Vertiv NetSure 2100 Series User manual

NetSure™ 2100 Series
-48 VDC Power System
User Manual
Specification Number: 582138000
Model Number: 2100

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iii
TABLE OF CONTENTS
Admonishments Used in this Document.............................................................................................................................iv
Important Safety Instructions..................................................................................................................................................v
1Customer Documentation Package..................................................................................................................................1
2System Description ...............................................................................................................................................................2
3Operating Procedures..........................................................................................................................................................3
3.1 Controller and Rectifier ...........................................................................................................................................................................................................................................3
3.2 Controller Battery Charge Current Limit Feature...........................................................................................................................................................................3
3.3 Local Controls and Indicators ...........................................................................................................................................................................................................................3
4Maintenance.............................................................................................................................................................................4
4.1 System Maintenance Procedures..................................................................................................................................................................................................................4
4.2 Adding a Rectifier .........................................................................................................................................................................................................................................................4
4.3 Field Installing Compact Type Load Distribution Circuit Breakers in a List BA and List BB Distribution Unit.....................4
5Troubleshooting and Repair ..............................................................................................................................................5
5.1 Contact Information....................................................................................................................................................................................................................................................5
5.2 Controller and Rectifier ...........................................................................................................................................................................................................................................5
5.3 Controller Configuration.........................................................................................................................................................................................................................................5
5.4 System Troubleshooting Information ........................................................................................................................................................................................................5
5.4.1 Contact Information.............................................................................................................................................................................................................................5
5.4.2 General.............................................................................................................................................................................................................................................................5
5.4.3 Troubleshooting Alarm Conditions on the Controller..........................................................................................................................................5
5.4.4 Checking the Controller’s Current Limit Point after Adding or Removing a Rectifier ...........................................................5
5.4.5 Clearing a Rectifier Communications Fail Alarm after Removing a Rectifier .................................................................................6
5.4.6 Clearing a Rectifier Lost Alarm..................................................................................................................................................................................................6
5.5 Replacement Information......................................................................................................................................................................................................................................6
5.5.1 Replacement Assemblies................................................................................................................................................................................................................6
5.6 Replacement Procedures......................................................................................................................................................................................................................................6
5.6.1 Replacing a Rectifier............................................................................................................................................................................................................................6
5.6.2 Replacing the Mini Control Unit................................................................................................................................................................................................6
5.6.3 Replacing a GMT Distribution Fuse......................................................................................................................................................................................7
5.6.4 Replacing a Bullet Nose Circuit Breaker...........................................................................................................................................................................9
5.6.5 Replacing a Compact Circuit Breaker ...............................................................................................................................................................................12
5.6.6 Replacing the External IB4 Assembly (if furnished)........................................................................................................................................... 14

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iv
Admonishments Used in this Document
DANGER
! Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING
! Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided. This admonition is not used for situations that pose a
risk o
nly to equipment, software, data, or service. (ANSI)
CAUTION
! Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable standards. (OSHA)
ALERT
!Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (ISO)
ALERT
! Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption. (ISO)
FIRE SAFETY
! Informs the reader of fire safety information, reminders, precautions,
or policies, or of the locations of fire
-fighting and fire-safety equipment. (ISO)
SAFETY
! Informs the reader of general safety information, reminders, precautions, or
policies not
related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA)

