Vertiv Liebert ITA2 User manual

Vertiv™ Liebert® ITA2 1-3 kVA
User Manual

Vertiv™ Liebert® ITA2 1-3 kVA User Manual
Technical Support Site
If you encounter any installation or operational issues with your product, check
the pertinent section of this manual to see if the issue can be resolved by
following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.
The information contained in this document is subject to change without notice
and may not be suitable for all applications. While every precaution has been
taken to ensure the accuracy and completeness of this document, Vertiv assumes
no responsibility and disclaims all liability for damages resulting from use of this
information or for any errors or omissions. Refer to other local practices or building
codes as applicable for the correct methods, tools, and materials to be used in
performing procedures not specifically described in this document.
The products covered by this instruction manual are manufactured and/or sold by
Vertiv. This document is the property of Vertiv and contains confidential and
proprietary information owned by Vertiv. Any copying, use or disclosure of it
without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of the
respective companies. Any questions regarding usage of trademark names should
be directed to the original manufacturer.
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

TABLE OF CONTENTS
1 Important Safety Instructions 1
2 Special Declaration 3
3 Product Introduction 9
3.1 Product Features 9
3.2 Model Configurations 10
3.3 Product Appearance and Components 10
3.3.1 Product Appearance 10
3.3.2 Product Components 11
3.4 Operating Principal 14
3.5 UPS State and Operation Mode 15
3.5.1 Normal Mode 16
3.5.2 Bypass Mode 17
3.5.3 Battery Mode 18
3.5.4 ECO Mode (for UPS Equipped with Battery only) 19
3.5.5 Fault State 19
4 UPS Installation 21
4.1 Unpacking and Inspection 22
4.2 UPS Moving 22
4.3 Installation Preparation 23
4.3.1 Location 23
4.3.2 Environmental Requirement 23
4.3.3 Installation Tools 26
4.4 External Protective Devices 28
4.4.1 Overcurrent 28
4.4.2 Earth Leakage Current 28
4.4.3 Battery Input 29
4.5 Mechanical Installation 29
4.5.1 Tower Installation 29
4.5.2 Rack Installation 32
4.6 Connecting Power Cables 38
4.6.1 Connecting Input Plug and Load 38
4.6.2 Connecting Battery Cables 39
5 UPS Operation Instructions 43
i
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

5.1 UPS Start-Up 44
5.2 Initial Start-up Guidance 45
5.3 Transfer Procedures Between Operation Modes 48
5.3.1 Transfer from Normal Mode to Battery Mode 48
5.3.2 Transfer from Inverter Mode to Bypass Mode 48
5.3.3 Transfer from Bypass Mode to Inverter Mode 50
5.4 UPS Complete Shutdown 52
5.5 REPO 52
5.6 Auto Restart 52
5.7 Language Selection 53
5.8 Changing Current Date and Time 55
5.9 Setting Password 57
6 Operation and Display Panel 61
6.1 Introduction 61
6.1.1 LED Indicators 63
6.1.2 Audible Alarm (Buzzer) 63
6.1.3 LCD and Functional Keys 64
6.2 LCD Menu Structure 66
6.3 LCD Screen Types 66
6.3.1 Start Screen 66
6.3.2 Flow Screen 67
6.3.3 Main Menu Screen 67
6.3.4 Submenu Screen 68
6.3.5 Default Screen 78
6.4 Prompt Window 79
6.5 List of UPS Alarm and Fault Message 80
7 Communication 83
7.1 Connecting Built-in Ethernet Port 83
7.2 Connecting Serial Port Communication Cables 85
7.3 Installing Intelligent Card 85
7.3.1 Intelligent Card Port 85
8 Maintenance 87
8.1 Replacing Batteries 87
8.2 Fan Maintenance 88
8.3 Battery Maintenance 88
8.4 Cleaning UPS 90
ii
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

8.5 Checking UPS State 90
8.6 Checking UPS Functions 90
9 Options 91
9.1 Option List 91
10 Technical Specifications 93
11 Appendices i
Appendix A: LCD Parameters Setting i
Appendix B: Glossary v
iii
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

iv
This page intentionally left blank
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

