Vecow ECX-2000 Series User manual

USER
Manual
USER
Manual
1.0.0 Edition 20200925
10th Gen Intel®Xeon®/Core™i9/i7/i5/i3 Fanless Embedded System
Workstation-grade, 2.5GigE LAN, 10GigE LAN, 9V to 50V DC-in
ECX-2000

ii
©Vecow ECX-2000 User Manual
Version Date Page Description Remark
0.10 2020/09/09 All Preliminary Release
1.0 2020/09/17 All O󰀩cial Release
1.2 2020/09/25 P73, 134 Update
Record of Revision

iii
©Vecow ECX-2000 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
Vecow Co., Ltd. is under no legal commitment to the details of this document.
Vecow shall not be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use of this document, the products, or any third party
infringements, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual comply with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow ECX-2000 User Manual
Part Number Description
ECX-2025R ECX-2000, 3 2.5 GigE LAN, 6 GigE LAN with 4 PoE+, 2 SSD
Tray, 4 COM, 2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, Fanless
ECX-2025FR
ECX-2000, 3 2.5 GigE LAN, 6 GigE LAN with 4 PoE+, 2 SSD
Tray, 4 COM, 2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan
Sink
ECX-2025 ECX-2000, 3 2.5 GigE LAN, 6 GigE LAN with 4 PoE+, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, Fanless
ECX-2025F ECX-2000, 3 2.5 GigE LAN, 6 GigE LAN with 4 PoE+, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan Sink
ECX-2000-PoER ECX-2000, 6 GigE LAN with 4 PoE+, 2 SSD Tray, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, Fanless
ECX-2000F-PoER ECX-2000, 6 GigE LAN with 4 PoE+, 2 SSD Tray, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan Sink
ECX-2000-PoE ECX-2000, 6 GigE LAN with 4 PoE+, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 Isolated DIO, Fanless
ECX-2000F-PoE ECX-2000, 6 GigE LAN with 4 PoE+, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 Isolated DIO, with Fan Sink
ECX-2000-6FR ECX-2000, 6 GigE LAN with 2 SFP, 2 SSD Tray, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 GPIO, Fanless
ECX-2000F-6FR ECX-2000, 6 GigE LAN with 2 SFP, 2 SSD Tray, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 GPIO, with Fan Sink
ECX-2000-6F ECX-2000, 6 GigE LAN with 2 SFP, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 GPIO, Fanless
ECX-2000F-6F ECX-2000, 6 GigE LAN with 2 SFP, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 GPIO, with Fan Sink
ECX-2000-4R ECX-2000, 4 GigE LAN, 2 SSD Tray, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 GPIO, Fanless
ECX-2000F-4R ECX-2000, 4 GigE LAN, 2 SSD Tray, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 GPIO, with Fan Sink
ECX-2000-4G ECX-2000, 4 GigE LAN, 4 COM, 2 Nano SIM, 6 USB 3.2,
16 GPIO, Fanless
ECX-2000F-4G ECX-2000, 4 GigE LAN, 4 COM, 2 Nano SIM, 6 USB 3.2,
16 GPIO, with Fan Sink
Order Information

v
©Vecow ECX-2000 User Manual
Part Number Description
ECX-2000-2R ECX-2000, 2 GigE LAN, 2 SSD Tray, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 GPIO, Fanless
ECX-2000F-2R ECX-2000, 2 GigE LAN, 2 SSD Tray, 4 COM, 2 Nano SIM,
6 USB 3.2, 16 GPIO, with Fan Sink
ECX-2000-2G ECX-2000, 2 GigE LAN, 4 COM, 2 Nano SIM, 6 USB 3.2,
16 GPIO, Fanless
ECX-2000F-2G ECX-2000, 2 GigE LAN, 4 COM, 2 Nano SIM, 6 USB 3.2,
16 GPIO, with Fan Sink
ECX-2055R
ECX-2000, 2 10G RJ45, 6 GigE LAN with 4 PoE+, 2 SSD Tray,
4 COM, 2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Internal
Fan
ECX-2055FR
ECX-2000, 2 10G RJ45, 6 GigE LAN with 4 PoE+, 2 SSD Tray,
4 COM, 2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan Sink
and Internal Fan
ECX-2055 ECX-2000, 2 10G RJ45, 6 GigE LAN with 4 PoE+, 4 COM, 2
Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Internal Fan
ECX-2055F
ECX-2000, 2 10G RJ45, 6 GigE LAN with 4 PoE+, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan Sink and
Internal Fan
ECX-2071R ECX-2000, 2 10G SFP+, 6 GigE LAN with 4 PoE+, 2 SSD Tray,
4 COM, 2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, Fanless
ECX-2071FR ECX-2000, 2 10G SFP+, 6 GigE LAN with 4 PoE+, 2 SSD Tray,
4 COM, 2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan Sink
ECX-2071 ECX-2000, 2 10G SFP+, 6 GigE LAN with 4 PoE+, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, Fanless
ECX-2071F ECX-2000, 2 10G SFP+, 6 GigE LAN with 4 PoE+, 4 COM,
2 Nano SIM, 6 USB 3.2, 16 Isolated DIO, with Fan Sink

