Vega PROTRAC Series User manual

Operating Instructions
Supplementary electronics
PROTRAC sensors
PT30ZE
Document ID: 63552

2
Contents
Supplementary electronics • PROTRAC sensors
63552-EN-200814
Contents
1 About this document ............................................................................................................... 3
1.1 Function ........................................................................................................................... 3
1.2 Target group ..................................................................................................................... 3
1.3 Symbols used................................................................................................................... 3
2 For your safety ......................................................................................................................... 4
2.1 Authorised personnel ....................................................................................................... 4
2.2 Appropriate use................................................................................................................ 4
2.3 Approvals ......................................................................................................................... 4
2.4 Environmental instructions ............................................................................................... 4
3 Product description ................................................................................................................. 5
3.1 Conguration.................................................................................................................... 5
3.2 Principle of operation........................................................................................................ 5
3.3 Packaging, transport and storage..................................................................................... 5
4 Mounting................................................................................................................................... 7
4.1 Installation procedure....................................................................................................... 7
4.2 Electronics versions ......................................................................................................... 8
5 Maintenance ........................................................................................................................... 11
5.1 How to proceed if a repair is necessary.......................................................................... 11
6 Dismount................................................................................................................................. 12
6.1 Dismounting steps.......................................................................................................... 12
6.2 Disposal ......................................................................................................................... 12
7 Supplement ............................................................................................................................ 13
7.1 Technical data ................................................................................................................ 13
Editing status: 2020-08-13

3
1 About this document
Supplementary electronics • PROTRAC sensors
63552-EN-200814
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
ThissymbolindicatesspecialinstructionsforExapplications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

4
2 For your safety
Supplementary electronics • PROTRAC sensors
63552-EN-200814
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
The components described in this manual are replacement compo-
nentsforexistingsensors.
2.3 Approvals
If the instrument comes with approvals, the associated approval
documents of the sensor must always be noted. They are included
with the delivery but can also be downloaded under www.vega.com
via " VEGA Tools" and " Search" as well as via " Downloads" and "
Approvals".
2.4 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
to DIN EN ISO 14001.
Pleasehelpusfullthisobligationbyobservingtheenvironmental
instructions in this manual:
• Chapter " Packaging, transport and storage"
• Chapter " Disposal"

5
3 Product description
Supplementary electronics • PROTRAC sensors
63552-EN-200814
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Supplementary electronics for PROTRAC sensors
• Documentation
– This operating instructions manual
– Ifnecessary,furthercerticates
3.2 Principle of operation
The supplementary electronics module PT30ZE is a replacement
module for PROTRAC sensors with double chamber housing:
• FIBERTRAC
• SOLITRAC
• MINITRAC
• POINTRAC
• WEIGHTRAC
The supplementary electronics for PROTRAC sensors is used for
connection of a sensor with double chamber housing to the signal
cable.
3.3 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Notexposedtocorrosivemedia
• Protected against solar radiation
• Avoiding mechanical shock and vibration
Scope of delivery
Application area
Functional principle
Packaging
Transport
Transport inspection
Storage

6
3 Product description
Supplementary electronics • PROTRAC sensors
63552-EN-200814
• Storage and transport temperature see chapter " Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
Storage and transport
temperature

7
4 Mounting
Supplementary electronics • PROTRAC sensors
63552-EN-200814
4 Mounting
4.1 Installation procedure
The supplementary electronics is installed in the adjustment and con-
nection compartment. The following illustration shows the position of
the adjustment and connection compartment in the double chamber
housing.
2
1
Fig. 1: Position of adjustment and connection compartment ( supplementary
electronics) and electronics and connection compartment (sensor electronics)
1 Electronics and connection compartment (sensor electronics)
2 Adjustment and connection compartment (supplementary electronics)
Proceed as follows:
1. Unscrew the housing cover of the adjustment and connection
compartment (supplementary electronics)
1
3
2
5
Display4...20mA
678
12
+
( ) (-)
Fig. 2: Adjustment and connection compartment with supplementary electronics
1 Supplementary electronics
2 Dismounting tool
3 Screws (2 pcs.)
Installation procedure

