urmet domus 1098 User manual

DS1098-028A
Mod.
1098
NVR H.265 WITH HDMI
NVR 4K H.265 SERIES PRO
8 Channels Ref. 1098/318P
8 Channels Ref. 1098/318
16 Channels Ref. 1098/316
16 Channels with PoE Ref. 1098/316P
32 Channels Ref. 1098/332
USER MANUAL

DS1098-028A2
TABLE OF CONTENTS
1General information ..................................................................................................................................4
1.1 Product Description ...................................................................................................................5
General Features ..........................................................................................................................................5
1.2 Opening the package ................................................................................................................6
Contents of the package ...............................................................................................................................6
1.3 Warnings ...................................................................................................................................7
Power............................................................................................................................................................7
Safety precautions ........................................................................................................................................7
Installation precautions .................................................................................................................................7
Cleaning the device ......................................................................................................................................7
Hard disk.......................................................................................................................................................7
Image recording............................................................................................................................................8
Privacy and Copyright...................................................................................................................................8
Description of the parts .....................................................................................................................................9
1.4 Front panel ................................................................................................................................9
Front panel NVR Ref. 1098/318 ....................................................................................................................9
Front panel NVR Ref. 1098/316 and Ref. 1098/316P ...................................................................................9
Front panel NVR Ref. 1098/318P..................................................................................................................9
Front panel NVR Ref. 1098/332 ....................................................................................................................9
1.5 Rear panel .............................................................................................................................. 10
Rear panel NVR Ref. 1098/318 and Ref. 1098/316 ....................................................................................10
Rear Panel NVR Ref.1098/318P.................................................................................................................10
Rear panel NVR Ref. 1098/316P ................................................................................................................10
Rear panel NVR Ref. 1098/332...................................................................................................................11
Sensor/alarm functions ...............................................................................................................................11
1.6 Remote control ....................................................................................................................... 11
1.7 Operation with mouse............................................................................................................. 12
1.8 IP camera and monitor connection......................................................................................... 12
1.9 Power connection ................................................................................................................... 12
2OSD NVR menu settings........................................................................................................................ 13
2.1 First NVR login ....................................................................................................................... 13
2.2 Live interface and pop-up menu............................................................................................. 14
Taskbar.......................................................................................................................................................15
Camera Quick Toolbar................................................................................................................................15
Shutdown / Reboot / Lock Screen Menu.....................................................................................................16
PTZ control .................................................................................................................................................17
Fisheye camera management.....................................................................................................................17
2.2.5.1 Installation type........................................................................................................................................17
2.2.5.2 Viewing ....................................................................................................................................................18
2.2.5.3 Installation on the ceiling..........................................................................................................................19
2.2.5.4 Installation on a horizontal surface ...........................................................................................................23
2.2.5.5 Wall-mounted...........................................................................................................................................27
2.2.5.6 Installation on slanted surface..................................................................................................................31
Cruise Set ...................................................................................................................................................34
Tag Setup ...................................................................................................................................................35
To search for a Tag Record event...............................................................................................................36
2.3 Main Menu guide .................................................................................................................... 37
2.4 Main Menu .............................................................................................................................. 41
2.5 Channel .................................................................................................................................. 41
Channel ......................................................................................................................................................41
2.5.1.1 IP Channels .............................................................................................................................................42
2.5.1.2 Protocol Manage......................................................................................................................................44
2.5.1.3 POE Power ..............................................................................................................................................45
Live .............................................................................................................................................................46
Image Control .............................................................................................................................................47
PTZ.............................................................................................................................................................48
2.5.4.1 PTZ..........................................................................................................................................................48
Video Cover Settings (Privacy Zone) ..........................................................................................................49
Motion.........................................................................................................................................................49
PIR..............................................................................................................................................................50
Deterrence ..................................................................................................................................................51
Intelligent ....................................................................................................................................................51
2.5.9.1 PID (Perimeter Intrusion Detection)..........................................................................................................52
2.5.9.2 LCD (Line Crossing Detection).................................................................................................................53
2.5.9.3 SOD (Stationary Object Detection)...........................................................................................................55
2.5.9.4 PD (Pedestrian Detection)........................................................................................................................57
2.5.9.5 FD (Face Detection).................................................................................................................................58
2.5.9.6 CC (Cross-Counting)................................................................................................................................60
ENGLISH

