VIA Technologies AMOS-3000 User manual

user manual
AMOS-3000
Ultra Compact
Industrial Embedded PC
Revision 1.1
1
1
0
-
061
8
2009
-
1
811

II
Copyright and Trademarks
Copyright © 2009 VIA Technologies Incorporated. All rights reserved.
No part of this document may e reproduced, transmitted, transcri ed, stored in a
retrieval system, or translated into any language, in any form or y any means, electronic,
mechanical, magnetic, optical, chemical, manual or otherwise without the prior written
permission of VIA Technologies, Incorporated.
All trademarks are the property of their respective holders.
PS/2 is a registered trademark of IBM Corporation.
Disclaimer
No license is granted, implied or otherwise, under any patent or patent rights of VIA
Technologies. VIA Technologies makes no warranties, implied or otherwise, in regard to
this document and to the products descri ed in this document. The information provided
in this document is elieved to e accurate and relia le as of the pu lication date of this
document. However, VIA Technologies assumes no responsi ility for the use or misuse of
the information in this document and for any patent infringements that may arise from the
use of this document. The information and product specifications within this document are
su ject to change at any time, without notice and without o ligation to notify any person
of such change.
Regulatory Compliance
FCC-A Radio Frequency Interference Statement
This equipment has een tested and found to comply with the limits for a class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasona le protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case the user will e
required to correct the interference at his personal expense.
Notice
The changes or modifications not expressly approved y the party responsi le for
compliance could void the user's authority to operate the equipment.
Notice 2
Shielded interface ca les and A.C. power cord, if any, must e used in order to comply
with the emission limits.
Battery Recycling and Disposal
Only use the appropriate attery specified for this product.
Do not re-use, recharge, or reheat an old attery.
Do not attempt to force open the attery.
Do not discard used atteries with regular trash.
Discard used atteries according to local regulations.
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE

III
Safety Precautions
Do’s
oAlways read the safety instructions carefully.
oKeep this User's Manual for future reference.
oAll cautions and warnings on the equipment should e
noted.
oKeep this equipment away from humidity.
oLay this equipment on a relia le flat surface efore setting
it up.
oMake sure the voltage of the power source and adjust
properly 110/220V efore connecting the equipment to the
power inlet.
oPlace the power cord in such a way that people cannot
step on it.
oAlways unplug the power cord efore inserting any add-on
card or module.
oIf any of the following situations arises, get the equipment
checked y authorized service personnel:
oThe power cord or plug is damaged.
oLiquid has penetrated into the equipment.
oThe equipment has een exposed to moisture.
oThe equipment has not worked well or you cannot
get it work according to User's Manual.
oThe equipment has dropped and damaged.
oThe equipment has o vious sign of reakage.
Don’ts
oDo not leave this equipment in an environment
unconditioned or in a storage temperature a ove 60°C
(140°F). The equipment may e damaged.
oDo not leave this equipment in direct sunlight.
oNever pour any liquid into the opening. Liquid can cause
damage or electrical shock.
oDo not place anything over the power cord.
oDo not cover the ventilation holes. The openings on the
enclosure protect the equipment from overheating

IV
Box Contents
 1 x AMOS-3000
 1 x "Drivers" CD
 1 x package of screws for mounting
 1 x 2-pin Phoenix to DC Jack ca le
 1 x thermal pad for memory
 1 x set of ru er washers for desktop mounting
 1 x VESA mounting plate
Ordering Information
Model Number Description
AMOS-3000-1C10A1 VIA C7® 1.0GHz Processor, 1 x VGA, 1 x
DVI, HD Audio, 1 x GigaLAN, 4 x USB, 1 x
COM, DC-In@12V
AMOS-3000-2C10A1 VIA C7® 1.0GHz Processor, 1 x VGA, 1 x
DVI, 1 x COM, 1 x GigaLAN, 4 x USB, HD
Audio, DC-in 12V, AMOS-3000-1ZSZA1
storage chassis, SATA HDD ca le, SATA
HDD power ca le
Optional accessories
99G63-020095 AC-to-DC adapter, DC 12V/5A, 60W
99G33-02032C Power Ca le, 180 cm, USA type
99G33-02034C Power Ca le with PSE mark
99G33-02033C Power Ca le, 180 cm, Europe type
99G33-02031C Power Ca le, 180 cm, UK type

