Vertiv NetSure 802 Series User manual

NetSure™ 802 Series
-48 VDC Power System
Installation Manual (Section 5876), Revision ZA
Specification Number: 582140000
Model Number: 802NLDB,802NLEB,802NL-B

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
2
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the
pertinent section of this manual to see if the issue can be resolved by following outlined
procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
3
TABLE OF CONTENTS
Admonishments Used in this Document............................................................6
Important Safety Instructions ..............................................................................7
Safety Admonishments Definitions......................................................................................................7
General Safety ...........................................................................................................................................................7
Voltages...........................................................................................................................................................................7
AC Input Voltages........................................................................................................................................................ 7
DC Output and Battery Voltages .................................................................................................................. 7
Battery .............................................................................................................................................................................. 8
Personal Protective Equipment (PPE)............................................................................................. 9
Hazardous Voltage.............................................................................................................................................. 9
Handling Equipment Containing Static Sensitive Components............................. 9
Maintenance and Replacement Procedures..............................................................................9
Static Warning.........................................................................................................10
FCC Information.......................................................................................................11
Customer Documentation Package................................................................... 13
Installation Acceptance Checklist.....................................................................14
Placing the Bays and Installing Internal/External Busbars ........................16
General Requirements....................................................................................................................................16
Placing and Securing List 1 and List 11 Power/Distribution Bays
(without PDSC)...................................................................................................................................................... 17
Placing and Securing List 2 and List 12 Power/Distribution Bays
(with PDSC)...............................................................................................................................................................18
Placing and Securing List 3, 4, 5, 13, 14, and 15 Power Only Bays ......................20
Placing and Securing List 16, 17, 18, 19, and 22 Distribution Only Bays ......... 21
Installing Power/Distribution Bay to Power/Distribution Bay Negative
and Positive Busbar Links...........................................................................................................................41
Installing Power/Distribution Bay to Power/Distribution Bay Negative
and Positive Busbar Links (Newer Style Bay to an Existing Older
Style Bay)....................................................................................................................................................................44
Connecting Power/Distribution Bay Rectifier Mounting Position AC
Input Connectors to PDSC (Lists 2 and 12 Only) ...............................................................46
Installing Power/Distribution Bay External Top-Mount Horizontal
Battery Input Busbar Assembly, P/N 554873 (if furnished).....................................47
Installing Optional Power/Distribution Bay Busbar Shield Kit, P/N
528482 (if furnished) ......................................................................................................................................56
Installing Power/Distribution Bay External Top-Mount Ground (Load
Return) Busbar Assembly; P/N 514688, 514689, 514690, or 514691 (if
furnished) ................................................................................................................................................................... 57
Installing Power/Distribution Bay Load Return Lug Extension Busbar
Assembly, P/N 514543 (if furnished)................................................................................................73
Installing Power/Distribution Bay External Top-Mount Vertical
Battery Input Busbar Assembly, P/N 554874 (if furnished).....................................82

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
4
Installing Distribution Only Bay External Top-Mount Ground (Load
Return) Busbar Assembly; P/N 528775 (if furnished).....................................................91
Installing Distribution Only Bay External Top-Mount Ground (Load
Return) Extension Busbar Assembly; P/N 528780 (if furnished).......................93
Installing Distribution Devices and MCA/LMS Circuit Cards ................... 96
Installing Distribution Fuses and Circuit Breakers ............................................................96
Installing MCA and LMS Circuit Cards ........................................................................................113
Making Electrical Connections..........................................................................117
Observe the Following Admonishments ....................................................................................117
Wiring Considerations...................................................................................................................................117
MCA Network Interconnections Between Bays..................................................................118
Distribution Only Bay BAT RTN Connection to System Monitoring
and Control Section ........................................................................................................................................121
MCA Battery Charge Digital Temperature Compensation Probe
Connection...............................................................................................................................................................121
MCA External CAN Bus Port Connection ................................................................................122
MCA External Alarm, Reference, and Control Connections and MCA
I/O Circuit Card Connections ...............................................................................................................123
LMS Connections (if LMS Furnished).........................................................................................137
Bay Frame Grounding Connections...............................................................................................147
Load Connections........................................................................................................................................... 149
AC Input and AC Input Ground Connections.......................................................................158
Battery Connections.......................................................................................................................................171
Re-Install Shields and Cover Panels.............................................................................................. 177
