Vecow ECS-4500 User manual

USER
Manual
USER
Manual
1.1.0 Edition 20170331
Intel®Core™ i7/i5/i3 SoC Slim Fanless Embedded System
IEEE 802.3at PD/PoE+, High Performance, Rugged, -25°C to 70°C
ECS-4500

ii
Version Date Page Description Remark
1.0 03/31/2017 All Ofcial Release
Record of Revision

iii
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Disclaimer
Declaration of Conformity
Copyright and Trademarks

iv
Part Number Description
ECS-4500-
PoER600U
ECS-4500, Intel® Core™ i7-6600U Processor, 6 GigE LAN w/4
PoE+, 2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 16 Isolated DIO,
16 GPIO
ECS-4500-
PoER300U
ECS-4500, Intel® Core™ i5-6300U Processor, 6 GigE LAN w/4
PoE+, 2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 16 Isolated DIO,
16 GPIO
ECS-4500-
PoER955U
ECS-4500, Intel® Celeron® 3955U Processor, 6 GigE LAN w/4
PoE+, 2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 16 Isolated DIO,
16 GPIO
ECS-4500-
PoE600U
ECS-4500, Intel® Core™ i7-6600U Processor, 6 GigE LAN w/4
PoE+, 5 USB 3.0, 4 COM, 2 SIM, 16 Isolated DIO, 16 GPIO
ECS-4500-
PoE300U
ECS-4500, Intel® Core™ i5-6300U Processor, 6 GigE LAN w/4
PoE+, 5 USB 3.0, 4 COM, 2 SIM, 16 Isolated DIO, 16 GPIO
ECS-4500-
PoE955U
ECS-4500, Intel® Celeron® 3955U Processor, 6 GigE LAN w/4
PoE+, 5 USB 3.0, 4 COM, 2 SIM, 16 Isolated DIO, 16 GPIO
ECS-4500-
PDR600U
ECS-4500, Intel® Core™ i7-6600U Processor, 2 GigE PD LAN,
2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
PDR300U
ECS-4500, Intel® Core™ i5-6300U Processor, 2 GigE PD LAN,
2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
PDR955U
ECS-4500, Intel® Celeron® 3955U Processor, 2 GigE PD LAN,
2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
PD600U
ECS-4500, Intel® Core™ i7-6600U Processor, 2 GigE PD LAN,
5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
PD300U
ECS-4500, Intel® Core™ i5-6300U Processor, 2 GigE PD LAN,
5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
PD955U
ECS-4500, Intel® Celeron® 3955U Processor, 2 GigE PD LAN,
5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
2R600U
ECS-4500, Intel® Core™ i7-6600U Processor, 2 GigE LAN,
2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
2R300U
ECS-4500, Intel® Core™ i5-6300U Processor, 2 GigE LAN,
2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
2R955U
ECS-4500, Intel® Celeron® 3955U Processor, 2 GigE LAN,
2 SSD Tray, 5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
2G600U
ECS-4500, Intel® Core™ i7-6600U Processor, 2 GigE LAN,
5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
2G300U
ECS-4500, Intel® Core™ i5-6300U Processor, 2 GigE LAN,
5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
ECS-4500-
2G955U
ECS-4500, Intel® Celeron® 3955U Processor, 2 GigE LAN,
5 USB 3.0, 4 COM, 2 SIM, 32 GPIO
Order Information

v
Part Number Description
DDR4 16G Certied DDR4 16GB 2133MHz RAM
DDR4 8G Certied DDR4 8GB 2133MHz RAM
DDR4 4G Certied DDR4 4GB 2133MHz RAM
PWA-160W-WT 160W, 24V, 85V AC to 264V AC Power Adapter with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
PWA-120WM4P 120W, 24V, 90V AC to 264V AC Power Adapter with 4-pin
Mini-DIN Connector
PWA-120W 120W, 24V, 90V AC to 264V AC Power Adapter with 3-pin
Terminal Block
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector
and DIN-Rail Mounting
3G Module Mini PCIe 3G/GPS Module with Antenna
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth
Module Mini PCIe WiFi & Bluetooth Module with dual band Antenna
Order Accessories

vi
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 2
1.3.1 Specications of ECS-4500-PoER 2
1.3.2 Specications of ECS-4500-PoE 4
1.3.3 Specications of ECS-4500-PDR 6
1.3.4 Specications of ECS-4500-PD 8
1.3.5 Specications of ECS-4500-2R 10
1.3.6 Specications of ECS-4500-2G 12
1.4 Supported CPU List 14
1.5 Mechanical Dimension 15
1.5.1 Dimensions of ECS-4500-PoER 15
1.5.2 Dimensions of ECS-4500-PoE 15
1.5.3 Dimensions of ECS-4500-PDR 15
1.5.4 Dimensions of ECS-4500-PD 16
1.5.5 Dimensions of ECS-4500-2R 16
1.5.6 Dimensions of ECS-4500-2G 16
CHAPTER 2 GETTING TO KNOW YOUR ECS-4500 17
2.1 Packing List 17
2.2 Front Panel I/O Functions 18
2.3 Rear Panel I/O and Functions 24
2.4 Main Board Expansion Connectors 30
2.5 Main Board Jumper & Deep Switch Settings 42
2.6 Ignition Control 46
CHAPTER 3 SYSTEM SETUP 50
3.1 How to Open Your ECS-4500 50
3.2 Installing DDR4 SO-DIMM Modules 52

