User’sManual
Thank you for purchasing the VTech® V-Motion
tm
Active Learning System!
The V-Motion
tm
Active Learning System is a brilliant breakthrough gaming console
that combines wireless, motion-activated play, web connectivity and educational gaming
intoa system that plugs directlyinto your TV! Your child will lovethe wireless action-packed
play that guides them through age-appropriate skill levels and developmental activities.
Included in This PackageIncluded in This Package
• V-Motion
tm
Active Learning System console and User’s Manual
• One Wireless Controller
• One Wrist Strap
• One V.Link™and V.Link™Manual
• One Smartridge™ and Smartridge™ Manual
WARNING: All packing materials such as tape, plastic sheets, wire ties and tags are
not part of this toy and should be discarded for your child’s safety.
User’sManual
V-Motiontm Console
• Make sure the unit is turned OFF.
• Locate the battery cover on the bottom of the unit.
• Remove the battery cover and insert 4 X 1.5V AA LR6/AM-3
batteries as indicated in the diagram.
• Replace the battery cover and make sure it is secure.
Notice: When the V-Motion
tm
is running on batteries, you may
see thisicon appearon the screen. This indicates that
battery power is low, and you should replace the batteries
soon. Battery time remaining once the icon first appears
is approximately 10-30 minutes, depending on the type of
batteries in use. After that, the console will show the low
battery icon for 5 seconds as indicated in the diagram, and
then will turn OFF automatically.
V-Motiontm Wireless Controller
• Make sure the Wireless Controller is turned OFF.
• Locate the battery cover on the bottom of the unit.
• Removethe screw of the battery cover with a screwdriveror a coin,
and insert 3 x 1.5V AAA AM4/LR03 batteries as indicated in the
diagram.
• Make sure battery cover is securely attached.
Notice: Whenthe
V-Motion
tm
wireless controller’s battery power
is low, the direction lights will blink for 10-30 minutes, and
then the controller will turn OFF automatically.
VTech®recommendshigh quality alkaline batteries for best
performance.
Battery NoticeBattery Notice
• Install batteries correctly observing the polarity (+, -) signs to avoid leakage.
• Do not mix old and new batteries.
• Do not mixbatteries of different types: alkaline, standard (carbon-zinc)or rechargeable
(Ni-Cd or Ni-MH).
• Removethe batteries from the equipmentwhen the unit will not be usedfor an extended
period of time.
• Always remove exhausted batteries from the equipment.
• Do not dispose of batteries in fire.
• Do not attempt to recharge ordinary batteries.
l
• The supply terminals are not to be short-circuited.
• Only batteries of the same and equivalent type as recommended are to be used.
WE DO NOT RECOMMEND THE USE OF RECHARGEABLE BATTERIES.
AC AdaptorAC Adaptor
• Use a VTech® 9V 300mA AC/DC adaptor or a standard AC/DC adaptor
with equivalent specification.
• Make sure the unit is turned OFF.
• Plug the power jack into the 9V DC socket at the back of the unit.
• Plug the AC adaptor into a wall socket.
NOTE: The use of an adaptor will override the batteries. When the toy is not going to
be in use for an extended period of time, unplug the adaptor.
Standard Guidelines for Adaptor ToysStandard Guidelines for Adaptor Toys
• The toy is not intended for use by children under 3 years old.
• Only use the recommended adaptor with the toy.
• The transformer is not a toy.
• Never clean a plugged-in toy with liquid.
• Never use more than one adaptor.
• Do not leave the toy plugged-in for extended periods of time.
Connecting a TVConnecting a TV
NOTE: Beforeyou connect the V-Motion
tm
Active Learning System to a TV, check
to make sure that the unit is working. Once you have turned the unit ON, the
power indicator light (ON/RESTARTButton) should glow. If the ON/RESTART
Button does not glow, check to see that the adaptor is connected correctly, or
thatthe batteries are installed correctly.If the batteries are not installed correctly,
the V-Motion
tm
Active Learning System will not function and damage to
the unit could result. Make sure that your TV and the unit are turned OFF before
you begin making connections.
Connect the V-Motion
tm
Active Learning System to your TV or monitor by plugging
the colored cables on the unit into the matching color video and audio input jacks on
your TV set.
For TVs with stereo audio inputs:
- Connect the yellowplug on the
V-Motion
tm
cableto the yellow
videoinput terminalon your TV.
- Connect thewhite and redplugs on the
V-Motion
tm
cableto the
whiteand red audioinput terminalson your TV.