MCA “Alternate Current Limit” Feature .....................................................................................178
MCA “Power Share” Feature..................................................................................................................179
Connecting the 582140000 System to Other Systems.............................................183
Installing the Rectifiers and Initially Starting the Power System........... 191
Installing the Rectifiers ................................................................................................................................191
Setting Switch S1 on the MCA Circuit Card in the Primary
Power/Distribution or Power Only Bay .......................................................................................192
Setting Jumper J4 on MCA Distribution Bus Monitoring Circuit
Cards.............................................................................................................................................................................192
Initially Starting, Configuring, and Checking System Operation ...................... 196
MCA (Meter, Control, Alarm Panel).......................................................................................................196
Initial Startup Preparation ............................................................................................................................. 203
Initially Starting the System......................................................................................................................... 203
MCA Initialization................................................................................................................................................... 203
Checking the Inventory and Setting the Number of PCU (Rectifier)
Positions Available in the System.......................................................................................................... 207
Setting the Date and Time........................................................................................................................... 208
Setting the Temperature Units (degrees C or degrees F)............................................209
Setting and Testing MCA Customer Alarm Relays (and MCA Relay
Function Channels) .............................................................................................................................................209
Setting MCA I/O Circuit Card Parameters....................................................................................... 211

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
5
Checking Manual Test/Equalize and Manually Initiated Timed
Test/Equalize...............................................................................................................................................................212
Checking High Voltage Shutdown ........................................................................................................ 214
Checking Remote High Voltage Shutdown and Rectifier Emergency
Shutdown (ESTOP) Inputs.............................................................................................................................215
Checking Remote High Voltage Shutdown.................................................................................. 216
Checking Emergency Shutdown and Fire Alarm Disconnect..................................... 216
Checking Remote Test/Equalize..............................................................................................................217
Checking MCA Audible Alarm and MCA Audible Alarm Cutoff.................................217
Checking AC Fail Alarm.................................................................................................................................... 218
Checking Rectifier Fail Alarm...................................................................................................................... 218
Checking System High Voltage Alarm 1........................................................................................... 219
Checking System High Voltage Alarm 2......................................................................................... 220
Checking System Battery Is On Discharge Alarm...................................................................221
Checking Very Low Voltage Alarm.......................................................................................................222
Checking Total Distribution Load Alarm.........................................................................................223
Checking Distribution Group A Load Alarm................................................................................ 224
Checking Distribution Group B Load Alarm .................................................................................225
Checking Fuse Alarm/Circuit Breaker Alarm.............................................................................. 226
Checking Metering Functions.................................................................................................................... 227
Checking System Status................................................................................................................................. 229
Checking and Configuring the LMS System...............................................................................230

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
6
ADMONISHMENTS USED IN THIS DOCUMENT
DANGER
! Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING
! Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided. This admonition is not used for situations that pose a
risk only to equipment, software, data, or service. (ANSI)
CAUTION
! Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable st
andards. (OSHA)
ALERT
! Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (ISO)
ALERT
! Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption. (ISO)
FIRE SAFETY
! Informs the reader of fire safety information, reminders, precautions,
or policies, or of the locations of fire
-fighting and fire-safety equipment. (ISO)
SAFETY
! Informs the reader of general safety information, reminders, precautions, or
policies not related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA)

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
7
IMPORTANT SAFETY INSTRUCTIONS
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this
Document” on page 6.
General Safety
DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
Performing the following procedures may expose you to hazards. These procedures should be
performed by qualified technicians familiar with the hazards associated with this type of equipment.
These hazards may include shock, energy, and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage
or the expected voltage is present. Check for voltage with both AC and DC voltmeters prior to
making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for
the work to be performed.
Voltages
AC Input Voltages
DANGER! This system operates from AC input voltage capable of producing fatal electrical shock. AC
input power must be completely disconnected from the branch circuits wiring used to provide power to
the system before any AC electrical connections are made. Follow local lockout/tagout procedures to
ensure upstream branch circuit breakers remain de-energized during installation. DO NOT apply AC
input power to the system until all electrical connections have been completed and checked.
DC Output and Battery Voltages
DANGER! This system produces DC power and may have a battery source connected to it. Although
the DC voltage is not hazardously high, the rectifiers and/or battery can deliver large amounts of current.
Exercise extreme caution not to inadvertently contact or have any tool inadvertently contact an output
terminal or battery terminal or exposed wire connected to an output terminal or battery terminal.