V
T ABLE O C ONTENTS
1 Product Overview............................................................................................... 1
Key Features........................................................................................................... 2
Specifications ......................................................................................................... 4
AMOS- 000 Dimensions ................................................................................. 6
AMOS- 000 I/O Layout (front)..................................................................... 7
AMOS- 000 I/O Layout (rear) ...................................................................... 7
Accessories.............................................................................................................. 8
AMOS- 000-1ZSZA1 storage expansion kit...................................... 8
IDE Flash DOM................................................................................................ 8
SATA Flash DOM............................................................................................ 8
SATA extension cable................................................................................... 9
SATA 2.5” hard disk ....................................................................................... 9
SATA hard disk cables.................................................................................. 9
WLAN kit ..........................................................................................................10
VESA mounting kit ......................................................................................10
2 Basic installation .................................................................................................11
Installing the memory .....................................................................................12
Installing the IDE Flash DOM ......................................................................15
Installing the CMOS battery .........................................................................17
Installing the mounting plate ......................................................................20
Installing the expansion kit ...........................................................................21
Prepping the AMOS- 000 ............................................................................22
Installing the SATA Flash ROM ...................................................................28
Installing the SATA 2.5” hard disk.............................................................. 0
Installing the WLAN kit ...................................................................................
Mounting the AMOS- 000-1ZSZA1 ........................................................ 5
Installing the mounting plate ...................................................................... 6
4 BIOS Setup............................................................................................................ 8
Entering the BIOS Setup Menu .................................................................. 9
Control Keys ......................................................................................................... 9
Navigating the BIOS Menus ........................................................................40
Getting Help ........................................................................................................40
Main Menu ...........................................................................................................41
Standard CMOS Features.........................................................................41
Advanced BIOS Features .........................................................................41
Advanced Chipset Features....................................................................41

VI
Integrated Peripherals................................................................................41
Power Management Setup.....................................................................41
PnP/PCI Configurations.............................................................................41
Frequency/Voltage Control....................................................................42
Load Fail-safe Defaults ...............................................................................42
Load Optimized Defaults..........................................................................42
Set Supervisor Password...........................................................................42
Set User Password .......................................................................................42
Save & Exit Setup ..........................................................................................42
Exit Without Saving.....................................................................................42
Standard CMOS Features..............................................................................4
Date ....................................................................................................................4
Time ....................................................................................................................4
Video..................................................................................................................4
Halt On..............................................................................................................4
IDE Channels.......................................................................................................44
Advanced BIOS Features...............................................................................45
Virus Warning................................................................................................45
Quick Power On Self-Test.........................................................................45
First/Second/Third Boot Device............................................................46
Boot Other Device.......................................................................................46
Boot Up NumLock Status.........................................................................46
Typematic Rate Setting ..............................................................................46
Typematic Rate ..............................................................................................46
Typematic Delay ...........................................................................................47
Security Option..............................................................................................47
MPS Version Control for OS....................................................................47
OS Select for DRAM > 64 MB.................................................................47
Full Screen Logo Show .............................................................................47
CPU Features.......................................................................................................48
C7 CMPXCHG8.............................................................................................48
C7 NoExecute (NX).....................................................................................48
Hard Disk Boot Priority....................................................................................49
Advanced Chipset Features.........................................................................50
Memory Hole .................................................................................................50
System BIOS Cacheable ............................................................................50
Video RAM Cacheable ..............................................................................50
Init Display First..............................................................................................50
Select Display Device..................................................................................50
Panel Type .......................................................................................................51
AGP & P2P Bridge Control............................................................................52
AGP Aperture Size .......................................................................................52
AGP .0 Mode ................................................................................................52
AGP Driving Control...................................................................................52

VII
AGP Driving Value ......................................................................................52
AGP Fast Write ..............................................................................................5
AGP Master 1 WS Write ...........................................................................5
AGP Master 1 WS Read ............................................................................5
AGP .0 Calibration Cycle........................................................................5
VGA Share Memory Size ..........................................................................5
Direct Frame Buffer.....................................................................................5
CPU & PCI Bus Control ...................................................................................54
PCI Master 0 WS Write ..............................................................................54
PCI Delay Transaction ................................................................................54
DRDY_Timing.................................................................................................54
Integrated Peripherals.....................................................................................55
UltraDMA66 Control ..................................................................................55
WatchDog Support ....................................................................................55
WatchDog Timer Select............................................................................55
WatchDog Count Value..........................................................................55
Onboard Serial Port ....................................................................................55
VIA OnChip PCI Device..................................................................................56
Azalia HDA Controller................................................................................56
USB Device Setting ...........................................................................................57
USB 1.0 Controller .......................................................................................57
USB 2.0 Controller .......................................................................................57
USB Operation Mode ................................................................................57
USB Keyboard Function............................................................................58
USB Storage Function................................................................................58
Power Management Setup..........................................................................59
ACPI Suspend Type.....................................................................................59
Power Management Option..................................................................59
HDD Power Down .....................................................................................60
Suspend Mode ..............................................................................................60
Video Off Option..........................................................................................60
Video Off Method........................................................................................60
MODEM Use IRQ .........................................................................................60
Soft-Off by PWRBTN....................................................................................60
Run VGABIOS if S Resume....................................................................60
AC Loss Auto Restart ..................................................................................61
Wakeup Event Detect.....................................................................................62
PS2KB Wakeup Select ................................................................................62
PS2KB Wakeup Key Select .......................................................................62
PS2MS Wakeup Key Select ......................................................................62
PS2 Keyboard Power On..........................................................................62
PS2 Mouse Power On................................................................................62
PowerOn by PCI Card ...............................................................................6
Modem Ring Resume.................................................................................6