Yellow White Red
User’s Manual
GETTING STARTED
PARENT’S TV TIPS
A Healthy,Balanced “TV Diet”
By Dr. Helen Boehm
Television was long considered the “uninvited” guest in American households. However,
today many realistic and caring parents are partnering with television to create electronic
classrooms -- right in their own living rooms. They are no longer asking if children should
watch TV but, rather, which programs and on-screen activities should be part of their
children’s TV intake.
Thesame balanced and structuredapproach to developinghealthy eating habits translates
to watching less, different and better television! This “TV diet” gives families a menu for
regulatingchildren’sviewing, choosing“healthy” program contentand reducing thequantity
and potency of television consumed.
So, what does a healthy, balanced “TV diet” look like?
A well-balanced diet is best…
Consider a healthy mixture of age-appropriate programming and activities that educate,
engage and entertain! A variety of viewing and interactive experiences can turn a TV
screen into an electronic classroom for learning and fun.
Trim the fat…
It is important to reduce children’s sedentary behavior and eliminate unhealthy programs
that contain violent, aggressive or disrespectful behaviors.
Move out of the candy store…
Parents are children’s first teachers and their most powerful role models. It is difficult
to improve children’s viewing when parents are modeling other TV viewing behaviors.
Consider adapting your own TV habits as a healthy example for your child.
Plan menus and season to taste…
Whenever possible, eliminate channel surfing and encourage the viewing of specific,
pre-selected shows. The PG-TV ratings help parents make more informed selections
that take into account the content and age-appropriateness of programs. For example,
Y-7 shows are designed for children 7 and older who can distinguish between fact and
fantasy. A TV-Y7-FV rating indicates that “fantasy violence” is present in an episode of
an animated program.
CONTENTS
• PARENT’S TV TIPS ......................................................................... 1
•INTRODUCTION ............................................................................... 3
Included in this package ............................................................................ 3
• PRODUCT FEATURES................................................................... 4
V-Motion
tm
Console
V-Motion
tm
Wireless Controller
• GETTING STARTED ....................................................................... 5
Battery Installation ..................................................................................... 5
Battery Notice ............................................................................................ 5
AC Adaptor ................................................................................................ 6
Standard Guidelines for Adaptor Toys ..................................................... 6
Connecting to a TV ................................................................................... 6
Connecting to a VCR ................................................................................ 7
To Begin Play ............................................................................................ 7
V-Motiontm Console ........................................................................... 7
Using the V-Motiontm Wireless Controller ................................................... 8
How to Attach the Wrist Strap to the Controller
Connecting to the Console - One-Player Mode
Connecting to the Console - Two-Player Mode
Connect V.SMILE®Accessoriesor Wired Controllers to
V-Motiontm
• V-Motion
tm
PLAY GUIDELINES............................................... 9
For Best Results While Playing Games .................................................... 9
Using the
V-Motion
tm
Wireless Controller ........................................... 10
Using the V.Link
TM
.................................................................................... 11
• CARE & MAINTENANCE............................................................. 12
• TROUBLE SHOOTING .................................................................. 12
• TECHNICAL SUPPORT ................................................................ 15
• OTHER INFO ...................................................................................... 15
Disclaimer and Limitation of Liabilty
12356
Control couch potatoes…
Children benefit from participation in movement, fitness activities and sports. These
bodily actions are not only important for a child’s physical growth and development but
also to monitor their emotional stability, social skills and obesity. Limit sedentary screen
time and blend physical and mental pursuits, like active on-screen games and video
activities, into the TV mix.
Starvation diets don’t work…
Many parents have found that restricting all TV time is an impractical long-term strategy.
It is possible, however, to set realistic limits that are welcomed by both parent and child!
Makeviewing a choice andnot a habit. Eliminatesome TV time by settinga few basic rules,
such as restricting television during meals or before the day’s homework is completed.
News fast…
The realism of TVnews can be overwhelming and scary for young children and reinforces
theirprofound safety concerns.Exposure to TV news images, particularlywithout a context
for scenes of terrible suffering, can cause vivid and long lasting fears.
Food for thought…
Whenever possible, connect viewing with learning. Many programs and characters are
based on books and many on-screen subjects -- from geography to sports -- can inspire
a lifelong interest in reading. Choose age-appropriate video activities that encourage
interaction and challenge critical thinking.
Dr. HelenBoehm is the author of The Right Toys, Fearless Parenting and many magazine
articles on parenting and responsible children’s media. A distinguished psychologist
and nationally known authority on children’s development, play, and media, Dr. Boehm
headed Public Responsibility and Network Standards at MTV/Nickelodeon and was Vice
President of the Fox Children’s Network.