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
v
Important Safety Instructions
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on page iv.
Safety and Regulatory Statements
Refer to Section 4154 (provided with your customer documentation) for Safety and Regulatory Statements.
Déclarations de Sécurité et de Réglementation
Reportez-vous à la Section 4154 (fourni avec les documents de votre client) pour les déclarations de sécurité et de réglementation.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
vi
This page intentionally left blank.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
1
1Customer Documentation Package
This document (UM582138000) provides User Instructions for the Vertiv™ NetSure™ 2100 Series -48 VDC Power System: Model
2100, Spec. No. 582138000.
The complete Customer Documentation Package consists of…
Document Number Document Description How Provided
IM582138000 Power System Installation Instructions Printed Manual and PDF File
UM1M831ANA Mini Control Unit User Instructions Printed Manual and PDF File
(Per configuration file loaded into controller) Mini Control Unit Configuration Drawing (C-drawing) Printed Document and PDF File
UM582138000 Power System User Instructions
PDF files are provided on a supplied USB drive.
See also Note 1.
SAG582138000 Power System “System Application Guide”
UM1R481000e3 Rectifier Instructions
Section 4154 Contact Information Page
SD582138000 Power System Schematic Diagram
T582138000 Power System Wiring Diagram
Note 1: Also provided on the USB drive is a controller configuration drawing and the controller configuration files loaded into the
controller as shipped.
For factory settings of all configurable controller parameters, refer to the controller configuration drawing (C-drawing) supplied with
your power system.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
2
2System Description
-48 VDC @ up to 62.5 Amperes Power System
The Vertiv™ NetSure™ 2100 Series -48 VDC Power System is an integrated power system containing rectifiers, intelligent control,
metering, monitoring, and distribution.
The power system is designed to power a load while charging a positive grounded battery. The power system is capable of operating
in a batteryless installation or off battery for maintenance purposes.
The Vertiv NetSure 2100 Series -48 VDC Power System consists of the following components mounted in a 19” or 23” wide relay rack
or cabinet rack. Wall mounting options are also available.
NetSure™ Mini Control Unit (Controller)
The controller provides power system control (including optional Low Voltage Battery Disconnect [LVBD]), rectifier control (including
a charge control function), metering functions, monitoring functions, local/remote alarm functions, and connections for binary inputs
and programmable relay outputs. The controller also supports rectifier temperature compensation if the system is equipped with a
temperature probe(s). Temperature probe(s) may also be designated to monitor ambient temperature and/or battery temperature.
The controller also provides data acquisition, system alarm management, and advanced battery and energy management. The
controller contains a front panel display and keypad for local access. The controller provides an Ethernet port and comes with
comprehensive webpages for remote access. The controller has optional SNMP v3 capability for remote system management. Refer
to the mini control unit instructions (UM1M831ANA) for more information.
Rectifier Modules
The system contains rectifier modules which provide load power, battery float current, and battery recharge current during normal
operating conditions. Refer to the rectifier instructions (UM1R481000e3) for more information.
Distribution Unit
Various distribution unit options are available. See SAG582138000 for descriptions. The distribution unit can be equipped with an
optional Low Voltage Battery Disconnect (LVBD) contactor. The various distribution units provide DC distribution through circuit
breakers and/or fuses.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
3
3Operating Procedures
3.1 Controller and Rectifier
For operation instructions on these units, refer to the following documents.
•Mini Control Unit Instructions: UM1M831ANA
NOTE! The controller’s default “User Name” is "admin" and the default “Password” is “640275”.
•Rectifier Instructions: UM1R481000e3
3.2 Controller Battery Charge Current Limit Feature
Functionality: After a failure of the input source (commercial AC) or when some battery cells are permanently damaged, the current
to the batteries can be quite extensive. To avoid overheating or further damages to the battery, the controller can be programmed to
limit the battery current to a preset level by limiting the charging voltage of the rectifiers. Should the battery current still exceed a
higher preset value, an alarm is issued.
The controller limits the current going to the batteries based on the “Battery Current Limit” set point which is a percentage of the
battery capacity in C10. For example, 0.1C10 would mean 10% of the battery capacity.
Refer to the mini control unit Instructions (UM1M831ANA) to program this feature. Battery charge current is limited to the value set in
the controller, as long as battery voltage is above 47 VDC.
3.3 Local Controls and Indicators
Controller and Rectifier
Refer to the controller and rectifier instructions for descriptions of the local controls and indicators located on these units.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
4
4Maintenance
4.1 System Maintenance Procedures
It is recommended to perform the maintenance procedures listed in Table 4.1 every 6 months to ensure continual system operation.
Table 4.1 Maintenance Procedures to be Performed at 6-Month Intervals
Procedure Referenced In
Check ventilation openings for obstructions such as dust, papers, manuals, etc. --
Inspect and tighten all installer's connections. IM582138000
4.2 Adding a Rectifier
To increase system current capacity, a rectifier module can easily be added if an empty rectifier module mounting position is available.
Refer to rectifier instructions UM1R481000e3 for a rectifier installation procedure.
4.3 Field Installing Compact Type Load Distribution Circuit Breakers in a List
BA and List BB Distribution Unit
Refer to "Installing Compact Type Load Distribution Circuit Breakers (List BA, BB)" in the Installation Manual (IM582138000).