NEVER allow a metal object, such as a tool, to contact more than one termination or battery terminal at a
time, or to simultaneously contact a termination or battery terminal and a grounded object. Even a
momentary short circuit can cause sparking, explosion, and injury.
DANGER! Follow local lockout/tagout procedures to ensure DC branch circuit protection devices
remain de-energized during installation at loads, as required.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
8
Battery
Refer to the battery manufacturer documentation for specific battery safety instructions. The following are
general guidelines.
WARNING! Correct polarity must be observed when connecting battery leads.
WARNING! Special safety precautions are required for procedures involving handling, installing, and
servicing batteries. Observe all battery safety precautions in this manual and in the battery instruction
manual. These precautions should be followed implicitly at all times.
WARNING! A battery can present a risk of electrical shock and high short circuit current. Servicing of
batteries should be performed or supervised only by properly trained and qualified personnel
knowledgeable about batteries and the required precautions.
The following precautions should be observed when working on batteries:
•Follow the recommended PPE requirements per the SDS for the battery to be used.
•Batteries are an energy source that can produce high amounts of electrical current.
•Remove watches, rings, and other metal objects.
•Eye protection should be worn to prevent injury from accidental electrical arcs.
•Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for
the work to be performed. Ensure that wrenches with more than one working end have only one
end exposed.
•Do not lay tools or metal parts on top of batteries.
•Verify that no current will flow when the battery is connected or disconnected by opening battery
disconnects (if available) or adjusting the system to match battery voltage.
•Risk of explosion if battery is replaced with an incorrect type or if polarity is reversed.
Recommended to replace batteries with the same manufacturer and type, or equivalent.
•Dispose of used batteries according to the instructions provided with the batteries. Do not dispose
of batteries in a fire. They may explode.
•Batteries may generate explosive gases during normal operation. Systems containing batteries
should never be installed in an airtight room or space. Only install in a ventilated environment.
•Batteries may contain sulfuric acid. If battery acid enters your eye, immediately flush your eye with
running cold water for at least 15 minutes. Get medical attention immediately. If battery acid
contacts skin or clothing, wash immediately with soap and water.
•Do not open or mutilate batteries.
•ALWAYS FOLLOW THE BATTERY MANUFACTURER’S RECOMMENDATIONS AND SAFETY
INSTRUCTIONS.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
9
ALERT! Performing maintenance and/or troubleshooting procedures may interrupt power to the loads,
if battery reserve is not sufficient.
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection
boundary analysis should be done determine the “hazard/risk” category, and to select proper PPE.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain
the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work
Permits as required by the local authority, per NFPA 70E “Standard for Electrical Safety in the
Workplace”.
Hazardous Voltage
DANGER! HAZARD OF ELECTRICAL SHOCK.
More than one disconnect may be required to de-energize the system before servicing.
Handling Equipment Containing Static Sensitive Components
ALERT! Installation or removal of equipment containing static sensitive components requires careful
handling. Before handling any equipment containing static sensitive components, read and follow the
instructions contained in “Static Warning” on page 10.
Maintenance and Replacement Procedures
CAUTION! When performing any step in procedures that requires removal or installation of hardware,
use caution to ensure no hardware is dropped and left inside the unit; otherwise service interruption or
equipment damage may occur.
NOTE! When performing any step in procedures that requires removal of existing hardware, retain all
hardware for use in subsequent steps, unless otherwise directed.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
10
STATIC WARNING
This equipment contains static sensitive components. The warnings listed below must be observed to
prevent damage to these components. Disregarding any of these warnings may result in personal injury
or damage to the equipment.
Strictly adhere to the procedures provided in this document.
Before touching any equipment containing static sensitive components, discharge all static
electricity from yourself by wearing a wrist strap grounded through a one megohm resistor. Some
wrist straps have a built-in one megohm resistor; no external resistor is necessary. Read and follow
wrist strap manufacturer’s instructions outlining use of a specific wrist strap.
Do not touch traces or components on equipment containing static sensitive components. Handle
equipment containing static sensitive components only by the edges that do not have connector
pads.
After removing equipment containing static sensitive components, place the equipment only on
static dissipative surfaces such as conductive foam or ESD bag. Do not use ordinary Styrofoam™or
ordinary plastic.
Store and ship equipment containing static sensitive components only in static shielding containers.
