Liebert® PSI™
750/1000/1500/1920/3000VA, 60Hz,120VAC
User Manual
DISCONTINUED

Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of
this manual to see if the issue can be resolved by following outlined procedures. Visit
https://www.VertivCo.com/en-us/support/ for additional assistance.
DISCONTINUED

TABLE OF CONTENTS
Important Safety Instructions 1
Glossary of Symbols 5
1 Introduction 7
2 What’s Included 9
3 Installation 11
3.1 Preparation 11
3.2 Tower UPS Installation 11
3.3 Rack-Mount UPS Conversion and Installation 12
3.4 Orient Display for Installation 13
3.5 Charge Batteries and Perform Battery Startup 14
3.6 Connect Input Power and Load 14
3.7 Connect Network Surge protection 15
3.8 Connect Computer Interface Port 16
3.9 Set Up Liebert MultiLink software 16
3.10 EPO Switch 17
4 Controls and Indicators 19
4.1 Control Buttons 19
4.1.1 On/Alarm Silence/Manual Self-Diagnostic Test 19
4.1.2 Off Button 20
4.2 Status Indicators 20
4.2.1 Status Change Button 20
4.2.2 Load Level Indicator 20
4.2.3 Battery Level Indicator 21
4.2.4 UPS Status Indicators 21
5 Operational Modes 23
5.1 Normal Mode 23
5.2 Buck/Boost Mode 23
5.3 Battery Mode 23
5.4 Battery Recharge Operation 23
6 Communication 25
6.1 DB-9 Connector 25
6.2 Remote Shutdown Via the DB-9 Connector 25
6.2.1 Any Mode Shutdown Via Pins 5 & 6 25
6.2.2 Battery Mode Shutdown Via Pins 4 & 5 25
6.3 Network Surge Protection Connectors 26
6.4 UPS Communication 26
6.5 UPS Inverter/Transfer Voltage Configurations 26
7 Battery Maintenance 27
7.1 Battery Charging, Storage 27
7.2 Internal Battery Replacement Procedure 27
Vertiv | Liebert® PSI™ User Manual | i
DISCONTINUED

8 Specifications 29
Vertiv | Liebert® PSI™ User Manual | ii
DISCONTINUED

IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that should be followed during installation and maintenance
of the UPS.
•Intended for installation in a temperature-controlled, indoor area free of conductive
contaminants.
•Maximum ambient temperature 104°F (40°C).
Read this manual thoroughly before attempting to install or operate this UPS.
The equipment can be installed and operated by individuals without previous training.
CAUTION: To reduce the risk of fire, connect PS3000RT3-120 models only to a circuit provided
with 30 amperes maximum branch circuit overcurrent protection in accordance with the
National Electric Code, ANSI/NFPA 70. Other Liebert PSI models must be connected to a circuit
with 20 amperes maximum branch circuit overcurrent protection.
WARNING! Operate the UPS only from a properly grounded (earthed) 110-127VAC, 50Hz or
60Hz AC supply.
Some components are live, even when AC power is disconnected. For service, contact a
properly trained and qualified technician. Do not remove the cover; the UPS has no
user-serviceable parts inside except the internal battery pack.
WARNING! Although the UPS has been designed and manufactured to ensure personal safety,
improper use can result in electrical shock or fire. To ensure safety, observe the following rules:
Turn Off and unplug the UPS before cleaning it. Clean the UPS with a dry cloth. Do not use
liquid or aerosol cleaners.
Do not install or operate the UPS in or near water.
Never block or insert any objects into the ventilation holes or other openings of the UPS. Keep
all vents free of dust accumulation that could restrict air flow.
Do not place UPS power cord anywhere it might be damaged.
Vertiv | Liebert® PSI™ User Manual | 1
DISCONTINUED

