Varimixer W150N MK-I User manual

W150N

LIFT SYSTEM
Fig.No. Order No.
Description
1 140-23/24 BOWLARMS
2 140- 8 BOWL ARM SHAFT
3 STA 34 4 SNAP RING 50UK
4 140- 9M ECCENTRIC/MOUNTED
5 3 1205
R
SUPPORT ROLLER
STA 34 7 SNAPRING AS25
7 140-70 NUT M30X2
8 140- 9.1 LOCK PLATE
9 140-71.1 BOWL ARM GUIDE PLATE
10 STA 5 20 SCREW M10X25
11 15OE-8 (1993-1997) BOWL LIFT MOTOR
11
A
140-8 .5 (1998- BOWL LIFT MOTOR 220V 250MM
11B 140-8 . (1998- BOWL LIFT MOTOR 115V,250MM
11C 140-8 .15 (1998- BOWL LIFT MOTOR 24V , 250MM
11D 140-87 WHITE CONTROL BOX BOWL LIFT)
11E 140-430 TRANSFORMER 240/120
11F 140-430.1 TRANSFORMER 480/240 OPTION
12 150E-70.2 PIN FOR SERVO MOTOR
13 STA 205 COTTERPIN
14 140-11 FITTINGS FOR B/L MOTOR
15 STA 5454 SCREW M12X25
1 140-117 FITTINGS FOR SPRING
17 0-110 LIFTING SPRING
18 STA 010 WASHER 10.5X20X2.0
19 STA 5344 SCREW M10X25
20 STA 5345 SCREW M10X30
21 STA 5825 NUT M10
22 STA 2527 BUSHING
23 STA 2530 BUSHING
24 140-127 ROLL FOR BOWL RING
25 140-128 BUSHING
2 STA 010 WASHER 10.5X20X2.0
27 STA 5 78 SCREW M10X50
28 STA 518 PLUG BUTTON
29 31-128 ROLL FOR CLAMPING
30 STA 5088 SCREW M8X16 S/S
31 140-119 BRACKET
32 140-120 BOLT
33 140-121m DAMPNER
34 STA 5811 NUT M12
35 140-121.1 SOCKET JOINT
3 140-121.2 BALL JOINT
37 STA 5450 BOLT M12X50