DS1098-028A3
2.5.9.7Sound Detection ......................................................................................................................................61
2.5.9.8 Occlusion Detection .................................................................................................................................62
2.5.9.9 Schedule..................................................................................................................................................63
2.5.9.10 Intelligent Analysis Log ............................................................................................................................63
2.6 Record Settings ...................................................................................................................... 64
Encode........................................................................................................................................................64
2.6.1.1 Mainstream / Substream / Mobile Stream ................................................................................................64
Record ........................................................................................................................................................65
2.6.2.1 Record .....................................................................................................................................................65
2.6.2.2 Record Schedule .....................................................................................................................................66
Capture .......................................................................................................................................................67
2.6.3.1 Capture....................................................................................................................................................67
2.6.3.2 Capture Schedule ....................................................................................................................................67
2.7 Alarm Configuration................................................................................................................ 68
Motion Alarm Settings.................................................................................................................................68
PIR Notification ...........................................................................................................................................69
IO Alarm Settings........................................................................................................................................71
Intelligent Analysis Notification....................................................................................................................72
PTZ Linkage ...............................................................................................................................................73
Exception ....................................................................................................................................................74
Alarm Schedule...........................................................................................................................................74
2.8 AI ............................................................................................................................................ 75
Setup ..........................................................................................................................................................75
2.8.1.1 Face Detection.........................................................................................................................................75
2.8.1.2 Human & Vehicle Detection .....................................................................................................................76
2.8.1.3 Schedule..................................................................................................................................................78
Recognition .................................................................................................................................................78
2.8.2.1 Model Configuration.................................................................................................................................78
2.8.2.2 Database Management............................................................................................................................79
Alarm ..........................................................................................................................................................83
2.8.3.1 Face Recognition .....................................................................................................................................83
2.8.3.2 Human & Vehicle Detection .....................................................................................................................85
Statistics .....................................................................................................................................................86
2.8.4.1 Face Recognition .....................................................................................................................................86
2.8.4.2 Human & Vehicle Detection .....................................................................................................................87
2.9 Network Configuration ............................................................................................................ 88
General Settings .........................................................................................................................................88
2.9.1.1 General Settings ......................................................................................................................................89
2.9.1.2 PPPoE.....................................................................................................................................................90
2.9.1.3 SNMP ......................................................................................................................................................90
2.9.1.4 Port Configuration ....................................................................................................................................91
DDNS Set ...................................................................................................................................................92
Email...........................................................................................................................................................93
2.9.3.1 Email Set .................................................................................................................................................93
2.9.3.2 Email Schedule........................................................................................................................................94
FTP.............................................................................................................................................................95
2.9.4.1 FTP..........................................................................................................................................................95
2.9.4.2 FTP Schedule ..........................................................................................................................................96
IP Filter .......................................................................................................................................................97
2.9.5.1 IP Filter ....................................................................................................................................................97
2.10 Device..................................................................................................................................... 99
Disk Manage...............................................................................................................................................99
2.10.1.1 Disk Manage............................................................................................................................................99
2.10.1.2 S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) information.......................................101
Cloud ........................................................................................................................................................102
AF Controls FOR Auto-Focus cameras.....................................................................................................102
2.11 System.................................................................................................................................. 103
General.....................................................................................................................................................103
2.11.1.1 General settings.....................................................................................................................................103
2.11.1.2 Date and Time .......................................................................................................................................104
2.11.1.3 Output Configuration..............................................................................................................................105
Multi-user Settings ....................................................................................................................................107
Maintenance Settings................................................................................................................................109
2.11.3.1 Log ........................................................................................................................................................109
2.11.3.2 Load Default ..........................................................................................................................................110
2.11.3.3 Upgrade .................................................................................................................................................110
2.11.3.4 Parameter Management ........................................................................................................................111
2.11.3.5 Auto Reboot...........................................................................................................................................111
IP Camera Maintain ..................................................................................................................................112
2.11.4.1 Upgrade.................................................................................................................................................112
2.11.4.2 Load Default ..........................................................................................................................................112
2.11.4.3 Reboot IPC ............................................................................................................................................113
2.11.4.4 Parameter Management ........................................................................................................................113
Information................................................................................................................................................114
2.11.5.1 Information.............................................................................................................................................114
2.11.5.2 Channel Information...............................................................................................................................114