Battery Handling Precautions
WARNING! Batteries should be replaced only by properly trained and qualified personnel
knowledgeable of batteries and required precautions.
A battery can present a risk of electrical shock and high short-circuit current. The following
precautions must be observed when working on batteries:
Remove watches, rings and other metal objects.
Use tools with insulated handles.
Do not dispose of the battery or batteries in a fire. The battery may explode.
Do not open or mutilate the battery or batteries. Released electrolyte is toxic. It may cause
injury to the skin and eyes.
When replacing the battery, use the same type of battery as is listed in Table 8-1.
Handle, transport and recycle batteries in accordance with local regulations.
CONDITIONS OF USE —The input supply outlet must be within 6 ft. (1.8m) of the UPS and be easily
accessed.
This UPS provides conditioned power to connected equipment. It is not intended for use with life-support
and other designated “critical” devices. Maximum load must not exceed that shown on the UPS rating
label. If uncertain, consult your local dealer, local Vertiv representative or Channel Support Applications.
When installing the UPS or making input and output connections, comply with all relevant safety codes
and standards (e.g., UL 1778).
Placing magnetic storage media on top of the UPS may result in data corruption.
ELECTROMAGNETIC COMPATIBILITY—The Liebert PSI complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received, including interference that may cause
undesired operation.
This equipment uses, generates and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference with radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the UPS and the receiver.
•Connect the UPS to an outlet on a circuit different from the one the receiver is connected to.
Vertiv | Liebert® PSI™ User Manual | 2
DISCONTINUED

NOTICE
Do not connect equipment that could overload the UPS or demand half-wave rectification from
the UPS, such as electric drills, vacuum cleaners, laserjet printers and hair dryers.
Vertiv | Liebert® PSI™ User Manual | 3
DISCONTINUED

Vertiv | Liebert® PSI™ User Manual | 4
This page intentionally left blank.
DISCONTINUED

GLOSSARY OF SYMBOLS
Risk of electrical shock
Indicates caution followed by important instructions
Indicates the unit contains a valve-regulated, lead-acid battery
Recycle
DC voltage
Equipment grounding conductor
Bonded to ground
AC voltage
ON/Alarm Silence/Manual Self-Diagnostic Test
OFF
Status Change Button
Vertiv | Liebert® PSI™ User Manual | 5
DISCONTINUED

Vertiv | Liebert® PSI™ User Manual | 6
This page intentionally left blank.
DISCONTINUED

1 INTRODUCTION
The Liebert PSI™ is a 2U, line-interactive UPS that may be installed in a rack or used as a tower UPS.
Status indicators on the front of the Liebert PSI display load level, battery level, buck/boost, site-wiring
fault and battery status. Controls include a combination ON/ Alarm Silence/Manual Self-Diagnostic
button, an Off button and a Display Status Change button.
The Liebert PSI has USB, DB-9 (contact closure) and Liebert IntelliSlot® ports. The DB-9 and USB ports
provide detailed operating information including voltages, currents, and alarm status to the host system
when used in conjunction with Liebert MultiLink™ shutdown software.
Figure 1.1 Front view of UPS, rack mount
Figure 1.2 1000 and 1500VA—rear view
Vertiv | Liebert® PSI™ User Manual | 7
DISCONTINUED

Figure 1.3 1920VA—rear view
Figure 1.4 3000VA—rear view
Vertiv | Liebert® PSI™ User Manual | 8
DISCONTINUED

2 WHAT’S INCLUDED
The Liebert PSI is shipped with the following items:
•Multi-Language User Manual on CD
•Liebert MultiLink Shutdown Software and User Manual on CD
•Contact Closure (ML9P9S) Cable
•USB Cable
•Tower Stand
•Rack-Mount Handles
•Battery-UPS Tab
•Mounting Hardware
•Fixed Mounting Rails
•EPO Connector
Figure 2.1 Accessories
Vertiv | Liebert® PSI™ User Manual | 9
DISCONTINUED

Vertiv | Liebert® PSI™ User Manual | 10
This page intentionally left blank.
DISCONTINUED

