VIBIA Swing User manual

Swing
Design by Lievore, Altherr, Molina
ASSEMBLY INSTRUCTIONS
TECHNICAL SPECIFICATIONS
0513
1 Shade screws 2 un.
2 Shade 1 un.
3 La p structure 1 un.
SUPPLIED MATERIAL
2.
1.
3.
CAUT ON : TO AVO D POSS BLE ELECTR CAL SHOCK,MAKE CERTA N ELECTR C TY S SHUT OFF AT MA N PANEL BEFORE W R NG.
All wiring ust be in accordance with national and local electrical codes. If you are not fa iliar with wiring, you should us
e a qualified electrician.
This product ust be installed in acordance withthe applicable installation code by a person fa iliar with the construction and operation of the product and the hazards involved.
Ce produit doit être installé selon le code d’installation pertinent, par une personne qui connaît bien les produit et son fonctionne ent ainsi que les risques inhérents.
Class I. Product with an additional protection
cable (grounds).
Product protected against solid object as big as
or bigger than 12 . No protection against
water.
Product that CAN be in contact with nor ally-
fla able aterials (wood or others).
0513.
Net Weight 1 Kg
1 x A19 Med. Base 120V 60W Max.
1 x LED 120V 1W 350 A
Opción
1 x E26 Med. Co pact Fluorescent 120V 11W
1 x LED 120V 1W 350 A
-This la p is for indoor use only, excluding bathroo s or any type of hu id surface.
-We reco end reading the anual before installaing the la p. Keep this instructions for future reference since thei contain Infor ation on bulb replacing and aintenance.
-To install on the wall, always choose the ost adequate fixing tools for the ceiling aterial.
Caution
Before assembling and installing this product, carefully read the following:
-Switch of the ains before installing the la p.
-Never use a bulb with a wattage exceeeding the reco ended one. Always use a bulb with the reco ended wattage or lower.

ASSEMBLY INSTRUCTIONS
MPORTANT NO
T CE:
Caution: to avoid possible electrical shock, make
certain electricity is shut off at main panel before
wiring.
1.
Making certain that the threads of the cross bar
screws are pointing away fro the wall, secure the round
cross bar (R) to the junction box using the ounting
screws (S1).
2. Unfasten the dowels (A) to release the counter-plaque
(B). Connect the white fixture wire to the white wire of
the supply circuit. Connect the black fixture wire to the
black wire of the supply circuit. Secure with the wire nuts
(N) and tape connections with electrical tape. Connect
the fixture copper ground wire and the supply ground
wire to the ground screw on the round cross bar using
the ground ter inal.
Push the connections and all excess wire to the interior
of the junction box. Spread the electrical splices on the
so that the black wires are on one side of the junction
box and the white wires on the other.
Secure the counter-plaque (B) to the round cross bar
using the screws (S2).
3. Fix the base (C) to the counter-plate (B) fastening the
dowels (A). In this way the la p will be fixed to the wall.
4. After installing the bulb, position the shade on the
plaque (D) and fix it with the supplied screws (E).
NOTE: The spotlight (H) is orientable as indicated by the
arrow.
5. To adjust the stiffness of the ove ent, first re ove
the cover as shown in the illustration. Second, ake the
necessary adjust ent using a 10 socket spanner
and finally replace the cover.
2
1
4
5
2
nd
1
st
10 mm.
10 .
3
3
rd
Maintenance
-Use a slightly-wet cotton cloth for cleaning.
-In case of alfunction or da age, please contact the retailer who sold the la p.
R
S1
RS2
NC
B
A
A
C
DF
E