DS1098-028A4
2.11.5.3 Record Info ............................................................................................................................................115
2.11.5.4 Network State ........................................................................................................................................115
2.12 Playback & Backup............................................................................................................... 116
Using the Search function .........................................................................................................................116
Search & Play Video in General................................................................................................................117
2.12.2.1 Video Clip Backup..................................................................................................................................118
Event Search, Playback & Backup............................................................................................................119
2.12.3.1 Event Playback Control..........................................................................................................................120
Sub-periods Playback ...............................................................................................................................121
Smart ........................................................................................................................................................122
Fisheye camera management for Playback ..............................................................................................123
Tag ...........................................................................................................................................................123
External File ..............................................................................................................................................123
Picture Search & View ..............................................................................................................................124
2.12.9.1 Picture Preview Control..........................................................................................................................125
Slice..........................................................................................................................................................126
AI ..............................................................................................................................................................126
3Video Player to view backup videos on PC ....................................................................................... 129
3.1 Video Player Control............................................................................................................. 129
4Remote access via Web Client............................................................................................................ 131
4.1 Basic system environment requirements ............................................................................. 131
4.2 Download and install web plug-ins ....................................................................................... 131
4.3 Web Client Manager............................................................................................................. 133
4.4 Access to the NVR web interface via IP address, URL or Urmet DDNS account................ 133
4.5 Live interface ........................................................................................................................ 134
Fisheye camera management...................................................................................................................137
4.6 Playback ............................................................................................................................... 137
Playback control buttons ...........................................................................................................................138
Fisheye camera management for Playback ..............................................................................................139
4.7 Remote Settings ................................................................................................................... 140
Display Configuration................................................................................................................................140
Record ......................................................................................................................................................146
AI ..............................................................................................................................................................147
Alarm Set ..................................................................................................................................................151
Network Parameters .................................................................................................................................153
Device.......................................................................................................................................................157
System......................................................................................................................................................158
4.8 Local Setting......................................................................................................................... 160
4.9 Logout................................................................................................................................... 160
5Mobile device software ........................................................................................................................ 161
5.1 Smartphone Devices ............................................................................................................ 161
Urmet IUVS Plus Software Mobile ............................................................................................................161
5.1.1.1 Live........................................................................................................................................................162
5.1.1.2 Playback ................................................................................................................................................165
5.1.1.3 Record ...................................................................................................................................................166
5.1.1.4 Image.....................................................................................................................................................166
5.1.1.5 Remote Settings ....................................................................................................................................167
5.1.1.6 Alarm .....................................................................................................................................................167
5.1.1.7 Device....................................................................................................................................................168
5.1.1.8 Help .......................................................................................................................................................169
5.2 P2P function ......................................................................................................................... 170
6NVR Specifications Ref. 1098/318-1098/316-1098/332 (Pal format)................................................. 172
7NVR Specifications Ref. 1098/318P-1098/316P (Pal format) ............................................................ 173
8Maximum recording time with 2000GB Hard Disk ............................................................................ 175
8.1 Ref. 1098/318 - 1098/316 - 1098/318P - 1098/316P - 1098/332......................................... 175
9Recording alarm setting ...................................................................................................................... 181
10 Troubleshooting ................................................................................................................................... 181
11 Maintenance.......................................................................................................................................... 182
Appendix: ActiveX installation..................................................................................................................... 183
1 GENERAL INFORMATION
Dear Customer,
Thank you for purchasing this product.