vi
©Vecow ECX-2000 User Manual
CPU List
Series Cores GHz TDP
(W) CPU Cores GHz TDP (W) ECC RAM
Intel®
Xeon®
W-1290E 10 4.8 W-1290TE 10 4.5 35 Yes
W-1270E 8 4.8 W-1270TE 8 4.4 35 Yes
W-1250E 6 4.7 W-1250TE 6 3.8 35 Yes
Intel®
Core™
i9-10900E 10 4.7 i9-10900TE 10 4.5 35 NA
i7-10700E 8 4.5 i7-10700TE 8 4.4 35 NA
i5-10500E 6 4.2 i5-10500TE 6 3.7 35 NA
i3-10100E 4 3.8 i3-10100TE 43.6 35 Yes

vii
©Vecow ECX-2000 User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 3200MHz RAM
DDR4 16G Certied DDR4 16GB 3200MHz RAM
DDR4 8G Certied DDR4 8GB 3200MHz RAM
DDR4 4G Certied DDR4 4GB 3200MHz RAM
PWA-160W-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
PWA-280W-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail and VESA Mounting Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
M.2 Storage Module M.2 Key M/Key B PCIe Storage Module
5G Module 5G Module with Antenna
4G Module 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Optional Accessories

viii
©Vecow ECX-2000 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of ECX-2025R 3
1.3.2 Specications of ECX-2025FR 5
1.3.3 Specications of ECX-2025 7
1.3.4 Specications of ECX-2025F 9
1.3.5 Specications of ECX-2000-PoER 11
1.3.6 Specications of ECX-2000F-PoER 13
1.3.7 Specications of ECX-2000-PoE 15
1.3.8 Specications of ECX-2000F-PoE 17
1.3.9 Specications of ECX-2000-6FR 19
1.3.10 Specications of ECX-2000F-6FR 21
1.3.11 Specications of ECX-2000-6F 23
1.3.12 Specications of ECX-2000F-6F 25
1.3.13 Specications of ECX-2000-4R 27
1.3.14 Specications of ECX-2000F-4R 29
1.3.15 Specications of ECX-2000-4G 31
1.3.16 Specications of ECX-2000F-4G 33
1.3.17 Specications of ECX-2000-2R 35
1.3.18 Specications of ECX-2000F-2R 37
1.3.19 Specications of ECX-2000-2G 39
1.3.20 Specications of ECX-2000F-2G 41
1.3.21 Specications of ECX-2055R 43
1.3.22 Specications of ECX-2055FR 45
1.3.23 Specications of ECX-2055 47
1.3.24 Specications of ECX-2055F 49
1.3.25 Specications of ECX-2071R 51
1.3.26 Specications of ECX-2071FR 53
1.3.27 Specications of ECX-2071 55
1.3.28 Specications of ECX-2071F 57
1.4 Supported CPU List 59

ix
©Vecow ECX-2000 User Manual
1.5 Mechanical Dimension 60
1.5.1 Dimensions of ECX-2025R 60
1.5.2 Dimensions of ECX-2025FR 60
1.5.3 Dimensions of ECX-2025 60
1.5.4 Dimensions of ECX-2025F 61
1.5.5 Dimensions of ECX-2000-PoER 61
1.5.6 Dimensions of ECX-2000F-PoER 61
1.5.7 Dimensions of ECX-2000-PoE 62
1.5.8 Dimensions of ECX-2000F-PoE 62
1.5.9 Dimensions of ECX-2000-6FR 62
1.5.10 Dimensions of ECX-2000F-6FR 63
1.5.11 Dimensions of ECX-2000-6F 63
1.5.12 Dimensions of ECX-2000F-6F 63
1.5.13 Dimensions of ECX-2000-4R 64
1.5.14 Dimensions of ECX-2000F-4R 64
1.5.15 Dimensions of ECX-2000-4G 64
1.5.16 Dimensions of ECX-2000F-4G 65
1.5.17 Dimensions of ECX-2000-2R 65
1.5.18 Dimensions of ECX-2000F-2R 65
1.5.19 Dimensions of ECX-2000-2G 66
1.5.20 Dimensions of ECX-2000F-2G 66
1.5.21 Dimensions of ECX-2055R 66
1.5.22 Dimensions of ECX-2055FR 67
1.5.23 Dimensions of ECX-2055 67
1.5.24 Dimensions of ECX-2055F 67
1.5.25 Dimensions of ECX-2071R 68
1.5.26 Dimensions of ECX-2071FR 68
1.5.27 Dimensions of ECX-2071 68
1.5.28 Dimensions of ECX-2071F 69
CHAPTER 2 GETTING TO KNOW YOUR ECX-2000 70
2.1 Packing List 70
2.1.1 ECX-2000-PoE/6F/4G/2G/2025/2055/2071 Packing List 70
2.1.2 ECX-2000-PoER/6FR/4R/2R/2025R/2055R/2071R Packing List 71

