ BEEP TONE - RESET

014200 0B142

DECODE OPTIONS REVERSE IMAGE

– ENABLE

IMAGE DECODE OPTIONS REVERSE IMAGE

- DISABLE

01391 01390

DECODE OPTIONS SEND BAR CODE

ID - DISABLE

CODE ID DECODE OPTIONS SEND BAR CODE

ID – AS A PREFIX

01400 01401

DECODE OPTIONS SEND BAR CODE

ID - RESET

DECODE OPTIONS SEND BAR CODE

ID – AS A SUFFIX

Multi-Interface Functions - 2

SCAN MODE – SINGLE SCAN

READING

MODE

SCAN MODE – SINGLE SCAN

NO TRIGGER

013300 013301

SCAN MODE – MULTISCAN

NO TRIGGER

013302 013303

SCAN MODE – CONTINUOUS SCAN SCAN MODE - PULSE

013304 013305

LASER/CCD TIMEOUT – 5 SECONDS LASER/CCD TIMEOUT – 2 SECONDS

0134005 0134002

LASER/CCD PULSE RATE - 7 LASER/CCD PULSE RATE - 3

013507 013503

Multi-Interface Functions - 1 (cont.)

Interface - Keyboard Wedge

WEDGE MODE - AUTODETECT

Communication

WEDGE MODE – SCAN SET 2

` PASS THRU

000200 000204

TRANSMIT SPEED - 0

TRANSMIT

SPEED TRANSMIT SPEED - 25

0000000 0000025

KEYBOARD COUNTRY - USA LANGUAGE KEYBOARD COUNTRY - GERMAN

0005000 0005010

KEYBOARD COUNTRY – FRANCE KEYBOARD COUNTRY - UNIVERSAL

0005009 0005025

Introduction

This section contains a list of supported symbologies with congurable settings for

each symbology.

Symbologies On/Off - 1

CODE 11 - ENABLE CODE 11 CODE 11 - DISABLE

01261 01260

CODE 39 ENABLE

CODE 39

CODE 39 DISABLE

00221 00220

FULL ASCII ENABLE FULL ASCII DISABLE

00231 00230

Bar Code Symbologies

Chapter 4

Symbologies On/Off - 2

CODE 93 - ENABLE CODE 93 CODE 93 - DISABLE

00621 00620

CODE 128 - ENABLE CODE 128 CODE 128 - DISABLE

00691 00690

CODE 128 ISBT - ENABLE CODE 128 ISBT - DISABLE

00701 00700

CODABAR - ENABLE

CODABAR

CODABAR - DISABLE

00851 00850

I2OF5 - ENABLE

INTERLEAVED

2 OF 5 I2OF5 - DISABLE

00961 00960

Symbologies On/Off - 2 (cont.)

ID2OF5 - ENABLE

INDUSTRIAL

2 OF 5 ID2OF5 - DISABLE

01061 01060

Symbologies On/Off - 3

MSI - ENABLE MSI MSI - DISABLE

01151 01150

UPC-A ENABLE UPC/EAN UPC-A DISABLE

00341 00340

UPC-E ENABLE UPC-E DISABLE

00351 00350

EAN-13 ENABLE EAN-13 DISABLE

00361 00360

EAN-8 ENABLE EAN-8 DISABLE

00371 00370

Symbologies Setup - 1

CODE 11 ID CHARACTER – “m” CODE 11 CODE 11 ID CHARACTER – “Z”

0131M 0131Z

CODE 11 LASER/CCD REDUNDANCY

- ENABLE

CODE 11 LASER/CCD REDUNDANCY

- DISABLE

01321 01320

CODE 39 SS CHAR - NONE

CODE 39

CODE 39 SS CHAR ‘+’

002700 002704

CODE 39 SEND START/STOP CHARS

ENABLE

CODE 39 SEND START/STOP CHARS

DISABLE

00281 00280

CODE 39 ID CHARACTER ‘a’ CODE 39 ID CHARACTER ‘z’

0031A 0031Z

Symbologies Setup - 1 (cont.)