DS1098-028A5
This quick start guide was written to help you set up the NVR Series PRO URMET S.p.A, Ref. 1098/318 - Ref. 1098/316 -
Ref. 1098/318P -Ref. 1098/316P - Ref. 1098/332 models rapidly and easily.
Carefully read this manual which contains information for correct, safe use.
Keep this manual at hand so that you can refer to it when needed.
1.1 PRODUCT DESCRIPTION
This Urmet S.p.A. product is a digital video recorder for recording images from multiple cameras on an internal hard disk.
GENERAL FEATURES
•Three available modes (simultaneous recording, playback and transmission on network)
•H. 265 and H.264 (retro-compatible) video compression with 8MP(4K) max. resolution
•Windows graphic interface, integrated real-time operating system
•Recording with 8MP(4K), 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1MP(720P) resolution
•Dual Stream recording (Mainstream and Mainstream + Substream)
•Fish-Eye IP Camera management (in LIVE and Playback)
Customized password and robust password definition to be set mandatory at the first
access, pattern definition (graphic sign) menu access, possibility to select the language to be
set on the device.
•New programming algorithms for Intelligent Video Analysis
•Video Intelligence Algorithm for Face Recognition (active function disabling other
intelligent video analysis functions and disabling the spot video output).
•Supports PIR, Deterrence, sound detection and camera dimming functions if present on the
IP camera.
•Multiple or single recording
•VGA/ HDMI video output
•User-friendly menu
•Multiple operating modes (preview, recording, playback, backup, monitoring via network and via
mobile phone)
•Mainstream, Substream and Mobile Stream (for IP channels) transmission on network
•Remote control (via browser, via mobile and via Urmet UVS Client Software)
•Remote control via Urmet iUVS mobile software for iOS and Android platforms
•Configuration using Urmet DDNS ID via Internet Explorer, Mobile and Client Software
•P2P function available for Urmet UVS Client and Mobile Urmet iUVS
•RTSP function
•ADPCM audio compression
•Supports zoom in/out and loop function
•Alarm management
•For PoE models only: SWITCH Auto/Manual mode can be set independently
for single PoE port.
•For PoE models only: possibility to activate EPoE mode independently for each PoE port
(EPoE = possibility to manage PoE-connected cameras over extended distances at reduced bitrate).
•Addition of a pop-up window or event bar on LIVE Preview (with playback that can be called up from each
event preview).
•Multiple alarm recording
•Picture memory function
•E-mail alarm notification
•Alarm actions and notifications can be called up directly from the event programming menus.
•Added time programming for the following event drives: Buzzer, Alarm Out, loading
of images/video on FTP and Server Cloud, push notifications sent to the Android/iOS App.
•IP FILTER function: possibly of setting whitelist and blacklist for single or group IP addresses (network
segments).
•PTZ connection: Association of one or more preset points on an alarm or motion detection event on Speed Dome.
•Automatic maintenance mode
•PTZ control via network and via RS-485
•AF Control for Auto Focus IP Cameras
•USB 2.0 port on rear panel for backup, update and operation via mouse
•Backup to USB 2.0 from front panel (USB flash drive or hard disk)
•Group creation on HDD
•Loading and saving NVR configurations by means of USB flash drive
•Restore Default Password
•Remote control
•Multilingual OSD
•Mobile software for the following platforms: iOS (iPhone and iPad), Android (Smartphone and Tablet)
•Multi-Channel synchronous playback.
•Sub-Period Playback: see different periods of time of the channel selected on each call of the grid
•Instant Playback on LIVE: launch the playback of a channel in LIVE preview of the channel itself.

DS1098-028A6
•SPOT Monitor output to VGA video output (option enabled, disabling intelligent video analysis functions, not available
for Ref. 1098/318P).
•Local Monitor Video Output settings from Web Interface.
•Playback of recordings based on several dedicated modes: Events, Subperiods, SMART Search, Files
"labelled", External Device Files (ex: files on USB flash drive), display on annual/monthly macro scale, Images only,
Face Search (with settable threshold of similarity) and possibility to trace on map the path of faces during playback (face
tracking function).
•Automatically recover Downloads in case of network blackout
The main features are summarised in the following table:
1.2 OPENING THE PACKAGE
Check that the packing and the contents are not visibly damaged. Contact the retailer immediately if parts are either missing
or damaged. Do not attempt to use the device in this case. Send the product back in its original packing if it is damaged.
CONTENTS OF THE PACKAGE
•NVR
•Power supply unit
INPUT ⇒100-240 Vac 50/60Hz 1.5 A max
OUTPUT ⇒12Vdc 5A for Ref. 1098/318 Ref. 1098/316 Ref. 1098/332
⇒48Vdc 2A for Ref. 1098/318P and Ref. 1098/316P
•Shuko plug
•Italian plug
•One mouse
•One IR remote control (2 AAA batteries included)
•LAN CAT.5 crossover network cable
•Quick Guide
•MINI CD containing Urmet viewing network
øIMPORTANT NOTE:
Accessories may be changed without prior notice.
Function Description
Live
Double video output with monitor, VGA virtual output port or HDMI Output; Support
URMET UVS Client Software and MP live surveillance and also support zoom in/out,
auto sequence and PIP display.
Record
Video compression standard: H.265; adjustable recording quality, resolution and
frame rate; multiple recording modes: continuous, programmed, manual, on alarm (if
available), motion detection and remote activation.
Capture Images Captures images or snapshots of individual channels automatically or manually.
Recording
storage Supports high-capacity SATA hard disk and saves recording in real time on hard disk.
Play Supports playback of files recorded on the NVR with single and multiple channel
search.
Backup Supports NVR backup to USB flash drive, removable disk, recorder and network.
Alarm setting Supports alarm management from hard disk, from input video signal and from external
alarm inputs (on available models).
Operation via
network Supports remote monitoring by authorized users to guarantee system safety.
Operation with
mouse
Supports use of mouse for quick menu navigation.
PTZ control Supports PTZ camera operations via RS-485.

