Vecow ECX-1000 series User manual

USER
Manual
USER
Manual
1.1.0 Edition 20181228
8th Gen Intel®Xeon®/Core™ i7/i5/i3 Fanless Embedded System
Workstation-grade, 10GigE LAN, Extended Temperature
ECX-1000

ii
©Vecow ECX-1000 User Manual
Version Date Page Description Remark
0.10 10/05/2018 All Preliminary Release
1.0 10/08/2018 All Ofcial Release
1.1 12/28/2018 63 Update
Record of Revision

iii
©Vecow ECX-1000 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow ECX-1000 User Manual
Part Number Description
ECX-1000-9R ECX-1000, 9 GigE LAN with 4 PoE+, 2 Front-access SSD Tray,
2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
ECX-1000-9GD ECX-1000, 9 GigE LAN with 4 PoE+, 2 M.2, 6 USB 3.1, 4 COM,
2 SIM, 16 Isolated DIO
ECX-1000-PoER ECX-1000, 6 GigE LAN with 4 PoE+, 2 Front-access SSD Tray,
2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
ECX-1000-PoE ECX-1000, 6 GigE LAN with 4 PoE+, 2 M.2, 6 USB 3.1, 4 COM, 2
SIM, 16 Isolated DIO
ECX-1000-6FR ECX-1000, 6 GigE LAN with 2 SFP, 2 Front-access SSD Tray,
2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 GPIO
ECX-1000-6F ECX-1000, 6 GigE LAN with 2 SFP, 2 M.2, 6 USB 3.1, 4 COM,
2 SIM, 16 GPIO
ECX-1000-4R ECX-1000, 4 GigE LAN, 2 Front-access SSD Tray, 2 M.2,
6 USB 3.1, 4 COM, 2 SIM, 16 GPIO
ECX-1000-4G ECX-1000, 4 GigE LAN, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM,
16 GPIO
ECX-1000-2R ECX-1000, 2 GigE LAN, 2 Front-access SSD Tray, 2 M.2,
6 USB 3.1, 4 COM, 2 SIM, 16 GPIO
ECX-1000-2G ECX-1000, 2 GigE LAN, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM,
16 GPIO
ECX-1055R
ECX-1000, 6 GigE LAN with 4 PoE+, 2 10GigE LAN, 2 Front-
access SSD Tray, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM, 16 Isolated
DIO
ECX-1055 ECX-1000, 6 GigE LAN with 4 PoE+, 2 10GigE LAN, 2 M.2, 6
USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
ECX-1071R
ECX-1000, 6 GigE LAN with 4 PoE+, 2 10G SFP+, 2 Front-
access SSD Tray, 2 M.2, 6 USB 3.1, 4 COM, 2 SIM,
16 Isolated DIO
ECX-1071 ECX-1000, 6 GigE LAN with 4 PoE+, 2 10G SFP+, 2 M.2,
6 USB 3.1, 4 COM, 2 SIM, 16 Isolated DIO
Order Information

v
©Vecow ECX-1000 User Manual
Part Number Description
E-2176G Intel® Xeon® E-2176G Processor (12M Cache, up to 4.70GHz)
E-2124G Intel® Xeon® E-2124G Processor (8M Cache, up to 4.50GHz)
i7-8700 8th Gen Intel® Core™ i7-8700 Processor
(12M Cache, up to 4.60GHz)
i7-8700T 8th Gen Intel® Core™ i7-8700TE Processor
(12M Cache, up to 4.00GHz)
i5-8500 8th Gen Intel® Core™ i5-8500 Processor
(9M Cache, up to 4.10GHz)
i5-8500T 8th Gen Intel® Core™ i5-8500TE Processor
(9M Cache, up to 3.50GHz)
i3-8100 8th Gen Intel® Core™ i3-8100 Processor
(6M Cache, 3.60GHz)
i3-8100T 8th Gen Intel® Core™ i3-8100TE Processor
(6M Cache, 3.10GHz)
DDR4 32G Certied DDR4 32GB 2666MHz RAM
DDR4 16G Certied DDR4 16GB 2666/2400/2133MHz RAM
DDR4 8G Certied DDR4 8GB 2666/2400/2133MHz RAM
DDR4 4G Certied DDR4 4GB 2666/2400/2133MHz RAM
PWA-280W-WT 280W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
PWA-160W-WT 160W, 24V, 85V AC to 264V AC Power Adaptor with 3-pin
Terminal Block, Wide Temperature -30°C to +70°C
VESA Mount VESA Mounting Kit
DIN-RAIL Kit DIN Rail and VESA Mounting Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector and
DIN-Rail Mounting
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
Order Accessories

