Upright X27RT Guide

S
E
R
VI
C
E
&
P
A
R
T
S
M
A
NU
A
L
POWERED ACCESS
WORK PLATFORM
X27-33RT

www.upright.com
Europe
TEL: [phone]
FAX: [phone]
Please note:
The Upright X-27-33-40-RT is also sold as the
Snorkel SR Series in some regions.
Therefore any reference to the Snorkel
SR Series also applies to the UpRight X-27-33-40-RT .
UpRight Powered Access HQ
Vigo Centre
Birtley Road
Washington
Tyne & Wear
NE38 9DA
USA
TEL: [phone]
FAX: [phone]

LIMITED WARRANTY
Snorkel warrants each new machine manufactured and sold by it to be free from defects in material and workmanship for a
period of one (1) year from date of delivery to a Customer or for one year after the machine has been placed in first service in a
Dealer rental fleet, whichever comes first. Any part or parts which, upon examination by the Snorkel Service Department, are
found to be defective, will be replaced or repaired, at the sole discretion of Snorkel, through its local Authorized Dealer at no
charge.
Snorkel further warrants the structural components; specifically, the mainframe chassis, turntable, booms and scissor arms,
of each new machine manufactured by it to be free from defects in material and workmanship for an additional period of four
(4) years. Any such part or parts which, upon examination by the Snorkel Service Department, are found to be defective will
be replaced or repaired by Snorkel through its local Authorized Dealer at no charge; however, any labor charges incurred as a
result of such replacement or repair will be the responsibility of the Customer or Dealer.
The Snorkel Service Department must be notified within forty-eight (48) hours of any possible warranty situation during the
applicable warranty period. Personnel performing warranty repair or replacement must obtain specific approval by Snorkel
Service Department prior to performing any warranty repair or replacement.
Customer and Dealer shall not be entitled to the benefits of this warranty and Snorkel shall have no obligations hereunder
unless the “Pre-Delivery and Inspection Report” has been properly completed and returned to the Snorkel Service
Department within ten (10) days after delivery of the Snorkel product to Customer or Dealer’s rental fleet. Snorkel must be
notified, in writing, within ten (10) days, of any machine sold to a Customer from a Dealer’s rental fleet during the warranty
period.
At the direction of the Snorkel Service Department, any component part(s) of Snorkel products to be replaced or repaired
under this warranty program must be returned freight prepaid to the Snorkel Service Department for inspection. All warranty
replacement parts will be shipped freight prepaid (standard ground) from the Snorkel Service Department or from Snorkel’s
Vendor to Dealer or Customer.
REPLACEMENT PARTS WARRANTY
Any replacement or service part made or sold by Snorkel is not subject to the preceding Limited Warranty beyond the
normal warranty period of the machine upon which the part was installed.
THIS WARRANTY EXCLUDES AND SNORKEL DOES NOT WARRANT:
1. Engines, motors, tires and batteries which are manufactured by suppliers to Snorkel, who furnish their own warranty.
Snorkel will, however, to the extent permitted, pass through any such warranty protection to the Customer or Dealer.
2. Any Snorkel product which has been modified or altered outside Snorkel’s factory without Snorkel’s written approval, if
such modification or alteration, in the sole judgment of Snorkel’s Engineering and/or Service Departments, adversely
affects the stability, reliability or service life of the Snorkel product or any component thereof.
3. Any Snorkel product which has been subject to misuse, improper maintenance or accident. “Misuse” includes but is
not limited to operation beyond the factory-rated load capacity and speeds. “Improper maintenance” includes but is not
limited to failure to follow the recommendations contained in the Snorkel Operation, Maintenance, Repair Parts
Manuals. Snorkel is not responsible for normal maintenance, service adjustments and replacements, including but not
limited to hydraulic fluid, filters and lubrication.
4. Normal wear of any Snorkel component part(s). Normal wear of component parts may vary with the type application or
type of environment in which the machine may be used; such as, but not limited to sandblasting applications.
5. Any Snorkel product that has come in direct contact with any chemical or abrasive material.
6. Incidental or consequential expenses, losses, or damages related to any part or equipment failure, including but not
limited to freight cost to transport the machine to a repair facility, downtime of the machine, lost time for workers, lost
orders, lost rental revenue, lost profits or increased cost.
This warranty is expressly in lieu of all other warranties, representations or liabilities of Snorkel, either expressed or implied,
unless otherwise amended in writing by Snorkel’s President, Vice President-Engineering, Vice President-Sales or Vice
President-Marketing.
SNORKEL MAKES NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION OF THIS LIMITED WARRANTY.
SNORKEL MAKES NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
AND DISCLAIMS ALL LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT
LIMITED TO INJURY TO PERSONS OR PROPERTY.
The Customer shall make all warranty claims through its local Authorized Dealer and should contact the Dealer from whom
the Snorkel product was purchased for warranty service. Or, if unable to contact the Dealer, contact the Snorkel Service
Department for further assistance.
Effective July 1995
© Snorkel – all rights reserved Printed in New Zealand