If necessary to repair equipment containing static sensitive components, wear an appropriately
grounded wrist strap, work on a conductive surface, use a grounded soldering iron, and use
grounded test equipment.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
11
FCC INFORMATION
The MCA Interface Modem Option (if installed) has been granted a registration number by the Federal
Communications Commission, under Part 68 rules and regulations for direct connection to the telephone lines.
In order to comply with these FCC rules, the following instructions must be carefully read and applicable
portions followed completely:
a) Direct connection to the telephone lines may be made only through the standard plug- ended cord
furnished to the utility-installed jack. No connection may be made to party or coin phone lines. Prior to
connecting the device to the telephone lines, you must:
b) Call your telephone company and inform them you have an FCC registered device you desire to connect
to their telephone lines. Give them the number(s) of the line(s) to be used, the make and model of the
device, the FCC registration number and ringer equivalence. This information will be found on the
device or enclosed with instructions as well as the jack suitable for your device.
c) After the telephone company has been advised of the above you may connect your device if the jack is
available, or after the telephone company has made the installation.
d) Repairs may be made only by the manufacturer or his authorized service agency. Unauthorized repairs
void registration and warranty. Contact seller or manufacturer for details of permissible user performed
routine repairs, and where and how to have other than routine repairs.
e) If, through abnormal circumstances, harm to the telephone lines is caused, it should be unplugged until
it can be determined if your device or the telephone line is the source. If your device is the source, it
should not be reconnected until necessary repairs are affected.
f) Should the telephone company notify you that your device is causing harm, the device should be
unplugged. The telephone company will, where practicable, notify you, that temporary discontinuance of
service may be required. However, where prior notice is not practicable, the telephone company may
temporarily discontinue service, if such action is reasonably necessary, in such cases the telephone
company must (A) Promptly notify you of such temporary discontinuance, (B) Afford you the
opportunity to correct the condition and (C) Inform you of your rights to bring a complaint to the FCC
under their rules.
g) The telephone company may make changes in its communications facilities, equipment, operations or
procedures, where such action is reasonably required in the operation of its business and is not
inconsistent with FCC rules. If such changes can be reasonably expected to render any customer’s
devices incompatible with telephone company facilities, or require modification or alteration, or
otherwise materially affect its performance, written notification must be given to the user, to allow
uninterrupted service.
The following information is provided here and on a label attached to the outside of the MCA Interface Modem
Option (if installed).
JACK
RINGER EQUIVALENCE
FCC REGISTRATION NUMBER
RJ-11
0.2A
B46USA-22429-MM-E

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
12
This page is intentionally blank.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
13
CUSTOMER DOCUMENTATION PACKAGE
NOTE! These instructions are for the NetSure™ 802 Series -48 VDC Power System, Model 802NLDB
(208V Input Power/Distribution and Power Only Bays), 802NLEB (480V Input Power/Distribution and
Power Only Bays), and 802NL-B(Distribution Only Bay); Spec. No. 582140000. This power system is
equipped with the MCA (Meter, Control, Alarm Panel) and LMS (Lorain Monitoring System).
If you have a NetSure™ 8200 Series -48 VDC Power System, Model 8200NLDB (208V Input
Power/Distribution and Power Only Bays), 8200NLEB (480V Input Power/Distribution and Power Only
Bays), and 8200NL-B(Distribution Only Bay); Spec. No. 582140000, refer to IM582140000 provided with
your system. This power system is equipped with the NCU controller.
This document (Section 5876) provides Installation Instructions for the NetSure™ 802 Series -48 VDC Power
System, Model 802NLDB (208V Input Power/Distribution and Power Only Bays), 802NLEB (480V Input
Power/Distribution and Power Only Bays), and 802NL-B(Distribution Only Bay); Spec. No. 582140000.
The complete Customer Documentation Package consists of…
NetSure™ 802 Series
•MCA Menu Tree: Section 5886
•Power System Installation Instructions: Section 5876
•Power System User Instructions: Section 5877
•Power System Installation Guide: Section 5957
(condensed version of Section 5876 Installation Instructions)
•Power System “System Application Guide”: SAG582140000
•Contact Information Page: Section 4154
•Engineering Drawings
-SD582140000
-T582140000
Optional Integrated LMS System
•LMS “System Application Guide”: SAG586505000
•LMS Installation Instructions: Section 5879
•LMS User Instructions: Section 5847

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
14
INSTALLATION ACCEPTANCE CHECKLIST
Provided below is an Installation Acceptance Checklist. This checklist helps ensure proper installation and
initial operation of the system. As the procedures presented in this document are completed, check the
appropriate box on this list. If the procedure is not required to be performed for your installation site, also
check the box in this list to indicate that the procedure was read. When installation is done, ensure that each
block in this list has been checked. Some of these procedures may have been factory performed for you.
