Viavi SmartOTDR 100 User manual

SmartOTDR 100
Mainframe
Handheld OTDR, designed for
the construction, turn-up and
maintenance of fiber networks
User Manual

Viavi Solutions
1-844-GO-VIAVI
www.viavisolutions.com
SmartOTDR 100 Mainframe
Handheld OTDR, designed for the
construction, turn-up and
maintenance of fiber networks
User Manual

User Manual 7SMART102 Rev002 v
Notice Every effort was made to ensure that the information in this document
was accurate at the time of printing. However, information is subject to
change without notice, and Viavi reserves the right to provide an
addendum to this document with information not available at the time that
this document was created.
Copyright © Copyright 2016 Viavi, LLC. All rights reserved. Viavi, Enabling Broad-
band and Optical Innovation, and its logo are trademarks of Viavi, LLC.
All other trademarks and registered trademarks are the property of their
respective owners. No part of this guide may be reproduced or trans-
mitted electronically or otherwise without written permission of the
publisher.
Trademarks Viavi and SmartOTDR are trademarks or registered trademarks of Viavi
in the United States and/or other countries.
Microsoft, Windows and Microsoft Internet Explorer are either trade-
marks or registered trademarks of Microsoft Corporation in the United
States and/or other countries.
Specifications, terms, and conditions are subject to change without
notice. All trademarks and registered trademarks are the property of their
respective companies.
WEEE Directive
Compliance
Viavi has established processes in compliance with the Waste Electrical
and Electronic Equipment (WEEE) Directive, 2002/96/EC, and the
Battery Directive, 2006/66/EC.
This product, and the batteries used to power the product, should not be
disposed of as unsorted municipal waste and should be collected sepa-
rately and disposed of according to your national regulations. In the
European Union, all equipment and batteries purchased from Viavi after
2005-08-13 can be returned for disposal at the end of its useful life. Viavi
will ensure that all waste equipment and batteries returned are reused,
recycled, or disposed of in an environmentally friendly manner, and in
compliance with all applicable national and international waste legisla-
tion.
It is the responsibility of the equipment owner to return equipment and
batteries to Viavi for appropriate disposal. If the equipment or battery was
imported by a reseller whose name or logo is marked on the equipment
or battery, then the owner should return the equipment or battery directly
to the reseller.

vi User Manual 7SMART102 Rev002
Instructions for returning waste equipment and batteries to Viavi can be
found in the Environmental section of Viavi’s web site at www.viavisolu-
tions.com.. If you have questions concerning disposal of your equipment
or batteries, contact Viavi’s WEEE Program Management team.

User Manual 7SMART102 Rev002 vii
Table of Contents
About This Guide xv
Purpose and scope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Assumptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Chapter 1 Safety information 1
Battery and AC/DC safety information . . . . . . . . . . . . . . . . .2
Precautions relating to optical connections . . . . . . . . . . . .3
Laser Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Laser classes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Warning labels for the laser classes. . . . . . . . . . . . . . . . . . .3
Chapter 2 Introducing the SmartOTDR mainframe 5
Unpacking the instrument . . . . . . . . . . . . . . . . . . . . . . . . . .6
Main features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Hard keys and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Front panel hard keys . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Front panel indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Table of Contents
User Manual 7SMART102 Rev002 viii
Chapter 3 Starting up 11
Setting the adaptable plug to the mains adapter . . . . . . . .12
Charging the battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connecting the mains adapter. . . . . . . . . . . . . . . . . . . . . .13
First use of the battery . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Charging the Li-Polymer battery . . . . . . . . . . . . . . . . . . . .13
Li-Polymer Battery charging time. . . . . . . . . . . . . . . . . . . .14
Battery charge level display . . . . . . . . . . . . . . . . . . . . . . .14
Switching the SmartOTDR on and off . . . . . . . . . . . . . . . .15
Switching on the SmartOTDR . . . . . . . . . . . . . . . . . . . . . .15
Switching off the SmartOTDR . . . . . . . . . . . . . . . . . . . . . .15
Resetting the SmartOTDR . . . . . . . . . . . . . . . . . . . . . . . .15
Choosing the position of the instrument on the work
surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
First start: configuring your regional settings. . . . . . . . . .16
Chapter 4 Configuring the SmartOTDR 19
Displaying the System Settings screen . . . . . . . . . . . . . . .20
Defining the screen parameters of the SmartOTDR. . . . . .20
Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Defining the Automatic shutdown and the type of batteries .
22
Automatic shutdown. . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Type of batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Chapter 5 Power meter & VFL (Visual Fault Locator) 23
Connection to the power meter and VFL . . . . . . . . . . . . . .24
Using the Power meter via USB port . . . . . . . . . . . . . . . . .24
Configuring the parameters of the power meter . . . . . . . . .24
Configuring the alarm parameters . . . . . . . . . . . . . . . . .25
Configuring the Measurement parameters. . . . . . . . . . . .25
Configuring the Link parameters . . . . . . . . . . . . . . . . . .26
Configuring the File parameters . . . . . . . . . . . . . . . . . .31

