Vestil UNI User manual

02/05 03-126-121.doc
VESTIL MFG.CO. 1
VESTIL MANUFACTURING CORP.
2999 N. Wayne St., Angola, IN 46703
Ph: 260-665-7586 · Fax: [phone]
E-mail: [email protected] Website: www.vestil.com
MODEL UNI
Serial number ____________
Installation Instructions ……………….....................… 2
Operation Instructions ……………………….……… 3-4
Routine Maintenance & Safety Checks ……………… 5
Exploded Structural Parts Drawing & BOM ………... 6-7
Motor and Transformer Connections ............................ 8
Electrical & Hydraulic Diagrams & BOM ………….. 9-10
Power Unit’s Operation ………………...…..………... 11
Troubleshooting …………………………....………… 12
Safety Label Identification .............................................13
Warranty …………………………………….……..…. 14
IMPORTANT NOTES,WARNINGS AND SAFETY INSTRUCTIONS
Ensure that all employees understand and follow the following.
oRead and understand the owner’s manual before using or servicing
the Uni-Tilt.
oThe load must be removed and the platform supported or fully
lowered before any work is performed on the lift.
oEnsure that all safety and warning labels stay in place and are
legible.
oDo not use the Uni-Tilt if any damage or unusual noise is observed.
oAlways watch the platform and the container carefully when the
tilter is in operation.
oDo not transport the Uni-Tilt with any load on the platform.
oDo not use brake fluid or jack oils in the hydraulic system. If oil is
needed, use an anti-wear hydraulic oil with a viscosity grade of
150 SUS at 100°F, (ISO 32 cSt @ 40°C), or Dexron transmission fluid.
oContact the manufacturer for any needed MSDS information.
♦Do not perform any modifications to the Uni-Tilt without the
manufacturer’s approval. Failure to receive authorization for
changes to the equipment could void the warranty.
♦Maintenance and repairs are to be done only by personnel qualified
to perform the required work. Warranty labor charges will not
receive consideration without prior written authorization by the
manufacturer.
WHEN ORDERING
REPLACEMENT PARTS:
We take pride in using quality
parts on the equipment we
manufacture. We are not
responsible for equipment
problems resulting from the use
of unapproved replacement
parts.
To order replacement or
spare parts for this equipment,
contact the factory.
In any communication with
the factory please be prepared
to provide the machine’s serial
number, which is indicated on
the machine dataplate.
RECEIVING INSTRUCTIONS
Every unit is thoroughly
tested and inspected prior to
shipment. However, it is
possible that the unit could
incur damage during transit.
Inspect the unit closely when
it arrives. If you see evidence
of damage or rough handling to
either the packaging or to the
product when it is being
unloaded, immediately make a
note of it on the Bill Of Lading!
It is important that you
remove the product’s packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
O
WNER
’
S
MANUAL