vi
©Vecow ECX-1000 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of ECX-1000-9R 3
1.3.2 Specications of ECX-1000-9GD 5
1.3.3 Specications of ECX-1000-PoER 7
1.3.4 Specications of ECX-1000-PoE 9
1.3.5 Specications of ECX-1000-6FR 11
1.3.6 Specications of ECX-1000-6F 13
1.3.7 Specications of ECX-1000-4R 15
1.3.8 Specications of ECX-1000-4G 17
1.3.9 Specications of ECX-1000-2R 19
1.3.10 Specications of ECX-1000-2G 21
1.3.11 Specications of ECX-1055R 23
1.3.12 Specications of ECX-1055 25
1.3.13 Specications of ECX-1071R 27
1.3.14 Specications of ECX-1071 29
1.4 Supported CPU List 31
1.5 Mechanical Dimension 31
1.5.1 Dimensions of ECX-1000-9R 31
1.5.2 Dimensions of ECX-1000-9GD 31
1.5.3 Dimensions of ECX-1000-PoER 32
1.5.4 Dimensions of ECX-1000-PoE 32
1.5.5 Dimensions of ECX-1000-6FR 32
1.5.6 Dimensions of ECX-1000-6F 33
1.5.7 Dimensions of ECX-1000-4R 33
1.5.8 Dimensions of ECX-1000-4G 33
1.5.9 Dimensions of ECX-1000-2R 34
1.5.10 Dimensions of ECX-1000-2G 34
1.5.11 Dimensions of ECX-1055R 34
1.5.12 Dimensions of ECX-1055 35
1.5.13 Dimensions of ECX-1071R 35
1.5.14 Dimensions of ECX-1071 35

vii
©Vecow ECX-1000 User Manual
CHAPTER 2 GETTING TO KNOW YOUR ECX-1000 36
2.1 Packing List 36
2.2 Front Panel I/O Functions 38
2.3 Rear Panel I/O & Functions 47
2.4 Main Board Expansion Connectors 53
2.5 Main Board Jumper Settings 65
2.6 Ignition Control 68
CHAPTER 3 SYSTEM SETUP 71
3.1 How to Open Your ECX-1000 71
3.2 Installing CPU 77
3.3 Installing DDR4 SO-DIMM Modules 88
3.4 Installing Mini PCIe Card 90
3.5 Installing Antenna Cable 92
3.6 Installing CFast Card 94
3.7 Installing SIM Card 95
3.8 Installing SSD/HDD 96
3.9 Installing M.2 100
3.10 Mounting Your ECX-1000 101
CHAPTER 4 BIOS SETUP 103
4.1 Entering BIOS Setup 103
4.2 Main 104
4.3 Advanced 104
4.4 Chipset 116
4.5 Security 121
4.6 Boot 123
4.7 Save & Exit 124

viii
©Vecow ECX-1000 User Manual
APPENDIX A : Isolated DIO Guide 125
APPENDIX B : Software Functions 132
APPENDIX C : Power Consumption 137
APPENDIX D : RAID Functions 141
APPENDIX E : Supported Memory & Storage List 147

