Hodedah HIKF 96 User manual

1

1 2
3 4
56
78 9 10 11
12 13 14 15 16
17 18 19 20 21
22 23 24 25 26
Down Side Panel (Left)
1 pcs
770 x400x 15mm
Middle Support
1 pcs
576 x66x 15mm
Bottom Panel
1 pcs
576 x398 x 15mm
Leg Panel
1 pcs
576 x103 x 15mm
Middle Panel
1 pcs
576 x380x 15mm
D-Mouding
1 pcs
576 x 51x 15mm
Down Side Panel (Right)
1 pcs
770 x400x 15mm
Up Side Panel (Left)
1 pcs
1030 x300x 15mm
Middle Panel
1 pcs
576 x 280 x 15mm
Drawer Side R/L
2 pcs
357 x116x 15mm
Back Panel
2 pcs
605 x400x 15mm
Drawer Front & Back
1 pcs
520 x116 x 15mm
Glass Door Panel (Left)
1 pcs
474 x 282 x 15mm
Back Panel
2 pcs
605 x 400 x 15mm
Drawer Head
1 pcs
568 x171x 15mm
Door Panel(Right)
1 pcs
400 x 282 x 15mm
Door Panel (Left)
1 pcs
400 x 282 x 15mm
Shelf Panel
1 pcs
576 x246x 15mm
Drawer Bottom Panel
1 pcs
549 x357x 2.5mm
D-Mouding
1 pcs
576 x 51x 15mm
Top Panel
1 pcs
576 x 280 x 15mm
D-Mouding
1 pcs
576 x 51x 15mm
Up Side Panel (Right)
1 pcs
1030 x300x 15mm
Back Panel
1 pcs
605 x 400 x 15mm
Shelf Panel
1 pcs
576 x235x 15mm
Glass Door Panel (Right)
1 pcs
474 x 282 x 15mm
2

AWood Dowel 8x25mm
9 pcs BCD E F
GH I J K L
M N OPQ
Wood Dowel 8x40mm
4 pcs
CB Screw M3x12mm
4 pcs
CB Screw M3.5x16mm
12 pcs
CB Screw M4x25mm
8 pcs
CB Screw M4x38mm
10 pcs
CSK Cap Wood
M6x50MM
18 pcs
Screw Cap
24 pcs
L Key
1 pcs
Metal Shelf Support
8 pcs
Door Support Spring
8 pcs
Moon Handle
96mm-(PVC)
5 pcs
Minifix 5654+5546
6 Sets 3.5KG Magnet(1 Hole) 4 Sets Nail 5/8
50 pcs Furniture Glue(10G)
1 pcs Drawer Slide 14' 1 set
SCREW DRIVER HAMMER PLASTIC HAMMER
3

4

5

Pre - Assembly
M2
Insert Wood
Dowels (A) in
6,
Using Hammer to
gently tap them in
D-Mouding
D-Mouding
D-Mouding
Middle Support
Leg Panel
A
A
A
A
A
A
A
A
A
Insert Wood
Dowels (B) in
13,8 Using
Hammer to
gently tap them
in
Up Side Panel(R) Up Side Panel(L)
D-Mouding
D-Mouding
D-Mouding
BBBB
Tighten
minifix(M2) to
panel(6,10,12)
M2
M2
M2
M2
M2
M2
J
Insert 2 Shelf
Support(J) on
panel 8
Insert 2 Shelf
Support(J) on
panel 1
Insert 2 Shelf
Support(J) on
panel 13
Insert 2 Shelf
Support(J) on
panel 7
Down Side Panel(L)
Up Side Panel(L) Up Side Panel(R)
Down Side Panel(R)
Q1
D
Down Side Panel(L) Down Side Panel(R)
Place the drawer slide
on to 2 holes area
shown at Left Down
side panel 1.Then
tighten it with 3 screws
(D).
Place the drawer slide
a on to 2 holes area
shown at Right Down
side panel 7.Then
tighten it with 3 screws
(D).
Q1 Q1
6

Pre - Assembly
K
Glass Door Panel(L) Glass Door Panel(R)
Door Panel(L) Door Panel(R)
E
L
Glass Door Panel(L) Glass Door Panel(R)
Door Panel(L) Door Panel(R)
Tighten 2 screws(E)
from Door Panel
(23,24,25,26)into the
handle (L) hole.
Glass Door Panel(L) Glass Door Panel(R)
Door Panel(L) Door Panel(R) BOTTOM
VIEW
Middle Support
Top Panel
Insert door spring
support(K) to both end
of glass door
panel(25,26) and door
panel(23,24).
Fix and tighten metal piece(N1) with screw (C) at
glass door panel (25,26)and Door panel (23,24) as
shown.
Insert magnet (N2) onto panel (2,11)'s non-thru
holes as shown, make sure the magnets, iron side
facing frontward to edging direction.
7