DS1098-028A7
1.3 WARNINGS
POWER
Check mains rating before plugging the power unit in.
Do not pull the cord to unplug the device.
Switch the device off before unplugging power unit. This operation must not be performed when the NVR Boost
3.0 Series is recording or playing or when the configuration menu is open. Stop recordings and playback in progress
before disconnecting power from the device to prevent damaging the hard disk beyond repair.
SAFETY PRECAUTIONS
Keep the device away from rain and humidity to prevent the risk of fire and electrocution. Do not introduce material
(solid or liquid) inside. If this should accidentally occur, disconnect the device from the mains and have it inspected
by qualified personnel.
Never open the device. In all cases, contact a qualified personnel or authorized service centre for repairs.
Keep the device away from children to prevent accidental damage.
Do not touch the device with wet hands to prevent electrical shock or mechanical damage.
Do not use the device if it should fall or the external casing is damaged. Risk of electrocution if the device is used
in such conditions. Contact the retailer or authorized installer.
INSTALLATION PRECAUTIONS
To prevent overheating the device, arrange it in a position allowing the flow of air through the slots in the casing.
Ensure at least 5 cm of free space when installing inside a rack. For the same reason, do not install sources of
heat, such as radiators or hot air ducts. Keep away from direct sunlight. Do not install in areas subject to excessive
dust, mechanical vibrations or shocks.
Do not arrange this device on an unstable surface, such as a tottering or slanted table. The device could fall causing
injury or mechanical failures.
Do not install the device in a place where it could be exposed to humidity or water. Do not direct a jet of water onto
the device: risk of fire, electrocution or mechanical failure.
Stop using the device if water or other material should penetrate inside: risk of fire and electrocution. Contact the
retailer or authorized installer.
Do not place heavy or heat generating objects on top of the device: this could damage the casing and/or increase
internal temperature causing faults.
Do not cover the device with a cloth while it is running to prevent deforming the external casing and overheating
the internal parts: risk of fire, electrocution and mechanical failure.
Keep magnets and magnetised objects away from the device to prevent faults.
Do not use the device in presence of smoke, vapour, humidity, dust or intense vibrations.
Wait for a while before operating a device immediately after transporting it from a cold place to a warm place and
vice versa. Wait on average for three hours: this will allow the device to adapt to the new ambient (temperature,
humidity, etc.).
CLEANING THE DEVICE
Rub delicately with a dry cloth to remove dust and dirt.
Dip the cloth in neutral detergent if dirt cannot be removed with a dry cloth alone.
Do not use volatile liquids (such a petrol, alcohol, solvents, etc.) or chemically treated clothes to clean the device
to prevent deformation, deterioration or scratches to the paint finish.
HARD DISK
The hard disk installed in this device is sensitive to shocks, differences in temperature and vibrations. Failure to
respect these precautions can compromise correct operation of the device and cause loss of data stored on the
hard disk.
If repairs are required, it is advisable to backup all important data before taking the device to the service centre.
Urmet S.p.A. is not liable for loss of stored data.
The addition of a hard disk must be performed by qualified technical personnel or by contacting the technical
assistance service.

