About this Guide
This section explains how to use this Getting Started Guide.
•“Purpose and scope” on page iv
•“Assumptions” on page iv
•“Conventions” on page iv
•“Safety and compliance information” on page vi
•“Technical assistance” on page viii

About this Guide
Purpose and scope
ONA-800 Getting Started Guide
Page iv 22142812, D1 R004 August 2020
Purpose and scope
The purpose of this manual is to help you successfully use the features and capabilities
of the ONA-800. This manual includes task-based instructions that describe how to
configure, use, and troubleshoot the general functions of the base unit.
Assumptions
This manual is intended for novice, intermediate, and experienced users who want to
use the test instrument effectively and efficiently. VIAVI assumes that you have basic
computer experience and are familiar with basic telecommunication concepts, termi-
nology, and safety.
Conventions
This guide uses typographical and symbols conventions as described in the following
tables.
Table 1 Text formatting and other typographical conventions
Item(s) Example(s)
Buttons, keys, or switches that you
press or flip on a physical device.
Press the On button.
– Press the Enter key.
– Flip the Power switch to the on position.
Buttons, links, menus, menu
options, tabs, or fields on a PC-
based or Web-based user inter-
face that you click, select, or type
information into.
Press the On button.
– Click File > Properties.
– Click the Properties tab.
– Type the name of the probe in the Probe Name
field.
Directory names, file names, and
code and output messages that
appear in a command line interface
or in some graphical user interfaces
(GUIs).
$NANGT_DATA_DIR/results (directory)
–test_products/users/defaultUser.xml
(file name)
–All results okay. (output message)
Text you must type exactly as
shown into a command line inter-
face, text file, or a GUI text field.
– Restart the applications on the server using the
following command:
$BASEDIR/startup/npiu_init restart
Type: a:\set.exe in the dialog box.
Command line option separators. platform [a|b|e]
Optional arguments (text variables
in code).
login [platform name]
Required arguments (text variables
in code).
<password>

About this Guide
Conventions
ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page v
Table 2 Symbol conventions
This symbol indicates a note that includes important supplemental information or
tips related to the main text.
This symbol represents a general hazard. It may be associated with either a DAN-
GER, WARNING, CAUTION, or ALERT message. See Table 3 for more informa-
tion.
This symbol represents an alert. It indicates that there is an action that must be per-
formed in order to protect equipment and data or to avoid software damage and
service interruption.
This symbol represents hazardous voltages. It may be associated with either a
DANGER, WARNING, CAUTION, or ALERT message. See Table 3 for more infor-
mation.
This symbol represents a risk of explosion. It may be associated with either a DAN-
GER, WARNING, CAUTION or ALERT message. See Table 3 for more information.
This symbol represents a risk of a hot surface. It may be associated with either a
DANGER, WARNING, CAUTION, or ALERT message. See Table 3 for more infor-
mation.
This symbol represents a risk associated with fiber optic lasers. It may be associ-
ated with either a DANGER, WARNING, CAUTION or ALERT message. See
Table 3 for more information.
This symbol, located on the equipment, battery, or the packaging indicates that
the equipment or battery must not be disposed of in a land-fill site or as municipal
waste, and should be disposed of according to your national regulations.
Table 3 Safety definitions
Term Definition
DANGER Indicates a potentially hazardous situation that, if not avoided, will result
in death or serious injury. It may be associated with either a general haz-
ard, high voltage, or other symbol. See Table 2 for more information.
WARNING Indicates a potentially hazardous situation that, if not avoided, could
result in death or serious injury. It may be associated with either a gen-
eral hazard, high voltage, or other symbol. See Table 2 for more informa-
tion.
CAUTION Indicates a potentially hazardous situation that, if not avoided, could
result in minor or moderate injury and/or damage to equipment.
It may be associated with either a general hazard, high voltage, or risk of
explosion symbol. See Table 2 for more information.
When applied to software actions, indicates a situation that, if not
avoided, could result in loss of data or a disruption of software operation.
ALERT Indicates that there is an action that must be performed in order to pro-
tect equipment and data or to avoid software damage and service inter-
ruption.

