Vecow ECX-2200A User manual

USER
Manual
USER
Manual
1.0.0 Edition 20221018
10th Gen Intel®Xeon®/Core™i9/i7/i5/i3 Expandable Fanless System
Workstation-grade, 6 GigE LAN w/4 X-coded M12 PoE+, 2 SSD Tray, PCI/PCIe Slot
ECX-2200A/2100A

ii
©Vecow ECX-2200A/2100A User Manual
Version Date Page Description Remark
0.10 2022/10/05 All Preliminary Release
1.00 2022/10/18 All O󰀩cial Release
Record of Revision

iii
©Vecow ECX-2200A/2100A User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
Vecow Co., Ltd. is under no legal commitment to the details of this document.
Vecow shall not be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use of this document, the products, or any third party
infringements, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual comply with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow ECX-2200A/2100A User Manual
Part Number Description
ECX-2210MXA
ECX-2200A, 6 GigE LAN with 4 X-coded M12 PoE+, 1 PCIe x16,
2 SSD Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO,
Fanless
ECX-2210MXAF
ECX-2200A, 6 GigE LAN with 4 X-coded M12 PoE+, 1 PCIe x16,
2 SSD Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO,
with Fan Sink
ECX-2201MXA ECX-2200A, 6 GigE LAN with 4 X-coded M12 PoE+, 1 PCI, 2 SSD
Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO, Fanless
ECX-2201MXAF
ECX-2200A, 6 GigE LAN with 4 X-coded M12 PoE+, 1 PCI, 2 SSD
Tray, 6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO,
with Fan Sink
ECX-2210A ECX-2200A, 6 GigE LAN with 4 PoE+, 1 PCIe x16, 2 SSD Tray,
6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO, Fanless
ECX-2210AF ECX-2200A, 6 GigE LAN with 4 PoE+, 1 PCIe x16, 2 SSD Tray,
6 USB 3.2, 4 COM, 3 Nano SIM, 32 Isolated DIO, with Fan Sink
ECX-2201A ECX-2200A, 6 GigE LAN with 4 PoE+, 1 PCI, 2 SSD Tray, 6 USB 3.2,
4 COM, 3 Nano SIM, 32 Isolated DIO, Fanless
ECX-2201AF ECX-2200A, 6 GigE LAN with 4 PoE+, 1 PCI, 2 SSD Tray, 6 USB 3.2,
4 COM, 3 Nano SIM, 32 Isolated DIO, with Fan Sink
ECX-2110A ECX-2100A, 2 GigE LAN, 1 PCIe x16, 2 SSD Tray, 6 USB 3.2,
4 COM, 3 Nano SIM, 16 GPIO, Fanless
ECX-2110AF ECX-2100A, 2 GigE LAN, 1 PCIe x16, 2 SSD Tray, 6 USB 3.2,
4 COM, 3 Nano SIM, 16 GPIO, with Fan Sink
ECX-2101A ECX-2100A, 2 GigE LAN, 1 PCI, 2 SSD Tray, 6 USB 3.2, 4 COM,
3 Nano SIM, 16 GPIO, Fanless
ECX-2101AF ECX-2100A, 2 GigE LAN, 1 PCI, 2 SSD Tray, 6 USB 3.2, 4 COM,
3 Nano SIM, 16 GPIO, with Fan Sink
Order Information

v
©Vecow ECX-2200A/2100A User Manual
CPU List
Series CPU Cores TDP Cache Max.
Frequency
ECC
Memory
Intel®
Xeon®
W-1290E 10 95W 20M Up to 4.8GHz Y
W-1290TE 10 35W 20M Up to 4.5GHz Y
W-1270E 8 80W 16M Up to 4.8GHz Y
W-1270TE 835W 16M Up to 4.4GHz Y
W-1250E 6 80W 12M Up to 4.7GHz Y
W-1250TE 6 35W 12M Up to 3.8GHz Y
Intel®
Core™
i9-10900E 10 65W 20M Up to 4.7GHz NA
i9-10900TE 10 35W 20M Up to 4.5GHz NA
i7-10700E 865W 16M Up to 4.5GHz NA
i7-10700TE 835W 16M Up to 4.4GHz NA
i5-10500E 6 65W 12M Up to 4.2GHz NA
i5-10500TE 6 35W 12M Up to 3.7GHz NA
i3-10100E 4 65W 6M Up to 3.8GHz Y
i3-10100TE 4 35W 6M Up to 3.6GHz Y

