Verano V610 Oslo User manual

Conservatory awning
V610 Oslo
Installation manual

2
Installation V610-Oslo
A V610-Oslo with a width above the 5 meter must be linked.
Attention! Link exactly above the heart of the click frames. (See Figure 2)
1 Mounting the feet and side guides
• Mount the feet on the veranda roof. The feet are placed in the middle of the guides.
We advise to place the upper foot 100 mm from the bin, at the bottom also around 1000 mm from the bottom of the
 prole (See Figure 4 and 5)
• Slide the high foot in the side guide and mount the side guide to the foot on the veranda roof. (See Figure 3)
Attention! We advise to place a intermediate roll with a projection larger than 3500 mm.
Also mount the fabric roll supports in the side guide. (See Figure 1 and 3)
• Aerallthesideguidesaremounted,youneedtomakesurethatallsideguidesaremeasuredequalbothparalleland
diagonal. (See Figure 6)
• Slide the V610-Oslo in the side guides.
Important before installation
Be careful for damages
Don’t use a knife or any other sharp object when opening the packing. This may cause damage to the content of the
package.Putthecontentofthepackageonasosurface.
Be careful when drilling, falling drill cuttings can cause damages.
General warning
Installing the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the installation of
thisspecicVerano®product.Ifyoucannotinstalltheproductyourself,youcanalwaysoptforprofessionalinstallation.
The installation team of Verano® is pleased to help you.
Necessary tools
• Drilling machine
• Metal drill 3,5 mm
• Stitch- or ring wrench 10 mm
• Crosshead screwdriver
• Allen key set
• Ladder
• Tapeline
• Level
• cord
• Pencil
• Plastic hammer
• Installation manual
Subject to misprints, errors and technical modifications.

Installation manual V610 Oslo
3
Awning length
45 200
26,75 26,75
65
178
36
166
Intermediate roll
Awning width
Total awning width
Foot
High foot
Foot
High foot
Guide
Intermediate roll
Awning length
45 200
26,75 26,75
65
178
36
166
Intermediate roll
Awning width
Total awning width
Foot
High foot
Foot
High foot
Guide
Intermediate roll
100 100
300
Measured diagonal, all measurements equal Measured diagonal, all measurements equal
Awning width
60
(= distance to the wall)
5
Awning length
100
26,75
100
300
Awning length
60
100200
Sizes in mm
Fig. 1 Side view
Fig. 4 Side view, mounting feet Fig. 5 Top view, mounting feet
Fig. 2 Front view
Fig. 3 Front view foot and intermediate roll
Fig. 6 Top view
14010206-161103EN

4
2 The cord (see Figure 7)
• Open the cover of the conservatory awning.
• Dismount the cover from the pull frame.
• Loosenthecordatthecordxationblockandloosenthexationscrew.
• Demount the covers of the rotary wheel blocks.
• Blocktheconnectionbetweentheleandrightcordbystickingascrewdriverthroughtheclosureandpullframe.
There is a hole in the pull frame intended for this purpose.
Attention!
Maximum 4 cm above the values of the advise table.
In case of exceptional measures of the V610-Oslo take one
step higher in the table.
*Thespanlengthisthedierencebetween
the tensioned spring and the spring without tension.
This can simply be measured.
Projection Span length*
cm cm
150 6
200 6
250 7
300 7
350 8
400 8
450 10
500 10
Rota
ry wheel block
B
2x
Side guide
Cord melter
Cord disk
Conservatory car
Mount the
bearing hub
1
2
3
4
5
7
9
6
8
0
Cord fixation block
Fixation screw
Check if the cords run
properly over the pulleys.
Warning!
There must be two strokes of cord
on the cord disk at all times.
Fig. 7
Subject to misprints, errors and technical modifications.

Installation manual V610 Oslo
5
3
4
5
2
6
6
1
3 Optional: Linking the V610 Oslo (see Figure 8)
A linked V610 Oslo has a coupling pin already mounted in the motor section.
1. Place the part with the motor.
2. Demount the coupling pin. Therefore remove the allen screws M6 (1) on the plug at the motor side and remove
the strip (2).
3. LinktheV610-Osloboxesbyputtingthemagainsteachotherwiththeincludedxationmaterial.
4. Remove the allen screws M6 (1) on the part without the motor and take strip (2) away.
5. Remove the allen screws M6 (3), the strips (4) and the bearings (5).
6. Tightly turn the gag with fabric at the non-motor side. Due to transportation this gag can be twisted.
7. Place the axis with bearings.
Warning! Make sure that the slots in both plugs (6) are oriented to the opening in the end caps.
8. Place the strips (2) back and tighten all screws M6 (1) evenly.
9. Place the strips (4) back and tighten them with the allen screws (3).
4 The cord, continued (see Figure 7)
• Place the cord on the rotary wheel block and pull it to the end of the side guide.
• Do the same at the other side.
• Then pull the cord to tension at a closed V610-Oslo according to the table in Figure 7.
Fig. 8
14010206-161103EN

6
5 Finishing
• Adjust the motor regarding the included adjustment details.
• Close the box.
• Close the pull frame.
Remark
At larger widths of the V610 Oslo the pull frame without a cover can sag, making it appear that the cover is too wide.
 Toclosethepullframe,youneedtoliitslightlyinthemiddle.
Subject to misprints, errors and technical modifications.

Installation manual V610 Oslo
7
controler no.
date
particulars
Warranty conditions
The factory warranty is valid only if the assembly has been executed by a
certiedengineer(professionalplacement).Duringthemanufacturingofits
products, Verano® has used the greatest precision. However, if during the
normaluseandmaintenancewithin5yearsaerthepurchasedate,there
are faults resulting from manufacture or construction errors, provided that
all the instructions concerning the correct use and maintenance have been
followed, Verano® will put at the dealer’s disposal the replacement material,
for free.
Warranty:
- The term is not extended or renewed because of repair or the
replacement of faulty parts;
- Does not include the replacement of fuses, limit switches and slide
contacts;
- It is Verano®’s obligation to give to the buyer whatever right
to compensation or dissolution of the purchase contract;
- Verano®reservesitsright,withoutpreviousnotication,tocarryout
changes in its products;
- All our transactions occur according to the conditions deposited
at the Chamber of Commerce in Eindhoven under number 17119924;
- Small colour changes can occur due to the fact that the ordered
colours are manufactured according to the number or that a present
steel colour is imitated;
- The paintwork is not resistant to strong chemicals and /or damage
with a sharp tool;
- Some colour shade can occur due to the fact that the colours can be
 moreorlesseectedbyUV-radiation(sunlight).
The warranty elapses:
- Asaresultofinsuicientmaintenanceorincorrectuse;
- Theproductisnotttedbyacertiedengineer;
- Normal wear resulting from use;
- Discolorationduetoeectsofweather;
- Faulty assembly.
The second party does not derive a right from the warranty other than the
one above mentioned, especially the right to compensation in case of con-
sequentiallossandalsoduetofaultsofthirdparties.Alsoinconsequential
damagewillnotbecompensated.Thesecondpartyindemniesusagainst
alltheconsequencesoftheotherclaimsofhiscustomers.