1
©Vecow ECX-1000 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow ECX-1000 Series is a workstation-grade compact integrated Fanless
Embedded System. LGA1151 Socket supports workstation-grade 6-core 8th
Generation Intel® Xeon®/Core™ i7/i5/i3 processor (Coffee Lake-S) running
with workstation-grade Intel® C246 chipset, dual channel DDR4 2666MHz up
to 64GB ECC memory, advanced Intel® UHD Graphics P630/630 supporting
DirectX 12, OpenGL 4.5 and OpenCL 2.0 API, onboard DVI-I, DVI-D and
DisplayPort display interface for Ultra HD 4K resolution. ECX-1000 delivers
new generation CPU & chipset performance, power efficiency, and graphics
performance; multiple 10GigE (10Gbps), PCIe 3.0 (8GT/s), SATA III (6Gbps),
USB 3.1 (5Gbps), PoE (1Gbps) LAN and wireless connections make seamless
real-time high-speed data conveying possible. Vecow ECX-1000 Series Fanless
Embedded System delivers outstanding system performance and power
productivity for demanding workloads in real-time mission critical embedded
computing applications.
Fanless -40°C to 75°C operating temperature, onboard DVI-I, DVI-D and
DisplayPort display interfaces support triple independent displays, 9 GigE
LAN ports with 4 IEEE 802.3at (25.5W/48V) PoE+ without additional power
connections, max 6 external USB 3.1 connections, 2 Front-access 2.5" SSD/
HDD trays, up to 5 Mini PCIe expansions for multiple WiFi/4G/3G/LTE/GPRS/
UMTS wireless data transfer, 1 Front-access CFast socket, 2 SATA III support
software RAID function, 4 COM RS-232/422/485, 2 M.2 expansions, 16 Isolated
DIO, 6V to 36V wide range power input with 80V surge protection, congurable
ignition power control, smart remote management features, remote power
switch, EN50155 and EN50121-3-2 compliant, optional full function SUMIT A,
B expansion supports multiple 10GigE RJ45/SPF+ Fiber connections, Vecow
ECX-1000 Series Fanless Embedded System serves new-generation compact
integrated functions for any AI-oriented embedded applications.
With outstanding system performance, leading integrated features & functions,
smart manageability, flexible mobile availability, secure power protection and
rugged reliability, Vecow ECX-1000 Series Fanless Embedded System is your
great solution for Machine Vision, Intelligent Automation, Smart Manufacturing,
Intelligent Surveillance, Vehicle Computing, Robotic Control, and any Articial
Intelligence oriented real-time Industrial IoT or Industry 4.0 embedded
applications.
1

2
©Vecow ECX-1000 User Manual GENERAL INTRODUCTION
1.2 Features
• LGA 1151 Socket supports 6 cores 8th Generation Intel® Xeon®/Core™ i7/i5/i3
Processor (Coffee Lake) with workstation-grade Intel® C246 Chipset
• Fanless, -40°C to 75°C Operating Temperature
• 2 DDR4 2666MHz Memory, up to 64GB
• Up to 9 GigE LAN with 4 IEEE 802.3at PoE+, iAMT 12.0 supported
• 6 Independent GigE LAN with 2 SFP, iAMT 12.0 supported
(ECX-1000-6FR/ECX-1000-6F)
• DVI-I, DVI-D and DisplayPort display interface, up to 4K display
• 6 USB 3.1, 4 COM RS-232/422/485, 16 Isolated DIO
• 2 External SIM Card sockets support WiFi/4G/3G/LTE/GPRS/UMTS
• Storage : Up to 2 Front-access 2.5" HDD/SSD Tray, 1 Front-access CFast
Socket, 1 M.2 Socket
• Expansion : SUMIT A, B, M.2, up to 5 Mini PCIe
• 6V to 36V DC Power Input with 80V Surge Protection
• Configurable Ignition Power Control
• Optional supports multiple 10GigE RJ45/10GigE SFP+ Configuration
(ECX-1055R/ECX-1055/ECX-1071R/ECX-1071)
