Vaisala HUMICAP HMT140 User manual

QUICK GUIDE
Vaisala HUMICAP® Humidity and
Temperature Transmitter
HMT14
English
M211484EN-A

PUBLISHED BY
Vaisala Oyj Phone (int.): +35 9 949 1
P.O. Box 26 Fax: [phone]
FI-00421 Helsinki
Finland
Visit our Internet pages at www.vaisala.com .
© Vaisala 2012
No part of this manual may be reproduced in any form or by any means, electronic or
mechanical (including photocopying), nor may its contents be communicated to a third party
without prior written permission of the copyright holder.
The contents are subject to change without prior notice.
Please observe that this manual does not create any legally binding obligations for Vaisala
towards the customer or end user. All legally binding commitments and agreements are
included exclusively in the applicable supply contract or Conditions of Sale.

__________________________________________________________________________
VAISALA _________________________________________________________________ 3
Table of Contents
ENGLISH ........................................................................................................ 5
Product Overview ..................................................................... 5
Di ensions ............................................................................... 6
Duct Installation Kit .................................................................. 7
Wiring ........................................................................................ 8
Hardware Setup ...................................................................... 11
HMT140 Utility Installation..................................................... 11
HMT140 Utility Configuration ................................................ 12
Battery Replace ent .............................................................. 12
IR Sensor ................................................................................. 13
Technical Support .................................................................. 14
Product Returns ..................................................................... 14
Warranty .................................................................................. 14
Technical Data ........................................................................ 15
DRILLING TEMPLATE................................................................................. 19

QUICK GUIDE ______________________________________________________________
4 _____________________________________________________________ M2114 4EN-A
This page intentionally left blank.

____________________________________________________________________ English
VAISALA _________________________________________________________________ 5
ENGLISH
Product Overview
The Vaisala HUMICAP
®
Wireless Humidity and Temperature Transmitter
HMT140 measures relative humidity and temperature using the connected
probe and analog signals – RTD, Voltage, Current loops and Contacts. It
outputs data via wireless transmitter and is powered with three 3.6 volt DC
batteries and optional 9-30VDC connection and comes in 2 models, with or
without the optional LCD display.
The HMT140 transmitter's output quantities are configurable. Available
quantities are Relative Humidity (RH), Temperature (T), RTD, Contact, mV
and mA. The default output quantities are set at the factory during order time.
These factory preset quantity selections and other wireless parameters can be
changed afterward using the configuration port and included utility if necessary.
The HMT140 is available either with a fixed probe directly attached to the
transmitter housing or a remote probe with different (3/5/10m) cable lengths.
The HMT140 is also available with an optional LCD display without backlight.
It is typically installed mounted on the wall with up to four screws (not
included). Duct installation kits are available as accessories. There is a drilling
template inside the back cover of this guide to help you position the screws
correctly.

QUICK GUIDE ______________________________________________________________
6 _____________________________________________________________ M2114 4EN-A
Di ensions
1
4
5
7
2
12
37
1
2
4
Ø 12
116
46
39
M
4
;
4
p
c
s
91
92
78
Wall Assembly dimensions

____________________________________________________________________ English
VAISALA _________________________________________________________________ 7
Duct Installation Kit
A = Probe (HMP11 )
B = Duct installation kit
C = Probe Cable
1. Pass the probe cable through the plastic pipe of the duct installation kit.
2. Connect the probe cable to the HMP11 .
3. Use a 24mm drill bit to make a hole in the duct wall.
4. Use a 3.2mm drill bit to make four holes for the installation screws
(ST4.2x16-C-Z DIN7981 screw, 4pcs). The holes should be arranged
in a square around the 24mm hole, at a distance of 42mm from each other.
5. Mount the probe holder using the screws (D).
6. Adjust the depth of the plastic pipe and tighten the screw (E)
to lock the probe in place.
A
B
C
42
F
D
E
D = Installation screw
E = Pipe locking screw
F = Probe (HMP11 )
Ø24
Ø3,2x 4 pcs
29
59
2
Ø 15
2 5
42 53
Ø22
6
Ø
1
2
266
42
42