DS1098-028A8
IMAGE RECORDING
This device was designed to record images, not as a burglar alarm. Please note that URMET S.p.A. is not liable
for loss of stored data consequent to loss or damage caused by incorrect observation installation, use, improper
use or malfunctioning of the device.
Test recording before using the device to make sure that is working correctly. Please note that Urmet S.p.A. is not
liable for loss of stored data consequent to loss or damage caused by incorrect installation, use, improper use or
malfunctioning of the device.
This device contains precision electronic components. Protect the device from shocks to ensure correct recording
of images.
PRIVACY AND COPYRIGHT
The digital video recorder Series PRO Ref. 1098/318 - Ref. 1098/318P - Ref. 1098/316 - Ref. 1098/316P - Ref.
1098/332 is a device for CCTV systems. Recording of images is subject to the laws in force in your country.
Recording of images protected by copyright is forbidden.
Product users shall be responsible for checking and respecting all local rules and regulations concerning monitoring
and recording video signals. The manufacturer SHALL NOT BE LIABLE for use of this product not in compliance
with the laws in force. For more information see the website http://www.garanteprivacy.it

DS1098-028A9
DESCRIPTION OF THE PARTS
1.4 FRONT PANEL
NVR stands for Network Video Recorder Equipment.
FRONT PANEL NVR REF. 1098/318
FRONT PANEL NVR REF. 1098/316 AND REF. 1098/316P
FRONT PANEL NVR REF. 1098/318P
FRONT PANEL NVR REF. 1098/332
1
3
2
4
1
3
2
4
1
3
4
2
4
1
3

DS1098-028A10
Number Writing or
indicator Symbol Function and description
1 Power indicator PWR The green LED on means that the NVR is powered correctly.
2 IR receiver This receives the IR signal from the remote control.
3 Hard disk
indicator HDD
The red LED blinking means that the user is reading or writing on
the hard disk. The red LED on fixed means that the hard disk is not
working correctly, not formatted or does not contain recorded files.
4 USB USB port
1.5 REAR PANEL
REAR PANEL NVR REF. 1098/318 AND REF. 1098/316
REAR PANEL NVR REF.1098/318P
REAR PANEL NVR REF. 1098/316P
8
1
11
2
3
4
6
10
5
7
9
8
1
11
2
3
4
6
10
5
9
7
12
1
2
3
4
5
6
7
9
8
10
12
11

DS1098-028A11
REAR PANEL NVR REF. 1098/332
SENSOR/ALARM FUNCTIONS
Alarm input: Connect signal [-] of the sensor to pin G (GND) and the signal [+] to the input of channel 1...16 as
alarm device.
Alarm output: Connect to the two ports marked with “ALARM”
1.6 REMOTE CONTROL
Number Physical port Connection method
1 Power switch Power on and off
2 Power connector Power connector
3 Sensor/Alarm Alarm or for alarm device connector
4
USB 2.0 port
USB device connector, e.g. USB mouse
5
USB 3.0 port
USB 3.0 device connector, for backups and firmware upgrades
6 HDMI port High-definition HDMI port
7
VGA port
VGA monitor connector, e.g. PC monitor
8
Audio input
Audio signal input, RCA interface
9
Audio output
Audio signal output, RCA interface
10 WAN port Router network input interface/IP camera connection
11 eSATA port eSATA port for backup
12 LAN PoE ports LAN interface, supports POE and can therefore power the camera
N.
Button name
Button function
1
1-8
Channel 1-8 selection; numeric button
2
9, 0
Number pad: Pressing Button 9 or 0 has no effect.
3
ALL
Multiple viewing mode
4
Menu
Open/close main menu
5
MUTE
Mute mode on/off
6
SUBMENU
Enter the submenu
7
▲
Arrow up, adjust volume
8
SEL
Select/Edit button; confirm selected operation
9 ◄/
Left/right arrow, decreases/increases the value of the
control bar parameter
10
▼
Arrow down, adjust volume
11
Rewind button
12
Forward button
13
Open record search menu; playback button
14
●
Record button
15
■
Interrupt manual recording; interrupt playback
16
Pause/sequence button
8
1
11
2
3
4
6
10
5
7
9