About this Guide
Safety and compliance information
ONA-800 Getting Started Guide
Page vi 22142812, D1 R004 August 2020
Safety and compliance information
Safety information is provided in the document Safety Instructions - ONA-800 Base
Unit, 22137678, which is shipped with the ONA-800. Compliance information is listed
below.
California Proposition 65
California Proposition 65, officially known as the Safe Drinking Water and Toxic
Enforcement Act of 1986, was enacted in November 1986 with the aim of protecting
individuals in the state of California and the state’s drinking water and environment from
excessive exposure to chemicals known to the state to cause cancer, birth defects or
other reproductive harm.
For the VIAVI position statement on the use of Proposition 65 chemicals in VIAVI prod-
ucts, see the Hazardous Substance Control section of VIAVI’s Standards and Policies
web page.
Federal Communications Commission (FCC)
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment was tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case you
will be required to correct the interference at your own expense.
The authority to operate this equipment is conditioned by the requirements that no
modifications be made to the equipment unless the changes or modifications are
expressly approved by VIAVI.
Caution:
•The device complies with FCC and Industry Canada RF exposure limits set forth
for an uncontrolled environment. For body worn operation, the instruments meet
the FCC RF exposure limits when used with an accessory that contains no metal
and that positions the instrument a minimum of 0cm from the body.
•This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.

About this Guide
Safety and compliance information
ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page vii
Industry Canada (IC)
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions: 1) This device may not cause interference; and,
2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appar-
eils radio exempts de licence. L'exploitation est autorisée aux deux conditions suiva-
ntes: 1) l'appareil ne doit pas produire de brouillage; et, 2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Device operation in the band 5150–5250 MHz is for indoor use only.
Dans la bande de fréquence 5150-5250 Mhz, l’utilisation du produit doit être unique-
ment en intérieur.
Europe
EU WEEE and Battery Directives
This product, and the batteries used to power the product, should not be disposed of
as unsorted municipal waste and should be collected separately and disposed of
according to your national regulations.
VIAVI has established a take-back processes in compliance with the EU Waste Elec-
trical and Electronic Equipment (WEEE) Directive, 2012/19/EU, and the EU Battery
Directive, 2006/66/EC.
Instructions for returning waste equipment and batteries to JDSU can be found in the
WEEE section of VIAVI’s Standards and Policies web page.
If you have questions concerning disposal of your equipment or batteries, contact
JDSU’s WEEE Program Management team at [e-mail].
EU REACH
Article 33 of EU REACH regulation (EC) No 1907/2006 requires article suppliers to
provide information if a listed Substances of Very High Concern (SVHC) is present in
an article above a certain threshold.
For information on the presence of REACH SVHCs in VIAVI products, see the
Hazardous Substance Control section of VIAVI’s Standards and Policies web page.
EU CE Marking Directives (LV, EMC, RoHS, RE)
This product conforms with all applicable CE marking directives. Please see EU Decla-
ration of Conformity for details.

About this Guide
Technical assistance
ONA-800 Getting Started Guide
Page viii 22142812, D1 R004 August 2020
EU Radio Equipment Directive
In accordance with Article 10.8 of the EU Radio Equipment Directive 2014/53/EU, the
following table provides information on the frequency bands and the maximum RF
transmit power of this product for sale in the EU:
Technical assistance
For technical assistance, call 1-844-GO-VIAVI. For the latest TAC information, go to
http://www.viavisolutions.com/en/services-and-support/support/technical-assistance.
Frequency Range
(MHz)
Channels Used Max Transmit Power
(dBm/mW)
2402-2480 0-78 9dBm (8mW)
2412-2462 1-11 20.5dBm (112mW)
5180-5240 36-48 15.5dBm (36mW)
5260-5320 52-64 15.5dBm (36mW)
5500-5700 100-140 15.5dBm (36mW)
5745-5825 149-165 15dBm (32mW)

ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 1
ONA-800 Getting Started Guide
Purpose and scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Safety and compliance information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
California Proposition 65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Federal Communications Commission (FCC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Industry Canada (IC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Europe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Chapter 1 Getting started 1
About the ONA-800 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpacking and inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What’s included with the base unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Attaching the screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Attaching modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CAA/OTDR Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Solution modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Powering the base unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Battery Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
AC power adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2 Setting up the system 11
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Job Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting up remote access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting to a Wi-Fi network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting up a Bluetooth connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 2
Using Smart Access Anywhere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Enabling software options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Viewing available software options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Enabling purchased software options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Updating the system software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Updating the system software using a USB drive . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Updating the system software over the network. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Synchronizing to the StrataSync server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 3 Smart Access Anywhere 23
About Smart Access Anywhere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Licensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Downloading and extracting the utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Establishing a connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Wired Ethernet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
WiFi Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Smartphone with Data Tethering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Launching the utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Launching the utility on the instrument. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Testing your connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Launching the utility on your PC or mobile device . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Displaying the instrument’s user interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Transferring files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Displaying and modifying connection settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Appendix A Physical specifications 31

ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 1
1
Chapter 1 Getting started
This chapter explains how to use this Getting Started Guide.
The topics discussed in this chapter are as follows:
•“About the ONA-800” on page 2
•“Unpacking and inspection” on page 2
•“Features” on page 3
•“Attaching the screen” on page 5
•“Attaching modules” on page 6
•“Powering the base unit” on page 7

Chapter 1 Getting started
About the ONA-800
ONA-800 Getting Started Guide
Page 2 22142812, D1 R004 August 2020
About the ONA-800
The ONA-800 is a modular communications test and measurement instrument that may
be used both indoors and outdoors. Modules with specific test capabilities can be
added and removed as required. The unit features an 8-inch touchscreen for quick
access to the touch-based user interface. Powered by either external AC power or
batteries in the field, the ONA-800 is both rugged and portable. Capabilities such as
WiFi and Bluetooth are optional.
Figure 1 shows the front panel touchscreen.
Figure 1 Front panel touchscreen
This section covers the following topics:
•“Unpacking and inspection” on page 2
•“Features” on page 3
•“Attaching the screen” on page 5
Unpacking and inspection
VIAVI typically ships our instruments using anti-static packing material to stabilize the
components inside the box. When unpacking the components, verify that all the items
you ordered are included in the package. Accessories may be shipped in a separate
box.
After you unpack the components, examine the top, bottom, front, and side panels,
including ports, LEDs, and the touchscreen for damage.
If any component shows signs of damage, contact VIAVI Customer Care at 1-844-GO-
VIAVI. For the latest TAC information, go to http://www.viavisolutions.com/en/services-
and-support/support/technical-assistance. For information about returning equipment,
see “Returning equipment to VIAVI”.
Consider saving shipping boxes and packing materials in case you need to repackage
the components for shipment.

Chapter 1 Getting started
Features
ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 3
What’s included with the base unit
The ONA-800 base unit ships with the following equipment:
•One field-replaceable Lithium Ion battery (C5BATTERY98)
•AC adapter (PS-330W24V) and cord
•Up to two dummy modules, depending on the number of solution modules
ordered
•LCD screen protector
•Soft-shell travel case
Features
Figure 2 shows the top panel of the ONA-800.
Figure 2 ONA-800 top panel
Figure shows the right and left side panels.
1Modules
2AC/DC power adapter port (19-27 V, 15A Max)
3Power button
4LAN port
5USB port
6USB port
7USB-C port (device only)
8Micro SD card port
9Optional module slot

Chapter 1 Getting started
Features
ONA-800 Getting Started Guide
Page 4 22142812, D1 R004 August 2020
Figure 3 Right and left side panels
Figure 4 shows the back panel without the CAA/OTDR modules attached.
Figure 4 Back panel, no modules
1Modules
2Cooling fans
3Battery access door
1Screws
2ESD ground
3Module connector ports
4Hex key

Chapter 1 Getting started
Attaching the screen
ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 5
Attaching the screen
To attach the screen to the base unit
1Set the screen onto the base, ensuring the mating connectors between the two
pieces are aligned, as shown in Figure 5.
Figure 5 Set screen to base
2Set unit so you have access to the back. Using the Hex Key located in the
groove on the back panel of the screen, tighten the four fasteners, as
shown in Figure 6.
Figure 6 Fastener locations