V-Motion
tm
Active Learning System Console Smartridge™
4
Wireless Controller
Wrist Strap
V.Link
TM
The V-Motion
tm
wireless
controller accommodates both
right- and left-handed players.
Turn the switchon the bottom of
the controller, thenturn the center
partof thecontrollerto yourdesired
position.Youwill hear a clickwhen
the controlleris locked intoplace.
Parent Letter
Der Pr,
A VT®,  n th vry er, clr r n g t lay id gm  ngr n
ngr ag. A t sm m,  ndrt n t ti   rts t p tr
clr t t nrit ct  ny  lr id gm. H c rts ply
l tr clr t lay t gm, n  euct n  trt t   ethy,
ag-rit nr?
Or wr t ts qui s V-Mi™ Acv Lerng Syt! A ig retru r ir
gmrs, V-Mi™ tk eucin idgng t  l  lv t  i-acte
gng t th ngag b acv ns n oi.
V-Mi™ us rely t tTV t r vid is t ig-t g ng pinc ng
tng, ag-rit lerng gm n  i-acte, v rl crlr.
 V-Mi™ Acv Lerng Syt ngag clr t w od  lay: t Lerng
Avr -  cng lrtry rn  c lerng cncpts r elly tegrte,
n t Lerng Zn -  i  gm digne t cs  pfi s   , ngagng
ay. Eac Smrid™ gm ncrag acv gng l gv ng is’ns   r, t,
s t ler b t, eang, scinc, png n r.
I adi tt aci-acke Smrid™ gmlay, t V-Mi™ ncud tV.L™ (USB
v) thcnes ist VT®’s r nt t lcs gm n rac tr scr
ag rgmrs.
AVT®, rru trvid rtst uc-edeittid gmlm,
s s nrnv ayr clr tler lhvng . Wth r ng
VT®t t prt b  ng r cl lr   rl lerng!
Sncrly,
Ji Fzgrl
Vc Prid, Mrkng
Vt Elers, NA
Tler  r  tV-Mi™ Acv Lerng Syt™ n r VT® ts, 
w.tis.c
4 X 1.5V AA LR6/AM-3
batteries
3 X1.5V AAA AM 4 /
LR 03 batteries
V-MOtION
tm
Wireless Console V-MOtION
tm
Wireless Console
INTRODUCTION PRODUCT FEATURES
User’s Manual
User’sManual
• Storage Compartment
Stores up to nine Smartridges™.
• Smartridge™ Slot
Insert a Smartridge™. The Smartridge™
should lock into place.
• Wireless Controller Signal Receiver
Light will turn on when it’s receiving a
signal from a wireless controller.
• Wired Controller Port
Pull down the rubber door and plug in a
wired V.SMILE®controlleror accessory
(sold separately).
• Battery Compartment
Please see page 6.
• AV Cable
Connectsto TV or VCR. Please seepages 6 & 7.
• Power Jack
Please see page 6.
• OFF Button
Press this button to turn the unit OFF.
Always do this before removing a Smartridge™.
• ON/RESTART Button
Press this buttonto turn the unit ON. If you press
the ON/RESTARTButton while playinga game,
the game willstart over from the beginning.
• Microphone Port
Connects to a microphone (sold separately).
• V.Link™ Port
Inserta V.Link™to downloadyour game scores.
Pleasesee page 11for more V.Link™information.
• Direction Lights
Lightsturn on to indicatewhen thecontroller
is movingup, down,left or right.
• HELP Button
Press this button to hear helpful hints in
certain games.
• Joystick
• 4 Color Buttons
Use these buttons to choose
answers in certain activities, or to
preform certain game actions.
• OFF/Player1/Player2 Switch
Move this switchto turn the controller OFF
or to assignPlayer 1 or Player 2 to the
controller.Be sure to turn the controller
OFF when it’snot in use. Please see
pages 8-11for more information.
• Wrist Strap Attachment
Attach wrist strap here. Please see page 8
for more information.
• Wrist Strap
• Motion Sensor Signal
Light turns on when controller is
connected to the V-Motion
tm
console.
• Enter Button
Press this button to make a choice,
or to perform certain game actions.
• Battery Compartment
Please see page 5.
• LEARNING ZONE Button
Press this button to enter the Learning
Zone play mode.
• EXIT Button
Press this button to exit or pause a game.
Smartridge™Manual
Battery InstallationBattery Installation
V-MOtION
tm
Wireless Controller V-MOtION
tm
Wireless Controller
V.Link
TM
Manual
USB
USB

14
For TVs with a mono audio input:
- Connect the yellow plug on the
V-Motion
tm
cable to the
yellow video input terminal on your TV.