CODE 39 LASER/CCD REDUNDANCY

ENABLE

CODE 39 CODE 39 LASER/CCD REDUNDANCY

DISABLE

00331 00330

Symbologies Setup - 2

CODE 93 ID CHARACTER – “h” CODE 93 CODE 93 ID CHARACTER – “Z”

0066h 0066Z

CODE 93 LASER/CCD REDUNDANCY

- ENABLE

CODE 93 LASER/CCD REDUNDANCY

- DISABLE

00681 00680

CODE 128 ID CHARACTER – ‘g’

CODE 128

CODE128 ID CHARACTER - ‘Z’

0081g 0081Z

CODE 128 LASER/CCD REDUNDANCY

- ENABLE

CODE 128 LASER/CCD REDUNDANCY

- DISABLE

00841 00840

CODABAR SEND START/STOP CHARS

- ENABLE

CODABAR CODABAR SEND START/STOP CHARS

- DISABLE

00861 00860

Symbologies Setup - 2 (cont.)

CODABAR WIDE GAPS ALLOWED -

ENABLE CODABAR CODABAR WIDE GAPS ALLOWED

- DISABLE

00901 00900

Symbologies Setup - 3

CODABAR ID CHARACTER – ‘k’ CODABAR CODABAR ID CHARACTER – ‘Z’

0094k 0094Z

CODABAR LASER/CCD REDUNDANCY

- ENABLE

CODABAR LASER/CCD REDUNDANCY

- DISABLE

00951 00950

I2OF5 CHECK DIGIT - DISABLE

Interleaved

2 of 5 I2OF5 CHECK DIGIT - ENABLE

00970 00981

I2OF5 ID CHARACTER – ‘i’ I2OF5 ID CHARACTER – ‘Z’

0104i 0104Z

I2OF5 LASER/CCD REDUNDANCY -

ENABLE

I2OF5 LASER/CCD REDUNDANCY

- DISABLE

01051 01050

Symbologies Setup - 3 (cont.)

ID2OF5 BAR START/STOP - ENABLE

Industrial

2 of 5 ID2OF5 BAR START/STOP - DISABLE

01071 01070

ID2OF5 BAR START/STOP - ENABLE ID2OF5 BAR START/STOP - DISABLE

0113j 0113Z

Symbologies Setup - 4

ID2OF5 LASER/CCD REDUNDANCY

- ENABLE

ID2OF5 LASER/CCD REDUNDANCY

- DISABLE

01141 01140

MSI CHECK DIGIT – MOD 10

MSI

MSI CHECK DIGIT –RESET

01160 0B116

MSI ISBN ID CHARACTER –’f’ MSI ISBN ID CHARACTER –’Z’

0053f 0053Z

MSI LASER/CCD REDUNDANCY - ENABLE

MSI LASER/CCD REDUNDANCY

- DISABLE

01251 01250

EXPAND UPC-E TO UPC-A ENABLE

UPC/EAN

EXPAND UPC-E TO UPC-A DISABLE

00381 00380

Symbologies Setup - 4 (cont.)

EXPAND UPC-A TO EAN-13 ENABLE UPC/EAN EXPAND UPC-A TO EAN-13 DISABLE

00391 00390

CONVERT EAN-13 TO ISBN ENABLE CONVERT EAN-13 TO ISBN DISABLE

00481 00480

Symbologies Setup - 5

SEND UPC-A CHECK DIGIT ENABLE SEND UPC-A CHECK DIGIT DISABLE

00421 00420

SEND UPC-E CHECK DIGIT ENABLE SEND UPC-E CHECK DIGIT DISABLE

00431 00430

SEND EAN-13 CHECK DIGIT ENABLE SEND EAN-13 CHECK DIGIT DISABLE

00461 00460

SEND EAN-8 CHECK DIGIT ENABLE SEND EAN-8 CHECK DIGIT DISABLE

00471 00470

UPC-A ID CHARACTER ‘b’ UPC-A ID CHARACTER ‘Z’

0049b 0049Z

Symbologies Setup - 5 (cont.)