vi
©Vecow ECX-2200A/2100A User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 3200MHz RAM
DDR4 16G Certied DDR4 16GB 3200MHz RAM
DDR4 8G Certied DDR4 8GB 3200MHz RAM
DDR4 4G Certied DDR4 4GB 3200MHz RAM
PWA-160WB-WT
160W, 24V, 85V AC to 264V AC Power Adapter with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWA-280WB-WT
280W, 24V, 85V AC to 264V AC Power Adapter with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWS-480W-WT 480W, 24V, 90V AC to 305V AC Power Supply, Wide-Temp,
IP65
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail and VESA Mounting Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
M.2 Storage Module M.2 Key M/Key B PCIe Storage Module
5G Module 5G Module with Antenna
4G Module 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Optional Accessories

vii
©Vecow ECX-2200A/2100A User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of ECX-2210MXA 3
1.3.2 Specications of ECX-2210MXAF 5
1.3.3 Specications of ECX-2201MXA 7
1.3.4 Specications of ECX-2201MXAF 9
1.3.5 Specications of ECX-2210A 11
1.3.6 Specications of ECX-2210AF 13
1.3.7 Specications of ECX-2201A 15
1.3.8 Specications of ECX-2201AF 17
1.3.9 Specications of ECX-2110A 19
1.3.10 Specications of ECX-2110AF 21
1.3.11 Specications of ECX-2101A 23
1.3.12 Specications of ECX-2101AF 25
1.4 Supported CPU List 27
1.5 Mechanical Dimension 28
1.5.1 Dimensions of ECX-2210MXA 28
1.5.2 Dimensions of ECX-2210MXAF 28
1.5.3 Dimensions of ECX-2201MXA 28
1.5.4 Dimensions of ECX-2201MXAF 29
1.5.5 Dimensions of ECX-2210A 29
1.5.6 Dimensions of ECX-2210AF 29
1.5.7 Dimensions of ECX-2201A 30
1.5.8 Dimensions of ECX-2201AF 30
1.5.9 Dimensions of ECX-2110A 30
1.5.10 Dimensions of ECX-2110AF 31
1.5.11 Dimensions of ECX-2101A 31
1.5.12 Dimensions of ECX-2101AF 31

viii
©Vecow ECX-2200A/2100A User Manual
CHAPTER 2 GETTING TO KNOW YOUR ECX-2200A/2100A 32
2.1 Packing List 32
2.1.1 ECX-2210MXA/2201MXA/2210A/2201A Packing List 32
2.1.2 ECX-2110A/2101 Packing List 33
2.2 Front Panel I/O Functions 34
2.3 Rear Panel I/O & Functions 41
2.4 Main Board Expansion Connectors 50
2.5 Main Board Jumper Settings 63
2.6 Ignition Control 69
CHAPTER 3 SYSTEM SETUP 72
3.1 How to Open Your ECX-2200A/2100A 72
3.2 Installing CPU 75
3.3 Installing DDR4 SO-DIMM Modules 76
3.4 Installing Mini PCIe Card 78
3.5 Installing Nano SIM Card 81
3.6 Installing Micro SD Cards 82
3.7 Installing PCI/PCIe Card 83
3.8 Installing SSD/HDD 86
3.9 Installing M.2 87
3.10 Installing Antenna Cable 94
3.11 Mounting Your ECX-2200A/2100A 97
CHAPTER 4 BIOS SETUP 102
4.1 BIOS Setup 102
4.2 Main 103
4.3 Advanced 104
4.4 Chipset 120
4.5 Security 126
4.6 Boot 129
4.7 Save & Exit 130

ix
©Vecow ECX-2200A/2100A User Manual
APPENDIX A : Isolated DIO/GPIO Guide 131
APPENDIX B : Software Functions 135
APPENDIX C : RAID Functions 140
APPENDIX D : Power Consumption 146
APPENDIX E : Supported Memory & Storage List 151
APPENDIX F : Install Win11 (BIOS TPM Setting) 156

