Vaporfi V-GRIP User manual

QUICK START GUIDE
ENGLISH

WHAT’S INCLUDED
» [ 1 ] 75 Watt TC Mod (18650 Battery Not Included)
» [ 1 ] USB Charger
» [ 1 ] Quick Start Guide

USING THE V-GRIP MOD
To turn on the VaporFi V-GRIP mod, insert battery with the negative
pole facing upwards and the positive pole facing downwards, then
press the fire bar five times, you will do the same to turn off the
device as well. Before using the device, make sure you are in the
correct mode depending on the atomizer you are using. To adjust
modes, press the fire bar 3 times to enter the designated menu. Once
there, use the – button the navigate the menu and the + button to
make any necessary changes. Use the + and – buttons to determine
the best wattage or temperature, depending on your atomizer, that
works for your vaping style. Once you’ve checked your settings,
you are now ready to vape. Hold the fire bar while inhaling from the
drip tip, releasing the fire bar once the desired vapor production is
achieved.

SWITCHING FROM CELSIUS TO FAHRENHEIT
TCR (M1, M2, M3)
Switching from Celsius to Fahrenheit or vice versa is fairly easy.
Hold the + button to increase the temperature, until you’ve reached
the maximum temperature (300 degrees Celsius or 600 degrees
Fahrenheit). Once you reach the maximum temperature, press the +
button once more to complete the switch.
The V-GRIP mod offers the TCR function, which enables users to
customize their temperature control atomizers (Ni, Ti, SS). To enter
TCR mode, press the fire bar three times, once you have entered the
NOTE: When using new atomizers in temperature control mode, it
is important to start at lower temperatures to avoid burning your
atomizer.

mode menu, press the + button until you see the TCR mode. While
the mode is still flashing you can press the – button to scroll through
the set memories (M1, M2, M3), once entered only the memory
setting will flash. Now press the + button to choose a memory and
follow that by pressing the power button to confirm.
TCR SETUP
BYPASS MODE
With the device turned off, hold the fire bar and + button for five
seconds. Once you have entered the TCR menu, press the + or -
button to choose a memory. You will then press the fire bar to enter
your parameter setting. Press the + or - button to set the parameter
for your atomizer. Then hold the fire bar to confirm.
Bypass Mode is a direct output mode of voltage. This mode can only

EXTRA FEATURES
NEW COIL/SAME COIL PROMPT:
When replacing your atomizer, especially from a nickel atomizer to a
temperature controlled atomizer (Ni, Ti, SS 316), you will be required
to reset the resistance of that atomizer. This helps the device
recognize that the new atomizer is to be used at room temperature,
which ensures that you will not experience a burnt hit, if properly
primed. When prompted press the + button to indicate that the
replacement atomizer is new. If you are using the same atomizer,
select old.
be used with atomizer resistances under the range of 0.15-3.5 ohms;
otherwise the device will not work properly. Press the fire bar three
times to enter the menu. Press the + until you enter bypass mode and
press the fire bar to confirm.

LOCK/UNLOCK IN TEMPERATURE MODE:
KEY LOCK:
When using an atomizer in temperature control, to ensure that
your atomizer is read at the correct base resistance, you have the
ability to lock your resistance. Press the fire bar three times to enter
the menu. Then press the – button to enter the second row of your
display, you will notice the resistance display is now blinking. Now,
press the + button to lock the resistance.
While the device is on, hold the + and – buttons to enter key lock
mode. While in this mode, you will be unable to change the wattage/
temperature, but will still be able to fire.
NOTE: It is important to unlock your atomizer’s resistance before
replacing the atomizer. This will ensure that the new atomizer is
installed at room temperature.

LOCKING THE FIRE BAR:
CHANGING YOUR BATTERY:
To lock the fir bar, face the screen towards yourself and slide the lock
located on top of the MOD to the left. To unlock the fire bar, with the
screen facing towards you, slide the lock to the right.
To Change your battery, remove the side battery door and pull the
to the left. Pulling the String will allow your battery to be easily
removed and protect your insulator from tearing. Place your battery
inside of the MOD with the positive pole facing down and the
negative pole facing up. Put the battery door back onto the MOD and
prepare to activate your MOD. Click the fire bar five times to activate
the MOD and enjoy your favorite vape juice.

STEALTH MODE:
1. LOW BATTERY
2. NO ATOMIZER FOUND
PROTECTIONS & ALERTS
While the device is on, hold the fire bar and – button to enter stealth
mode. While in stealth mode, you will be able to fire your device
without the screen lighting up. This help save battery life. You can
still see the screen when changing your wattage/temperature.
You will receive the “Low Battery” message when your battery meter
begins to blink. If you continue to press the fire bar, the message will
then change to “Battery Low Lock.” The device will not work until
the battery is replaced or charged.
You will receive the “No Atomizer Found” message if the device is

3. TEMPERATURE PROTECTION
BATTERY LIFE
In temperature control mode, if the temperature of the atomizer is
higher than the set temperature of the device, the “Temperature
Protection” message will be displayed.
There is a battery meter at the bottom of your screen that will display
the device’s current battery strength. As you use the device, this
meter will continue to decrease until the device can no longer fire
and the “Low Battery” message is displayed on the screen. Once this
message is displayed, it is now time to replace your drained 18650
battery with a new one. If you do not have a fully charged battery,
unable to read there is an atomizer attached or if the atomizer has
shorted. Please ensure atomizer is attached properly. Also make sure
the atomizer is not damaged in any way before use.