- Connect the white or red plug on the
V-Motion
tm
cable to
the white or red audio input terminal on your TV.
Connecting to a VCRConnecting to a VCR
Ifthere is no video IN and audioIN terminal on your TV set, youcan connect V-Motion
tm
to a VCR.
- Connect the yellow plug on the
V-Motion
tm
cable to theyellow
video input terminal on your VCR.
- Connect the white and red plugs on the
V-Motion
tm
cable to
the white and red audio input terminals on your VCR.
To Begin PlayTo Begin Play
V-Motion
tm
Console
• Make sure the unit is turned OFF.
• Insert a Smartridge™ into the Smartridge™ slot on the front of the main unit.
The Smartridge™ should lock into place. Please use care when removing the
Smartridge™ from the slot.
• Turn on the TV.
• Set your TV input mode to accept input from the port to which
V-Motion
tm
is
connected. In many cases this will involve setting the TV to “video” mode; however,
since all TVs vary, please refer to your TV or VCR manual for further details.
• Turn the
V-Motion
tm
Active Learning System on by pressing the ON/RESTART
Button.
Notice: V-Motion
tm
can play both V-Motion
tm
and V.SMILE®Smartridges™.
1. Keep your V-Motion
tm
cleanby wiping it with a slightly damp cloth.Never use solvents
or abrasives.
2. Keep it out of direct sunlight and away from direct sources of heat.
3. Remove the batteries when not using it for an extended period of time.
4. Avoid dropping it. NEVER try to dismantle it.
5. Always keep the
V-Motion
tm
away from water.
6. The AC adaptor should be regularly examined for damage to the cord, plug, enclosure
and other parts. In the event of such damage, the V-Motion
tm
must not be used with
this adaptor until the damage has been repaired.
CAUTION-Adequate Space Required
Besure you have enough space around you during
gameplay. To avoid injury or damage, make sure
otherpeople or objects are not within your range
ofmotion.
Forbest results, put the V-Motion
tm
consolein front of the TV. Then align
thecenter of the V-Motion
tm
console
withthe center of the TV.
• For best results, put the V-Motion
tm
console in front of the TV. Then align the
center of the V-Motion
tm
console with the center of the TV.
• Avoid blocking the signal between the
V-Motion
tm
console and wireless controller.
• The optimal distance between the
V-Motion
tm
console and wireless controller is
three to 15 feet.
• Avoid having bright light sources, including sunlight, that shine behind or near the TV
toward the controller.
• Avoid having other radio-frequency devices in the game play area.
• Avoid putting the
V-Motion
tm
console on a metal table or near metal objects.
Using the V-MOtION
tm
Wireless ControllerUsing the V-MOtION
tm
Wireless Controller
Make sureall players wearthe wrist strapsecurely on theirwrist and hold thecontroller with
bothhands duringplay.
The recommended distance between the V-Motion
tm
console and wireless controller is three to 15 feet.
7 8 9 10 11 12 13
Note:The V-Motion
tm
wirelesscontrollerisnotcompatiblewiththeoriginal
V.Smile®TVLearningSystem.
Using the V-Motion
tm
Wireless Controller
Howto Attach theWrist Strapto the Controller
• Locate the wrist strap attachment on the bottom of the controller. Attach the wrist strap
through the hole. (Figure 1)
• Place your handthrough the wrist strap, so thatthe strap fits comfortablyon your wrist.
Hold thecontroller firmly in yourhands while playing. (Figure 2)
Connectingto the Console- One-PlayerMode
• Locate the OFF/Player 1/Player 2 Switch on the bottom of the controller. Move the
switch to Player 1. (Figure 3)
• Make sure the controller’s Motion Sensor Signal is directly facing the
V-Motion
tm
console . (Figure 4)
• When the direction lights and the light on the
V-Motion
tm
console stop blinking, the
connection is complete. (Figure 5)
• Movethe OFF/Player 1/Player 2 Switch to OFFwhen controller is not in use. (Figure6)
Connectingto the Console- Two-Player Mode
• Locatethe OFF/Player1/Player 2 Switchon the bottom of the controller. Move the switch
to Player 2. (Figure 7)
• Repeat the steps aboveto be sure the controller is connected for Player 2.
ConnectV.SMILE®Accessories or Wired Controllerto V-Motiontm
Pull down the rubber flap on the front of the V-Motion
tm
console. Plug the V.SMILE®
accessory or controller into the port.
