VANPOWERS URBANEASE Series User manual

EBIKE
USER MANUAL

Dear customer,
Hello from the Vanpowers team! We believe above all else that a good electric bike should be powerful, long-lasting,
and infused with innovative technology. This belief is at the core of everything we do. Each meticulously crafted e-bike
we deliver is a symbol of how we strive to create a better day to day commuting experience for riders all over the
world.
Your Vanpowers journey begins right now, and we are so excited to share it with you.
“
”
Vanpowers Team
-

If you have any questions about using your e-bike, feel free to contact us at any time!
vanpowers.com
[e-mail]
[phone]
1120 US-22 BRIDGEWATER TOWNSHIP,
NJ 08807, USA
Vanpowers USA
02

NOTICE!
Pedelec / EPAC
United States
Pedelecs are electric bikes that provide pedal assistance up to a maximum speed of 20 mph. According to US regulations, pedelecs
are classified as Class 1 &Class 2 electric bikes. Depending on the model, there may also be a push assist feature that allows the bike
to accelerate up to 4 mph as you walk with it. In most places, electric bikes are legally considered bicycles. You should familiarize
yourself with the regulations and classifications in your region.
Europe
A pedelec is a type of bicycle equipped with electric pedal assist functionality. It can provide assistance up to a maximum speed of
25 km/h when pedaling. Depending on the model, activate the walk assistance mode and verify that the speed increases up to 6
km/h (4 mph) maximum.
The Vanpowers UrbanGlide - Pro is classified as a Class 2 electric pedal assist bike in the United States and as an EPAC in Europe.
Electric Pedal-Assist Bicycle (EPAC) Instructions

01
03
08
15
31
33
41
47
49
CONTENTS.
USING THIS MANUAL
SAFETY WARNINGS
PRODUCT OVERVIEW
INSTALLATION INSTRUCTIONS
TROUBLESHOOTING ISSUES
CHARGING & REMOVAL OF BATTERY
DISPLAY INSTRUCTIONS
WARRANTY
CARE&MAINTENANCE
05
07
12
19
34
36
44
51
53

OverviewVanpowers E-bike user manual
USING THIS MANUAL

Thank you for choosing Vanpowers . Before you get rolling, please make sure to familiarize yourself with the basics of riding safely. Ride safety
is influenced by various factors, including your understanding of and proficiency with your e-bike, the e-bike’s condition and maintenance
history, and the riding conditions. Please note that any e-bike or other mode of transportation carries unforeseeable risks that the rider accepts
by using it. As we cannot control or predict the various situations that may occur while you ride, we cannot guarantee the safe use of this bike.
We hope you have a great ride!
This manual contains essential information on how to safely operate and maintain your Vanpowers e-bike and its accessories. Before using the
e-bike, please read and familiarize yourself with the contents of this manual, paying particular attention to safety precautions to ensure safe and
proper use of the e-bike. The manual also includes many warnings regarding safe operation of the e-bike as well as the potential consequences
of incorrect operation, settings, and maintenance. Please carefully read all the information in this manual and contact us immediately if you
have any questions.
Please be sure to keep this manual and any accompanying documents for future reference. Additionally, please note that any updates or
revisions to the contents of this manual will not be individually. Please visit to download the latest version for the most up-to-date information.
Using This Manual
06

03
OverviewVanpowers E-bike user manual
SAFETY WARNINGS

03
Safety Warnings
Please carefully read the user manual and safety warnings before using your e-bike and ensure that you understand and accept all associ-
ated risks. Any loss or damage caused by improper use is the responsibility of the user.
INSTRUCTIONS PERTAINING TO RISK OF FIRE or ELECTRIC SHOCK
IMPORTANT SAFETY INSTRUCTIONS
WARNING ‒When using this product, basic precautions should always be followed, including the following:
a) Read all the instructions before using the product.
b) To reduce the risk of injury, close supervision is necessary when the product is used near children.
c) Do not put fingers or hands into the product.
d) Do not use this product if the flexible power cord or output cable is frayed, has broken insulation, or any other signs of damage.
e) This equipment is not intended to be used at ambient temperatures less than -20°C (-4°F) or above ambient temperatures of 45°C
(113°F).
f) The battery is intended to be charged when the ambient temperature is between 0°C (32°F) and 40°C (104°F). Never charge the battery
when ambient temperatures are outside this range.
SAVE THESE INSTRUCTIONS
08

General Warnings
This e-bike is designed for riders aged 16 and up. Children should operate and ride the e-bike with adult supervision .
Please ensure that the e-bike and its components are not accessible to children under 3 years old.
The maximum total weight limit for this e-bike is 330 lbs (150 kg), and the maximum weight capacity for the rear rack is 55 lbs (25 kg). The
calculation method for total weight is as follows: e-bike weight + rider weight + luggage/backpack weight = total weight. If you have any
questions about the maximum weight limit, please contact Vanpowers for assistance.
As with all products with mechanical components, EPACs are subject to wear and high stress. Different materials and components may
react to wear and stress fatigue in different ways. If the recommended lifespan of a component has been exceeded, it may suddenly fail,
possibly causing injury. Any cracks, scratches, or changes in coloring in high-stress areas indicate that the lifespan of the components in
those has been exceeded and they should be replaced.
When replacing parts, be sure to use genuine replacement parts provided by the Vanpowers. Using non-Vanpowers parts may cause
malfunctions that can seriously affect your ride safety. Vanpowers is not responsible for any damages incurred due to the rider’s decision
to use non-Vanpowers replacement parts.
Without the guidance of the Vanpowers Service Center, do not attempt to disassemble, modify, repair, or replace any parts of the product
or equipment, as this will void the warranty and may result in malfunctions and/or injuries.
Inappropriate modifications to the e-bike or its accessories can cause malfunctions. In order to reduce the risk of accidents and injuries,
do not install any additional accessories that have not been purchased from or authorized by the seller, including but not limited to child
safety seats and trailers.
09

