UTEPO N1-SW0801-TP120 User manual

Please check the following items before installation, if it is missing, please contact the
dealer .
8 ports PoE Ethernet Switch 1pc
Power adaptor 1pc
AC power cable 1pc
Accessory 1pc
User manual 1pc
1) Please turn off the signal power and display device power before installation, installation
with power will damage the transmission equipment;
2) Use network cable connect PoE IP camera and 1～8 downlink ports of product respectively;
3) Use a network cable connect equipment uplink port and NVR or computer;
4) Connect power adapter;
5) Check if the installation is correct, equipment is in good condition, the connection is
stable, then provide power for system;
6) Ensure the Ethernet equipment with power and work properly.
Installation step
Feature
8 Ports PoE Ethernet Switch
8 Ports PoE Ethernet Switch
User Manual
12
8 ports PoE Ethernet Switch is a security surveillance Ethernet Switch which aims at Ethernet
high definition surveillance and Ethernet project security system. The product fully combines
the characteristics of security surveillance, provides fast packet forwarding ability and
abundant backplane bandwidth, which ensures clear image and fluent transmission. ESD
and surge protection circuit can improve product stability. The product supports one key
CCTV mode, enable to achieve VLAN, control the Net storm, protect the information security,
prevent the viral transmission and Ethernet attack, fully satisfy the needs ofEthernet video
security surveillance system and Ethernet project.
Board Diagram
VerB 2.0
● Major ports: 1* 10/100 Ethernet port
● One key CCTV mode; 1～8 downlink ports can only communicate with uplink ports;
Restrain network storm under 3Mbps;Extend downlink ports transmission distance
to 250m;
● Power input: DC48V～57V;
● Standard: Meet IEEE802.3 、IEEE802.3u、IEEE802.3 af/at standards,PoE use End-Span,
the spare cable can be used for other purposes;
● Protection: Excellent anti-thunder, anti-static and anti-interference ability;
● Appearance: Delicate design and easy installation, configure the anti-theft lock hole,
guard against theft;
●Operation: Plug and Play, No Setting required.
8*10/100Base-TX Ethernet ports(PoE) , Base-TX ,
Notice
The transmission distance is related to the connected cable. We suggest standard Cat5e/6
network cable, so the transmission distance can up to further distance!
1) Device must be connected with lightning protection grounding; otherwise protection
level will reduce; please use above No.20 wire to connect the grounding terminal.
2) Turn the dial switch for left, the equipment can enter surveillance module after providing
equipment power.
Please follow below the installation steps
Notice
8 ports PoE ethernet switch
Cat5/5e/6 network cable
PoE IP camera
PoE IP camera
power
PoE IP camera
PoE IP camera
PoE IP camera
PoE IP camera
Application
LCD
NVR
Power LED
CCTV mode
Front board
Back board
Side board
Kensington lock
uplink Ethernet port
Grounding Terminal
Power input port PoE Downlink Ethernet port
9
10/100Bas e-TX 10/100B ase-T X

连接接 口
Specification
连接接 口
8 Ports PoE Ethernet Switch
34
Specification change will not be noticed
8 Ports PoE Ethernet Switch
连接接 口
连接接 口
Troubleshoot
Please follow this step if the equipment have trouble.
Make sure the equipment is installed according to the manufactures installation guide.
Confirm RJ45 cable order meet EIA/TIA568A or 568B standard.
Every PoE port can provide PoE equipment maximum power less than 30W, please do not
connect the PoE equipment with power over 30W.
Replace the equipment that can not work with a proper functioning 8port PoE Ethernet
switch to check if the equipment is damaged.
Please contact your vendor if trouble still exists.
Instruments to be used: wire crimper, network tester. Wire sequence of RJ45 plug should
conform with EIA/TIA568A or 568B.
1) Please remove 2cm long the insulating layer, and bare 4 pairs UTP cable;
2) Separate the 4 pairs UTP cable and straighten them;
3) Line up the 8 pieces of cables per EIA/TIA 568A or 568B;
4) Cut off the cables to leave 1.5cm bare wire;
5) Plug 8 cables into RJ45 plug, make sure each cable is in each pin;
6) Use the wire crimper to crimp it;
7) Repeat above 5 steps to make the another end;
8) Using network tester to test the cable if it works.
Plug Producing Method
Pin Color
White/Green
Green
Blue
White/Orange
White/Blue
White/Brown
Orange
Brown
1
2
3
4
5
6
7
8
Pin Color
1
2
3
4
5
6
7
8
White/Green
Green
Blue
White/Orange
White/Blue
White/Brown
Orange
Brown
EIA/TIA 568A EIA/TIA 568B
When choose RJ45 make sure if one end is EIA/TIA568A,the other end should also be EIA/TIA568A.
When choose RJ45 make sure if one end is EIA/TIA568B,the other end should also be EIA/TIA568B.
Notice
Item
Description
Downlink Ports
8x10/100Base-TX (PoE)
Uplink Ports
1x 10/100Base-TX
Network Standard
IEEE 802.3/802.3u/IEEE802.3x
Switch Capacity
1.8Gbps
Packet Forwarding Rate
1.34Mpps
Exchange Type
Storage&Fowarding
Buffer
768k
MAC Address List
2K
PoE Standard
802.3af/at(PSE)
PoE Mode
End-span
PoE Power Supply
1/2(+)，3/6(-)
PoE Output
Single PoE Output≤30W(54V DC), Whole machine PoE output≤120W
CCTV Mode
1. Downlink ports only communicate with uplink ports
2.Extend transmission distance to 250m(Downlink Ports)
3.Bandwidth:10Mbps(Downlink Ports)
Surge Immunity
6KV ： IEC61000-4-5
ESD Protection
Contact discharge 6K, Air discharge 8KV, Per: IEC61000-4-2
Voltage Input
DC 48V~57V
Power Consumption
<5W
Operation Temperature
-10℃~+55℃
Storage Temperature
-40℃~+85℃
Operation Humidity
5%-95%(Non-condensing)
Dimensions(LxWxH)
200mm×101.8mm×27mm
Material
Metal
Weight
500g