x
©Vecow ECX-2000 User Manual
2.2 Front Panel I/O Functions 72
2.3 Rear Panel I/O & Functions 81
2.4 Main Board Expansion Connectors 87
2.5 Main Board Jumper Settings 103
2.6 Ignition Control 107
CHAPTER 3 SYSTEM SETUP 110
3.1 How to Open Your ECX-2000 110
3.2 Installing CPU 114
3.3 Installing DDR4 SO-DIMM Modules 116
3.4 Installing Mini PCIe Card 119
3.5 Installing Nano SIM Card 122
3.6 Installing Micro SD Card 123
3.7 Installing SSD/HDD 124
3.8 Installing M.2 130
3.9 Installing Antenna Cable 135
3.10 Mount Your ECX-2000 137
CHAPTER 4 BIOS SETUP 139
4.1 Entering BIOS Setup 139
4.2 Main 140
4.3 Advanced 140
4.4 Chipset 152
4.5 Security 158
4.6 Boot 160
4.7 Save & Exit 161
APPENDIX A : Isolated DIO Guide 162
APPENDIX B : Software Functions 166

xi
©Vecow ECX-2000 User Manual
APPENDIX C : RAID Functions 170
APPENDIX D : Power Consumption 176
APPENDIX E : Supported Memory & Storage List 181

1
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow ECX-2000 Series is a workstation-grade compact integrated Fanless
Embedded System. Featuring 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3
processor with Intel® W480E Chipset and CPU support up to 95W TDP, Vecow
ECX-2000 Series reinvents itself from the inside out because it is optimized
for modern computer vision applications at the edge including Machine Vision,
Factory Automation, Intelligent Vending, Intelligent Transportation System (ITS),
Robotic Control, AMR/AVG, Deep Learning, and any Articial Intelligent oriented
AIoT or Industry 4.0 applications.
Vecow ECX-2000 Series offers fully featured I/O, including USB 3.2, up to
9 GigE LAN with multiple configurations such as 10G LAN/2.5G LAN/10G
SFP+/1G Ethernet configurations, making it ideally suited for Machine Vision,
ITS and AMR/AGV applications. For flexible system expansion, ECX-2000
Series is outfitted with Mini PCIe, M.2 and SUMIT A, B and enables mobile
communication connectivity through SIM Sockets. By integrating interfaces
including multi-port GigE LAN with 4 IEEE 802.3at PoE+, expansions
configurations like M.2, Mini PCIe, 2 front-access trays, 2 SIM sockets, and
1 SD card, ECX-2000 Series delivers flexible options to scale functionality.
In addition, the ECX-2000 series adopts the latest 2.5G Ethernet networking
technology for high performance-driven industrial embedded faanless system,
to meet the system throughput requirements of large amounts of image data
transmission for edge computing.
With new generation workstation-grade performance, leading integrations,
rugged reliability and smarter system maintenance, Vecow ECX-2000 Series is
your smarter choice for modern computer vision applications.
1

2
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
1.2 Features
• Workstation-grade Platform : 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/
i3 Processor (CML-S) running with Intel® W480E chipset supports max 95W
TDP CPU
• DDR4 2933MHz Memory supports up to 64GB, optional with ECC
• 9V to 50V wide range DC Power Input with 80V Surge Protection
• Fanless, -40°C to 75°C Operating Temperature
• 9 Independent GigE LAN with 4 IEEE 802.3at PoE+
• Nano SIM Sockets for 5G/WiFi 6/4G/3G/LTE/GPRS/UMTS
• Expansion : 1 M.2 Key B, 1 M.2 Key E, 1 Mini PCIe, optional SUMIT A, B
• 6-port USB 3.2 supports up to 10Gbps data transfer
• Front Access : 2 2.5" SSD Tray, 2 Nano SIM Socket, 1 Micro SD Card
• Supports Configurable Software Ignition Power Control and TPM 2.0
• Optimized user-friendly design for easier system maintenance
• Supports multiple Ethernet Configuration options such as : 10G LAN/2.5G
LAN/10G SFP+/1G SFP
• Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI
accelerator and advanced Edge AI applications