02/05 03-126-121.doc
VESTIL MFG.CO. 2
INSTALLATION INSTRUCTIONS –UNI
Review this entire page before installing the Uni-Tilt.
Consult the factory in the event there are any questions or problems at the time of installation, or for
information regarding optional features not covered by the owner’s manual.
•Modifications or additions to the Uni-Tilt without prior manufacturer’s authorization may void the unit’s warranty.
The addition of ancillary equipment to the platform may necessitate that its load capacity be reduced.
•The installation must be made so that it complies with all the regulations applicable to the machine and its
location. The end-user must verify that the supplied equipment is installed so it will be suited to the environment
in which it will be used.
•Installation must be performed by suitably trained personnel with access to the appropriate equipment. The
electrical aspects of the installation should be performed by an electrician.
---------------------------------------------------------------------------------------
For a typical installation you will need the following:
1. A fork truck or hoisting means to unload the Uni-Tilt from the freight truck and set it into place.
2. A smooth, level, and adequately strong concrete surface on which to mount and operate the Uni-Tilt.
3. Concrete anchors, a masonry drill, a masonry bit, hand tools, grout, and steel shims. Consult the building’s
architect or facility engineer to determine the best size and type of hardware with which to anchor the machine to
the floor.
•Portable units do not need to be anchored to the floor.
4. A power supply circuit and electrical disconnect matching the motor voltage and current requirements. Refer to
the machine’s dataplate, to the labels on the control enclosure, and to the electrical section in this manual for
more information. The end-user is responsible for supplying the branch circuit’s required ground fault and short-
circuit protection. (Motor overload protection is provided by a thermostat built into the motor.)
---------------------------------------
1. Move the tilter into place with a fork truck having at least a 2,000 lb capacity.
2. Temporarily connect the power supply to the pigtail cord supplied with the Uni-tilt, and raise the platform so the
unit’s safety maintenance prop(s) can be utilized. Lower the platform so the unit is supported by the prop(s).
oThe maintenance prop(s) is located in the Uni-tilt’s frame next to the lifting assembly. It is a rod with a 90° bend.
To install the prop(s), raise the platform to its full raised height and insert the longer end through the holes in the
frame roller weldment. Lower the frame roller assembly unit it rests on the prop.
oIf the platform must be raised without first having the proper power supply connected, raise the platform at the
side of the table opposite the platform cradle. Use rigging or insert a lift truck’s forks under the front edge of the
platform to tilt the platform up. Hold the frame down at the ends of the shipping 4 x 4’s on the hinged side of the
Uni-tilt while the platform is raised.
3. Anchor the frame to the floor through the holes located at the frame’s corners. (Non-portable units only.)
4. Make permanent connection to the power supply, using an appropriate wiring method.
5. Operate the Uni-Tilt through several full raise and lower cycles. Verify that the upper travel limit switch functions
properly.
6. Check the hydraulic oil level. It should be filled to within 1” to 1½” of the reservoir’s fill hole. If oil is needed,
use an anti-wear hydraulic oil with a viscosity grade of 150 SUS at 100°F (ISO 32 at 40°C) or a non-synthetic
automatic transmission fluid.
7. Clean up any debris or spilled oil, and verify that all of the warning and safety labels are intact.

02/05 03-126-121.doc
VESTIL MFG.CO. 3
OPERATION INSTRUCTIONS –UNI
oConsult ANSI MH29.2 - 2000, Safety Requirements for Industrial Tilters, Section 12, for the owner’s / user’s
responsibilities regarding the operation, care, and maintenance of this machine.
oEnsure that all employees involved in the operation of this machine understand and follow these instructions!
The standard model UNI (stationary) and UNI-P (portable) is suitable for use indoors in most industrial locations and
many commercial locations. It is intended to be used to lift and tilt stable, non-hazardous loads and containers having
a size or footprint approximately the same size as the platform.
Loading:
The load rating, in pounds, is shown on the machine dataplate located on the right front corner of the loading
(opposite the backstop) side of the platform . It indicates the net capacity of the machine, with a static load that is
centered and evenly distributed on the platform and having a vertical center of gravity not more than 20” above the
platform surface.
For applications involving side loading or loads with higher centers of gravity, consult the manufacturer.
The standard design Uni-Tilt is intended to be loaded with a fork truck or similar material handling equipment.
Always center the load, and place it up against the back cradle of the platform to prevent sudden load shifting when
the platform is tilted.
Do not exceed a rate of two feet per second when moving loads onto the platform.
Note: The addition of any ancillary equipment to the platform by third parties must be taken into account when
determining the maximum working load to be placed on the platform.
Warning: Do not exceed the Uni-tilt’s load ratings. Injury to personnel or permanent damage to the structure could
result from exceeding the listed capacity.
Operation:
Warning: Keep all personnel clear of the machine when it is in operation. Be certain no part of any person or object is
under any part of the platform before lowering the unit.
Caution: Always carefully watch the container and any load in it when it is in operation.
To raise or tilt the platform back toward the operator, press the “UP” pushbutton.
To lower or tilt the platform toward the floor, press the “DN” pushbutton.
When a pushbutton is not being pressed, the unit will hold its position wherever it is in its travel range.
The Uni-tilt can be operated in either one of two movement sequences.
•Sequence #1:
•Starting with the platform in the fully lowered position, press and hold the “UP” pushbutton while you push the
sequence selector pedal in against the frame of the table with your foot. After about five seconds, the pedal can
be released.
•The platform will tilt back toward the operator until it reaches a tilt angle of 40° to the floor. It then will lift
vertically until the bottom of the cradle reaches a height of 16½” above the floor.
•To lower the platform, press and hold the “DN” pushbutton. The platform will drop vertically until the bottom of
the cradle is about 12” above the floor, and then the platform will tilt down away from the operator until it is
again fully collapsed and level with the floor.
•Sequence #2:
•Again starting with the platform in the fully lowered position, press and hold the “UP” pushbutton. (Do not press
the sequence selector pedal.) The platform will rise and tilt back at the same time, until it reaches a height of 19”
from the floor to the bottom of the cradle and a tilt angle of 35°.
•To return to the fully collapsed position, press and hold the “DN” pushbutton. The platform will both lower and
tilt down towards the floor concurrently until the unit is again fully collapsed and level with the floor.
On DC-powered units, attempting to raise the lift when the battery is low will cause the motor relay protection to
prevent the motor’s operation. Adequate battery voltage is indicated by a green LED on the motor relay. See the next
page for more notes regarding operation of battery-powered units.
Ensure that all safety and warning labels stay in place and are legible. Refer to the labels page in this manual.