1 Important Safety Instructions
IMPORTANT! This manual contains important safety instructions that must be followed during the
installation and maintenance of the Vertiv™ Liebert® ITA2 1-3 kVA. Read this manual thoroughly, and
the safety and regulatory information are available at Compliance Regulatory Info.
Purpose of the Document
This document applies to Vertiv™ Liebert® ITA2 1-3 kVA UPS and cooling solutions which maintain optimal
environmental control of technological ecosystems at minimal operating costs. This document gives an
overview of the specifications, installation, commissioning, and maintenance procedures with
troubleshooting from the user's perspective. The figures used in this document are for reference only.
Please read this manual carefully before installing, maintaining, and troubleshooting.
Styling used in this Guide
The styles used in the manual will be defined as mentioned in the following table:
Situation Description
Warning/Danger/Caution
WARNING! The Warning/Danger/Caution note indicates a hazardous or potentially
harmful situation that can result in death or injury. It also indicates instructions that
need to be adhered to, failing which may result in danger and safety issues thereby
having an adverse effect on the reliability of the device and security. Even for
practices not related to physical injury, to avoid equipment damage, performance
degradation, or interruption in service, follow the warning instruction.
Note
NOTE: The Note section indicates additional and useful information. It also calls attention to
best practices and industry-best protocols that are standardized and help make maximum
utilization of the resources at hand. Helpful information related to the product also comes under
the Note heading, helping the users with the definitions, concepts, and terminologies used in
the manual.
Version History
Version Revision Date Remarks
V1 05/07/2022 Manual Part Code: 190321003302
V2 01/06/2023 Updated Global Guidelines
1 Important Safety Instructions 1
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

1 Important Safety Instructions
2
This page intentionally left blank
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

2 Special Declaration
Personnel Safety
CAUTION: Only trained engineers by the Vertiv or the representative of the Vertiv must
install and commission this unit. Failure to comply with these precautions might risk the
personnel safety or put the product in danger.
CAUTION: Read this product manual and the safety precautions carefully, before installing,
and commissioning this unit. Failure to comply with these precautions might risk the
personnel safety or put the product in danger.
CAUTION: This product is not intended for life support equipment application.
CAUTION: Do not attempt to dispose of batteries by burning them as this may result in a
battery explosion. Failure to comply with these precautions might risk the safety of the
personnel.

2 Special Declaration 3
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

Product Safety
1. If this unit is required to be stored or remain de-energized for a long period, it must be placed in
a dry and clean environment within a specified temperature range.
2. This unit must be operated only within the permissible environmental conditions. For details,
refer to the section 10 , Technical Specifications on page93 in this user manual.
3. The application of this product must be prohibited for the following environmental conditions:
• In casethe relative humidity and temperature exceedthe permissible limits.
• Subjecttovibrationsorshocks.
• Inpresence of conductivedusts,corrosivegases,salts,orflammablegases.
• Exposure to heatsourcesorstrongelectromagneticinterferences.

Disclaimer
The Vertivdisclaimsanyandallresponsibilityorliabilityforthedefects ormalfunctioncaused by the
following:
• Applicationrange oroperatingenvironmentoutsidethespecifications.
• Unauthorizedmodification,improperinstallation,oroperation.
• Forcemajeure.
• Otheractionsnotincompliancewiththeinstructionsinthismanual.
2 Special Declaration
4
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

Safety Precautions
This manual contains the information concerning the installation and operation of the Vertiv™ Liebert®
ITA2 1-3 kVA UPS (hereinafter referred to as UPS). Please read this manual carefully prior to installation.
Please read the safety precautions very carefully before operating the unit in order to minimize the risk of
any accident. The words "Caution," "Note," and "Warning" used in this user manual and on the product do not
represent all the safety precautions to be observed and are only a supplement to the various safety
precautions. Therefore, installation and operation personnel must receive the required training and follow
the correct operations and all the safety points before operation.
When operating the Vertiv products, the operation personnel must observe the safety rules in the industry,
the general safety points, and special safety instructions provided by the Vertiv.

WARNING! The UPS must be installed, commissioned, and serviced only by the engineers
appointed by the manufacturer or its dealers. Failure to observe this could result in personnel
safety risk, UPS malfunction and invalidation of warranty.
WARNING! It is not recommended to use the UPS in life support applications as it is designed
primarily for commercial and industrial use.
WARNING! This is a Class C2 UPS product. It is recommended to take additional precautions
to minimize radio interference in a residential environment as this unit may continue to
generate radio interference.