3
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of ECX-2025R
System
Processor Intel® 10th Generation Xeon®/Core™ i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB • 6 USB 3.2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, PoE, Wireless
SIM Card 2 Nano SIM Card Socket (External)
Expansion
Mini PCIe 1 Full-size Mini PCIe Socket for PCIe/USB/SIM Card/Optional
mSATA
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230, supports CNVi)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN

4
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
2.5G Ethernet
LAN 7 Intel® I225 2.5GigE LAN
LAN 8 Intel® I225 2.5GigE LAN
LAN 9 Intel® I225 2.5GigE LAN
Power
Input Voltage 9V to 50V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• 4-pin Mini-DIN
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 260.0mm x 175.0mm x 79.0mm (10.24" x 6.89" x 3.11")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

5
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
1.3.2 Specications of ECX-2025FR
System
Processor Intel® 10th Generation Xeon®/Core™ i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB • 6 USB 3.2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, PoE, Wireless
SIM Card 2 Nano SIM Card Socket (External)
Expansion
Mini PCIe 1 Full-size Mini PCIe Socket for PCIe/USB/SIM Card/Optional
mSATA
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230, supports CNVi)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210

6
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
2.5G Ethernet
LAN 7 Intel® I225 2.5GigE LAN
LAN 8 Intel® I225 2.5GigE LAN
LAN 9 Intel® I225 2.5GigE LAN
Power
Input Voltage 9V to 50V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• 4-pin Mini-DIN
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 260.0mm x 175.0mm x 79.0mm (10.24" x 6.89" x 3.11")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
80W, 95W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
1.3.3 Specications of ECX-2025
System
Processor Intel® 10th Generation Xeon®/Core™ i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB • 6 USB 3.2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, PoE, Wireless
SIM Card 2 Nano SIM Card Socket (External)
Expansion
Mini PCIe 1 Full-size Mini PCIe Socket for PCIe/USB/SIM Card/Optional
mSATA
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230, supports CNVi)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 2.5" SSD/HDD Bracket (Internal)
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210

8
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
2.5G Ethernet
LAN 7 Intel® I225 2.5GigE LAN
LAN 8 Intel® I225 2.5GigE LAN
LAN 9 Intel® I225 2.5GigE LAN
Power
Input Voltage 9V to 50V, DC-in
Power Interface • 3-pin Terminal Block : V+, V-, Frame Ground
• 4-pin Mini-DIN
Ignition Control 16 Mode Software Ignition Control
Remote Switch 3-pin Terminal Block : On, O󰀨, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 260.0mm x 175.0mm x 79.0mm (10.24" x 6.89" x 3.11")
Weight 3.8 kg (8.38 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating
Temperature
35W TDP CPU : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU : -40°C to 55°C (-40°F to 131°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 70°C
Shock • IEC 60068-2-27
• SSD : 50G @ wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

9
©Vecow ECX-2000 User Manual GENERAL INTRODUCTION
1.3.4 Specications of ECX-2025F
System
Processor Intel® 10th Generation Xeon®/Core™ i7/i5/i3 Processor
(Comet Lake-S)
Chipset Intel® W480E
BIOS AMI
SIO IT8786E
Memory • DDR4 2933MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 (ESD 8kV)
USB • 6 USB 3.2 (External)
• 1 USB 2.0 (Internal)
Isolated DIO 16 Isolated DIO : 8 DI, 8 DO
LED Power, HDD, PoE, Wireless
SIM Card 2 Nano SIM Card Socket (External)
Expansion
Mini PCIe 1 Full-size Mini PCIe Socket for PCIe/USB/SIM Card/Optional
mSATA
M.2 • 1 M.2 Key B Socket (3042/3052)
• 1 M.2 Key E Socket (2230, supports CNVi)
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1080 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support S/W RAID 0, 1
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
M.2 1 M.2 Key M Socket (2280, PCIe x4)
Storage Device • 1 Micro SD Card, Push-in/Push-out Ejector
• 2 2.5" SSD/HDD Bracket (Internal)
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 14.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