NOTE! The system is not powered up until the end of this checklist.
NOTE! Some of these procedures may have been performed at the factory for you.
Placing the Bays and Installing Internal/External Busbars
Bays (and PDSC if furnished) Bolted Together (if required) and Mounted to Floor
Bay-to-Bay Busbar Links Installed (if required)
PDSC (if furnished) AC Input Connectors Connected to Power/Distribution Bay
External Top-Mount Busbar Assemblies Installed (if furnished)
Installing Distribution Devices, MCA Relay Circuit Cards, MCA I/O Circuit Cards, and LMS Circuit Cards
Distribution Fuses and Circuit Breakers Installed
Distribution Lug Adapter Plates Installed
MCA Customer Alarm Relay Circuit Card(s) Installed (if required)
MCA I/O Circuit Card(s) Installed (if required)
LMS CPU Circuit Card Installed (if required)
LMS Modem Circuit Card Installed (if required)
LMS Four Input Analog Circuit Card Installed (if required) after Making any Jumper Adjustment as
Required
LMS Eight Input Analog Circuit Card Installed (if required)
LMS Twelve Input Analog Circuit Card Installed (if required)
LMS Four Input Binary Circuit Card Installed (if required)
LMS Eight Input Binary Circuit Card Installed (if required)
after Making any Jumper Adjustment as Required
LMS Four Output (Form-C) Relay Circuit Card Installed (if required)
after Making any Jumper Adjustment as Required
LMS Eight Input Temperature Circuit Card Installed (if required)
and Ground Lead Attached to Frame Ground

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
15
Making Electrical Connections
MCA Network Bay Interconnections Made
MCA Battery Charge Digital Temperature Compensation Probe Mounted and Connected (if furnished)
MCA External Alarm, Reference, and Control Connections Made
Connections Made to all MCA I/O Circuit Cards Installed
External LMS CPU/Hardware Fail Alarm Connections Made (as required)
LMS Local Port Connections Made (if required)
LMS Ethernet Port Connections Made (if required)
LMS Modem Port Connections Made (if required)
LMS OEM (RS-485) Port Connections Made (if required)
Connections Made to all LMS Four Input Analog Circuit Cards Installed
Connections Made to all LMS Eight Input Analog Circuit Cards Installed
Connections Made to all LMS Twelve Input Analog Circuit Cards Installed
Connections Made to all LMS Four Input Binary Circuit Cards Installed
Connections Made to all LMS Eight Input Binary Circuit Cards Installed
Connections Made to all LMS Four Output (Form-C) Relay Circuit Cards Installed
Connections Made to all LMS Eight Input Temperature Circuit Cards Installed
LMS Energy Management Connections Made (as required)
LMS Sequential Start Connections Made (as required)
LMS Expansion Assembly(s) (if furnished) Interconnected to Customer Equipment
LMS Network Bay and Optional LMS Expansion Cabinet(s) and Assembly(s) Interconnections Made (as
required)
Frame Grounding Connections Made
Load Connections Made
AC Input and AC Input Ground Connections Made
Battery Connections Made
All Shields and Cover Panels in Re-Installed
MCA “Power Share” Connections Made (if required)
Connections to Other Systems Made (if required)
Installing the Rectifiers and Initially Starting the Power System
Rectifiers Installed

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
16
Router Circuit Cards Switches Set
MCA Distribution Bus Monitoring Circuit Cards Jumper Set
System Started, Configured, and Checked
LMS Checked and Configured (as required)
PLACING THE BAYS AND INSTALLING
INTERNAL/EXTERNAL BUSBARS
General Requirements
•The installer should be familiar with the installation requirements and techniques to be used in securing
the bay(s) to the floor.
•This product is intended only for installation in a Restricted Access Location on or above a non-
combustible surface.
•This product is intended for installation in Network Telecommunication Facilities (CO, vault, hut, or other
environmentally controlled electronic equipment enclosure).
•This product is intended to be connected to the common bonding network in a Network
Telecommunication Facility (CO, vault, hut, or other environmentally controlled electronic equipment
enclosure).
•Front and rear access is required for installation.