02/05 03-126-121.doc
VESTIL MFG.CO. 4
ADDITIONAL INSTRUCTIONS FOR BATTERY-POWERED UNITS
Warning!
!Working with or near lead acid batteries is dangerous. Batteries contain sulfuric acid and produce explosive gases.
A battery explosion could result in loss of eyesight or serious burns.
!Do not smoke or allow a spark or flame near batteries. Charge batteries in locations that are clean, dry, and well
ventilated. Do not lay tools or anything metallic on top of any battery. All repairs to a battery must be made by
experienced and qualified personnel.
!When working with batteries, remove personal items such as rings, bracelets, necklaces, and watches. Batteries
can produce enough energy to weld jewelry to metal, causing a severe burn.
!Always have fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes.
!Operating the battery with a low battery voltage can cause premature motor contact failure.
!Do not expose the lift or charger to rain or adverse conditions.
!Replace defective cords or wires immediately.
!Check the battery’s water level frequently.
Battery Charger Operating Instructions
Never operate the charger with either of the cables coiled. Operating a battery charger with the cord either coiled
or wrapped around itself could cause the cord to overheat, melt, and cause a short-circuit or a fire.
Connection: the ribbed wire of the charger’s output cord must be connected to the battery’s negative (-) terminal.
The non-ribbed wire (with words printed on it) must be connected to the battery’s positive (+) terminal.
When properly connected, the charger will indicate the status of charger output:
Flashing green LED – the charger is not seeing a good connection to the battery.
Solid yellow LED – the charger is providing charging current to the battery.
Solid green LED – the charger is maintaining a fully charged battery.
Plug the charger into a standard 115V receptacle. If an extension cord must be used, keep it as short as possible.
Caution: Remember to unplug the charger before moving the equipment. Failure to do so could cause damage to
cords, receptacles, and other equipment.
The battery charger can be left connected to the battery indefinitely without risk of harming the battery.
Troubleshooting:
If the unit does not operate, check all of the wiring connections to make sure they’re both mechanically and
electrically sound – specifically at the battery, the motor, and at any location a wire is connected to the chassis.
Also, make sure the quick-connect plug on the end of the pendant control cord is plugged in correctly (if
applicable).
A fully charged lead acid battery in good condition at room temperature should read 12.65 volts. At 11.9 volts it is
considered to be fully discharged and in need of charging. When checking battery voltage, wait at least 1/2 hour
after the charger has been turned off before checking the battery’s voltage.
If the batteries don’t seem to be taking a charge, check the charger’s 115V supply circuit and the charger’s output
with a voltmeter. If all check okay, confirm the battery’s state of charge using a hydrometer or a voltmeter.