vii
3.3 Installing Mini PCIe Card 53
3.4 Installing Antenna Cable 54
3.5 Installing CFast Card 55
3.6 Installing SIM Card 56
3.7 Installing SSD/ HDD 57
3.8 Mounting Your ECS-4500 60
CHAPTER 4 BIOS SETUP 63
4.1 Entering BIOS SETUP 63
4.2 Main 64
4.3 Advanced 64
4.4 Chipset 75
4.5 Security 79
4.6 Boot 80
4.7 Save & Exit 81
APPENDIX A : Isolated DIO Guide 82
APPENDIX B : GPIO-WDT Functions 85
APPENDIX C : RAID Functions 88
APPENDIX D : Power Consumption 92
APPENDIX E : Supported Memory & Storage List 96

1
GENERAL INTRODUCTION
1
GENERAL INTRODUCTION
Vecow ECS-4500 Series is an innovative all-in-one integrated Slim Fanless
Embedded System. Powered by 6th Generation Intel® Core™ i7/i5/i3 U-series
SoC (Skylake-U), dual channel DDR4 2133MHz up to 32GB ECC memory,
ECS-4500 Series serves up to 10% CPU performance enhancements than
the former generation SoC solution lower CPU power consumption; Advanced
Intel® HD Graphics 520 graphics engine supports DirectX 12, OpenGL 4.4 and
OpenCL 2.0 API, onboard DVI-D and DisplayPort display interfaces support
up to ultra HD 4K resolution, ECS-4500 offers up to 34% improved graphics
performance than the former generation; Multiple Gen 3 PCIe (8GT/s), SATA
III (6Gbps), USB 3.0 (5Gbps), GigE (1Gbps) LAN and flexible 3G/4G/WiFi/
LTE/GPS/GPRS/UMTS wireless connections make high-speed data conveying
possible.
All-in-one and cable-less designs, fanless -25°C to 70°C operating temperature,
innovative 2 independent GigE LAN ports supporting IEEE 802.3at Powered
Device (PD), 6 GigE LAN ports with 4 IEEE 802.3at (25.5W/48V) PoE+ without
additional power connections, 2 Front-access 2.5” SSD/HDD trays, 2 SIM card
sockets for 3G/4G/LTE/ WiFi/GPRS/UMTS, 1 Front-access CFast socket, 2
SATA III supports software RAID function, 5 external USB 3.0, 4 COM RS-
232/422/485, 2 Mini PCIe expansions, 16 Isolated DIO, 6V to 36V wide range
power input with 80V surge protection, congurable ignition power control, smart
remote management features, remote power switch, EN50155 and EN50121-3-
2 compliant, Vecow ECS-4500 Series Slim Fanless Embedded System is an all-
in-one integrated solution for rugged embedded applications.
With outstanding performance, remarkable power productivity, smart
manageability, mobile availability, secure power protection, and extremely
rugged reliability, Vecow ECS-4500 Series Slim Fanless Embedded System
is your great solution for Machine Vision, Intelligent Automation, Smart
Manufacturing, Intelligent Surveillance, Vehicle Computing, Mobile NVR/DVR,
and any performance-driven real-time Industry 4.0/IIoT applications in harsh
environments.
1.1 Overview

2
GENERAL INTRODUCTION
©Vecow ECS-4500 User Manual
1.2 Features
• 6th Generation Intel® Core™ i7/i5/i3 U-series SoC (Skylake-U)
• 2 GigE LAN with IEEE 802.3at Powered Device (PD)
• 6 GigE LAN with 4 IEEE 802.3at PoE+, Power on/off enabled, iAMT 11.0
supported
• Slim design, Fanless, -25°C to 70°C Operating Temperature
• 2 DDR4 2133MHz Memory, up to 32GB
• DVI-D and dual DisplayPort display interfaces, up to 4K display
• 2 Mini PCIe support 3G/4G/LTE/WiFi/GPRS/UMTS
• Front-access : 2 2.5" SSD Tray, 2 SIM Socket, 1 CFast Socket
• 5 USB 3.0, 4 RS-232/422/485 COM, 2 SATA III, 1 mSATA
• 16 Isolated DIO with NPN/PNP, 16 GPIO
• 6V to 36V DC Power Input with 80V Surge Protection
• Configurable Ignition Power Control with Smart Battery Protection
1.3 Product Specication
1.3.1 Specications of ECS-4500-PoER
System
Processor Intel® Core™ i7-6600U/i5-6300U/Celeron® 3955U
Processor (Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 w/auto flow control (ESD 8KV)
USB • 5 USB 3.0 (External)
• 3 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO (8 DI, 8 DO) , support NPN/PNP
GPIO 16 GPIO
LED Power, HDD, Wireless, PoE
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Full-size for PCIe/USB/External SIM Card
• 1 Full-size for PCIe/USB/External SIM Card/mSATA