•Typical industry standards recommended minimum aisle space clearance is 2' 6" for the front of the
bay(s) and 2' for the rear of the bay(s). See also next paragraph.
•Rectifier ventilating openings must not be blocked and temperature of air entering Rectifiers must not
exceed rated Operating Ambient Temperature Range found in System Application Guide
SAG582140000. Distance from rear of a Power/Distribution or Power Only Bay to a wall or other solid
structure must not be less than 6 inches. This assures proper airflow through the Rectifiers.
•The system consists of from 1 to 10 bays, depending upon your power requirements. All bays that are
designed to be bussed together must be placed in a line adjacent to each other, with no space between
bays. It is recommended to place the Primary Power/Distribution or Power Only Bay on the far right or
far left end of the bay line-up, and to expand the system to the left or right of the Primary
Power/Distribution or Power Only Bay. This allows simple cable connections between bays, and a
consistent MCA Bay numbering scheme. The Primary Power/Distribution or Power Only Bay is identified
by the MCA as Bay #1. The other bays are numbered consecutively, following the bay-to-bay cabling
scheme. Thus, bays are numbered #1-#10 from right to left or from left to right. The Primary
Power/Distribution or Power Only Bay may be placed in the middle of the bay line-up, expanding the
system to the left and right of the Primary Power/Distribution or Power Only Bay. In this configuration,
bay-to-bay cabling MUST start with the Primary Power/Distribution or Power Only Bay, then each
Secondary Power/Distribution or Power Only Bay and Distribution Only Bays are daisy-chained into the
cabling string. Remember, the Primary Power/Distribution or Power Only Bay is identified by the MCA as
Bay #1, the other bays are numbered consecutively following the bay-to-bay cabling scheme.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
17
Placing and Securing List 1 and List 11 Power/Distribution Bays (without PDSC)
NOTE! If you are installing List 2 and List 12 bays (with List 30, 31, or 32 PDSC), skip this procedure and
refer to “Placing and Securing List 2 and List 12 Power/Distribution Bays (with PDSC)".
•PDSC = AC Input 'Power Distribution Service Cabinet'.
•Refer to Figure 1 through Figure 18 as this procedure is performed. Figure 1provides a floor hole
drilling pattern.
•Bays are typically placed next to each other and bolted together. Refer to the previous Section,
GENERAL REQUIREMENTS, for bay line-up recommendations.
Procedure
Preparing the Bays
1. Remove all front Rectifier mounting position blank cover panels from each Power/Distribution Bay to
provide access to bay's floor mounting holes and leveling feet. Cover panels will be re-installed in empty
Rectifier mounting positions after all Rectifiers are installed. To do so: Remove the screws and ground
washers securing the cover panel. Remove the cover panel.
2. Remove the three rear cover panels from each Power/Distribution Bay. These cover panels will be re-
installed after all mounting and electrical connection procedures have been completed. To do so: Top
Panel: Loosen the screws securing the cover panel. Lift the cover panel until the screw heads clear the
keyhole slots. Remove the cover panel. Lower Panels: Remove the screws and ground washers
securing the panel. Remove the panel.
3. Remove the side cover panels from each Power/Distribution Bay (two per side) as follows, if equipped.
Note that you may leave the side cover panels on the "outside side" of the two end bays.
a) Remove the rear-most side cover panel as follows: Remove the screws and ground washers
securing the side cover panel. Screws are accessible from the rear of the bay through holes in the
side channels. After removing screws, pivot rear edge of cover panel outward, then slide cover
panel toward rear of bay to disengage tabs at the front of the cover panel from slots in the bay.
b) Remove the front-most side cover panel as follows: Open the bay's front door. Remove the
screws and ground washers securing the side cover panel. Screws are accessible from the front of
the bay through holes in the side channels. After removing screws, pivot front edge of cover panel
outward, then slide cover panel toward front of bay to disengage tabs at the rear of the cover panel
from slots in the bay.
Placing and Securing the Bay(s)
1. Place bay(s) in position. Note that clearance holes for 1/4” bolts are provided in the side rails of each
bay. These holes are for bolting the bays together.
2. Level bay(s) as required, using leveling feet in base plate. Adjust leveling feet so that all bays are even
at top, and bolt holes in the side of each bay line up with holes in the adjacent bay(s).