SR3370 & SR2770 (CE) – 12864B page 1
Table of Contents
General Specifications
General Specifications SR3370 .................3
General Specifications SR2770 .................4
Engine Data.................................5
Engine Oil Charts ............................5
Table of Contents
Maintenance Information
About this Manual: ...........................7
Manual Organization..........................7
General Specifications.......................7
Maintenance ..............................7
Auto level system...........................7
Repair parts and drawings....................7
Hydraulics ................................7
Electrical .................................7
Options...................................7
Parts index - Page locator ....................7
Maintenance and Schematics...................7
Maintenance information .....................7
Maintenance schedules .......................8
Daily Maintenance ...........................9
Pre-operational inspection....................9
Hydraulic Hose Age ..........................9
90 Day or 150 Hour Maintenance
(Trained Service Technician) ................10
Yearly or 500 Hour Maintenance
(Trained Service Technician) ................10
Lubricants .................................11
Pressure gun application....................11
Lubrication ...............................11
King pins (Item 1)..........................11
Tie rods (Item 2) ..........................11
Steer cylinder end (Item 3) ..................11
Wheel bearings
Drive wheels (Item 4) .....................11
Engines (Item 5) ..........................12
Hydraulic oil reservoir (Item 6) ...............12
Return filter (Item 7)........................12
Door hinges and latches (Item 8) .............12
Slide pads (Item 9).........................12
Scissor arm bearings (Item 10) ...............12
Batteries (Item 11) ..........................12
Preventive inspection maintenance
90 day or 150 hour checklist .................14
Torque chart ...............................16
Servicing STC Fittings .......................17
Disconnection ............................17
Inspection................................17
Installation and connection ..................17
Seal replacement instructions ................18
Auto Level System Troubleshooting.............19
Test procedures...........................19
Using the EZcal ...........................19
EZcal auto level calibration procedure .........20
To order service or repair parts ................22
ANSI and OSHA compliance.................22
Manuals ................................22
Section 1. - Repair Parts
Chassis assembly SR3370 ...................1-2
Chassis assembly drawing SR3370 ............1-3
Chassis assembly drawing SR2770 ............1-4
Chassis assembly SR2770 ...................1-5
Steer axle assembly ........................1-6
Steer axle assembly drawing .................1-7
Drop axle assembly drawing ..................1-8
Drop axle assembly .........................1-9
Tray assembly, hydraulic and electrical ........1-10
Tray assembly, hydraulic and electrical
drawing ................................1-11
Engine side tray assembly drawing............1-12
Engine side tray assembly ..................1-13
Cable operated emergency bleed down SR3370 .1-14
Cable operated emergency bleed down
drawing SR3370 .........................1-15
Cable operated emergency bleed down
drawing SR2770 .........................1-16
Cable operated emergency bleed down SR2770 .1-17
Scissor arm assembly SR3370 ...............1-18
Scissor arm assembly drawing SR3370 ........1-19
Scissor arm assembly drawing SR2770 ........1-20
Scissor arm assembly SR2770 ...............1-21
Outrigger Installation .......................1-22
Outrigger Installation - drawing ...............1-23
Platform assembly drawing ..................1-24
Platform assembly .........................1-25
Platform assembly .........................1-26
Fuel tank assembly, diesel fuel ...............1-27
Engine assembly, Kubota D905 ..............1-28
Engine assembly, Kubota D905 drawing .......1-29
Upper control box mounting assembly .........1-31
Placards and decals installation ..............1-32
Placards and decals drawing ................1-33

page 2SR3370 & SR2770 (CE) – 12864B
Table of Contents
Section 2. - Hydraulics
Hydraulic assembly .........................2-2
4 wheel drive hydraulic schematic drawing.......2-3
Hose Part Numbers and Colour Codes..........2-5
Hose part numbers and colour codes ...........2-5
Manifold assembly, main .....................2-6
Manifold assembly, main drawing ..............2-7
Manifold assembly, 4 wheel drive ..............2-8
Manifold assembly, stabilisers.................2-9
Hydraulic oil tank assembly..................2-10
Hydraulic oil tank assembly drawing ...........2-11
Steer axle cylinder .........................2-12
Axle cylinder..............................2-13
Main lift cylinder assembly ..................2-14
Section 3. - Electrical
Electrical Schematic drawing - Auto Level .......3-3
Colour coded wiring circuit ...................3-5
Ground control box assembly drawing ..........3-6
Ground control box assembly .................3-7
Ground box ...............................3-8
Ground box drawing - sheet 1 .................3-9
Ground box drawing - sheet 2 ................3-10
Platform control box assembly ...............3-12
Platform Control Box Assembly drawing
Sheet 1 ................................3-13
Platform Control Box Assembly drawing
Sheet 2 ................................3-14
Section 4. - Options
AC outlet at platform, 230 volt .................4-2
AC outlet at platform 230V drawing.............4-3
Flashing light installation .....................4-5
Fuel gauge option ..........................4-6