UPC-E ID CHARACTER ‘c’ UPC-E ID CHARACTER ‘Z’

0050c 0050Z

EAN-13 ID CHARACTER ‘e’ EAN-13 ID CHARACTER ‘Z’

0051e 0051Z

Symbologies Setup - 6

EAN-8 ID CHARACTER ‘d’ UPC/EAN EAN-8 ID CHARACTER ‘Z’

0052d 0052Z

ISBN ID CHARACTER ‘f’ ISBN ID CHARACTER ‘Z’

0053f 0053Z

UPC/EAN SUPPLEMENTS - DISABLE

UPC/EAN SUPPLEMENTS – 2 DIGIT

ONLY

00550 00551

UPC/EAN SUPPLEMENTS – 5 DIGIT ONLY UPC/EAN SUPPLEMENTS – 2 & 5 DIGIT

00552 00553

UPC/EAN LASER/CCD REDUNDANCY

ENABLE

UPC/EAN LASER/CCD REDUNDANCY

DISABLE

00541 00540

Edit Setup Bar Codes

EDIT #1 – STRIP 1 LEADING CHARACTER ON

ALL BAR CODES THAT START WITH ‘12345’ EDIT #1 - OFF

02000101000000100000000112345 0B20001

EDIT #2 – STRIP 1 TRAILING CHARACTER EDIT #2 – OFF

020002020000001 0B20002

EDIT #1 – FILTER LEADING SPACES EDIT #1 - OFF

020001030000032 0B20001

EDIT #1 – FILTER TRAILING SPACES EDIT #1 - OFF

020001040000032 0B20001

EDIT – FILTER ALL’-’ CHARACTERS

EDIT – DISABLE FILTER OF ALL ‘-’

CHARS

020000050000045 0B20000050000045

Symbologies On/Off - 5

UPC-E ID CHARACTER ‘c’ UPC-E ID CHARACTER ‘Z’

0050c 0050Z

EAN-13 ID CHARACTER ‘e’ EAN-13 ID CHARACTER ‘Z’

0051e 0051Z

Edit Setup Bar Codes (cont.)

EDIT - INSERT LEADING ZERO

EDIT – DISABLE INSERT LEADING

ZERO

020000060000000048 0B20000060000000048

Macro/Special Keys Setup Bar Codes

MACRO #1 – FIND ‘1’ AND REPLACE WITH ‘ONE’ MACRO #1 - DISABLED

02010101011ONE 0B20101

MACRO #2 – FIND ‘2’ AND REPLACE WITH ‘TWO’

FOR CODE 39 ONLY MACRO #2 - DISABLED

0201023012TWO 0B20102

MACRO – FIND ‘0’ AND REPLACE WITH ‘A’

MACRO – FIND ‘0’ AND REPLACE WITH

‘A’ - DISABLE

02010001010A 0B2010001010A

SPECIAL KEY –MAP F3 TO ‘0’

SPECIAL KEY – DISABLE F3 KEY

MAPPING

0162048 0B162

SPECIAL KEY – MAP KEYPAD ENTER TO ‘2’

SPECIAL KEY – DISABLE KEYPAD

ENTER MAPPING

0182050 0B182

Termination String Setup Bar Codes

STRING #1 – TERMINATION CHAR - CR STRING #1 – TERMINATION - LF

0202011000$0D 0202011000$0A

STRING #1 – TERMINATION CR+LF STRING #1 - DISABLE

0202011000$0D$0A 0B20201

STRING #2– CODE 128 TERMINATION CHAR

- CR

STRING #2 – CODE 128 TERMINATION

CHAR - LF

0202021080$0D 0202021090$0A

STRING #2– CODE 128 TERMINATION

CHAR – CR+LF

STRING #2– CODE 128 TERMINATION

CHAR - REMOVED

0202021080$0D$0A 0B20202

STRING – CODE 39 TERMINATION CHAR - TAB

STRING – CODE 39 TERMINATION CHAR

– TAB - REMOVED

0202001020$09 0B202001020$09

Termination String Setup Bar Codes (cont.)