3 INSTALLATION
3.1 Preparation
CAUTION: The UPS is heavy (see Table 8.1 on page29). Take proper precautions when lifting
or moving it.
The Liebert PSI may be installed in either a tower or rack configuration. Determine the method that suits
the application and proceed.
Decide where to install the Liebert PSI. The UPS must be installed indoors in a controlled environment.
Place it in an area with unrestricted airflow around the unit, away from water, flammable liquids, gases,
corrosives and conductive contaminants (see Figure 3.1 below).
Maintain a minimum clearance of 12 inches (305mm) in the front and rear of the UPS. Maintain an ambient
temperature range of 32°F to 104°F (0°C to 40°C).
Figure 3.1 Placing the Liebert PSI
3.2 Tower UPS Installation
See Figure 3.2 on the next page when using the Liebert PSI in a tower configuration.
Vertiv | Liebert® PSI™ User Manual | 11
DISCONTINUED

Figure 3.2 Tower configuration—attach Tower Stand
3.3 Rack-Mount UPS Conversion and Installation
See Figure 3.3 on the facing page when installing the Liebert PSI in a rack.
Vertiv | Liebert® PSI™ User Manual | 12
DISCONTINUED

Figure 3.3 Convert the Liebert PSI for rack installation
WARNING! Placing heavy equipment near the top of a rack may increase the risk of tipping.
Place the UPS in the bottom of the rack.
CAUTION: Lifting equipment into rack may be a two-person job, depending on weight of
equipment.
NOTICE
When rack-mounted, the UPS must be supported by a shelf, slide rails, brackets or fixed rails on
each side. The rack-mount handles WILL NOT support the weight of the UPS. They are used to
move the UPS into and out of the rack.
3.4 Orient Display for Installation
The Liebert PSI features a rotating display that may be oriented for either tower or rack installations.
To set the display for your installation, pull out on the display and rotate it until it is oriented correctly,
then press it into the UPS until it is seated.
Vertiv | Liebert® PSI™ User Manual | 13
DISCONTINUED

Figure 3.4 Adjusting the UPS display
3.5 Charge Batteries and Perform Battery Startup
Before connecting input power or connecting the load, Vertiv recommends these steps:
•Charge the battery for at least 8 hours.
•start the UPS on battery to ensure the battery is fully functional and charged.
•Turn the unit Off and proceed to Connect Input Power and Load below.
3.6 Connect Input Power and Load
Connect input power to the UPS, then plug the equipment into the outlets on the rear of the UPS. These
UPS outlets provide battery backup and surge protection to the equipment when utility power fails,
spikes or sags (see Figure 3.5 on the facing page).
Vertiv | Liebert® PSI™ User Manual | 14
DISCONTINUED

Figure 3.5 Connect input power and load
3.7 Connect Network Surge protection
Connect a 10 base-T/100 network cable to the RJ-45 network surge protection IN jack on the rear of the
UPS. Connect from the OUT jack with network cabling to network equipment (see Figure 3.6 below).
Figure 3.6 Connect network surge protection
Vertiv | Liebert® PSI™ User Manual | 15
DISCONTINUED

3.8 Connect Computer Interface Port
Determine what type of communication connection to use to manage the UPS. The Liebert PSI can be
monitored with any of these communication methods:
•contact closure
•USB
•SNMP (requires optional IS-WEBRT3 card)
Connect the appropriate, factory-supplied cable to the interface port on the rear of the UPS and to the
computer interface port. See the Liebert MultiLink shutdown software user manual for details and
installation information; the manual, SL-53625, is available online at www.VertivCo.com. Also refer to UPS
Communication on page26.
Figure 3.7 Connect computer interface port
3.9 Set Up Liebert MultiLink software
To start using Liebert MultiLink (software and user manual available at www.VertivCo.com):
•Install the software. See the Liebert MultiLink quick-start guide or user manual for installation
instructions.
•Connect one end of the USB cable (supplied) to the USB port on the rear of the UPS. Connect
the other end to a USB port on the computer. See the Liebert MultiLink user manual for
operating instructions.
NOTE: Vertiv recommends connecting the USB cable directly to the computer WITHOUT using a USB
hub.
Vertiv | Liebert® PSI™ User Manual | 16