Riding environment
We recommend avoiding riding in wet weather, especially in
damp, salty, corrosive, or dusty environments.
Avoid riding in severe weather and low-visibility conditions,
such as dawn, dusk, darkness, or fog, to reduce the risk of
accidents.
Do not use the product to ride in heavy rain or through
streams, and do not immerse or submerge it in water or other
liquids, as this may cause damage to the electrical system.
When riding on slippery roads, reduce your speed and brake
in advance to ensure that the e-bike can stop safely.
Install reflectors and make sure they are clean, securely
fastened, and unobstructed.
When riding at night, use lights and reflectors properly to
ensure that others can see you.
Please note that insufficient lighting measures can lead to
serious injury or death.
Notes on road use
This product is designed for use on smooth asphalt,
concrete, and paved surfaces. Do not ride on/over
non-standard terrain, such as hills or mounds, stairs,
rocks, or drops greater than 15 centimeters.
To ride the e-bike safely on the road, it is necessary to
understand and comply with the safety regulations of
your country or region.
To reduce the risk of injury, always wear your helmet
correctly (covering the forehead) and fasten the safety
buckle correctly under your chin.
You are responsible for equipping yourself and your bike
with appropriate equipment (such as reflectors and
lights) in accordance with local legal requirements.
Do not ride the bike in a dangerous manner. Make sure
you can control the bike and do not attempt dangerous
actions, including but not limited to hands-free riding,
jumps, and wheelies.
10

FCC Compliance Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-locat-
ed or operating in conjunction with any other antenna or transmitter.
This equipment (the display) should be installed and operated with minimum distance 20cm between the radiator and your body.
11

OverviewVanpowers E-bike user manual
PRODUCT OVERVIEW

-Side view-
Product Overview
08. Saddle
06. Battery
01. Handlebars
03. Head tube
02. Front light
04. Front wheel
15. Front fender
05.Front brake
12. Rear carrier
07. Pedals
11. Kickstand
10. Chain
09. Seat post
clamp
13. Hub motor
16. Rear derailleur
14. Rear wheel
17. Tail light
13
18. Seat post

14
Time
-Handlebars-
02. Front brake lever
04. Assist
switch
05.Shifter
06. Stem
03. Rear brake lever
01. Display
07. Throttle

03
Please check the accessory box to ensure that all the following accessories are inside.
If any parts are missing or damaged, please contact the Vanpower Service Center immediately.
-Bell
-Pedals
-Charger-Keys
-Thru-Axle-Front light & Reflector
-User Manual
-Display
-Phillips Screwdriver
0.08inch（2mm） Allen Key
0.10inch（2.5mm）Allen Key
0.12inch（3mm） Allen Key
0.16inch（4mm） Allen Key
0.20inch（5mm） Allen Key
0.24inch（6mm） Allen Key
0.32inch（8mm） Allen Key
0.40inch（10mm） Allen Key
13
L R
-13-15&08-10
Open-End Wrench
13
15
08
10
Box Contents
15

03
Geometry
Choosing the right size bike is an important step to ensure safety and comfort while riding. If you are unsure which size is suitable for you,
please refer to the table in page 17.
K
B
G
E
OC
A
I
N
JD
L
H
F
M
16

Frame Size SLFrame Size SL
Ideal rider height
Seat post length
Frame length
Bottom bracket drop
Head tube length
Seat tube angle
Head tube angle
Rear wheel to center
440mm
642mm
70mm
180mm
73°
67.5°
451mm
736mm
1179mm
440mm
663mm
480mm
44mm
98mm
370mm
758mm
1201mm
468mm
666mm
480mm
44mm
94mm
370mm
460mm
672mm
70mm
180mm
73°
68°
451mm
Front wheel to center
Wheelbase
Reach
Stack
Fork length
Fork offset
Trail
Standover height
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
155-175cm
(51‒59)
170-190cm
(57‒63)
17

Specifications
Tire pressure
Waterproof rating
Mudguard
Front+ rear lights
Rear rack
Model
Max speed
Max load
Motor
Battery
Charger
Display
20 mph (32 km/h)
330 lbs. / 150kg
48V 500W Hub motor
48V 14.4Ah Li-ion
54.6V 4A
3.5Colorful LCD
Mileage
30‒50 psi
IPX5
Up to 60 Miles
Yes
Yes
Yes
HDA000008 Wheel diameter 27.5” × 2.2” front + rear
18
