Valor H3 Series User manual

1
4007391-01
© Copyright Miles Industries Ltd., 2019
1040BPB Four-sided Backing Plate Kit
INSTALLATION MANUAL
H3 Series
CSA approved for use with Valor H3 1000 Heater Models
in New Construction/Zero Clearance applications
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
40” [1016 mm]
30-13/16” [783 mm]
from bottom of plate
30-9/16” [776 mm]
from bottom of appliance
Backing plate 1/4” [7 mm] below bottom of appliance
The 1040BPB backing plate is intended to be used on Valor heaters models H3 1000 in new construction
applications/zero clearance. Refer to installation manual supplied with appliance for clearances to combustible
and other specifications when using the 1040BPB “New Construction” Backing Plate.
The 1040BPB needs to be fitted with with a Four-Sided Front 1041FSV or 1041FSCB to complete the installation.
Note: When mounting over top of the wall finish, this trim allows for non-combustible material up to
maximum 3/4” (19 mm) thickness installed over top of the required 1/2” (13 mm) cement board. Otherwise,
run non-combustible finish to outer edge of backing plate.
Left hand door
Backing plate
assembly
Removeable
bottom plate Right hand
door
Overview
Left hand door
Right hand
door
Removable
bottom plate
Backing plate
assembly
H3 1000

2
Installation
1. On completion of appliance installation and wall
finish application, insert the backing plate assembly
into the liner box, and attach it using 4 screws into
the left and right sides.
Note that the fixing points are slotted, allowing for
variable depth of wall finish.
2. Slide the removable bottom plate into the clips in
the side panels.
3. Install the left hand side door.
a. Insert the left hand door tabs straight into
the top and bottom slots behind the front
panel of the plate.
b. Slide the door down to secure it.
4. Repeat with right hand door.
a
b

3
Code Description Part Number
1 Backing plate assembly 4007530AZ
2 RH door assembly 4007620AZ
3 LH door assembly 4007618AZ
4 Removable bottom panel 4007362AZ
Sheet metal screws (4) 100A757
Repair Parts List
Designed and Manufactured by / for
Miles Industries Ltd.
190 – 2255 Dollarton Highway, North Vancouver, B.C., CANADA V7H 3B1
Tel. [phone] Fax [phone]
www.valorfireplaces.com
Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication.
3
1
4
2

4
Plaque de finition à 4 côtés 1040BPB
DIRECTIVES D’INSTALLATION
Série H3
Left hand door
Backing plate
assembly
Removeable
bottom plate Right hand
door
Concept
Porte gauche
Porte droite
Panneau
amovible
Plaque de
finition
H3 1000
Homologuée par la CSA pour usage avec les foyers Valor H3 1000 dans installé dans une
nouvelle construction ou à dégagement zéro
INSTALLATEUR : Laissez cette notice avec l’appareil.
CONSOMMATEUR : Conservez cette notice pour consultation ultérieure.
La Plaque de finition 1040BPB est conçue pour être installée sur les foyers Valor 1000 H3 installés dans une
nouvelle contruction ou à dégagement zéro. Consultez le guide d’installation fourni avec l’appareil pour connaître
les dégagements aux matériaux combustibles et autres spécifications lorsque vous installez la Plaque de finition
1040BPB pour Nouvelles constructions.
La Plaque 1040BPB doit être installée avec une des Bordures à 4 côtés 1041FSV ou 1041FSCB afin de compléter
l’installation.
Note : Lors du montage par-dessus la finition du mur, cette plaque permet l’usage de matériaux
incombustibles jusqu’à une épaisseur maximale de 3/4” (19 mm) par-dessus le panneau de béton
de 1/2” (13 mm) exigé. Autrement, appliquez le matériau incombustible jusqu’au périmètre extérieur
de la plaque de finition.
40” [1016 mm]
30-13/16” [783 mm]
from bottom of plate
30-9/16” [776 mm]
from bottom of appliance
Backing plate 1/4” [7 mm] below bottom of appliance
de la base de la plaque
de la base de l’appareil
Plaque se termine 1/4” [7 mm] en bas de l’appareil

5
Installation
1. On completion of appliance installation and wall
finish application, insert the backing plate assembly
into the liner box, and attach it using 4 screws into
the left and right sides.
Note that the fixing points are slotted, allowing for
variable depth of wall finish.
2. Slide the removable bottom plate into the clips in
the side panels.
3. Install the left hand side door.
a. Insert the left hand door tabs straight into
the top and bottom slots behind the front
panel of the plate.
b. Slide the door down to secure it.
4. Repeat with right hand door.
a
b

6
Code Description Part Number
1 Backing plate assembly 4007530AZ
2 RH door assembly 4007620AZ
3 LH door assembly 4007618AZ
4 Removable bottom panel 4007362AZ
Sheet metal screws (4) 100A757
Repair Parts List 3
1
4
2
Conçue et fabriquée par / pour
Miles Industries Ltd.
190 – 2255 Dollarton Highway, North Vancouver, BC, CANADA V7H 3B1
Tél. [phone] Téléc. 604-984-0246
www.foyervalor.com
Parce que nous favorisons une politique de développement continu, certains détails de la présente publication peuvent varier.
