Aufbauanleitung / assembly instructions mod.
Q647, Q648 EXTEND mit Mittenauszug / with middle
extension
1. Montagematerial
1. fitting material
2. Den Oberbau umgedreht auf eine ebene
Fläche ablegen und die Verpackung öffnen.
Die alteplatte abschrauben und die
Inbusschrauben aufheben.
2. Put the table top upside down onto the floor
and open the packing.
Unscrew the holding plate and keep the socket
screws.
3. Die alteplatte umgedreht auf gepolsterten
Montageböcken ablegen.
3. Put the holding-plate upside down onto padded
assembling trestles.
4. Die Füße mit je 2 Unterlegscheiben und 2
Muttern fixieren.
4. Fi the table legs with each 2 washers and 2
nuts.
Q647, Q648 EXTEND mit Mittenauszug.odt 1 / 5 Änderungsdatum: 11.01.18
8x
4,5 x 45
8x
29,5 x 10,5
8x
M10
M10
29,5 x 10,5
M10
SW4
5. Den Unterbau wenden.
5. Turn the table-base right-side-up.
6. Den Oberbau auspacken und so auf dem
Unterbau positionieren, dass die Bohrungen
fluchten.
6. Unpack the table top and put it onto the base
so that the bore holes align.
7. Auf beiden Seiten je 3 Inbusschrauben wieder
einschrauben, welche unter Punkt 2
ausgeschraubt worden sind.
7. Fi both sides by using a he -wrench and 3
socket screws each, which have been
unscrewn unter No. 2.
8. Auf den beiden anderen Seiten je 4 Spax-
Schrauben einschrauben.
8. Screw in each 4 Spa -screws at the other
sides.
Q647, Q648 EXTEND mit Mittenauszug.odt 2 / 5 Änderungsdatum: 11.01.18
M6 x 30
SW4
4,5 x 45
9. Vor dem Ausziehen auf beiden Seiten die
schwarzen Bremshebel lösen.
9. Loose the black brake-levers on both sides
before e tending the table.
10. Prüfen, ob die Oberkanten des Auszugs und
der auptplatte außen auf einer öhe sind.
Wenn nicht … → siehe Punkte 11 / 12
10. Check at the table edges, if the upper
surfaces of the table top and the e tension
align.
If not … → see step 11 / 12
Q647, Q648 EXTEND mit Mittenauszug.odt 3 / 5 Änderungsdatum: 11.01.18
Rechte Seite einstellen:
Adjust right side:
11a: Auszug einklappen.
11b: An beiden weißen Stellschrauben mit einem
Schlitz-Schraubendreher die öhe
einstellen.
11c: Die Klappeinlage mit dem Ledergriff aus-
klappen, die öhe rechts erneut kontrollie-
ren und wenn nötig erneut einstellen.
11a. Fold in the e tension.
11b. Adjust the hight by turning the two white
screws. Use a slotted screwdriver.
11c. Swing out the e tension by using the leather
strap. Check the hight again; if necessary
adjust again.
Linke Seite einstellen:
Adjust left side:
12a. Die Klappeinlage fassen und beide Teile
gleichzeitig vorsichtig hochklappen...
12a. Take both pieces of the table e tension and
fold out both pieces of the table e tension
at once ...
12b. … und beide albteile ganz umklappen.
Die öhe mit einem Kreuz-Schraubendreher
an den schwarzen Laschen einstellen.
12b. … and fold over both pieces.
Turn the scews of the black plastic-straps to
adjust the hight.
Q647, Q648 EXTEND mit Mittenauszug.odt 4 / 5 Änderungsdatum: 11.01.18
weiße Stellschrauben
white adjusting-screws
13. Fertiger Tisch; Auszug eingeklappt.
13. Finished table; not e tended.
14. Fertiger Tisch; ausgezogen.
14. Finished table; e tended.
Q647, Q648 EXTEND mit Mittenauszug.odt 5 / 5 Änderungsdatum: 11.01.18