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
5
5Troubleshooting and Repair
5.1 Contact Information
Refer to Section 4154 (provided with your customer documentation) for support contact information.
5.2 Controller and Rectifier
For troubleshooting and repair instructions on these units, refer to the following documents.
•Mini Control Unit Instructions: UM1M831ANA
•Rectifier Instructions: UM1R481000e3
5.3 Controller Configuration
If any controller configuration settings were changed, refer to the mini control unit instructions (UM1M831ANA) and save a copy of
the configuration file. This file can be used to restore the controller settings, if required, at a later date.
NOTE! Provided on a USB drive furnished with the system is a controller configuration drawing (C-drawing) and the
controller configuration files loaded into the controller as shipped.
5.4 System Troubleshooting Information
5.4.1 Contact Information
Refer to Section 4154 (provided with your customer documentation) for support contact information.
5.4.2 General
This system is designed for ease in troubleshooting and repair. The various indicators as described in the controller and rectifier
instructions are designed to isolate failure to a specific element. Once the faulty element has been identified, refer to “Replacement
Information” on page 6 and “Replacement Procedures” on page 6.
5.4.3 Troubleshooting Alarm Conditions on the Controller
The controller displays alarm conditions as listed in the “Resolving Alarms” section of the controller’s user manual. Programmable
external alarm relays are also available. Refer to the system installation instructions (IM582138000) and the controller configuration
drawing (C-drawing) supplied with your power system documentation for your alarm relay configurations.
The controller’s Active Alarm and Alarm History submenus allow the user to view alarm details. Refer to the mini control unit
instructions (UM1M831ANA) to access these menus.
5.4.4 Checking the Controller’s Current Limit Point after Adding or Removing a Rectifier
If a rectifier module is added; the respective current limit point in amps will automatically increase to maintain the same percentage.
For example, if the current limit was set to 100% of combined capacity and a rectifier module is added, the new current limit setpoint
will be 100% of the combined capacity including the new rectifier module.
If a rectifier module is removed from the system (and the Rect Comm Fail is cleared), the current limit point will remain unchanged
unless the capacity of the remaining rectifiers is not sufficient to maintain this current limit point. If that happens, the current limit
point will automatically decrease to the maximum (121% of the remaining rectifiers).
It is recommended that the current limit point be checked whenever a rectifier is added to or removed from the power system.
When setting total rectifier current limit, the set point to each rectifier is the total set point divided by the number of rectifiers. For
example, if the system contains three rectifiers and the current limit is set to 30 amps then each rectifier has a current limit set point