3
GENERAL INTRODUCTION
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5” SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux

4
GENERAL INTRODUCTION
©Vecow ECS-4500 User Manual
Mechanical
Dimensions (WxDxH) 257mm x 141mm x 48mm (10.1" x 5.6" x 1.9")
Weight 2.1 kg (4.6 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.2 Specications of ECS-4500-PoE
System
Processor Intel® Core™ i7-6600U/i5-6300U/Celeron® 3955U
Processor (Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 w/auto flow control (ESD 8KV)
USB • 5 USB 3.0 (External)
• 3 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO (8 DI, 8 DO) , support NPN/PNP
GPIO 16 GPIO
LED Power, HDD, Wireless, PoE
SIM Card 2 SIM Card Socket (External)

5
GENERAL INTRODUCTION
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Full-size for PCIe/USB/External SIM Card
• 1 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 2.5" SSD/HDD Bracket (Internal)
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported

6
GENERAL INTRODUCTION
©Vecow ECS-4500 User Manual
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 257mm x 141mm x 48mm (10.1" x 5.6" x 1.9")
Weight 2.1 kg (4.6 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.3 Specications of ECS-4500-PDR
System
Processor Intel® Core™ i7-6600U/i5-6300U/Celeron® 3955U
Processor (Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 w/auto flow control (ESD 8KV)
USB • 5 USB 3.0 (External)
• 3 USB 2.0 (Internal)
GPIO 32 GPIO

7
GENERAL INTRODUCTION
LED Power, HDD, Wireless, PD
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Full-size for PCIe/USB/External SIM Card
• 1 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5” SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports IEEE 802.3at
(25.5W/48V) Powered Device (PD) and iAMT 11.0
LAN 2 Intel® I210 GigE LAN supports IEEE 802.3at (25.5W/48V)
Powered Device (PD)
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.

8
GENERAL INTRODUCTION
©Vecow ECS-4500 User Manual
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 257mm x 141mm x 48mm (10.1" x 5.6" x 1.9")
Weight 2.1 kg (4.6 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.4 Specications of ECS-4500-PD
System
Processor Intel® Core™ i7-6600U/i5-6300U/Celeron® 3955U
Processor (Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 w/auto flow control (ESD 8KV)
USB • 5 USB 3.0 (External)
• 3 USB 2.0 (Internal)
GPIO 32 GPIO
LED Power, HDD, Wireless, PD
SIM Card 2 SIM Card Socket (External)

9
GENERAL INTRODUCTION
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Full-size for PCIe/USB/External SIM Card
• 1 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 2.5" SSD/HDD Bracket (Internal)
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports IEEE 802.3at
(25.5W/48V) Powered Device (PD) and iAMT 11.0
LAN 2 Intel® I210 GigE LAN supports IEEE 802.3at (25.5W/48V)
Powered Device (PD)
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux

10
GENERAL INTRODUCTION
©Vecow ECS-4500 User Manual
Mechanical
Dimensions (WxDxH) 257mm x 141mm x 48mm (10.1" x 5.6" x 1.9")
Weight 2.1 kg (4.6 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.5 Specications of ECS-4500-2R
System
Processor Intel® Core™ i7-6600U/i5-6300U/Celeron® 3955U
Processor (Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 w/auto flow control (ESD 8KV)
USB • 5 USB 3.0 (External)
• 3 USB 2.0 (Internal)
GPIO 32 GPIO
LED Power, HDD, Wireless, PD
SIM Card 2 SIM Card Socket (External)

11
GENERAL INTRODUCTION
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Full-size for PCIe/USB/External SIM Card
• 1 Full-size for PCIe/USB/External SIM Card/mSATA
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5” SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux

12
GENERAL INTRODUCTION
©Vecow ECS-4500 User Manual
Mechanical
Dimensions (WxDxH) 257mm x 141mm x 48mm (10.1" x 5.6" x 1.9")
Weight 2.1 kg (4.6 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature -25°C to 70°C (-13°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
1.3.6 Specications of ECS-4500-2G
System
Processor Intel® Core™ i7-6600U/i5-6300U/Celeron® 3955U
Processor (Skylake-U)
Chipset Intel® SoC
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 w/auto flow control (ESD 8KV)
USB • 5 USB 3.0 (External)
• 3 USB 2.0 (Internal)
GPIO 32 GPIO
LED Power, HDD, Wireless
SIM Card 2 SIM Card Socket (External)
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Full-size for PCIe/USB/External SIM Card
• 1 Full-size for PCIe/USB/External SIM Card/mSATA

13
GENERAL INTRODUCTION
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
• DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 SSD/HDD Bracket (Internal)
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
Power
Input Voltage 6V to 36V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• Mini-DIN 4-pin
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 257mm x 141mm x 48mm (10.1" x 5.6" x 1.9")
Weight 2.1 kg (4.6 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