DS1098-028A12
1.7 OPERATION WITH MOUSE
The mouse can be used to operate the system in addition to the buttons on the front panel and the remote control.
TYPE
Function
Left click
In locked menu mode, open the pop-up menu and click on any submenu to open the
login window; in unlocked menu mode, open the pop-up menu and left-click to open any
submenu directly.
After having opened the main menu, left-click to open any submenu; in [Detailed file]
mode, left-click to play the recording file.
Change the check box state and the motion detection area.
Click on the combo box to open the drop-down menu; left-click to stop timed view when
active.
Left-click to adjust the colour control bar and the volume control bar.
Click on the combo box to access the drop-down menu.
Left-click to select the values in the specific boxes. This activates the drop-down menu
for support to enter Chinese characters, special symbols, numbers and letters to be used
instead of [Enter- ] or [Backspace
]
Right click
In live mode, right-click to view the pop-up menu.
In main menu or submenu mode, right-click to close the current menu.
Double left-click In live or playback mode, double-click to display the image in full screen mode.
Move the mouse
This selects the menu item
Drag the mouse In motion detection mode, drag the mouse to select the motion detection area; in [Color
set] mode, drag the mouse to adjust the colour and volume bar.
1.8 IP CAMERA AND MONITOR CONNECTION
Connect the IP cameras to the NVR using the network connections and connect the VGA port and/or the HDMI output port
to the monitor (see paragraph 1.5 Rear panel).
1.9 POWER CONNECTION
Use the power supply unit provided with the NVR only.
After switching on, check that the video output connections are correct and that the audio device is connected via the RCA
cable.

DS1098-028A13
2 OSD NVR MENU SETTINGS
After having plugged in the NVR, the system will run the initialisation procedures during which the following image will
appear:
At the end of the boot-up, the NVR will switch to Live view.
2.1 FIRST NVR LOGIN
For the first time when you run the NVR, you must be required to set your own password immediately in order to protect
your privacy. Please be sure to record your username and password and save them in a secure place.
•Language: Select an OSD language
•Device ID: Input the device ID in the brackets. Default ID: 000000.
•New Admin Name: Enter the name of your administrator.
•Password Strength: This shows how safe the edited password is.
•New Admin Password: Enter your password. The password can be a combination of 8 characters.
•Confirm Password: Enter your own password again.
•Pattern: If you enable this function and store and confirm a drawn pattern, each time you
draw a pattern in order to login into HVR system.
Click on Apply to confirm your settings and goes to the login interface. Enter your user name and password to Login the
NVR system.
NOTE: If you forget your password and your email is turned off, you will not be able to access the system; contact your
dealer to reset your password.

DS1098-028A14
2.2 LIVE INTERFACE AND POP-UP MENU
Camera title
To display the camera title:
IP: This indicates that the camera connected is an IP camera
Status icons
This indicates that the NVR is currently recording.
This icon appears when the camera has detected motion.
PIR This icon appears when the camera has detected PIR event.
S This icon appears when the camera has detected intelligent video analysis.
The icon indicates that the external I/O alarm device is triggered.
This icon indicates that the hard disk (HDD) is in error to work
This icon indicates the hard disk (HDD) is not formatted.
This icon indicates the hard disk (HDD) is full.
This icon indicates the hard disk (HDD) is read-only.
Preview Playback events: This displays a pop-up window or event bar on the LIVE Preview (with playback which can be
called from each event preview, video intelligence and alarm, detected by NVR).
Important: for the previous generation IP cameras with H264 CODEC (example models: 1093/139M2, 1093/141M2 ...) and
for Wi-Fi cameras (example models: 1099/209, 1099/214, 1099/216 ...) the display is not guaranteed in the Event Preview
sidebar of some NVR models (example: 1098/318P).
VIDEO LOSS: The IP camera is disconnected.
Click to open Quick Add menu to add the IP camera.
Click to edit the current IP camera.
Task Menu