VIII
RTC Alarm Resume ......................................................................................6
Date (of Month)............................................................................................6
Resume Time (hh:mm:ss) .........................................................................6
PnP/PCI Configurations..................................................................................64
PNP OS Installed ...........................................................................................64
Reset Configuration Data.........................................................................65
Resources Controlled By...........................................................................65
PCI/VGA Palette Snoop ............................................................................65
Assign IRQ for VGA.....................................................................................65
Assign IRQ for USB ......................................................................................65
Maximum ASPM supported....................................................................65
Maximum Payload Size..............................................................................65
IRQ Resources .....................................................................................................66
Frequency/Voltage Control.........................................................................67
Auto Detect PCI Clock ...............................................................................67
Spread Spectrum..........................................................................................67
DRAM Clock/Drive Control ..........................................................................68
DRAM Clock....................................................................................................68
DRAM Timing.................................................................................................68
SDRAM CAS Latency Control.................................................................68
Bank Interleave..............................................................................................69
Precharge to Active (Trp) .........................................................................69
Active to Precharge (Tras)........................................................................69
Active to CMD (Trcd)..................................................................................69
REF to ACT/REF (Trfc).................................................................................69
ACT(0) to ACT(1) (TRRD) ..........................................................................69
Read to Precharge (Trtp)..........................................................................70
Write to Read CMD (Twtr).......................................................................70
Write Recovery Time (Twr)......................................................................70
RSAIT Mode.....................................................................................................70
RSAIT Selection ..............................................................................................70
Load Fail-Safe Defaults....................................................................................71
Load Optimized Defaults...............................................................................72
Set Supervisor/User Password ....................................................................7
Save & Exit Setup ...............................................................................................74
Exit Without Saving ..........................................................................................75
5 Driver Installation...............................................................................................76
Driver Utilities.......................................................................................................77
Getting Started ..............................................................................................77
Running the Driver Utilities CD .............................................................77
CD Content ..........................................................................................................78

1
1
Product Overview

2
The AMOS- 000 is a fanless and ultra compact embedded system,
which supports intensive I/O functions for diversified embedded
applications. Based on the VIA Pico-ITX form factor, its innovative
design helps to simplify the efforts of embedded system
integration. The AMOS- 000 carries a qualified thermal
performance design that allows a wide range of operating
temperatures — making it suitable for various industrial or
embedded applications.
The AMOS- 000 is composed of a few main mechanical parts
such as top cover, bottom plate, and front and rear I/O access
plates, which brings optimization to the system integration. It
comes with a built-in IDE 44-pin Flash disk on module (DOM) slot.
The AMOS- 000 also supports SATA storage devices through the
AMOS- 000-1ZSZA1 storage sub-system chassis expansion kit.
With the expansion kit, users choose to either use a SATA Flash
DOM or a 2.5” SATA HDD. The expansion kit also features
mounting holes for the WLAN kit. The AMOS- 000-1ZSZA1
enables the AMOS- 000 to become a flexible storage and WiFi
networking capable embedded system.
KEY EATURES
A fanless, ultra compact chassis for the E
A fanless, ultra compact chassis for the EA fanless, ultra compact chassis for the E
A fanless, ultra compact chassis for the EPIA
PIAPIA
PIA-
--
-P700
P700P700
P700
The AMOS- 000 houses the EPIA-P700 Pico-ITX form factor
embedded board. With a maximum mounting height of only 45
mm, the AMOS- 000 can be used in space critical installation
environments.
Slim
SlimSlim
Slim, s
, s, s
, stylish, fully sealed
tylish, fully sealed tylish, fully sealed
tylish, fully sealed metal alloy
metal alloymetal alloy
metal alloy design
design design
design
The chassis of the AMOS- 000 is composed of four main parts.
The stylishly ridged aluminum top cover does double duty and
acts as the heatsink of the AMOS- 000. Its qualified thermal
performance design allows a wide range of operating
temperatures, suitable for space and environment critical
applications.
D
DD
Dual independent display
ual independent displayual independent display
ual independent display
The AMOS- 000’s dual independent DVI and VGA display
interfaces are designed for diversified applications such as Point of
Information, gaming, and digital signage.
Optimized integration w
Optimized integration wOptimized integration w
Optimized integration with front and rear I/O access
ith front and rear I/O accessith front and rear I/O access
ith front and rear I/O access
Front and rear I/O access enables the AMOS- 000 to easily
support various applications.