3. Bolt all bays together. Use 1/4” hardware, six places per pair of bays. Use a ground washer in two
locations with the 1/4" hardware bolting two bays together.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
18
NOTE! A ground washer is an internal-external tooth, dish-type lock washer. When installing ground
washers, ensure that the ground washer is oriented so that the teeth dig into the paint on the metal part
the ground washer is secured to (concave side faces the metal part).
4. Install shims between bottom of each bay and the floor as required to distribute floor loading.
5. Secure bay(s) to floor using fastening hardware per site requirements.
Installing Side Cover Panels on End Bays
1. If the outside sides of the end bays do not have side cover panels, install them now (two per side). Note
that ground washers are used with each screw securing the side cover panels.
a) Install the rear-most side cover panel as follows: Insert tabs at front of cover panel into slots in
bay. Pivot cover panel into position against side of bay. Install the previously removed screws and
ground washers into cover panel from rear of bay.
b) Install the front-most side cover panel as follows: Open the bay's front door. Insert tabs at rear
of cover panel into slots in bay. Pivot cover panel into position against side of bay. Install the
previously removed screws and ground washers into cover panel from front of bay.
Placing and Securing List 2 and List 12 Power/Distribution Bays (with PDSC)
NOTE! If you are installing List 1 and List 11 Bays (without List 30, 31, or 32 PDSC), skip this procedure
and refer to “Placing and Securing List 1 and List 11 Power/Distribution Bays (without PDSC)".
•PDSC = AC Input 'Power Distribution Service Cabinet'.
•Refer to Figure 1through Figure 18 as this procedure is performed. Figure 2provides a floor hole
drilling pattern.
•Bays are typically placed next to each other and bolted together. Refer to the previous Section,
GENERAL REQUIREMENTS, for bay line-up recommendations. PDSCs are located to the left (as viewed
from the front) of each Power/Distribution Bay.
Procedure
Preparing the Bays and PDSCs
1. Remove all front Rectifier mounting position blank cover panels from each Power/Distribution Bay to
provide access to bay's floor mounting holes and leveling feet. Cover panels will be re-installed in empty
Rectifier mounting positions after all Rectifiers are installed. To do so: Remove the screws and ground
washers securing the cover panel. Remove the cover panel.
2. Remove the three rear cover panels from each Power/Distribution Bay. These cover panels will be re-
installed after all mounting and electrical connection procedures have been completed. To do so: Top
Panel: Loosen the screws securing the cover panel. Lift the cover panel until the screw heads clear the
keyhole slots. Remove the cover panel. Lower Panels: Remove the screws and ground washers
securing the panel. Remove the panel.
3. Remove the side cover panels from each Power/Distribution Bay (two per side) as follows, if equipped.
Note that you may leave the side cover panels on the "outside side" of the right-most (as viewed from
the front) end bay.
a) Remove the rear-most side cover panel as follows: Remove the screws and ground washers
securing the side cover panel. Screws are accessible from the rear of the bay through holes in the

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
19
side channels. After removing screws, pivot rear edge of cover panel outward, then slide cover
panel toward rear of bay to disengage tabs at the front of the cover panel from slots in the bay.
4. Remove the front-most side cover panel as follows: Open the bay's front door. Remove the screws
and ground washers securing the side cover panel. Screws are accessible from the front of the bay
through holes in the side channels. After removing screws, pivot front edge of cover panel outward, then
slide cover panel toward front of bay to disengage tabs at the rear of the cover panel from slots in the
bay.
5. Remove the front cover panel from each PDSC. This cover panel will be re-installed after all mounting
and electrical connection procedures have been completed. To do so: Remove the screws and ground
washers securing the cover panel. Remove the cover panel.
6. Remove the rear lower cover panel from each PDSC. This cover panel will be re-installed after all
mounting and electrical connection procedures have been completed. To do so: Remove the screws
and ground washers securing the cover panel. Remove the cover panel.
7. Remove the rear upper cover panel from each PDSC. This cover panel will be re-installed after all
mounting and electrical connection procedures have been completed.. To do so: Loosen the screws
securing the cover panel. Lift the cover panel until the screw heads clear the keyhole slots. Remove the
cover panel.
8. Remove the plug-button located on the left side (towards the front) of each PDSC, except the end
PDSC. This opening is provided for data communications cable routing between bays.
Placing and Securing the Bay(s) and PDSCs
1. Place bay(s) and PDSC(s) in position. Note that PDSCs are placed to the left (as viewed from the front)
of each bay. Note that clearance holes for 1/4” bolts are provided in the side rails of each bay and PDSC.