DS1098-028A15
TASKBAR
Click to open the Main Menu.
Click to pop up the shutdown options pop-up box.
Click to select different layout for live view.
Click to select more layouts for live view.
Click to start viewing channels in a sequence.
Quick playback. You can select to play the latest recording for all channels from the beginning of the day, or you can
select the playback from the latest 5s, 10s, 30s, 1Min, 5Min.
Quick backup. Click to backup the video file.
Click to adjust audio volume.
Click to switch all IP channels between mainstream and substream (for live view resolution).
Click to switch among real-time, balanced, or smooth view. The view effect modes affect only the live view video
quality by bitrate and frame rate but do not affect the recording quality.
To start or stop Manual Record and Manual Alarm.
To view system information, channel information, record info and network state.
CAMERA QUICK TOOLBAR
In live viewing, left-click on a connected camera to display the Camera Quick Toolbar.
IP Camera Quick Toolbar
Click to manually record the channel immediately. If the manually recording is in process, the icon will be red. Click
one more time to stop the manual record.
Click to save a snapshot of the current camera image. The Manual Capture option must be enabled to use this feature.
For details on enabling Manual Capture, see the "2.6.3 Capture" section).
Click to play the latest 5 minutes recording of this channel.
Click to enter PTZ control panel.
Click to zoom into the channel. When the icon appears, press and hold the left button of your mouse to drag the
area you want to zoom into.
Click to adjust the image colour of the channel. You can adjust the HUE, BRIGHT, CONTRAST & SATURATION of
the image.
(Only for IP channel) To switch the live view video stream between HD & SD. HD is the mainstream live view, SD is
the substream live view.
Add customized tag: see the respective section for more information.

DS1098-028A16
SHUTDOWN / REBOOT / LOCK SCREEN MENU
Click on the Shutdown button on the Taskbar and the check the further action you want to move. Click on OK button,
system will require to input the Admin password to authenticate.
If you select Shutdown option, the system will be turned off. If you select Reboot option, the system will be rebooted.
If you select Lock Screen option, the live viewing screen will be disappeared. You will need to login in the system again for
further operations.
Afterwards, edit the Password in order to re-login to system press Unlock button for login again.
If press the Forgot Password: button, the system will send an email to the configured address with a code useful to access
the system if the password is forgotten.
Note:
The parameters for sending emails described in paragraph “2.9.3 - Email” must be correctly configured to use this
function.
Administrator has full authority over Main Menu operations and has an authority to limit common user’s operation.

DS1098-028A17
PTZ CONTROL
After finishing the PTZ setup, you can use the PTZ function to control your PTZ camera.
1. Left-click on a channel in the Live Viewing screen to open the Camera Quick Toolbar and select the PTZ control
icon .
2. PTZ control panel will be displayed.
N.
Icon
N.
Description
1 Channel Click to select the channel of the PTZ AHD/IP Camera.
2
Step
Command execution speed 1/5/20
3
Zoom
Click to zoom in/out.
4
Focus
Click to adjust the focus
5
Auto
Focus
Automatic focus adjustment
6 Restore Restore Auto-Focus IP Camera
FISHEYE CAMERA MANAGEMENT
2.2.5.1 Installation type
On the NVR Live screen, select the IP channel to which the fisheye camera is connected and click to launch the pop-up
menu for the IP channel as shown in the following figure:
Selecting button in the IP channel pop-up menu to enter the fisheye camera management mode shown in the following
figure.
1
2
3
4
5
6

DS1098-028A18
As shown in the Live screenshot above, moving the mouse cursor downwards will display a shortcut Fisheye multi-function
bar. On the Fisheye multi-function bar, select button to specify the installation type ("Fisheye Mode Select") of the
camera: ceiling, horizontal plane, wall, slanted surface. After choosing the installation type, select "Save" to save.
2.2.5.2 Viewing
The LIVE view (“Display Mode”) currently shown on the screen can be changed according to the selected installation type:
•Fisheye view:wide angle lens fisheye lens
•Panorama view: fisheye view adapted to the rectangular view
•3D Cylinder view: fisheye view adapted to 3D cylinder view
•VR view: 3D fisheye view after adaptation. Use the mouse to drag and drop to change the view angle. Use the
mouse wheel to gradually enlarge the perspective image. Use the mouse to select an area and double right-click
to navigate to the corresponding area and view the PTZ image of this area

DS1098-028A19
2.2.5.3 Installation on the ceiling
From the multi-function bar displayed at the bottom of the LIVE screen on the local monitor, select the button . At this
point, if the fisheye camera is mounted on the ceiling, select the button in the fisheye camera installation menu, shown
in the figure below, and save the settings.
There are nine display modes on the multi-function bar as shown above:
VR view, double right-click to start navigation.

DS1098-028A20
3D cylinder, as shown in the figure:
180° Panorama view, as shown in the figure:
360° Panorama view, as shown in the figure:
4PTZ, as shown in the figure
