This Quick Start Guide is intended for experienced installing technicians. It is a basic reference to ensure all connections are properly made.
Models include VAX-300R, VAX-500R and VAX-600KP, as well as variants supporting most industry leading card and tag technologies. For
additional information please refer to Vicon's website www.vicon-security.com.
1.0 Introduction
A key component of a physical security electronic access control
system, a proximity card reader is based on RFID technology. In
operation it is capable of reading data stored on a proximity credential
via radio frequency and without physical contact, and then passing the
data obtained to the physical access control system. Access control
systems typically manage and record the movement of individuals
through a protected area, such as a locked door.
2.0 Mounting Provisions
Each reader may be installed either indoors or outdoors. Mounting
options shown in the table below. Use supplied #6 mounting screws, or
equivalent security screws, for installation.
Models
Mullion
Mount
Single-
Gang
Wall Mount*
VAX-300R •
VAX-500R •
VAX-600KP •
*Plastic or metal
3.0 Reader Wiring
Wiegand Magstripe
Conductor Function Conductor Function
Red DC (5-16 VDC) Red DC (5-16 VDC)
Black Ground Black Ground
Green Data 0 Green Clock
White Data 1 White Data
Brown Red LED aBrown Red LED
Orange Green LED bOrange Green LED
Yellow Card Present Yellow Card Present
Blue Beeper Blue Beeper
Violet fleaPower Violet fleaPower
Drain Shield Ground Drain Shield Ground
4.0 Cable Requirements
24 AWG minimum, multi-conductor stranded with an overall foil shield,
for example Belden 9535 or similar, supporting the five conductors
comprising the physical layer of the Wiegand interface (power, ground,
data 0, data 1, and/or beeper and LED). Alternatively, Belden 9539 or
similar, for all reader functions. Contact your access control system
manufacturer for their specific requirements. Per the SIA’s Wiegand
specification, maximum cable length is 500 feet (152 m).
5.0 Output Formats
Wiegand (industry standard 26-bit Wiegand and custom Wiegand
formats).
6.0 Grounding
Shield (drain) continuity must run from the reader to the access panel.
Shield (drain) and reader ground must be tied together at the access
panel and connect to an earth ground at one point.
7.0 Power
Reader may be powered by the access panel. A linear power supply is
recommended for best operation.
8.0 Voltage
5 to 16 VDC. 12 VDC at the reader is recommended for best operation.
Model Current Draw
VAX-300R 30 to 75 mA
VAX-500R 35 to 75 mA
VAX-600KP 70 to 110 mA
WIRING NOTES:
aSingle Line LED: This is the standard operating mode and does not make use of the
Orange conductor. The LED is Red when the reader is idle and flashes when a card is
presented. The LED turns Green when the Brown Conductor is pulled low by the access
control panel.
bDual Line LED: This mode makes use of both the Brown and Orange conductors. The
Brown conductor controls the Red LED and the Orange conductor controls the Green
LED. LED states are determined by the access control system option and capability.
Unused conductors should be trimmed, isolated and taped back to prevent unintended
current flows. Apply positive voltage only to the Red DC Conductor.
Quick Installation Guide
VAX-300R, VAX-500R and VAX-600KP Proximity Card Readers
XX277-01

9.0 fleaPower™ Control Line
To reduce the average current required by the reader,
pull the purple conductor low.
10.0 Connection
Connection must be done in accordance with NFPA 70. Do not
connect to a receptacle controlled by a switch. Connect to a power
limited DC voltage source.
11.0 Troubleshooting
1. When the reader is first powered on it will beep 4-times,
and the LED will shine red.
2. Presenting a supported access credential will result in the
reader beeping and the LED flashing once.
NOTE: The access panel controls LED functionality,
such as switching the LED to green.
If the reader does not recognize the card or tag (no beep, no LED
flash) or exhibits short read range, please see the table below for
possible causes and solutions.
Possible Cause Corrective Action
Incorrect cabling Verify gauge, connections
and cabling length
Not enough power 12 VDC recommended, 5 VDC
at reader is minimum
Incorrect card used Verify if card technology
is supported
Reader/access panel not
properly grounded
Earth ground needed—verify shield
and reader ground are tied at access
panel and connect to ground at
one point
Supply generating
interference
Linear power supply recommended,
verify switching power supply
before use
Should any of the corrective actions mentioned above not improve
performance, disconnect the reader from the access panel and power
it with a separate power supply or 9 VDC battery, and re-test card
functionality. By powering the readers separately, most variables that
may lead to reduced performance can be eliminated. Should the
problem persist, please contact Vicon Technical Support.
Operating Temperature: –31° F to +150° F (–35° C to +66° C)
Operating Humidity: 0% to 90% Relative Humidity
IP Rating: IP67-rated for outdoor use
Access Control Performance Levels Conforming to UL STD 294:
Destructive Attack Line Security Endurance Standby Power
Level II Level I Level IV Level I
Grade Classification Certified to CAN/ULC STD 60839-11-1:
Risk Level Application
Skill/
Knowledge
of Attackers
Typical
Examples
Grade 2 Grade 2 Grade 2 Grade 2
Many Vicon Readers carry the following certifications:
FCC Compliance Statement: This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by Farpointe Data could
void the user's authority to operate the equipment.
Product can be used without license conditions or restrictions in all European Union
countries, including Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Spain,
Sweden, United Kingdom, as well as other non-EU countries, including Iceland,
Norway, and Switzerland.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause unde-sired operation of the device.
Cet appareil est conforme à Industrie Canada exempts de licence standard RSS (s).
Le fonctionnement est soumis aux deux conditions suivantes : (1) ce dispositif ne
peut pas provoquer d’interférences et (2) ce dispositif doit accepter toute
interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
For proper PIN security with keypad readers, please review
PIN Best Practices Reference Document.
QUICK START GUIDE
VAX-300R, VAX-500R AND VAX-600KP 125-kHz
PROXIMITY CARD READERS
P/N: 8009-8277-01-00
Vicon Industries Inc.
Tel: [phone]
Toll Free: 800-645-9116
Fax: [phone]
24-Hour Technical Support:
800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300
Product specifications are subject to
change without notice.
REV June 2021