These holes are for bolting the bays and PDSCs together.
2. Level bay(s) and PDSC(s) as required, using leveling feet in base plate. Adjust leveling feet so that all
bays and PDSCs are even at top, and bolt holes in the side of each bay and PDSC line up with holes in
the adjacent cabinet(s).
3. Bolt all bays and PDSCs together. Use 1/4” hardware, five places per pair of cabinets. Use a ground
washer in two locations with the 1/4" hardware bolting two cabinets together.
NOTE! A ground washer is an internal-external tooth, dish-type lock washer. When installing ground
washers, ensure that the ground washer is oriented so that the teeth dig into the paint on the metal part
the ground washer is secured to (concave side faces the metal part).
4. Install shims between bottom of each bay and the floor as required to distribute floor loading.
5. Secure Power/Distribution Bay(s) and PDSC(s) to floor using fastening hardware per site requirements.
Installing Side Cover Panels on Right-Most End Bay
1. If the outside side of the right-most end bay does not have side cover panels, install them now (two per
side). Note that ground washers are used with each screw securing the side cover panels.
a) Install the rear-most side cover panel as follows: Insert tabs at front of cover panel into slots
in bay. Pivot cover panel into position against side of bay. Install the previously removed screws
and ground washers into cover panel from rear of bay.

Vertiv™ | NetSure™ 802 Series -48 VDC Power System Installation Manual (Section 5876)|Rev. ZA
20
b) Install the front-most side cover panel as follows: Open the bay's front door. Insert tabs at
rear of cover panel into slots in bay. Pivot cover panel into position against side of bay. Install the
previously removed screws and ground washers into cover panel from front of bay.
Placing and Securing List 3, 4, 5, 13, 14, and 15 Power Only Bays
•Refer to Figure 1through Figure 18 as this procedure is performed. Figure 1provides a floor hole
drilling pattern.
•Bays are typically placed next to each other and bolted together. Refer to the previous Section,
GENERAL REQUIREMENTS, for bay line-up recommendations.
Procedure
1. Remove all front Rectifier mounting position blank cover panels from each Power Only Bay to provide
access to bay's floor mounting holes and leveling feet. Cover panels will be re-installed in empty
Rectifier mounting positions after all Rectifiers are installed. To do so: Remove the screws and ground
washers securing the cover panel. Remove the cover panel.
2. Remove the three rear cover panels from each Power Only Bay. These cover panels will be re-installed
after all mounting and electrical connection procedures have been completed. To do so: Top Panel:
Loosen the screws securing the cover panel. Lift the cover panel until the screw heads clear the
keyhole slots. Remove the cover panel. Lower Panels: Remove the screws and ground washers
securing the panel. Remove the panel.
3. Remove the side cover panels from each Power Only Bay (two per side) as follows, if equipped. Note
that you may leave the side cover panels on the "outside side" of the two end bays.
a) Remove the rear-most side cover panel as follows:Remove the screws and ground washers
securing the side cover panel. Screws are accessible from the rear of the bay through holes in the
side channels. After removing screws, pivot rear edge of cover panel outward, then slide cover
panel toward rear of bay to disengage tabs at the front of the cover panel from slots in the bay.
b) Remove the front-most side cover panel as follows:Open the bay's front door. Remove the
screws and ground washers securing the side cover panel. Screws are accessible from the front of
the bay through holes in the side channels. After removing screws, pivot front edge of cover panel
outward, then slide cover panel toward front of bay to disengage tabs at the rear of the cover panel
from slots in the bay.
4. Place bay(s) in position. Note that clearance holes for 1/4” bolts are provided in the side rails of each
bay. These holes are for bolting the bays together.
5. Level bay(s) as required, using leveling feet in base plate. Adjust leveling feet so that all bays are even
at top, and bolt holes in the side of each bay line up with holes in the adjacent bay(s).
6. Bolt all bays together. Use 1/4” hardware, six places per pair of bays. Use a ground washer in two
locations with the 1/4" hardware bolting two bays together.
NOTE! A ground washer is an internal-external tooth, dish-type lock washer. When installing ground
washers, ensure that the ground washer is oriented so that the teeth dig into the paint on the metal part
the ground washer is secured to (concave side faces the metal part).
7. Install shims between bottom of each bay and the floor as required to distribute floor loading.
8. Secure bay(s) to floor using fastening hardware per site requirements.