QUICK GUIDE ______________________________________________________________
_____________________________________________________________ M2114 4EN-A
Wiring
Service
Header
Config
Switch
LCD
Status
Power
Display
LED
Switch
Cable grommet
(Rubber
plug)
Cable bushing:
cable gland,
cable grommet,
or conduit fitting
Field WireTerminals
SERVICE
ON
OFF
3
.
6
V
B
a
t
t
e
r
y
V
a
i
s
a
l
a
P
/
N
2
3
6
3
1
8
S
P
3
.
6
V
B
a
t
t
e
r
y
V
a
i
s
a
l
aP
/
N
2
3
6
3
1
8SP
3
.
6
V
B
a
t
t
e
r
y
V
a
i
s
a
l
a
P
/
N
2
3
6
3
1
8
S
P
CONFIG
+
+
+
Ir Sensor
Release Tab
HMT140 Components

____________________________________________________________________ English
VAISALA _________________________________________________________________ 9
1) RTD Wiring Diagram
Channel 1: RTD Channel 2: RTD

QUICK GUIDE ______________________________________________________________
10 ____________________________________________________________ M2114 4EN-A
4) Voltage Wiring Diagram
Channel 1: DC Voltage
Channel 2: DC Volatge
VinDC
VinDC
+
+
-
-
Channel 1 Channel 2
G
G
V
+
V
+
C
h
a
n
n
e
l
1
C
h
a
n
n
e
l
2
G
G
V
+
V
+

____________________________________________________________________ English
VAISALA _________________________________________________________________ 11
Hardware Setup
To set up the device initially:
1. Open the case by pulling out and up with your fingers while pressing the
release tab located between the two glands with your thumb. (See the
HMT140 components diagram in “Wiring” section for location of release
tab). A slot screwdriver may be used to pry if you are unable to open the
case by hand.
2. Ensure the power switch on the device is in the OFF position.
3. Install three 3.6V lithium batteries as indicated in the wiring section.
Note: Use only Part # 23631 SP Vaisala 3.6V Lithium Thionyl Chloride
batteries.
4. Ensure that the HMT140 Configuration Cable is disconnected.
5. Turn the device on by moving the power switch on the device to the “ON”
position.
HMT140 Utility Installation
Before using the HMT140 Configuration Cable cable to configure the HMT140, the provided
software must be installed on the PC. The driver is compatible with Windows 2000, Windows
XP, Windows 7, and Windows Server 2003.
To set up the software:
1. Disconnect the HMT140 Configuration Cable if it is already connected.
2. Insert the media that came with the cable, or download the software from
http://www.vaisala.com/hmt140
. Run the HMT140 installation program (HMT140UtilitySetup.exe).
4. Accept the license agreement terms and continue by pressing Next to accept
the installation defaults. The installation of the driver may take several
minutes.
5. After the software has been installed, connect the HMT140 Configuration
Cable to a USB port on your PC. You can then proceed to configure the
utility using the steps below.
If you wish to remove the software, you can do so by uninstalling the entry for HMT140
Utility under the publisher Vaisala from the “Programs and Features” or “Add or Remove
Programs” feature in the Windows Control Panel.

QUICK GUIDE ______________________________________________________________
12 ____________________________________________________________ M2114 4EN-A
HMT140 Utility Software Setup
Use the following procedure to quickly set up the HMT140:
1. Turn on the HMT140 and wait 5 seconds.
2. Plug the USB connector on the HMT140 Configuration Cable to the
computer if it is not already connected.
. Open the HMT140 Utility from the start menu.
4. Connect the end of the Configuration cable labelled “USB Wi-Fi
Programmer” to the HMT140 “CONFIG” pin header.
5. Click the Retrieve button to identify the HMT140.
6. If the IP address is static, uncheck the “IP Address Dynamically Assigned”
checkbox and enter the network parameters in “Network Settings”.
Otherwise leave this checkbox checked.
7. Enter the parameters for the “WLAN” (wireless LAN router settings).
8. Enter the Destination IP address/name and port number of the host.
(viewLinc server settings).
Note: If you do not know the information to enter for steps 6-9, please request
these parameters from your network administrator.
9. Click the Sensor tab and select a Transmit Period Time and number of tries
for the HMT140 if you do not wish to keep the default settings.
10. Click the Update button. The utility will configure the HMT140.
11. Click the Status tab and wait. Check that the settings appear as configured.
Click the “Get” button if they do not appear automatically.
12. Disconnect the HMT140 Configuration cable from the HMT140.
1 . Wait seconds.
14. Press the “SERVICE” button on the HMT140.
15. Optional: Enter a name for the saved settings in the Saved Settings field and
click the disk icon to save.
16. Refer to the viewLinc Administrator Guide to complete the process of
adding HMT140’s to viewLinc.
Battery Replace ent
Use the following procedure to replace the batteries in the HMT140:
1. Open the case by pulling out and up with your fingers while pressing the
release tab located between the two glands with your thumb. (See the
HMT140 components diagram in “Wiring” section for location of release
tab).
2. Turn the power switch off.
. Remove the batteries by pulling them up firmly. If the battery does not
come out easily, one of the battery tabs can be pulled out gently while
pulling up.
4. After replacing the batteries, press and hold the service button and turn the
power switch on. The LED light will flash and the device will beep times.
5. Release the service button.