Pre - Assembly
-Place 2 panel 21 on each side of panel 19 as
shown
21 20
21
19
22
19
21 20
21
20
21
21
19
22
19 21 20
21
22
FF
F
F
F
F
F
F
D
D
DD
D
D
FF
L
DRAWER 19
-Then,tighten screw (F) to panel 21 lower thru
holes to fix them onto panel 19
-Next tighten screw (F) to panel 21 upper thru
holes to fix up to the panel 20
(1)
(2)
(3)
(4)
-Filp drawer with bottom side up,place panel22 onto
the drawer and align properly.Then nail the nails
provided with hammer on the border of panel 22 as
shown.The gap between 2 nails is about 100mm.
-After that,place a drawer slide Q2 with the small
white roller facing outward and with other and tip
touching panel 19 onto each bottom side(angle)
edge of panel 21 and panel 21.Then tighten 3
screws (D) on each drawer slide Q2(as Shown).
D
D
-Tighten 2 screw (F) from inner side of panel 19 into
the handle (L) holes.
8

HIG
Assembly Instruction Step1
CKS CAP
WOOD
MX50MM
G
3
CSK
CAP
H
3
ALLEN
KEY
I
1
Fix Panel (2,3,4) onto panel (1) by inserting dowels(A)
onto non-thru at panel (1) use allen key (I) to tighten
screws (G) from the thru-holes of panel (1) and after
that insert minifix cap (H).
9

HIG
Assembly Instruction Step2
CKS CAP
WOOD
MX50MM
G
2
CSK
CAP
H
2
ALLEN
KEY
I
1
Fix Panel (5,6) onto panel (1) by inserting dowels(A)
onto non-thru at panel (1) use allen key (I) to tighten
screws (G) from the thru-holes of panel (1) and after
that insert minifix cap (H).
10

GH
I
M1 I
H
Assembly Instruction Step 3
Fix Panel (6) onto panel(5) by inserting minifix
(M1) into panel (5)'s L-thru holes and using
allen key (I) to tighten it after that insert
minifix cap(H).
CKS CAP
WOOD
MX50MM
G
5
CSK
CAP
H
7
ALLEN
KEY
I
1
MINIFIX
5654
M1
2
Fix Panel (2,3,4,5,6) onto panel (7) by
inserting dowels(A) onto non-thru at
panel (7) use allen key (I) to tighten
screws (G) from the thru-holes of panel
(7) and after that insert minifix cap (H).
11

PART 1
12

HIG
Assembly Instruction Step 4
CKS CAP
WOOD
MX50MM
G
4
CSK
CAP
H
4
ALLEN
KEY
I
1
Fix panel (9,10,11,12) onto panel (8) by inserting dowels
(A) onto non-thru holes at panel (8).
Use Allen key (I) to tighten screw (G) from the thru holes
of panel (8) and after that insert minifix cap (H).
13

M1 I
H
GH
I
CKS CAP
WOOD
MX50MM
G
4
CSK
CAP
H
8
ALLEN
KEY
I
1
MINIFIX
5654
M1
4
Assembly Instruction Step 5
Fix Panel (9,11) onto panel(10,12) by inserting
minifix (M1) into panel (9,11)'s L-thru holes
and using allen key (I) to tighten it after that
insert minifix cap(H).
Fix Panel (9,10,11,12) onto panel (13)
by inserting dowels(A) onto non-thru at
panel (13) use allen key (I) to tighten
screws (G) from the thru-holes of panel
(13) and after that insert minifix cap
(H).
14

PART 2
15

PART 1
PART 2
Assembly Instruction Step 6
Insert glue(P) into side panel (1,7)hole,and
insert Dowel(B) using hammer to gently tap
them in.
FURNITURE
GLUE(10G)
P
1
16

Assembly Instruction Step 7
NAIL 5/8
O
40
At face down position ,Place back panel (14,15,16)onto
the back of the main unit,and align it properly for nailing.
Use hammer to nail the nails one by one on the line drawn
and at center of 4side edges.Gap between 2 nails should
be about 100mm for all.
17

Assembly Instruction Step 8
Put in the drawer by slotting the rollers at each and of
drawer slide (Q2)onto the rail of drawer slide (Q1) fixed at
side panel 1 and 7.Then push the drawer in slowly.Then
take the movable shelf 17 and place it inside the lower
compartment by putting it on top the 4 shelf support.
Take panel (18) and place it inside the top compartment
by putting it on the 4 shelf support as shown.
18

Assembly Instruction Step 9
Fix upper Glass Panel (25,26) by
pushing and slotting the door support
(K) onto each holes at bottom of panel
(9)and top of panel(11)
Fix down door panel (23,24) by
pushing and slotting the door support
(K) onto each holes at bottom of panel
(3) and top panel (2).
19

Completion
In the interest of our environment please dispose of all packaging thoughtfully.