General Specifications
■General Specifications SR3370
SR3370 & SR2770 (CE) – 12864B page 3
SPECIFICATIONS SR3370
Nominal working height 12.12m 39' 2”
Roll out deck size 1200mm 48”
Drive speed (below 2.4m) 0 to 4.5kph 0 to 2.8mph
Drive speed (above 2.4m) 0 to 0.35kph 0 to 0.22mph
Safe working load - Main deck
(Roll out deck not extended)
450kg 990lbs
Safe working load - Main deck
Roll out deck extended - Roll out deck
330kg
120kg
726lbs
264lbs
Platform size 2.73 x 1.65m 8’ 11” x 5’ 5”
Stowed height 2.7m 8' 10"
Stowed height (hand rails folded down) 2.0m 6' 6"
Overall length 3.36m 11’ 0”
Overall width 1.77m 5' 9"
Gradeability 35%
Lift time 50 seconds
Turning radius (inner) 2.38m 7’ 8”
Turning radius (outer) 4.75m 15’ 6”
Maximum wind speed (12.5m/s) 45km/h 28mph
Insulation rating Nil
Tyres - Poly filled loader lug 27" x 10.5" x 15"
Overall weight 3620kg 7964lbs
Ground clearance 350mm 13.8”
Maximum sound level at platform 86db

■General Specifications SR2770
page 4SR3370 & SR2770 (CE) – 12864B
General Specifications
SPECIFICATIONS SR2770
Nominal working height 10.28m 33' 9”
Roll out deck size 1200mm 48”
Drive speed (below 2.4m) 0 to 4.5kph 0 to 2.8mph
Drive speed (above 2.4m) 0 to 0.9kph 0 to 0.6mph
Safe working load - Main deck
(Roll out deck not extended)
580kg 1280lbs
Safe working load - Main deck
Roll out deck extended - Roll out deck
460kg
120kg
1015lbs
265lbs
Platform size 2.73 x 1.65m 8’ 11” x 5’ 5”
Stowed height 2.5m 8' 2"
Stowed height (hand rails folded down) 1.7m 5' 8"
Overall length 3.36m 11’ 0”
Overall width 1.7m 5' 8"
Gradeability 35%
Lift time 26 seconds
Turning radius (inner) 2.83m 9’ 3”
Turning radius (outer) 4.6m 15’ 1”
Maximum wind speed (12.5m/s) 45km/h 28mph
Insulation rating Nil
Tyres - Poly filled loader lug 27" x 10.5" x 15"
Overall weight 2800kg 6272lbs
Ground clearance 350mm 13.8”
Maximum sound level at platform 86db

SR3370 & SR2770 (CE) – 12864B page 5
General Specifications
■Engine Data
ENGINE MAKE KUBOTA(gasoline) KUBOTA (LPG) KUBOTA (diesel)
Model WG750-G D905-B
Fuel gasoline LPG diesel no. 2-D
Fuel Grade Unleaded 85 octane
(motor method)
Do not use gasoline
blended with methyl
alcohol.
HD5
Gas Processors
Association Standard
2140
Category: special
dual propane
ASTM no. 2-D
ASTM D975
centane no. > 44
(For operating temp. below 32°F (0°C)
use "winterized" no. 2-D.)
Coolant 50% water + 50% ethylene glycol
Operating Temperature 180°F - 205°F(82°C - 96°C)
Oil Capacity 3.5 qt USA
(3.25 liters)
5.2 qt USA
(5.1 liters)
Oil Grade API: SF, SF/CD API: C/CD/CE
Oil Weight see chart below
Running Time
(one tank of fuel)
A full tank of gasoline or diesel, will last an entire eight hour shift, under normal working
conditions. It normally takes two tanks of LPG per eight hour shift.
KUBOTA D905-B
77
32
20
0
°F °C
+25
0
-7
-17
SAE 10W/30 or 10W40
SAE 30SAE 20SAE 10W
Single Viscosity Multi Viscosity
■Engine Oil Charts
KUBOTA WG750-G GASOLINE ENGINE
77
32
20
0
°F °C
+25
0
-7
-17
SAE 10W/30
SAE 30SAE 20SAE 10W
Single Viscosity Multi Viscosity