Table of Contents
User Manual 7SMART102 Rev002 ix
Display of results and commands . . . . . . . . . . . . . . . . . . .32
Result of the measurement in progress. . . . . . . . . . . . . .32
Table of results. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Commands of the power meter parameters . . . . . . . . . . .33
Performing a measurement . . . . . . . . . . . . . . . . . . . . . . .34
Power measurement . . . . . . . . . . . . . . . . . . . . . . . . . .34
Optical link loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
VFL Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
VFL connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Visual Fault Locator function (VFL) . . . . . . . . . . . . . . . . . .36
Storing and reloading results. . . . . . . . . . . . . . . . . . . . . . .36
File Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Storing results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Loading results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Chapter 6 Scope 37
Scope feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Installation of tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Configuring the P5000i Scope . . . . . . . . . . . . . . . . . . . . . .39
Scope connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Configuring the Scope . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Adding a new profile . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
About page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Starting up with the scope . . . . . . . . . . . . . . . . . . . . . . . . .43
Freeze mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
High Mag. / Low Mag. . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Live mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Launching a test of the connector and fiber end-face . . . .44
Launching a test of the connector and fiber end-face . . . . . .44
Overlay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Mosaic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Loading a picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
File menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Saving the test result in a jpg file and / or in a report . . . . . .48

Table of Contents
User Manual 7SMART102 Rev002 x
Chapter 7 Connectivity 51
Establishing connection. . . . . . . . . . . . . . . . . . . . . . . . . . .52
Via Bluetooth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Installing the Bluetooth option onto the SmartOTDR . . . . .52
Pairing the Platform with a device . . . . . . . . . . . . . . . . .53
Searching new devices to be paired with the Platform . . . .55
Removing the Pairing . . . . . . . . . . . . . . . . . . . . . . . . .56
Via Wifi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Installation of the WIFI option in the Platform . . . . . . . . . .56
Configuring the WIFI access. . . . . . . . . . . . . . . . . . . . .57
Connection to SSID . . . . . . . . . . . . . . . . . . . . . . . . . .59
Configuring the WIFI mode to which the Platform is connected
59
Via Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Connecting the SmartOTDR and the PC. . . . . . . . . . . . .60
Configuring the SmartOTDR via Ethernet . . . . . . . . . . . .61
Via Cloud Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Principle and prerequisites of the Cloud Storage . . . . . . .63
Configuring and connecting to Cloud Storage on the SmartOT-
DR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Smart Access Anywhere. . . . . . . . . . . . . . . . . . . . . . . . . .65
Connection modes . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Pre-requisite for using the Smart Access Anywhere Application
67
Downloading the Viavi application on PC . . . . . . . . . . . .68
Launching the SmartAccess Anywhere application . . . . . .69
Using Remote screen and File Transfer applications . . . . .71
Working with files and directories on SmartOTDR. . . . . . .74
Connection information and settings . . . . . . . . . . . . . . .74
Data Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Transferring files via Bluetooth . . . . . . . . . . . . . . . . . . .77
Transferring files to/from a PC via WIFI . . . . . . . . . . . . .78
Transferring files using Cloud Storage . . . . . . . . . . . . . .79
VNC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Transferring the interface on a PC via WIFI . . . . . . . . . . .80
Transferring the Interface via Ethernet . . . . . . . . . . . . . .81
Virtual control buttons bar . . . . . . . . . . . . . . . . . . . . . .82
Equivalence between the keyboard and SmartOTDR . . . .83
Stratasync. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Principle and prerequisites of the Stratasync . . . . . . . . . . .83