Note: When both a V-Motion
tm
wireless controller and a V.SMILE®wiredcontroller or
accessory are connected, the wired unit will register as Player 1. Please set the wireless
controller to Player 2.
CAUTION
WEAR THE WRIST STRAP WHEN USING THE V-Motion
tm
CONTROLLER.
• Makesure all players use the wrist strap.
• Whensharing the
V-Motion
tm
CONTROLLER among multiple players, make sure each person uses the wrist
strap properly.
• Wearingthe wrist strap will prevent you from accidentally dropping or throwing the controller during game play,
which could damage the controller or surrounding objects, or cause injury to other people.
ALLOW ADEQUATE SPACE AROUND YOU DURING GAME PLAY
• Adequatespace is required during game play. Stay at least 15 feet away from the TV.
• Asyou move around during game play, make sure objects and other people are out of your range of movement to
prevent damage or injury.
DO NOT LET GO OF THE V-Motion
tm
CONTROLLER DURING GAME PLAY
• Readthe user’s manual booklet for the game you are playing and follow all game control instructions for correct
use of the V-Motion
tm
controller or accessories.
• Holdthe controller securely and avoid excessive motion, as it may cause you to let go of the controller and may
break the wrist strap.
• Ifyour hands become moist, stop and dry your hands.
CAUTION: Use the Wrist Strap
Basic Operations
The following demonstrates the basic operations of the V-Motion
tm
wireless
controller. Operations will vary per game. Read the Smartridge™ user’s manual for the
game you are playing, and follow its instructions.
(Figure 2)
(Figure 3) (Figure 4) (Figure 5) (Figure 6)
(Figure 1)
(Figure 7)
• Insert the V.Link
TM
into the V.Link
TM
port. Be sure the sliding
button side of the V.Link
TM
is facing up for proper placement.
• The V.Link
TM
’s green indicator light will turn on to let you know the
V.Link
TM
is transferring information.
• For more details, please see the V.Link
TM
User’s Manual.
WARNING
Avery small percentage ofthe public, due to an existingcondition, may experienceepileptic
seizures or momentary loss of consciousness when viewing certain types of ashing colors or
patterns,especiallyon television.While the V-Motion
tm
doesnot contributeto any additional
risks, we dorecommend that parents supervisetheir children whilethey play video games.
If yourchild experiences dizziness,altered vision,disorientation,or convulsions, discontinue
use immediatelyand consultyour physician.
Pleasenote that focusingon a televisionand LCD screenat close range and handlingjoystick
controlsfor a prolonged periodof time may cause fatigueor discomfort.We recommend that
childrentake a 15 minute breakfor every hour of play.
For Best Results While Playing GamesFor Best Results While Playing Games
2008© VTech
Printedin China
91-002299-000-000
Yellow White Red
CARE & MAINTENANCE
TROUBLE SHOOTING
Disclaimer and Limitation of Liability
Disclaimer and Limitation of Liability
VTech® Electronics North America,L.L.C. and its suppliersassume no responsibilityfor any damage
or loss resulting from the use of this handbook. VTech® Electronics North America, L.L.C. and its
suppliers assume no responsibility for any loss or claims by third parties that may arise through
the use of this software. VTech® Electronics North America, L.L.C. and its suppliers assume no
responsibility for any damage or loss caused by deletion of data as a result of malfunction, dead
battery, or repairs. Be sure to make backup copies of important data on other media to protect
against data loss.
Company:
VTech® Electronics North America, L.L.C.
Address: 1155 West Dundee Road, Suite 130, Arlington Heights, IL 60004 USA
Phone : [phone] in the U.S. or 1-877-352-8697 in Canada
NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However , there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: changes or modifications not expressly approvedby the party responsible for compliance
could void the user’s authority to operate the equipment.
OTHER INFO
V-MOtION
tm
PLAY GUIDELINES
V-MOtION
tm
PLAY GUIDELINES
Drive
Tiltthe controller forward or backward.
15
TECHNICAL SUPPORT
If you have a problem that cannot be solved by using this manual, we encourage you to visit us
online or contact our Consumer Services Department with any problems and/or suggestions that
you might have. A support representative will be happy to assist you.
Before requesting support, please be ready to provide or include the information below:
• The name of your product or model number (the model number is typically located on the back
or bottom of your product).
• The actual problem you are experiencing.
• The actions you took right before the problem occurred.
Internet : www.vtechkids.com
Phone : [phone] in the U.S. or 1-877-352-8697 in Canada
Move the controllerfrom bottom to top.
Tiltthe controller right or left.
Shake thecontroller from side-to-side.