02/05 03-126-121.doc
VESTIL MFG.CO. 5
ROUTINE MAINTENANCE &SAFETY CHECKS –UNI
oWarning: Care should be taken to identify all potential hazards and comply with applicable safety procedures
before beginning work.
oWarning: Raise the platform and install the maintenance props before beginning any inspections or work on the
unit.
oOnly qualified individuals trained to understand mechanical devices and their associated electrical and hydraulic
circuits should attempt troubleshooting and repair of this equipment
(A) Before each use inspect for the following:
1.) Frayed wires
2.) Oil leaks
3.) Pinched or chafed hoses
4.) Damage or structural deformation to the structural members, the cylinder brackets, etc.
5.) Unusual noise or binding, or evidence thereof.
6.) Proper functioning of all limit switches, including those on the perimeter pinch point guard (if applicable).
(B) Inspect monthly for:
1.) The oil level. Oil should be 1½” to 2” below the reservoir’s fill hole with the lift in the fully raised position.
See below for oil specification.
2.) Worn or damaged hydraulic hoses and electrical wires.
3.) Pivot point wear.
4.) Rollers’ looseness and wear.
5.) Integrity of the retaining rings on all rollers and on all pivot point pins.
6.) The integrity of the frame anchor bolts, and for cracks in the concrete around them.
(Non-portable units only.)
7.) Damage or evidence of fatiguing to the fork tubes. (Portable units only.)
8.) Proper functioning of the foot-operated sequencing mechanism.
9.) Proper water level in the battery (DC units only.)
10.) Unusual noises or movement during operation.
11.) All the information, safety, and warning labels being in place and in good condition.
12.) The need to clean off dirt and debris.
(C) Yearly inspection
The oil should be changed if the oil darkens, becomes gritty, or turns a milky color (indicating the presence of water).
Replace with an anti-wear hydraulic oil with a viscosity grade of 150 SUS at 100°F, (ISO 32 at 40°C). Ex: AW 32 or HO
150 hydraulic oil, or a non-synthetic transmission fluid. You may use a synthetic transmission fluid if you flush the
system with the synthetic fluid before filling the reservoir.

02/05 03-126-121.doc
VESTIL MFG.CO. 6
EXPLODED PARTS VIEW -- UNI

02/05 03-126-121.doc
VESTIL MFG.CO. 7
BILL OF MATERIALS -- UNI
Item #: Description Part number Qty.
1 Weldment assembly, back leg 03-510-001 1
2 Weldment assembly, front leg 03-510-002 1
3 Weldment assembly, deck 03-513-035 1
4 Weldment assembly, frame 03-514-022 1
5 Cylinder, hydraulic, 3” x 10” displacement-style 99-021-901 1 or 2
6 Snap ring, external, 11/8ӯ A/L 10
7 Weldment assembly, foot lever mode selector arm 03-540-003 1
8 Pin, hinge, 11/8”Ø x 113/16” long 01-112-004 4
9 Bolt, cylinder retainer 01-118-001 2
10 Pin, roll,
3/16”Ø x 11/8” long A/L 2
11 Bushing, machine, 11/8” ID x 13/4” OD x 18 gauge A/L 6
12 Roller assembly, w/ bushing, 31/4” OD x 11/8” ID 01-527-001 2
13 Nut, jam, ½-13 UNC A/L 2
14 Pin, w/ stop boss, 11/8” OD x 91/4” long 01-112-001 1
15 Pin, roller, 11/8” OD x 95/16” long 03-112-002 1
16 Pin, cylinder clevis w/ stop boss, 11/8” OD x 73/4” long 01-112-015 1
17 Screw,
5/16”-16 UNC x 31/2” long HHCS A/L 1
18 Weldment assembly, foot lever push rod 03-540-004 1
19 Stop, wheel 03-037-001 2
20 Screw, grade 5, ½”-13 UNC x 11/2” long HHCS A/L 4
21 Weldment assembly, foot lever pedal 03-540-004 1
22 Nut, nylock, ½”-13 UNC A/L 4
23 Nut,
3/8”-16 UNC hex A/L 1
24 Screw,
5/16”-18 UNC x 11/2” long HHCS A/L 1
25 Nut, 5/16”-18 UNC hex A/L 2
26 Pin, maintenance 03-130-001 1
27 Guard, vinyl, 16” wide x 38” long A/L 1
28 Rivet, blind A/L 10