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
6
of 10 amps. If one or more rectifiers are removed or fails it will take several seconds for the individual set points to the remaining
rectifiers to be reset. In the example given, if one rectifier is removed the current limit set point will drop to 20 amps (10 amps times
two remaining rectifiers) until the controller can send updated set points to the remaining rectifiers.
This takes a couple communication cycles (several seconds) after which each rectifier would have a new set point of 15 amps for a
total of 30 amps. The total current limit of the rectifiers should not be set such that the loss of the redundant rectifiers will cause this
temporary set point to drop below the actual maximum expected load. If batteries are used on the rectifier output, the batteries
should support the load until the current limit set points can be re-established due to loss of a rectifier.
Refer to the mini control unit instructions (UM1M831ANA) for a procedure.
5.4.5 Clearing a Rectifier Communications Fail Alarm after Removing a Rectifier
If a rectifier module is removed from the system, a rectifier communications failure alarm is generated. If the rectifier module will not
be replaced, the alarm should be cleared.
Refer to the mini control unit instructions (UM1M831ANA) for a procedure to clear the alarm.
5.4.6 Clearing a Rectifier Lost Alarm
If the controller resets while a rectifier communications fail alarm is active, the rectifier communications fail alarm is replaced with a
rectifier lost alarm.
Refer to the mini control unit instructions (UM1M831ANA) for a procedure to clear the alarm.
5.5 Replacement Information
5.5.1 Replacement Assemblies
When a trouble symptom is localized to a faulty rectifier, controller, or system circuit card; that particular device or circuit card should
be replaced in its entirety. No attempt should be made to troubleshoot or repair individual components on any rectifier, controller, or
circuit card.
Refer to system application guide SAG582138000 for replacement part numbers.
5.6 Replacement Procedures
DANGER! Adhere to the “Important Safety Instructions” starting on page v.
5.6.1 Replacing a Rectifier
Refer to the rectifier instructions (UM1R481000e3) for a rectifier replacement procedure. Refer also to “System Troubleshooting
Information” on page 5.
The rectifier being replaced is assigned by the mini control unit the lowest available identification number. If desired, you can change
the identification number, see “Configuring the Mini Control Unit Identification of Rectifiers” in the separate power system installation
manual (IM582138000).
5.6.2 Replacing the Mini Control Unit
Refer to the mini control unit instructions (UM1M831ANA) for a controller replacement procedure.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
7
5.6.3 Replacing a GMT Distribution Fuse
Replace distribution devices with the same type and rating. Refer to system application guide SAG582138000 for part numbers.
Procedure
1. Refer to Figure 5.1, Figure 5.2, Figure 5.3, or Figure 5.4 and replace the fuse. Ensure a safety fuse cover is installed on the
replacement fuse, as shown in Figure 5.5.
2. Verify no alarms are active.
Figure 5.1 GMT Distribution Fuse Replacement (List AA)
Figure 5.2 GMT Distribution Fuse Replacement (List CA)
GMT Fuse
Safety Cover
Front
GMT Fuse
Safety Cover
Front

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
8
Figure 5.3 GMT Distribution Fuse Replacement (List BA)
Figure 5.4 GMT Distribution Fuse Replacement (List BB)
Figure 5.5 Installation of Safety Fuse Covers
GMT Fuse
Safety Cover
Front
GMT Fuse
Safety Cover
Front
Safety Cover
P/N 248898700
(GMT-X)