Table of Contents
User Manual 7SMART102 Rev002 xi
Configuring and synchronizing the SmartOTDR . . . . . . . . .84
Connecting the SmartOTDR to Stratasync . . . . . . . . . . . . .85
Chapter 8 File management 87
File Explorer Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Directories and Files selections. . . . . . . . . . . . . . . . . . . . .88
Directory selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Files selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Directories & Files editing functions . . . . . . . . . . . . . . . . .89
Copy/Cut & Paste files/directories . . . . . . . . . . . . . . . . . . .89
Renaming a directory / file . . . . . . . . . . . . . . . . . . . . . . . .90
Deleting a directory / file . . . . . . . . . . . . . . . . . . . . . . . . . .90
Working with directories and files from the explorer. . . . .90
Creating a directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Opening files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
File Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Sorting files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Transferring files between two SmartOTDR . . . . . . . . . . . .92
Establishing connection between two SmartOTDR . . . . . .92
Transferring files. . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Cancelling the connection . . . . . . . . . . . . . . . . . . . . . .93
Transferring files to a PC with the USB cable . . . . . . . . . . .93
Establishing connection SmartOTDR <-> PC . . . . . . . . . .94
Transferring files onto the PC . . . . . . . . . . . . . . . . . . . .95
Cancelling the connection . . . . . . . . . . . . . . . . . . . . . .95
Creating a screenshot . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Taking a screenshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Name of the screenshots files . . . . . . . . . . . . . . . . . . . . . .96
Merging pdf or txt files . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Storage media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Storage media built into the SmartOTDR . . . . . . . . . . . . . .98
External USB storage media . . . . . . . . . . . . . . . . . . . . . . .98
USB memory stick connection . . . . . . . . . . . . . . . . . . .98
USB memory stick disconnection . . . . . . . . . . . . . . . . .98
Abbreviations for storage media . . . . . . . . . . . . . . . . . . . .99
Chapter 9 Technical specifications 101
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .102

Table of Contents
User Manual 7SMART102 Rev002 xii
Display specifications. . . . . . . . . . . . . . . . . . . . . . . . . . .102
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Input/Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Mains adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Dimensions - Weight . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
EMI/ESD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Drop test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Shocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Bumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Flammability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Characteristics of the Source (standard) and Power Meter
(optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Power meter (through OTDR port). . . . . . . . . . . . . . . . . .104
Characteristics of the options . . . . . . . . . . . . . . . . . . . . .105
VFL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Bluetooth and WIFI . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Characteristics of the OTDR. . . . . . . . . . . . . . . . . . . . . . .105
OTDR Optical Interfaces . . . . . . . . . . . . . . . . . . . . . . . .105
OTDR Optical characteristics . . . . . . . . . . . . . . . . . . . . .105
Characteristics of reflectometry measurements . . . . . . . . .106
Manual Measurement . . . . . . . . . . . . . . . . . . . . . . . .107
Typical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Chapter 10 Options and accessories 109
References of the SmartOTDR . . . . . . . . . . . . . . . . . . . . . 110
References of accessories . . . . . . . . . . . . . . . . . . . . . . . . 111
References of firmware applications . . . . . . . . . . . . . . . . 111
Chapter 11 Maintenance and Troubleshooting 113
Maintenance procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Table of Contents
User Manual 7SMART102 Rev002 xiii
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Cleaning plates and housings . . . . . . . . . . . . . . . . . . . 114
Cleaning the screen . . . . . . . . . . . . . . . . . . . . . . . . . 114
Cleaning the optical cable connector . . . . . . . . . . . . . . 114
Cleaning the optical connections of the SmartOTDR . . . . 115
Accessing to the SmartOTDR information . . . . . . . . . . . . 115
General page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Software options page. . . . . . . . . . . . . . . . . . . . . . . . 116
Services Data page. . . . . . . . . . . . . . . . . . . . . . . . . . 116
Installing a new version of the software . . . . . . . . . . . . . . 117
Downloading from Internet . . . . . . . . . . . . . . . . . . . . . 117
Installation from Viavi Server . . . . . . . . . . . . . . . . . . . 117
Installation from another server . . . . . . . . . . . . . . . . . . 119
Installation from a USB memory stick . . . . . . . . . . . . . .120
Launching the upgrade . . . . . . . . . . . . . . . . . . . . . . .121
Checking new upgrade on Viavi Server . . . . . . . . . . . .122
Upgrading from the boot . . . . . . . . . . . . . . . . . . . . . .122
Install Software License . . . . . . . . . . . . . . . . . . . . . . . . .123
Enter Manually the Licence . . . . . . . . . . . . . . . . . . . .124
Import the license from the USB memory stick . . . . . . . .124
Locking the SmartOTDR . . . . . . . . . . . . . . . . . . . . . . . .125
Returning an instrument . . . . . . . . . . . . . . . . . . . . . . . . .126
Guarantee conditions . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Recycling Information . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Interpreting alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Formatting the USB memory stick onto the SmartOTDR . .128
Erase disk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129
Changing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . .129
Accessing to the damaged battery . . . . . . . . . . . . . . . .129
Installing a new battery . . . . . . . . . . . . . . . . . . . . . . .130
Accessing to the AA dry battery pack . . . . . . . . . . . . . .131
General information on warranty . . . . . . . . . . . . . . . . . . .131
Hardware Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
Warranty disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
Index 133

