Vaporesso Zero 2 User manual

User Manual

Thank you for choosing Vaporesso product.
Please read this instruction carefully before
use to ensure a perfect experience. If there is
any additional requirement about this product,
please consult the local agent or contact us
through our website: www.vaporesso.com
EXPLODED VIEW
Dimensions: 89 x 31.8 x 19 mm
Pod Capacity: 3ml (Standard) / 2ml (TPD)
Pod Resistance: 1.3ΩCCELL & 1.0ΩMESH
Baery Capacity: 800mAh
Display: 4 x LED Indicators
Charging: Type-C, 5V/1A
SPECIFICATIONS
POD
PTF Filling Slot
LED Indicator
Battery
Type-C USB Port

Figure 1: Replace the POD Figure 2: Fill the E-liquid
45°

1
English
ENGLISH
USE INSTRUCTIONS
1. Install & Replace the Pod (Refer to FIGURE)
Pull out the pod from the battery and install the new one.
*If it’s the first time using the device, please tear off the sticker of the pre-installed pod.
2. Fill the E-liquid (Refer to FIGURE)
Fill the e-liquid through the PTF filling slot at the bottom of the pod.
*If it’s the first time filling the e-liquid, please wait 5 minutes for the coil to prime.
3. Start Vaping
The device is draw-activated. Inhale through the mouthpiece and exhale to start vaping.
4. Check the Baery Level
TheLEDindicatorswillflashwhileinstallingthepodorchargingtoremainthebatterycapacity.
: 80%~100%
: 60%~80%
: 30%~60%
: 0~30%
5. Charge the device
Connect the Type-C cable with the device to charge the battery. The LED indicators will flash while charging.
When fully charged, all the LED indicators will be always on.

2English
PROTECTIONS
Protections Flash Status of LED Indicator
Short-circuit All lights will flash 5 times.
No Load All lights will be on gradually and repeat 3 times.
Low Voltage All lights will flash 3 times.
Over Charging All Lights will be always on.
Over Discharging All lights will flash 3 times.
Low Resistance All lights will flash 5 times.
High Resistance All lights will flash 3 times.
Overtime (8s) All lights will be on gradually and repeat 3 times.

3
English
CAUTIONS
1. Please turn off the device when it is not in use.
2. Do not leave the charging device unattended.
3. Do not drop, throw or abuse your device, which may cause damage.
4. Please use a standard USB output charger with proper charging current and voltage range.
5. Keep away from the water or any flammable gas, liquid .
6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
7. Do not expose the device to extreme temperature. (Recommended temperature range: -10~60℃
/14~140℉while using and -10~45℃/14~113℉while storing).
8. EEE Recycling: the product should not be treated as household waste, instead, it should be handed
over to the applicable collection point for the recycling of electrical and electronic equipment.
9. Battery Recycling: the product battery should not be treated as household waste, instead, it should
be handed over to the applicable used battery collection point for recycling.
10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage or
personal injury may occur.

4English
WARNINGS
This refillable electronic cigaree is intended for use with compatible e-liquid, which may contain
nicotine. Nicotine is an addictive substance and it is not suitable or recommended to use in following
cases:
1. This device is not suitable for:
- Persons under the legal smoking age.
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-
term throat disease or difficult breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the
adrenal gland that can affect blood pressure).
- Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..
2. This device is not recommended for:
- Non-smokers
- Pregnant or breastfeeding women
3. You may experience the following results if you use nicotine containing e-liquid with this product.
If it happens, please consult a healthcare professional and show them this leaflet if possible:
- Feeling faint - Nausea - Dizziness - Headache - Coughing - Irritation of the mouth or throat
- Stomach discomfort - Hiccups - Nasal congestion - Vomition
- Chest palpitations/pain or an irregular heart rate
This device should not be used by persons under the legal smoking age.

1
Français
FRANÇAIS
CONSIGNES D’UTILISATION
1. Pour installer et remplacer le POD, (Voyez la FIGURE)
Sortez le POD de la batterie et installez-en un neuf.
*Lors de la première utilisation de l’appareil, veuillez décoller l’autocollant du POD pré-installé.
2. Remplissez d'e-liquide, (Voyez la FIGURE)
Remplissez d’e-liquide par l’ouverture PTF située au dessous du POD.
*Si c’est la première fois que vous remplissez d’eliquide, veuillez aendre 5 minutes, le temps que la coil
s’amorce.
3. Commencer à vapoter
L’appareil s’active par prise de bouffée. Aspirez dans le bec et expirez pour commencer à vapoter.
4. Vérifier le niveau de la baerie
Les voyants LED clignoteront pendant l'installation du pod ou pendant la charge pour indiquer le niveau de
batterie restant.
: 80%~100%
: 60%~80%
: 30%~60%
: 0~30%
5. Charger l’appareil
Connectez le câble Type-C à l’appareil pour le charger. Les voyants DEL clignoteront pendant la charge.
Lorsque la batterie est pleine, tous les voyants LED sont allumés.

2Français
PROTECTIONS
Protections Signification des clignotements du voyant DEL
Court-circuit Tous les voyants clignotent 5 fois.
Aucune charge Tous les voyants s’illuminent graduellement, 3 fois.
Tension faible Tous les voyants clignotent 3 fois.
Surcharge Tous les voyants restent allumés
Surdécharge Tous les voyants clignotent 3 fois.
Basse résistance Tous les voyants clignotent 5 fois.
Haute résistance Tous les voyants s’illuminent graduellement, 3 fois.
Durée trop longue (8 s) Tous les voyants s’illuminent graduellement, 3 fois.