Chapter 1 Getting started
Attaching modules
ONA-800 Getting Started Guide
Page 6 22142812, D1 R004 August 2020
Attaching modules
This section describes how to attach CAA/OTDR modules and solution modules to the
ONA-800.
CAA/OTDR Modules
The following procedure describes how to attach CAA/OTDR modules to the ONA-800.
To attach CAA/OTDR modules
1Power down the ONA-800 and disconnect from AC power.
2Place the unit so that you have access to the back and remove the termination
cover by removing the screws that hold it in place.
3Locate the hinges on the module and insert them into the base at a 45 to 60
degree angle.
4Pivot the module down towards the connector.
5Seat the module into the connector with slight pressure.
6Tighten the screws on the module.
The following procedure describes how to remove CAA/OTDR modules.
To remove CAA/OTDR modules
1Power down the ONA-800 and disconnect from AC power.
2Place the unit so that you have access to the back.
3Remove the screws on the module.
4Remove the module from the ONA-800.
Solution modules
The following procedure describes how to install a solution module to the ONA-800.
To attach a solution module
1Power down the ONA-800 and disconnect from AC power.
2Place the unit so that you have access to the back and remove the termination
cover by removing the screws that hold it in place.
3Set the module onto the base, ensuring the mating connectors between the two
pieces are aligned, as shown in Figure 7.

Chapter 1 Getting started
Powering the base unit
ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 7
Figure 7 Solution module to screen
4Insert the hex key in the brass fittings on the rear of the module and tighten the
internal captive fasteners to secure the module to the display.
5Place the ONA-800 base onto the module, ensuring the mating connectors are
aligned, as shown in Figure 8.
Figure 8 ONA-800 base to module
6Using the hex key, tighten the captive fasteners on the rear of the base that
secure it to the module.
7Re-attach the CAA/OTDR modules or back cover.
Powering the base unit
Power is supplied to the instrument by the battery or the AC power adapter. For the
ONA-800, the adapter is supplied with the instrument. Use of AC power adapters or
batteries other than those supplied with your ONA-800 is not recommended as other
slices/modules may be supplied with incompatible adapters or batteries. When

Chapter 1 Getting started
Powering the base unit
ONA-800 Getting Started Guide
Page 8 22142812, D1 R004 August 2020
supplying power using AC power adapter, you need to verify that you have the correct
adapter.
Battery Installation
The base unit can operate supplied by the AC power adapter shipped with the unit.
Figure 9 shows the battery label.
Figure 9 ONA-800 battery label
CAUTION:
Do not attempt to run the ONA-800 in an enclosure such as the soft-shell travel
case. Doing so may damage the unit.
CAUTION:
The Lithium Ion batteries shipped with the unit can explode if incorrectly
installed. When replacing the battery, ensure that you only use VIAVI approved
battery types, as shown in Figure 7, and that they are properly installed. Always
dispose of batteries according to your local safety and environmental regula-
tions.
NOTE:
VIAVI recommends that you either power off the unit or switch to AC power
before replacing the batteries.

Chapter 1 Getting started
Powering the base unit
ONA-800 Getting Started Guide
August 2020 22142812, D1 R004 Page 9
To install the battery
AC power adapter
The base unit with all applications installed operates from 19-27V DC and can operate
supplied by the 19V DC, 160W AC power adapter shipped with the unit. The nominal
input ratings of the power adapter are 100-240V AC, 50-60Hz, and it auto-ranges
between 90-264V AC and 47-63Hz. The mains supply cord used with the power
adapter must be grounded with a connection to protective earth.
Figure 10 ONA-800 AC power adapter label
1Battery access door
2Field-replaceable Lithium Ion battery
NOTE:
Before connecting an AC power adapter to the base unit, refer to the label on
the adapter (Figure 10) to confirm that it is the correct adapter for use with the
unit. AC power adapters supplied with modules might not be compatible for use
with the ONA-800.