Table of Contents
xiv User Manual 7SMART102 Rev002

User Manual 7SMART102 Rev002 xv
About This Guide
The SmartOTDR of Viavi provides a handheld OTDR designed for the
construction, turn-up and maintenance of fiber networks.
The topics discussed in this chapter are as follows:
–“Purpose and scope” on page xvi
–“Assumptions” on page xvi
–“Technical assistance” on page xvi
–“Conventions” on page xvi

About This Guide
Purpose and scope
xvi User Manual 7SMART102 Rev002
Purpose and scope
The purpose of this guide is to help you successfully use the SmartOTDR
features and capabilities. This guide includes task-based instructions
that describe how to install, configure, use, and troubleshoot the Smar-
tOTDR.
Additionally, this guide provides a complete description of Viavi’s
warranty, services, and repair information, including terms and condi-
tions of the licensing agreement.
Assumptions
This guide is intended for novice, intermediate, and experienced users
who want to use the SmartOTDR effectively and efficiently. We are
assuming that you have basic computer and mouse/track ball experience
and are familiar with basic telecommunication concepts and terminology.
Technical assistance
If you require technical assistance, call 1-844-GO-VIAVI. For the latest
TAC information, go to http://www.viavisolutions.com/en/services-and-
support/support/technical-assistance.
Conventions
This guide uses naming conventions and symbols, as described in the
following tables.
Table 1 Typographical conventions
Description Example
User interface actions appear in
this typeface.
On the Status bar, click Start.
Buttons or switches that you
press on a unit appear in this
TYPEFACE.
Press the ONswitch.
Code and output messages
appear in this typeface.
All results okay

About This Guide
Conventions
User Manual 7SMART102 Rev002 xvii
Table 3 Symbol conventions
Text you must type exactly as
shown appears in this type-
face.
Type: a:\set.exe in the dia-
log box
Variables appear in this type-
face.
Type the new hostname
Book references appear in this
typeface.
Refer to Newton’s Telecom
Dictionary
A vertical bar | means “or”: only
one option can appear in a sin-
gle command.
platform [a|b|e]
Square brackets [ ] indicate an
optional argument.
login [platform name]
Slanted brackets < > group
required arguments.
<password>
Table 2 Keyboard and menu conventions
Description Example
A plus sign + indicates simulta-
neous keystrokes.
Press Ctrl+s
A comma indicates consecutive
key strokes.
Press Alt+f,s
A slanted bracket indicates
choosing a submenu from
menu.
On the menu bar, click
Start > Program Files.
Table 1 Typographical conventions (Continued)
Description Example
This symbol represents a general hazard.

About This Guide
Conventions
xviii User Manual 7SMART102 Rev002
Table 4 Safety definitions
This symbol represents a risk of electrical shock.
NOTE
This symbol represents a Note indicating related information or tip.
This symbol, located on the equipment or its packaging
indicates that the equipment must not be disposed of in a land-
fill site or as municipal waste, and should be disposed of
according to your national regulations.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.

1
User Manual 7SMART102 Rev002 1
Chapter 1 Safety information
This chapter gives the main information on the safety conditions when
using the SmartOTDR:
–“Battery and AC/DC safety information” on page 2
–“Precautions relating to optical connections” on page 3
–“Laser Safety instructions” on page 3

Chapter 1 Safety information
Battery and AC/DC safety information
2 User Manual 7SMART102 Rev002
Battery and AC/DC safety information
Li-Polymer battery
– The Li-Polymer battery is designed for maximum safety.
In particular, each cell is provided with a safety valve to prevent exces-
sive internal pressure in the event of overcharging or exposure to very
high temperatures.
AA Dry Battery Pack
Explosion danger
– Short-circuiting the batteries can result in overheating, explosion or
ignition of the batteries and their surroundings.
– Never short-circuit the battery contacts by touching both contacts
simultaneously with an electrical conducting object.
– Only use AA size dry batteries or rechargeable batteries.
– Make sure the batteries are inserted with the correct polarity.
– Battery supplied by Viavi incorporate protection means.
General precautions
Do not use any mains adaptor or battery other than those supplied with
the instrument, or supplied by Viavi as an option for this instrument.
If another adapter or battery is used, it may damage the SmartOTDR
itself.
Using the SmartOTDR with a battery other than the one supplied by the
manufacturer of the SmartOTDR may entail risks of fire or explosion.
The battery may explode, leak or catch fire:
– if it is exposed to high temperature or fire
– if it is opened or dismantled.
Other basic safety precautions are as follows:
– Do not use AC/Adapter/Charger outdoors or in wet or damp loca-
tions
– Connect the AC/Adapter/Charger to the correct mains voltage, as
indicated on the ratings label.
– Do not allow anything to rest on the power cord, and do not locate
the product where people can walk on the power cord.
– Avoid using this product during an electrical storm. There may be a
remote risk of electric chock from lightning.