1
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow ECX-2200A/2100A Series is a compact and rugged workstation-
grade expandable Fanless Embedded System. Featuring a new generation
workstation-grade platform : 10-core 10th Gen Intel® Xeon®/Core™ processor
that runs with an Intel® W480E chipset and supports max 95W TDP CPU,
Vecow ECX-2200A/2100A delivers up to 45% system performance and 87%
graphics performance over previous Vecow CFL-S solutions. The ECX-2200A/
2100A empowers any AI applications at the edge. To facilitate a wide array of
embedded use cases, Vecow ECX-2200A/2100A o󰀨ers high-speed connectivity
including USB 3.2(10G), PCIe 3.0 (8GT/S), SATA III (6G) and GigE LAN (1G).
The ECX-2200A/2100A o󰀨ers rugged and exible congurations. The system is
equipped with 6 GigE LAN brought out through 4 X-coded M12 and PoE+ ports
to support demanding AI-enabled vision applications. With a PCIe/PCI slot,
M.2, Mini PCIe, Vecow ECX-2200A/2100A provides limitless options to scale
functionality. Furthermore, the ECX-2200A/2100A comes in a novel mechanical
design that provides users with a way to maintain at a lower cost and time.
The external Nano SIM sockets for 5G/4G/3G/LTE/GPRS/UMTS and the latest
WiFi 6 technology enable seamless communications to function e󰀩ciently and
productively.
Powered by 10th Gen Intel® Xeon®/Core™ i9/i7/i5/3 Processor and includes
industrial-grade features of rugged X-coded M12 PoE+ GigE LAN port, 9V
to 50V DC-in, and fanless design with support for -40°C to 75°C extended
operating temperature, Vecow ECX-2200A/2100A provides high-performance
computing and reliable configurations for mission-crucial applications at the
edge and is ideal for Factory Automation, Rolling Stock, In-vehicle Computing,
Smart Retail, AMR/AGV, and any AIoT/Industry 4.0 applications.
1

2
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
1.2 Features
• Workstation-grade Platform : 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3
Processor (CML-S) running with Intel® W480E chipset support max 95W TDP
CPU
• 2 DDR4 2933MHz Memory support up to 64GB, optional with ECC
• 9V to 50V wide range DC Power Input with 80V Surge Protection
• Fanless, -40°C to 75°C Operating Temperature
• 6 Independent GigE LAN with 4 X-coded M12 IEEE 802.3at PoE+
• PCIe x16 expansion supports up to 250W Power Budget
• Expansion : 1 PCI/PCIe, 1 M.2 Key B, 1 M.2 Key E, 2 Mini PCIe
• Storage : 2 2.5" SSD Tray, 1 Micro SD Card, 1 M.2 Key M, 2 SATA III
• Display : VGA, DVI-D & 2 DisplayPort interfaces, up to 4K resolution
• 6-port USB 3.2 support up to 10Gbps data transfer
• 32 Isolated DIO, 4 COM RS-232/422/485
• 3 External Nano SIM Sockets for 5G/WiFi 6/4G/3G/LTE/GPRS/UMTS
• Supports Configurable Software Ignition Power Control and TPM 2.0
• Optimized user-friendly design for easier system maintenance
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI
accelerator and advanced Edge AI applications

3
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of ECX-2210MXA
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
PCI/PCIe 1 PCIe x16 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • 1 VGA : Up to 1920 x 1200 @60Hz
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE

4
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
Power
Input Voltage 9V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 79.0mm (10.24" x 9.45" x 3.11")
Weight 4.5 kg (9.92 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
1.3.2 Specications of ECX-2210MXAF
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
PCI/PCIe 1 PCIe x16 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • 1 VGA : Up to 1920 x 1200 @60Hz
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE

6
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
Power
Input Voltage 9V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 79.0mm (10.24" x 9.45" x 3.11")
Weight 4.5 kg (9.92 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W, 80W, 95W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
1.3.3 Specications of ECX-2201MXA
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
PCI/PCIe 1 PCI Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • 1 VGA : Up to 1920 x 1200 @60Hz
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE

8
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
Power
Input Voltage 9V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 79.0mm (10.24" x 9.45" x 3.11")
Weight 4.5 kg (9.92 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
1.3.4 Specications of ECX-2201MXAF
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
PCI/PCIe 1 PCI Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • 1 VGA : Up to 1920 x 1200 @60Hz
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE

10
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, X-Coded
M12 Connector
Power
Input Voltage 9V to 50V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x D x H) 260.0mm x 240.0mm x 79.0mm (10.24" x 9.45" x 3.11")
Weight 4.5 kg (9.92 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 75°C (-40°F to 167°F)
65W, 80W, 95W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

11
©Vecow ECX-2200A/2100A User Manual GENERAL INTRODUCTION
1.3.5 Specications of ECX-2210A
System
Processor Intel® 10th Generation Xeon®/Core™ i9/i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB 6 USB 3.2 (External)
Isolated DIO 32 Isolated DIO : 16 DI, 16 DO
LED Power, HDD, Wireless, PoE
SIM Card 3 Nano SIM Card Socket (External)
Expansion
Mini PCIe 2 Full-size Mini PCIe Socket for PCIe/USB/External SIM Card/
mSATA
PCI/PCIe 1 PCIe x16 Slot
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • 1 VGA : Up to 1920 x 1200 @60Hz
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE
