Velleman 3DPEN User manual

3DPEN
3D PRINTING PEN
3D-PEN
STYLO 3D
BOLÍGRAFO 3D
3D-STIFT
USER MANUAL 3
GEBRUIKERSHANDLEIDING 7
MODE D'EMPLOI 12
MANUAL DEL USUARIO 17
BEDIENUNGSANLEITUNG 22

3DPEN
V. 01 –07/08/2014 2 ©Velleman nv

3DPEN
V. 01 –07/08/2014 3 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that
disposal of the device after its lifecycle could harm the
environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a specialized
company for recycling. This device should be returned to
your distributor or to a local recycling service. Respect the local
environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly
before bringing this device into service. If the device was damaged in
transit, do not install or use it and contact your dealer.
2. Safety Instructions
Persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge,
should not use this appliance unless they have been given
supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
Children shall be supervised to ensure that they do not play
with the appliance.
For educational purposes only! To be used under the direct
supervision of an adult.
Indoor use only. Keep this device away from rain,
moisture, splashing and dripping liquids.
Always disconnect mains power when the device is not in
use. Handle the power cord by the plug only.

3DPEN
V. 01 –07/08/2014 4 ©Velleman nv
DO NOT disassemble or open the cover. There are no user-
serviceable parts inside the device. Refer to an authorized
dealer for service and/or spare parts.
Caution: Device heats up during use. Place the device on a
flat, heat-resistant surface. Do not place the device on
carpets, fabrics…
Do not use the device when damage to housing or cables is
noticed. Do not attempt to service the device yourself but
contact an authorised dealer.
3. General Guidelines
Refer to the Velleman®Service and Quality Warranty on the last
pages of this manual.
Protect this device from shocks and abuse. Avoid brute
force when operating the device.
Familiarise yourself with the functions of the device before actually
using it.
All modifications of the device are forbidden for safety reasons.
Damage caused by user modifications to the device is not covered
by the warranty.
Only use the device for its intended purpose. Using the device in
an unauthorised way will void the warranty.
Damage caused by disregard of certain guidelines in this manual
is not covered by the warranty and the dealer will not accept
responsibility for any ensuing defects or problems.
Do not switch the device on immediately after it has been exposed
to changes in temperature. Protect the device against damage by
leaving it switched off until it has reached room temperature.
Keep this manual for future reference.
4. Features
heat extrusion
filament: 1.75 mm ABS (included)
adjustable printing speed
for product designers, hobbyists and students

3DPEN
V. 01 –07/08/2014 5 ©Velleman nv
5. Overview
Refer to the illustrations on page 2 of this manual.
1
wire-feeding hole
5
heating nozzle
2
LEDs
6
wire-feeding button
3
temperature controller
7
wire-unloading button
4
speed controller
8
power input
6. Operation
1. Insert the power plug from the adapter into the power input [8].
Connect the adapter to the mains. The orange power LED [2a]
will light.
2. Press the wire-feeding button [6] once. The heating LED [2b]
will light red to indicate the pen is preheating.
3. Leave the pen to preheat for about 1 minute or until the heating
LED [2b] turns green.
4. Insert the filament through the wire-feeding hole [1] and hold
the wire-feeding button [6] pressed to load it into the pen. Wait
for molten filament to come out of the nozzle [5].
5. The pen is now ready for use. Adjust the feeding speed with the
speed controller [4] if necessary.
6. When done drawing, hold the wire-unloading button [7] pressed
to unload the filament out of the pen. Next, hold the wire-
feeding button [6]pressed to extrude molten filament rests and
to clean the inside of the nozzle [5]. Disconnect the pen from
the mains and leave it to cool down before storing.
Notes:
Do not touch the nozzle when the pen is switched on!
The pen will switch to stand-by after 5 minutes of inactivity.
Repeat step 2 above to reheat the pen.
Preheating time depends from the set temperature (adjust
through the temperature controller [3]) and the ambient
temperature. Make sure the set temperature is correct:
otoo hot: filament will be too hot and watery
otoo cold: filament will not melt
Cut off the end of the filament before inserting it through the
wire-feeding hole [1].
Always unload the filament and clean the inside of the nozzle [5]
after each use (see step 6 above).