STRING ALL CODES PREAMBLE - STX

STRING ALL CODES POSTAMBLE

- ETX

0202002000$02 0202003000$03

Scanner Settings Default

Keyboard Wedge Communication Default

Terminal Type PC/AT

Keyboard US Keyboard

Terminator Enter (Alpha numeric)

USB Communication Default

Terminator Type Enter

Code mode Scan mode

Keyboard US Keyboard

Decoder Selection Default

EAN/UPC Enable

Code 39 Enable

Code 32 Disable

CODABAR Enable

ITF 2 of 5 Enable

MSI Disable

Code 93 Enable

Code 128 Enable

EAN-128 Disable

Factory Default Settings

Chapter 5

Problem: Nothing happens when I follow the operating instructions.

Possible Cause: Possible Solution:

Interface cables are loose Check for loose cable connections. If

problem persits, call technical support

for assistance.

Problem: My computer gets a keyboard error while booting up.

Possible Cause: Possible Solution:

The scanner is damaged or is no longer

functioning.

Disconnect the scanner from your

computer and use your keyboard only.

Reboot your computer. If your computer

still gets a keyboard error, then the

problem may not be the scanner. Call

technical support for assistance.

Problem: Light comes on, but the scanner doesn’t read the bar code.

Possible Cause: Possible Solution:

Interface cables are loose Check for loose cable connections

Scanner is not programmed for the

correct bar code type.

Be sure to select the correct interface

selection and ensure that the scanner is

programmed to read the type of barcode

you are scanning.

Barcode symbol is unreadable. Check the symbol to make sure it is not

de-faced. Try scanning test symbols of

the same barcode type.

Distance between scanner and barcode

is incorrect.

Move the scanner closer or further from

the barcode.

Troubleshooting

Chapter 6

Problem: The scanner beeps, but no data is displayed on my computer.

Possible Cause: Possible Solution:

Scanner is not programmed for the

correct host type.

Please make sure the scanner is

congured to the appropriate host type

by scanning the corresponding

programming barcode on the User’s

Manual.

The scanner is congured to send the

numeric data as KEYPAD NUMERICS,

or the Keyboard Country setting is set to

UNIVERSAL

Recongure the scanner to Send

Numerics as MAIN KEYBOARD KEYS

and set the Keyboard Country setting to

the country setting of your computer.

Problem: My Caps Lock LED on my keyboard ickers when I read a

bar code.

Possible Cause: Possible Solution:

The Keyboard that you are using

requires shifting in and out of the shift

Lock mode to send the data properly.

You can reduce the ickering and speed

up the data transmition by sending

numeric data as keypad numerics, or

setting the keyboard country mode to

UNIVERSAL.

Other manuals for MS810

Table of contents

Popular Scanner manuals by other brands

Xerox

Xerox DocuMate 3920 Specifications

Epson

Epson 836XL - Expression - Flatbed Scanner Product support bulletin

Honeywell

Honeywell MS4980 Installation and user guide

Photon Focus

Photon Focus MV1-D2048-3D06 series user manual

Visioneer

Visioneer RoadWarrior Strobe XP 100 datasheet

Epson

Epson WorkForce Pro GT-S50 Specifications

Klarstein

Klarstein 10004235 user manual

UMAX Technologies

UMAX Technologies MIRAGE IISE Operation manual

Microtek

Microtek ScanMaker X12USL installation guide

Canon

Canon 4200F - CanoScan Flatbed Scanner quick start guide

Siemens

Siemens CLSC3000 installation manual

Canon

Canon CanoScan LiDE 35 quick start guide

DAVID

DAVID SLS-2 quick start guide

Photoneo

Photoneo PhoXi 3D Scanner M quick start guide

Canon

Canon CANOSCAN D1230 series Service manual

WizCom Technologies

WizCom Technologies Readingpen Basic Edition K-12 quick start

atiz

atiz scandock user guide

Bell and Howell

Bell and Howell Copiscan 8000 Plus Series Operator's manual

Unitech MS810 Installation and operation manual

Popular Scanner manuals by other brands