____________________________________________________________________ English
VAISALA _________________________________________________________________ 13
To reset the battery meter:
1. T urn off the HMT140. Make sure the configuration Cable is disconnected
from the sensor.
2. Press and hold the service button.
. Turn the HMT140 on while the service button is engaged.
4. Wait four seconds.
5. Release the service button. The battery meter has been reset.
IR Sensor
Use the following procedure to trigger a data packet transmission using the
IR Sensor:
1. Turn on the HMT140 and wait for the display to turn on then off.
2. Place your hand near the display. The display will turn on again and the
beeper will beep.
. To trigger a data packet transmission, ensure the Configuration Cable is
disconnected from the HMT140 (Sensor mode).
4. Place your hand over the display again and leave it for 5 seconds. The
Logger will beep twice to confirm transmission. It will attempt to connect
and transmit data to the host.

QUICK GUIDE ______________________________________________________________
14 ____________________________________________________________ M2114 4EN-A
Technical Support
The complete HMT140 User's Guide is available in English at
www.vaisala.com/hmt140 .
For technical questions, contact the Vaisala technical support by e-mail at
helpdes[email protected] . Provide at least the following supporting information:
- Name and model of the product in question.
- Serial number of the product.
- Name and location of the installation site.
- Name and contact information of a technically competent person who
can provide further information on the problem.
Product Returns
If the product must be returned for service, see www.vaisala.com/returns .
For contact information of Vaisala Service Centers, see
www.vaisala.com/servicecenters .
Warranty
Visit our Internet pages for more information and our standard warranty terms
and conditions: www.vaisala.com/warranty .
Please observe that any such warranty may not be valid in case of damage due
to normal wear and tear, exceptional operating conditions, negligent handling or
installation, or unauthorized modifications. Please see the applicable supply
contract or Conditions of Sale for details of the warranty for each product.

____________________________________________________________________ English
VAISALA _________________________________________________________________ 15
Technical Data
Humicap Relative Humidity Measurement Specifications
(With HMP110)
Property
Description / Value
Measurement range ... 1 % RH
Accuracy (including non-linearity,
hysteresis, and repeatability):
at ... +4 °C (+32 ... +1 4 °F) ±1.7 %RH ( ... 9 % RH)
±2.5 %RH (9 ... 1 % RH)
at -4 ... °C and +4 ... +8 °C
(-4 ... +32 °F and +1 4...+176 °F) ±3. %RH ( ... 9 % RH)
±4. %RH (9 ... 1 % RH)
Factory calibration uncertainty at
2 °C (+68 °F) ±1.5 %RH
Humidity sensor HUMICAP
®
18 R
Stability ±2 %RH over 2 years
Humicap Temperature Measurement Specifications
(With HMP110)
Property
Description / Value
Measurement range -4 ... +8 °C (-4 ... +176 °F)
Accuracy over temperature range:
at +15 ... +25 °C (+59 ... +77 °F) ± .2 °C (± .36 °F)
at +15 °C and +25 +4 °C
(+32 ... +59 °F and +77 ...+1 4 °F) ± .25 °C (± .45 °F)
at -4 ... °C and +4 ... +8 °C
(-4 ... +32 °F and +1 4...+176 °F) ± .4 °C (± .72 °F)
Temperature sensor Pt1 RTD 1/3 Class B IEC 751

