Vaporesso LUXE80 User manual

User Manual
80

GTX
Thank you for choosing Vaporesso
product. Please read this instruction
carefully before use to ensure a perfect
experience. If there is any additional
requirement about this product, please
consult the local agent or contact us
through our website: www.vaporesso.com
EXPLODED VIEW
1
9
8
10
11
2
3
4
5
6
7
SPECIFICATIONS
Dimensions: 111.1 x 28 x 39.4mm
POD Capacity: 5ml/2ml(TPD)
Coils & Suggested Waage:
GTX 0.2Ω MESH Coil (45-60W)
GTX 0.3Ω MESH Coil (32-45W)
Baery Capacity: 2500mAh
Output Power: 5-80W
Charging Current: DC 5V/2A,Type-C
Baery Display : 0.96’’ TFT Screen

1. Drip Tip
2. PCTG Tube
3. Power Button
4. 0.96" TFT Screen
5. “+” Button
6. “-” Button
7. Type-C USB Port
8. Top Cap
9. Coil
10. Air-inlet Port
11. Battery
1. Abtropfspitze
2. PCTG-Rohr
3. Einschalttaste
4. 0,69--Zoll-TFT Bildschirm
5. „+“-Taste
6. „-“-Taste
7. Typ C-USB-Anschluss
8. Obere Kappe
9. Coil
10. Lufteinlass-Anschluss
11. Akku
1. Punta de goteo
2. Tubo PTCG
3. Botón de encendido
4. Pantalla TFT de 0,96"
5. Botón “+”
6. Botón “-”
7. Puerto USB tipo C
8. Tapa superior
9. Coil
10. Puerto de entrada de aire
11. Batería
1. Ponta de gotejamento
2. Tubo PCTG
3. Botão de alimentação
4. Ecrã TFT de 0,96''
5. Botão"+"
6. Botão"-"
7. Porta USB Tipo C
8. Tampa superior
9. Bobina
10. Porta de entrada de ar
11. Bateria
1. Drip Tip
2. Tube PCTG
3. Bouton d’alimentation
4. Écran TFT de 0,96 pouce
5. Bouton « + »
6. Bouton « - »
7. Port USB de type C
8. Capuchon supérieur
9. Coil
10. Port d’entrée d’air
11. Batterie
1. Beccuccio
2. Tubo PCTG
3. Pulsante di accensione
4. Schermo TFT da 0,96”
5. Pulsante “+”
6. Pulsante “-”
7. Porta USB Tipo C
8. Cappuccio superiore
9. Coil
10. Porta ingresso aria
11. Batteria
English Italiano
Español
Français
Deutsch Português

Nederlands
日本語
ΕλληνικάPolski
Bahasa 中文
1. ドリップチップ
2. PCTG 管
3. 電源ボタン
4. 0.96’’ TFT ディスプレイ
5. “+” ボタン
6. “-” ボタン
7. USB ポート（タイプ C）
8. トップキャップ
9. Coil
10. エアインレットポート
11. バッテリー
1. 烟嘴
2. PCTG 管
3. 电源键
4. 0.69’’ TFT 屏
5. “+” 键
6. “-” 键
7. Type-C USB 接口
8. 顶盖
9. 雾化芯
10. 进气口
11. 电池
1. Επιστόμιο
2. PCTG Σωλήνας
3. Κουμπί ενεργοποίησης
4. Οθόνη TFT 0.96’’
5. “+” Κουμπί
6. “-” Κουμπί
7. Θύρα USB Τύπου-C
8. Άνω κεφαλή
9. Coil
10. Θύρα εισόδου αέρα
11. Μπαταρία
1. Druppelpunt
2. PCTG-buis
3. Aan/uit-knop
4. 0,96’’ TFT scherm
5. “+” knop
6. “-” knop
7. USB-poort type C
8. Dop
9. Coil
10. Luchtinlaatpoort
11. Accu
1. Drip Tip
2. Tabung PCTG
3. Tombol Daya
4. Layar TFT 0,96’’
5. Tombol "+"
6. Tombol "-"
7. Port USB Tipe-C
8. Tutup Atas
9. Coil
10. Port Masukan Udara
11. Baterai
1. Ustnik
2. Rurka PCTG
3. Port wlotu powietrza
4. Ekran TFT 0,96”
5. Przycisk „+”
6. Przycisk „-”
7. PortUSB typu C
8. Nasadka górna
9. Coil
10. Port wlotu powietrza
11. Akumulator

FIGURES
Figure 1: Replace the coil Figure 2: Fill e-liquid
PACKING LIST
1x LUXE 80 Battery
1x GTX POD 26 (5ml/2ml TPD)
1x GTX 0.2Ω MESHCoil (In-BOX)
1x GTX 0.3Ω MESHCoil (In-BOX)
1x Type-C Cable
1x User Manual
1x Warranty Card
OPEN CLOSE

1
English
ENGLISH
USE INSTRUCTIONS
1. Install the POD
Connect the battery and the pod by magnetic absorption, please ensure the assembly is stable.
2. Replace the Coil
- Place the drip tip of the pod face down, and pull out the used coil;
- Install a new coil to the pod;
- Press the coil to align the coil base with the pod.
* Refer to the gure 1.
3. Fill E-liquid
- Unscrew the top cap from the pod refer to the arrow;
- Fill e-liquid through the lling slot;
- Screw the top cap to reinstall it back into place as shown;
- Please wait 5 minutes for the e-liquid to soak into the coil completely.
* Refer to the gure 2.
4. Adjust the Airow
Please rotate the pod to match the air-inlet port with the battery to adjust the airow volume.

2English
5. Power on the Device
Click the power button 5 times in 2 seconds to power on or power off the device.
6. Power Adjustment
LUXE 80 is using the powerful GTX coil platform, and the suggested power need to be noticed
before start vaping.
GTX MESH Coils GTX 0.2Ω MESH GTX 0.3Ω MESH
Suggested Power 45-60W 32-45W
7. Start Vaping
Press the power button to enjoy extraordinary vaping experience.
8. Charge the Baery
After connecting the Type-C cable to the battery, the battery indicator and remaining charging
time will be showed on the screen.
9. Seings
SYSTEM LOCK/UNLOCK: Press power button 3 times.
Press “+”and “–” buttons together to enter the setting interface.
SMART VW: The power of device will be adjusted automatically according to the coils;
VW: Wattage adjustment mode;
VV: Voltage adjustment mode;

3
English
PUFF: The 7 days vaping information will be recorded in the puff counter;
DEFAULT: Restore factory settings;
THEME: Theme Color Selection
EXIT: Back to main interface.
PROTECTIONS
Protections Situation
USB Input Protection The USB input voltage is too high.
Low Battery Protection The battery drops too low.
No Load Protection The device detects no cartridge on the battery.
Short-circuit Protection The device detects a short-circuit.
Overtime Protection Constantly vape for more than 10 seconds.
Overheat Protection The device detects an overheated PCBA.

4English
CAUTIONS
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, which may cause damage.
4. Please use a standard USB output charger with proper charging current and voltage range.
5. Keep away from the water or any ammable gas, liquid .
6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
7. Do not expose the device to extreme temperature. (Recommended temperature range:
-10~60℃ /14~140℉ while using and -10~45℃ /14~113℉while storing).
8. EEE Recycling: the product should not be treated as household waste, instead, it should
be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.
9. Battery Recycling: the product battery should not be treated as household waste, instead, it
should be handed over to the applicable used battery collection point for recycling.
10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as
damage or personal injury may occur.