8
4 Mounting
Supplementary electronics • PROTRAC sensors
63552-EN-200814
2. Loosen the two holding screws (3) of the supplementary electron-
icswithascrewdriver(TorxsizeT10orslotsize4)
3. Pull the previous supplementary electronics out by using the
dismounting tool (2).
4. Insert the new supplementary electronics module (1) carefully.
5. Screw in the two holding screws (3) and tighten them
6. Screw the housing lid back on
Thesupplementaryelectronicsisexchanged.
Asarule,theexchangeofthesupplementaryelectronicsmustbe
documentedinternallywhenusedinExapplications.
4.2 Electronics versions
4.2.1 Electronics version 4 … 20 mA/HART
1
3
2
5678
Fig. 3: Adjustment and connection compartment with supplementary electronics
- 4 … 20 mA/HART - Non-Ex devices and devices with non-intrinsically safe
current output
1 Supplementary electronics
2 Dismounting tool
3 Screws (2 pcs.)
4 … 20 mA/HART - Non-
Ex devices and devices
with non-intrinsically safe
current output

9
4 Mounting
Supplementary electronics • PROTRAC sensors
63552-EN-200814
1
3
2
5
Display4...20mA
678
12
+
( ) (-)
Fig. 4: Adjustment and connection compartment with supplementary electronics
- 4 … 20 mA/HART - Devices with intrinsically safe current output
1 Supplementary electronics
2 Dismounting tool
3 Screws (2 pcs.)
4.2.2 ElectronicsversionsProbusPA,Foundation
Fieldbus
1
3
2
5678
Fig. 5: Adjustment and connection compartment with supplementary electronics
- Probus PA, Foundation Fieldbus - Non-Ex devices and devices with non-
intrinsically safe signal output
1 Supplementary electronics
2 Dismounting tool
3 Screws (2 pcs.)
4 … 20 mA/HART - De-
vices with intrinsically
safe current output
ProbusPA,Founda-
tion Fieldbus - Non-Ex
devices and devices with
non-intrinsically safe
signal output

10
4 Mounting
Supplementary electronics • PROTRAC sensors
63552-EN-200814
1
3
2
5
DisplayBus
678
12
+
( ) (-)
Fig. 6: Adjustment and connection compartment with supplementary electronics
- Probus PA, Foundation Fieldbus - Devices intrinsically safe signal output
1 Supplementary electronics
2 Dismounting tool
3 Screws (2 pcs.)
ProbusPA,Foundation
Fieldbus - Devices with
intrinsically safe signal
output

11
5 Maintenance
Supplementary electronics • PROTRAC sensors
63552-EN-200814
5 Maintenance
5.1 How to proceed if a repair is necessary
Youcanndaninstrumentreturnformaswellasdetailedinformation
about the procedure in the download area of our homepage. By doing
this you help us carry out the repair quickly and without having to call
back for needed information.
In case of repair, proceed as follows:
• Printandlloutoneformperinstrument
• Clean the instrument and pack it damage-proof
• Attach the completed form and, if need be, also a safety data
sheet outside on the packaging
• Ask the agency serving you to get the address for the return ship-
ment.Youcanndtheagencyonourhomepage.

12
6 Dismount
Supplementary electronics • PROTRAC sensors
63552-EN-200814
6 Dismount
6.1 Dismounting steps
Warning:
Before dismounting, be aware of dangerous process conditions such
as e.g. pressure in the vessel or pipeline, high temperatures, cor-
rosiveortoxicmediaetc.
Take note of chapters " Mounting" and " Connecting to voltage sup-
ply" and carry out the listed steps in reverse order.
6.2 Disposal
The instrument consists of materials which can be recycled by spe-
cialised recycling companies. We use recyclable materials and have
designed the electronics to be easily separable.
WEEE directive
The instrument does not fall in the scope of the EU WEEE directive.
Article2ofthisDirectiveexemptselectricalandelectronicequipment
from this requirement if it is part of another instrument that does not
fall in the scope of the Directive. These include stationary industrial
plants.
Pass the instrument directly on to a specialised recycling company
and do not use the municipal collecting points.
If you have no way to dispose of the old instrument properly, please
contact us concerning return and disposal.

13
7 Supplement
Supplementary electronics • PROTRAC sensors
63552-EN-200814
7 Supplement
7.1 Technical data
Technical data
The technical data are listed in the operating instructions manual of the respective device.

14
Notes
Supplementary electronics • PROTRAC sensors
63552-EN-200814

15
Notes
Supplementary electronics • PROTRAC sensors
63552-EN-200814

Printing date:
VEGA Grieshaber KG
Am Hohenstein 113
77761 Schiltach
Germany
63552-EN-200814
All statements concerning scope of delivery, application, practical use and operat-
ing conditions of the sensors and processing systems correspond to the information
available at the time of printing.
Subject to change without prior notice
© VEGA Grieshaber KG, Schiltach/Germany 2020
Phone [phone]
Fax [phone]
E-mail: [email protected]
www.vega.com