QUICK GUIDE ______________________________________________________________
16 ____________________________________________________________ M2114 4EN-A
Analog Inputs
Property
Description / Value
2 Channel Current input signals -22 mA
Resolution: .67 µA
Accuracy: ± .15 % F.S. at +25 °C
Input Impedance: 62 Ohms
2 Channel Voltage input signals -5 V, -1 V
Resolution . 34% F.S.
± .15 % F.S. at +25 °C
Input Impedance: 37K Ohms
2 Boolean Contacts
Open /Close with magnetic reed relay
cable connections
Isolation One common per logger
Overload Protection 4 mA max. (reverse polarity
protected)
±24 VDC max. (reverse
polarity protected)
2 Resistive Temperature input signal Pt 1 RTD / 4 wire
Class A IEC 751
RTD Measurement range -196 °C to +9 °C
RTD Accuracy over temperature
range
-196 to -9 +/- 2.5 Deg C.
-9 to -3 +/- .75 Deg C
-3 to +/- .5 Deg C
to 5 +/- .25 Deg C
5 to 9 +/- .75 Deg C
2 Contacts input signals Dry contact
Humicap Operating Environment Specifications
Property
Description / Value
Operating temperature range
Transmitter body, no display
Transmitter body, with display
HMP11 probe
-4 ... +6 °C (-4 ... +14 °F)
-2 ... +6 °C (-4 ... +14 °F)
-4 ... +8 °C (-4 ... +176 °F)
Storage temperature range -5 ... +7 °C (-58 ... +158 °F)
Electromagnetic compatibility EN 61326-1:2 6 Electrical
equipment for measurement, control
and laboratory use - EMC
requirements - Basic immunity test
requirements
EN 55 22:2 6 + Am 1:2 7
Information technology equipment -
Radio disturbance characteristics -
Limits and methods of
measurement. Class B.

____________________________________________________________________ English
VAISALA _________________________________________________________________ 17
Mechanics Specifications
Property
Description / Value
Operating Temperature Range
Transmitter body, no display
Transmitter body, with display
- 4 °C...+6 °C
-2 °C...+6 °C
Material
Transmitter housing PBT plastic
Display window PC plastic
Probe body Stainless steel (AISI 316)
Probe grid filter Chrome coated ABS plastic
Housing classification IP65 (NEMA 4)
Connections
Screw terminals 26 AWG ... 2 AWG
HMP11 Probe interface 4-pin M8 female panel connector
HMP11 Probe cable lengths 3 m, 5 m, 1 m, cables can be
cascaded up to 5 m
RTD Temperature Sensor
Sensor tip material
Sensor tip length
Sensor tip diameter
Cable length
Stainless steel (AISI 316)
5 .8 mm
4.76 mm
5 m
Hermetic Door Switch Sensor
Cable length 7.6 m
Display (optional) 128 x 64 resolution full graphics
B&W display without backlight
Weight (Wall model, including probe) 3 g
Wireless Specifications
Property
Description / Value
Networking Standards IEEE 8 2.11 b/g
Frequency Band 24 2 ~ 248 MHz
Modulation 8 2.11b compatibility: DSSS(CCK-
11,
CCK-5.5, DQPSK-2, DBPSK-
1) 8 2.11g: OFDM (default)
Channel intervals 5MHz
Channels 1 - 14
Wi-Fi Security WEP (128-bit), WPA, WPA2
(Personal)
Output Power +18dBm (63mW)
Receiver Sensitivity -85dBm typical
Antenna Onboard Wipe
Data Rates 8 2.11 b: 1,2, 5.5,11 Mbps : 8 2.11
g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Certifications FCC: U3O-G2M5477 (FCC Part 15,
FCC CRF Title 47 Part 15) IC:
8169A-G2M5477 (RSS-21 ), CE:
EU ID # 681 (ETSI EN 3 1 489-1,
489-17, 328, EN 55 22 Class B,
EN61 4-2, 4-3, 4-6, 4-8, EN
6 95 ) Wi-Fi Certified: WFA7649
United States requirements for
unintentional radiators, FCC 47 CFR
Part 15-2 11 Subpart B.

QUICK GUIDE ______________________________________________________________
1 ____________________________________________________________ M2114 4EN-A
Property
Description / Value
Canadian requirements for
unintentional radiators, IC ICES-
3:2 4
European Union CE Marking
requirements for process control,
measurement, and laboratory
equipment (EMC Directive
2 4/1 8/EC):EN 61326-1:2 6 for
emissions and immunity
EN 61326-2-3:2 6 for emissions
and immunity of transducers with
signal conditioning
EN 61 -3-2:2 6+A1:2 9
+A2:2 9 for harmonics
EN 61 -3-3:2 8 for flicker
Australian and New Zealand EMC
requirements for process control,
measurement, and laboratory
equipment, EN 61326-1:2 6 for
emissions.
Other Inputs Specifications
Property
Description / Value
Voltage inputs 5 Volts max, input impedances 37K
Ohms
Current inputs 4 mA., input impedances 62 Ohms
RTD inputs not a voltage or current input device,
input impedances 5.1K Ohms

_____________________________________________________________ Drilling template
VAISALA _________________________________________________________________ 19
DRILLING TEMPLATE
46
39
91
92
78
M4

www.vaisala.com
M211484EN-A