02/05 03-126-121.doc
VESTIL MFG.CO. 8
MOTOR &TRANSFORMER CONNECTION DIAGRAMS
CAUTION!If the motor voltage is changed, the wire on the control transformer’s primary wire has to be changed to
match the new motor voltage also.

02/05 03-126-121.doc
VESTIL MFG.CO. 9
ELECTRICAL DIAGRAM -- UNI
oWarning: Care should be taken to identify all potential hazards and comply with applicable safety procedures before
beginning work. Fully lower or secure the platform with the maintenance props, and ensure that all system
pressure and power have been removed, before attempting to work on the electrical or hydraulic systems.
oRaise the platform and install the maintenance props before beginning inspections or work on the unit.
oOnly qualified individuals trained to understand mechanical devices and their associated electrical and hydraulic
circuits should attempt troubleshooting and repair of this equipment

02/05 03-126-121.doc
VESTIL MFG.CO. 10
HYDRAULIC DIAGRAM –LIFT-HOLD-LOWER CIRCUITS
oWarning: Care should be taken to identify all potential hazards and comply with applicable safety procedures
before beginning work. Fully lower or secure the platform, and ensure that all system pressure and power have
been removed, before attempting to work on the electrical or hydraulic systems.
oOnly qualified individuals trained to understand mechanical devices and their associated electrical and hydraulic
circuits should attempt troubleshooting and repair of this equipment
oCaution: Do not use brake fluid or jack oils in the hydraulic system. If oil is needed, use an anti-wear hydraulic
oil with a viscosity of 150 SUS at 100°F (ISO 32 @ 40°C), or non-synthetic transmission fluid.
ELECTRIC /HYDRAULIC BOM –UNI
Item #: Qty.: Part number: Part description:
Electrical parts:
1 1 01-135-XXX Motor; varies by customer spec; contact factory
2 1 LC1-D1810-24V Motor contactor, 30A, w/ 24 VAC coil
3 1 01-129-001 Transformer, control; w/ 24 VAC secondary
4 1 AGC 2 Fuse, for control circuit
5 1 01-029-006 Control enclosure, 6” W x 6” L x 4” D
6 1 01-522-015 Pushbutton control on 8’ cord
7 1 99-034-008 Solenoid coil, 24 VAC
8 1 01-033-017 Connector cord, for solenoid coil
9 1 01-033-015 Cord, power, 14/3, 9’ long, w/ NEMA 5-15 plug (115V units)
10 1 01-022-001 Limit switch, roller-arm (N.C.)
11 1 01-033-002 Cable, 18/2 coil cord, 12”-60” (to toe guard switches)
12 2 159/D Multi-pole terminal strip
Hydraulic parts:
13 1 99-153-006 Valve, relief, 210 bar
14 1 99-153-015 Valve, solenoid, N.C.
15 1 99-153-011 Valve, check
16 1 99-153-040 Flow control spool, 2 gpm
17 1 or 2 99-021-XXX Cylinder, displacement; varies by model; contact factory
18 1 or 2 99-136-XXX Cylinder seal kit; varies by model; contact factory
19 1 99-127-001 Manifold, lift-hold-lower
20 1 01-143-XXX Pump, hydraulic; varies by model; contact factory
21 1 DPS-40-N06 Breather plug
22 1 01-031-005 Fitting, intake screen
23 1½ HO 150 Hydraulic fluid (gallons)