WARNING
Do not attempt to modify equipment; doing so can result in
permanent damage, overheating and/or explosion which may lead to
severe injuries or death.
For more information visit: vaporfi.com/how-it-works
feel free to use the USB cord included with the device, to charge
your battery.
NOTE: While the device is charging, you can still enjoy your favorite
e-liquid. Keep in mind, while it is possible to continue use during
charging, it drastically slows down the process.

DISCLAIMER
Vaporfi products are not smoking cessation products and have
not been tested as such. The U.S. FDA has not approved these
products for any use and they are not intended to diagnose, cure,
mitigate, treat or prevent any disorder, disease, or physical or
mental condition. Some Vaporfi products contain a chemical known
to the State of California to cause cancer or birth defects or other
reproductive harm. Nicotine is addictive and habit forming, and it is
very toxic by inhalation, in contact with the skin, or if swallowed.

GUIA DE INICIO
ESPAÑOL

¿QUÉ VIENE INCLUIDO?
» [ 1 ] 75 Watt TC Mod (18650 Bateria No Incluida)
» [ 1 ] Micro Usb
» [ 1 ] Guia de inicio rapido

USO DEL V-GRIP
Para encender el VaporFi V-GRIP, inserte la batería con el polo
negativo hacia arriba y el positivo hacia abajo, luego presione
la barra de activación cinco veces. Tendrá que repetir este
procedimiento para apagar el dispositivo. Para ajustar los modos,
presione la barra de activación tres veces para ingresar en el menú
designado. Una vez hecho esto, utilice el botón “–“ para para
navegar por el menú y el botón “+” para hacer los cambios que
necesite. Utilice los botones “+” y “–“ para determinar el voltaje o la
temperatura que funcione mejor según su estilo de vaporización y
su atomizador. Una vez que haya verificado que sus ajustes sean los
deseados, estará listo para vaporizar. Mantenga presionada la barra
de activación mientras inhala desde la punta de goteo, soltando la
barra una vez que alcance la producción de vapor deseada.

NOTA: Cuando se mantiene presionado el botón de encendido
por más de diez segundos, el dispositivo dejará de funcionar y la
pantalla mostrará el mensaje “Protección de 10s”.
MODO DE CONTROL DE TEMPERATURA
Si planea usar un atomizador en uno de los tres modos de
temperatura, presione la barra de activación tres veces para ingresar
en el menú designado. Una vez hecho esto, presione el botón “–“ y
notará que los modos comenzarán a parpadear. Ahora, presione el
botón “+” para desplazarse por los diferentes modos, y una vez que
haya encontrado el modo adecuado para su atomizador, estará listo
para vaporizar usando el modo de control de temperatura. Utilizando
los botones “+” y “–“, podrá ajustar la temperatura (con un rango
de entre 100 a 300 grados Celsius o 200 a 600 grados Fahrenheit)
hasta encontrar la mejor para su líquido.

NOTA: Al utilizar atomizadores nuevos en el modo de control de
temperatura, es importante comenzar a temperaturas bajas para
evitar quemarlo.
CAMBIAR DE CELSIUS A FAHRENHEIT
TCR (M1, M2, M3)
Cambiar de Celsius a Fahrenheit y viceversa es bastante fácil.
Mantenga presionado el botón “+” para incrementar la temperatura
hasta que haya alcanzado el máximo (300 grados Celsius o 600
grados Fahrenheit). Una vez hecho esto, presione el botón “+” otra
vez para completar el cambio.
El V-GRIP ofrece la función TCR, la cual les permite a los usuarios
personalizar sus atomizadores de control de temperatura (Ni, Ti o
SS). Para entrar en el modo TCR, presione la barra de activación tres
veces, y una vez que haya en el menú de modos, presione el botón

“+” hasta que vea el modo TCR. Mientras que el modo parpadea,
puede presionar el botón “–“ para desplazarse por las memorias
determinadas (M1, M2, M3), una vez ingresado solo parpadeará el
ajuste de memoria. Ahora presione el botón “+” para elegir una
memoria y luego presione el botón de encendido para confirmar.
AJUSTE DE TCR
Con el dispositivo apagado, mantenga presionada la barra de
activación y el botón “+” por cinco segundos. Una vez que haya
ingresado en el menú de TCR, presione el botón “+” o “–“ para
elegir una memoria. Luego, presione la barra de activación para
ingresar el ajuste de su parámetro. Presione el botón “+” o el “–“ para
fijar el parámetro para su atomizador. Luego, presione la barra de
activación para confirmar.