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
9
5.6.4 Replacing a Bullet Nose Circuit Breaker
Replace distribution devices with the same type and rating. Refer to system application guide SAG582138000 for part numbers.
Procedure
1. Operate the defective circuit breaker to the OFF position.
2. Remove the cover from the circuit breaker mounting positions.
3. List BB: Loosen the distribution unit captive fastener and partially slide the distribution unit out from shelf to facilitate circuit
breaker replacement.
4. Gently rock the defective circuit breaker back and forth while pulling firmly outward until the breaker is free from the
distribution unit.
5. Ensure that the replacement circuit breaker is in the OFF position, and is of the correct rating.
6. Orient the replacement circuit breaker as shown in Figure 5.6 or Figure 5.7. Insert the terminals on the rear of the circuit
breaker into their corresponding sockets on the distribution unit. Ensure the alarm contact on the back of the circuit breaker
makes contact with the alarm terminal on the distribution unit. Push distribution device in firmly until fully seated in the
distribution unit.
7. List BB: Slide the distribution unit back into the shelf and secure with the captive fastener.
8. Replace the cover over the circuit breaker mounting positions and tighten the captive fastener(s).
9. Operate the replacement circuit breaker to the ON position.
10. Verify no alarms are active.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
10
Figure 5.6 Replacing a Bullet Nose Circuit Breaker (List CA)
Load Disconnect Circuit Breakers
Front
Components removed in illustration for clarity only.
Insert these
terminals into
corresponding
sockets on
distribution unit.
Insert these
terminals into
corresponding
sockets on
distribution unit.
Shorter Side
of Breaker
Shorter Side
of Breaker
OFF Position Towards Center
Longer Side
of Breaker
Turn circuit breaker off before installing.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
11
Figure 5.7 Replacing a Bullet Nose Circuit Breaker (List BB)
Turn circuit breaker
off before installing.
Battery Disconnect Circuit Breaker
(OFF Position Towards Left)
Shorter Side
of Breaker
Longer Side
of Breaker
OFF
ON
Front
Front Circuit Breaker Cover
Insert these terminals into
corresponding sockets on
distribution unit.
Insert these terminals into
corresponding sockets on
distribution unit.
Partially slide distribution
unit out of shelf to facilitate
breaker replacement.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
12
5.6.5 Replacing a Compact Circuit Breaker
Replace distribution devices with the same type and rating. Refer to system application guide SAG582138000 for part numbers.
Procedure
1. Operate the defective circuit breaker to the OFF position.
2. Remove the cover from the circuit breaker mounting positions.
3. Loosen the distribution unit captive fastener and partially slide the distribution unit out from shelf to facilitate circuit breaker
replacement.
4. Gently rock the defective circuit breaker back and forth while pulling firmly outward until the breaker is free from the
distribution unit.
5. Ensure that the replacement circuit breaker is in the OFF position, and is of the correct rating.
6. Orient the replacement circuit breaker as shown in Figure 5.8 and Figure 5.9. Insert the terminals on the rear of the circuit
breaker into their corresponding sockets on the distribution unit. Push distribution device in firmly until fully seated in the
distribution unit.
7. Slide the distribution unit back into the shelf and secure with the captive fastener.
8. Replace the cover over the circuit breaker mounting positions and tighten the captive fasteners.
9. Operate the replacement circuit breaker to the ON position.
10. Verify no alarms are active.
Figure 5.8 Replacing a Compact Circuit Breaker (List BA)
Turn circuit breaker
off before installing.
Front
Load Circuit Breakers
Front Circuit Breaker Cover
On
Off
Insert these terminals
(top and bottom) into
corresponding sockets
on distribution unit.
Partially slide distribution
unit out of shelf to facilitate
breaker replacement.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
13
Figure 5.9 Replacing a Compact Circuit Breaker (List BB)
Turn circuit breaker
off before installing.
Front
Load Circuit Breakers
Front Circuit Breaker Cover
On
Off
Insert these terminals
(top and bottom) into
corresponding sockets
on distribution unit.
Partially slide distribution
unit out of shelf to facilitate
breaker replacement.

Vertiv™ NetSure™ 2100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
14
5.6.6 Replacing the External IB4 Assembly (if furnished)
DANGER! Adhere to the “Important Safety Instructions” starting on page v.
WARNING! Circuit cards used in this system contain static-sensitive devices. Refer to Section 4154 (provided with your
customer documentation) for static-sensitive device precautions.
The external IB4 assembly can be replaced with the system operating.
Procedure
1. Performing this procedure may activate external alarms. Do one of the following. If possible, disable these alarms. If these
alarms cannot be easily disabled, notify the appropriate personnel to disregard any future alarms associated with this system
while the procedure is being performed.
WARNING! Damage to the circuit card may result if the next step is not followed.
2. Connect an approved grounding strap to your wrist. Attach the other end to a suitable ground.
3. Loosen the captive fastener securing the latch mechanism to the front of the mini control unit. Pull the latch mechanism
away from the mini control unit (this will retract the latch mechanism located on the bottom of the mini control unit). This
unlocks the mini control unit from the shelf. Slide the mini control unit partially out from the shelf.
4. Carefully label the connectors plugged into the assembly. These connectors must be plugged into the same connectors on
the replacement assembly.
5. Unplug all connectors plugged into the assembly.
6. Replace the defective assembly with the new assembly.
7. Plug all connectors removed from the old assembly into the same position on the replacement assembly.
8. Slide the mini control unit completely into its mounting position. Push the latch mechanism into the front panel of the mini
control unit, and secure by tightening the captive fastener. This locks the mini control unit securely to the shelf.
9. Remove the grounding wrist strap.
10. To verify that the IB4 board is functioning, verify the mini control unit IP address is 192.168.100.100 as follows. From the Main
Screen on the mini control unit local display, press the ESC button, then the ENT key repeatedly until the IP address is
displayed. Verify the displayed IP address is 192.168.100.100.
11. Enable the external alarms, or notify appropriate personnel that this procedure is finished.
12. Ensure that there are no local or remote alarms active on the system.