3
Storage expansion kit
Storage expansion kitStorage expansion kit
Storage expansion kit
The AMOS- 000-1ZSZA1 storage sub-system chassis expansion kit
enables the AMOS- 000 to have flexible storage options of either
a 2.5” SATA HDD or a SATA interface Flash DOM.
Networking options
Networking optionsNetworking options
Networking options
The AMOS- 000 can provides Gigabit Ethernet support for high
speed data transmission. And through the storage expansion kit,
the optional wireless networking module can provide the AMOS-
000 with the freedom of WiFi access.
Multiple mounting solutions
Multiple mounting solutionsMultiple mounting solutions
Multiple mounting solutions
The AMOS- 000 supports multiple methods for mounting the
chassis securely. The rugged industrial PC can be mounted to a
table, wall, or even to VESA mountable surfaces with the VESA
mounting kit.
Embedded OS
Embedded OS Embedded OS
Embedded OS r
rr
ready
eadyeady
eady
The AMOS- 000 is 100% compatible with several operating
systems including Microsoft Widows XP, Windows XP Embedded,
Windows CE 6.0, and Ubuntu Linux. VIA also provides support for
implementing the AMOS- 000 into embedded applications with
VIA’s SDKs and post-sales consultation to help save development
time.

4
SPECI ICATIONS
CPU options
VIA C7
®
1.0 GHz processor
• NanoBGA2 package
• 400 MHz Front Side Bus
VIA Eden
TM
ULV 500 MHz processor
• NanoBGA2 package
• 400 MHz Front Side Bus
Chipset
VIA VX700 Unified Digital Media IGP chipset
Memory
Supports one 200-pin DDR2 5 MHz SDRAM SODIMM
• up to 1 GB memory size
Display
Integrated VIA UniChrome
TM
Pro II D/2D AGP graphics
• MPEG-2/4 and WMV9 video decoding acceleration
• optimized Unified Memory Architecture (UMA)
• up to 128 MB frame buffer using system memory
• supports dual independent views
Audio
VIA VT1708A High Definition Audio Codec
Storage
Supports one IDE 44-pin interface Flash DOM (default)
Optional AMOS- 000-1ZSZA1 expansion kit:
• supports one SATA 2.5” hard disk drive
• supports one SATA interface Flash DOM
Net ork
VT6122 Gigabit Ethernet controller
• 10/100/1000 Mbps Ethernet
I/O
Front I/O:
• four USB 2.0 ports
• one DIO port
• Line-out, Line-in, and Mic-in TRS jacks
Rear I/O:
• one VGA port
• one DVI-D port
• one COM port
• one LAN port
• one DC-in port
Dimensions
1 5 mm(w) x 45 mm(H) x 1 1 mm (D)
Weight
0.9 kg (net weight)
BIOS
Award BIOS
4Mbit Flash

5
System and
Po er
Management
Watchdog Timer
• programmable system reset 1~255 seconds
ACPI 2.0 Compliant
Po er supply
Output Rating:
• Maximum: 15.86 W
• Typical: 8.11 W
Fuse Rating:
• 7 A @ 24 V
Input Voltage:
• 12 VDC
Typical:
• 12 VDC @ 0.68 A,
Operating
temperature
• C7 1.0 GHz CPU & Flash DOM: -20°C ~ 60°C
• Eden ULV 500 MHz CPU & Flash DOM: -20°C ~ 70°C
• either CPU & 2.5” hard disk: 0°C ~ 45°C
Relative
humidity
• 95% @ 45°C (non-condensing)
Vibration
loading during
operation
• 7 Grms, IEC 60068-2-64, random
5 ~ 500Hz, 1 Oct./min, 1hr/axis
(Flash DOM only)
• 1 Grms, IEC 60068-2-64, random
5 ~ 500Hz, 1 Oct./min, 1hr/axis
(hard drive only)
Shock during
operation
• 70G , IEC 60068-2-27, half size, 11ms duration
(Flash DOM only)
• 20G , IEC 60068-2-27, half size, 11ms duration
(hard drive only)
Certifications
EMC Approval:
• CE
• FCC Class A
Safety Approval:
• UL

6
AMOS-3000 DIMENSIONS

7
AMOS-3000 I/O LAYOUT (RONT)
AMOS-3000 I/O LAYOUT (REAR)

8
ACCESSORIES
AMOS-3000-1ZSZA1 storage expansion kit
IDE lash DOM
SATA lash DOM

9
SATA extension cable
SATA 2.5” hard disk
SATA hard disk cables

10
WLAN kit
VESA mounting kit

11
2
Basic installation

12
INSTALLING THE MEMORY
Step 1
Step 1Step 1
Step 1
Locate memory access cover on the bottom of the AMOS- 000
and remove the two screws as indicated in the figure below.
Step
Step Step
Step 2
22
2
Remove the memory access cover.
