Vaporfi AIR 2 User manual

QUICK START GUIDE
ENGLISH

WHAT’S INCLUDED
» [ 1 ] All-In-One Vape Pen
» [ 2 ] 1.1 ohm Air 2 Atomizers
» [ 1 ] Micro USB
» [ 1 ] Quick Start Guide

USING DEVICE
PRIMING THE ATOMIZER
To turn on the VaporFi Air 2, Click the power button 5 times. You
will do the same to turn the device off. Hold the power button while
inhaling from the drip tip, releasing the power button once the
desired vapor production is achieved.
Priming your Atomizer is an important cost saving measure. To
prime, first you must remove the drip tip and unscrew the atomizer
base. Next, take the included VaporFi Air 2 1.1 Ohm Atomizer and
screw it into the bottom of the Atomizer base. Fill your tank with
e-liquid ensuring to not fill juice beyond the fill line. Next, you must
screw the Atomizer base into the built-in tank ensuring that the

atomizer is fully submerged in the e-liquid and is screwed in tightly.
Last, take short draws through the drip tip and allow the atomizer
to sit in the e-liquid for ten minutes. After ten minutes have elapsed
your device is ready to use. Press the fire button and enjoy your
favorite vape juice!
FILLING INTERNAL TANK
To fill your tank, remove the drip tip and atomizer base screwed into
the top of the built-in tank. Pour your e-liquid into the built-in tank
NOTE: We suggest using either side of the internal mouthpiece
to loosen and tighten the atomizer base. Using this mouthpiece as
a tightening tool will prevent leaking, and makes attaching your
atomizer easier.

We suggest using either side of the internal
mouthpiece to loosen and tighten the atomizer
base. Using this mouthpiece as a tightening tool
will prevent leaking, and makes attaching your
atomizer easier. First, remove the drip tip of your Air
2 by pulling in a straight up motion. Next unscrew
the atomizer base that sits atop the device. Once
the atomizer base has been removed, unscrew the
CHANGING YOUR ATOMIZER
making sure to not fill above the suggested fill line found on your
tank window.
NOTE: Over filling your tank will cause flooding and potential spit
back.

CHARGING YOUR DEVICE
To charge your device insert the included micro USB cable
into the USB port on the side of the device. While the device
is charging, you can still enjoy your favorite e-liquid. Keep in
mind, while it is possible to continue use during charging, it
drastically slows down the process.
NOTE: The Atomizers included in the Air 2 Kit are to
be used only with e-liquid and are not intended for oil
use.
bottom half, which is your atomizer. Throw out your
old atomizer, and follow priming instructions.

BATTERY LIFE INDICATOR
If your battery is fully charged, the built-in tank light will be green
when the fire button is pressed. If your battery life falls below 15%
a yellow light will indicate your draw. If your battery falls below 5%,
the LED light will flash Red indicating a need for re-charge.
To clean the VaporFi Air 2, make sure that your Atomizer base is
completely removed from the built-in tank. Using a moist paper
CLEANING THE VAPORFI AIR 2
SAFETY PROTECTIONS
Short Protection: If your Atomizer shorts out, the LED light will
flash. To troubleshoot this issue, ensure that your Atomizer is
screwed in tightly to both the Atomizer base and built-in tank.

TROUBLE SHOOTING YOUR VAPORFI AIR 2
Flooding/Spit back: To prevent excessive spit back and flooding
make sure to fill your e-liquid to the suggested fill line. If e-liquid
is filled beyond the suggested fill line you may still save your tank
of e-liquid. Blow directly into the drip tip while holding the button.
Vapor will be produced and come out of the air flow holes. Listen
for a reduction in gurgle, once the gurgling has reduced your tank
will be ready to vape. If flooding and spit back persists, remove the
towel or napkin, clean the built in tank gently ensuring that your
juice has been removed from the tank. Using a cotton cloth, gently
wipe the exterior of the Air 2. To clean the MICRO USB port, simply
use a cotton swab and carefully wipe the exterior area of the USB
port.

Air 2 Will Not Fire: If your Air 2 does not produce vapor or activate,
it is likely that your device is not fully charged. Charge your device
fully ensuring that your battery is not the cause for malfunction.
If your battery is fully charged and your device is flashing a green
light, you must tighten your atomizer. Ensuring that your atomizer is
attached to the built-in tank, take a draw from the Drip tip and the
issue will be resolved.
drip tip and atomizer. Pour some of the e-liquid out of the built-
in tank and prime your Atomizer again briefly. This should clear
excessive flooding and prevent spit back.