Back feed protection
WARNING! Before operating the circuit, firstly, isolate the UPS and then check the dangerous
voltage between the ports, and finally check the dangerous voltage between the dangerous
voltage the ports and the earth.

2 Special Declaration 5
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

Conformity and standards
WARNING! The UPS complies with 2014/35/EU (LVD), 2014/30/EU (EMC), 2011/65/EU (RoHS)
and the following product standards for UPS:
IEC/EN 62040-1/AS 62040-1: General and safety requirements for UPS.
IEC/EN 62040-2/AS 62040-2: Class C2 compliant.
IEC/EN 62040-3/AS 62040-3: (VFI SS 111): Performance requirements and test methods.
The UPS installation should follow the above instructions and use the accessories specified
by the manufacturer.
WARNING! When the UPS is operating, some parts have high voltage, therefore, contact with
them directly or through moist objects will result in fatal risk.
.
WARNING! Before moving or rewiring the UPS, disconnect mains input power and the battery
and make sure that the UPS is completely shut down. Otherwise, the output terminal may
carry live voltage, presenting an electric shock hazard
WARNING! Liquid or other irrelevant external objects are prohibited inside the UPS.
WARNING! In case of a fire, a dry chemical fire extinguisher is essential. It is prohibited to use
a foam fire extinguisher as it will cause electric shock.
WARNING! The output neutral line of the UPS is from the input, after the neutral line is
suspended by the upstream protection devices, the output neutral line will be unplugged.
WARNING! It is recommended to usea UPS output cable that is less than 10 meters in length
to prevent the radio frequency of the cable from affecting other electrical equipment.
2 Special Declaration
6
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

High leakage current
WARNING! Earth connection is essential before connecting the input power (AC mains and
battery included).
Earth leakage current not greater than 3.5 mA.
Transient and steady-state earth leakage currents, which may occur when starting the unit,
should be considered when selecting instantaneous residual current circuit breaker (RCCB) or
residual current detector (RCD).
Note that the earth leakage current of the load will be carried by RCCB or RCD.
This unit must be earthed in accordance with the local electrical codes.

WARNING! When selecting the UPS system upstream distribution protection equipment,
ensure that it complies with the local electric regulations.
The specified upstream breakers are required to obtain the conditional short-circuit current
rating, Icc at 10 kA symmetrical rms. The specified upstream breakers should comply with an
IEC 60947 series standard.
2 Special Declaration 7
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

User serviceable components
WARNING! There are no user-serviceable components in the UPS. Do not remove the cover.
Removing the cover may result in electric shock and will invalidate any implied warranty.
The UPS must fully comply with all safety regulations in the operator access area. Only
trained technicians are permitted access to the dangerous voltage within the UPS. However,
the risk of contracting these voltages is minimized because the components with hazardous
voltage may be contacted only by using a tool to remove the protective cover. If you follow
the general guidelines and use the recommended methods in this manual, the risk will subside.

Battery high voltage
WARNING! All the hardware service and maintenance of the battery are performed by the
trained technicians.
Operation on the battery will result in electric shock and high short- circuit current, therefore,
before operating the battery, the following should be observed:
• Remove the watches, rings, and other metal objects.
• Use the tools with insulation handle.
• Wear rubber glove, and shoes.
• Avoid placing the tools and metal objects on the battery surface.
• Cut off the charge power supply before connecting or disconnecting the battery terminals.
• Check to confirm whether the battery is accidentally earthed, and if so, disconnectthe
earthing.Contacting any earth battery parts will result in electric shock. Therefore, ensure
that the battery is not earthed during installation and maintenance.
Battery manufacturers provide the details of the safety precautions to be observed when
working on, or in the vicinity of the batteries, these precautions should always be followed
implicitly. It is recommended to pay careful attention to the local environmental conditions,
the provision of protective clothing, first aid, and fire-fighting facilities.

2 Special Declaration
8
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

3 Product Introduction
The Vertiv™ Liebert® ITA2 1-3 kVA is an intelligent online UPS system with sine wave output developed by
Vertiv. The UPS offers reliable and high-quality AC power to the precision instrument.
The rack/tower installation can be deployed depending on your requirements. It is applicable to supplying
AC power to small scale computer center, network, communication system, automatic control system, and
precision instrument.
This chapter introduces the features, model configurations, appearance, and components, operating
principle, UPS state and operation mode, and specifications of the UPS.

3.1  Product Features
The Liebert® ITA2 1-3 kVA UPS products features include:
• The outputpowerfactoris1,which enhancestheUPSloadcapacity.
• Integratethe Ethernetport, supportHTTPprotocol, andusethewebbrowser to achieve remote
monitoring, no extra monitoring software is required.
• On-linedoubleconversionefficiencyupto94%andECOefficiencyupto98%, which provide
more efficient products for customers.
• Operation and display panel with colorful LCD to help you learn about the UPS
operationstateandoperatingparameters.TheLCDdisplay willchangeaccording to the layout
of the model.
• Towerinstallationandrackinstallation(2Uthickness.)areoptionaltomeet different installation
requirements.
• Innovative design of the layout and whole machine process greatly improve the
reliabilityoftheproductandenhancethereliability. Passtheharshwetdusttestand limittest.
• Two-wayLLCcircuit topology, highinputpower factor, wideinputvoltage range.The output is
not affected by the power grid interference, suitable for the harsh powergrid environment.
• Comparedwiththepreviousgeneration,thevolumeoftheproduct isreducedby 10% on
average. Space saving, easy to handle, and install.
• Fulldigitalcontrol platformandhardware designplatform,whichcanadapt to worse unstable
mains supply and load impact.
• Automaticrecognitionfunction ofthe batterymodule.
3 Product Introduction 9
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

3.2 Model Configurations
The model configurations are shown in Table 3.1 below.
Model Type Description
1 kVA
Standard back-up model ITA-01k00AS1102C00
The UPS can be connected to 10 battery modules, and
automatically detect up to six
Long back-up model ITA-01k00AS1102C00
2 kVA
Standard back-up model ITA-02k00AS1102C00
Long back-up model ITA-02k00AS1102C00
3 kVA
Standard back-up model ITA-03k00AS1102C00
Long back-up model ITA-03k00AL1102C00
Table 3.1 Model configurations


3.3 Product Appearance and Components
3.3.1 Product Appearance
The UPS appearance is shown in Figure 3.1 below.
Figure 3.1 Appearance of UPS

3 Product Introduction
10
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

3.3.2 Product Components
Front panel
As shown in Figure 3.2 below, the UPS front panel provides ventilation holes, operation and display panel,
LED indicators, and functional keys.
Figure 3.2 UPS front panel
Parameter Description
1 Ventilation holes
2 Functional keys
3 Operation and display panel
4 LED indicators

3 Product Introduction 11
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

Rear panel
As shown in Figure 3.3 below , the UPS rear panel provides dry contact port, I/O outlet, battery module port,
Intellislot port, Ethernet port, USB port, and REPO port.
Figure 3.3 Vertiv™ Liebert® ITA2 (1 kVA) UPS rear panel

Figure 3.4 Vertiv™ Liebert® ITA2 (2 kVA) UPSrearpanel

Figure 3.5 Vertiv™ Liebert® ITA2 (3 kVA) UPSrearpanel
3 Product Introduction
12
Vertiv™ Liebert® ITA2 1-3 kVA User Manual


Parameter Description
1 Input outlet
2 Output outlet
3 Battery module port
4 Intellislot port (DB9)
5 Ethernet port
6 USB port
7 Battery module number detection port
8 REPO port
9 Output dry contact
10 Input dry contact port
11 Ouput terminal block
Table 3.2 Vertiv™ Liebert® ITA2 1-3 kVA UPSrearpanel details

NOTE: Non-authorized personnel are prohibited from opening the UPS chassis cover.

3 Product Introduction 13
Vertiv™ Liebert® ITA2 1-3 kVA User Manual

3.4 Operating Principal
The operating principle of the Vertiv™ Liebert® ITA2 1-3 kVA UPS is shown in Figure 3.6 below.

Figure 3.6 Vertiv™ Liebert® ITA2 (1-3 kVA) UPS operating principle
Parameter Description
1 Bypass input
2 Mains input
3 Rectifier/PFC
4 Inverter
5 Output relay
6 DC/DC Converter
7 Battery
8 UPS output
3 Product Introduction
14
Vertiv™ Liebert® ITA2 1-3 kVA User Manual
