Vicon VAX-CR-35L User manual

This Quick Start Guide is intended for experienced installing technicians. It is a basic reference to ensure all connections are properly made.
It is for models VAX-CR-35L and VAX-CSR-6.2. For additional information please refer to Vicon's website www.vicon-security.com.
1.0 Introduction
A key component of a physical security electronic access control
system, a mobile-ready reader combining BLE and contactless
smartcard technologies is based on RFID technology. In operation it is
capable of reading data stored on a contactless smartcard credential
via high frequency—or reading data from mobile credential stored in a
smartphone’s wallet app via BLE technology—and without physical
contact, and then passing the data obtained to the physical access
control system. Access control systems typically manage and record
the movement of individuals through a protected area, such as a
locked door.
2.0 Mounting Provisions
Each reader may be installed either indoors or outdoors. Mounting
options shown in the table below. Use supplied #6 mounting screws,
or equivalent security screws, for installation.
Model Mullion Mount Single-Gang Wall Mount*
VAX-CR-35L • •
VAX-CSR-6.2 •
*Plastic or metal.
3.0 Reader Wiring
Wiegand Magstripe
Conductor Function Conductor Function
Red DC (8-14 VDC) Red DC (8-14 VDC)
Black Ground Black Ground
Green Data 0 Green Clock
White Data 1 White Data
Brown Red LED aBrown Red LED
Orange Green LED bOrange Green LED
Yellow Not Used Yellow Not Used
Blue Beeper Blue Beeper
Violet Read ModecViolet Read Mode
Drain Shield Ground Drain Shield Ground
4.0 Cable Requirements
24 AWG minimum, multi-conductor stranded with an overall foil shield,
for example Belden 9535 or similar, supporting the five conductors
comprising the physical layer of the Wiegand interface (power, ground,
data 0, data 1, and/or beeper and LED). Alternatively, Belden 9539 or
similar, for all reader functions. Contact your access control system
manufacturer for their specific requirements. Per the SIA’s Wiegand
specification, maximum cable length is 500 feet (152 m).
5.0 Output Formats
• Wiegand (industry standard 26-bit Wiegand
and custom Wiegand formats)
• Magnetic Stripe (ABA Track II, clock and data,
with card present)
6.0 Grounding
Shield (drain) continuity must run from the reader to the access panel.
Shield (drain) and reader ground must be tied together at the access
panel and connect to an earth ground at one point.
7.0 Power
Reader may be powered by the access panel. A linear power supply is
recommended for best operation.
8.0 Voltage and Current
Voltage: 8 to 14 VDC
Current Draw: 60mA typical, 250mA peak
9.0 Read Mode
For sector data reads, do not connect the Violet conductor (leave it
high). For CSN reads, pull the Violet conductor low (connect the Violet
conductor to ground).
10.0 Connection
Connection must be done in accordance with NFPA 70. Do not
connect to a receptacle controlled by a switch. Connect to a power
limited DC voltage source.
WIRING NOTES:
aSingle Line LED: This is the standard operating mode and does not make use of the
Orange conductor. The LED is Red when the reader is idle and flashes when a card is
presented. The LED turns Green when the Brown Conductor is pulled low by the access
control panel.
bDual Line LED: This mode makes use of both the Brown and Orange conductors. The
Brown conductor controls the Red LED and the Orange conductor controls the Green
LED. LED states are determined by the access control system option and capability.
cRead Mode: In regards to contactless smartcard credentials, the reader will only read
and output the credential’s Card Serial Number (CSN) when the Violet conductor is
pulled low (connected to ground). Otherwise, the reader will only read and output the
credential’s programmed Sector data.
Unused conductors should be trimmed, isolated and taped back to prevent unintended
current flows. Apply positive voltage only to the Red DC Conductor.
Quick Installation Guide
VAX-CR-35L and VAX-CSR-6.2
Mobile-Ready Contactless Smartcard Readers
XX274-32

11.0 Troubleshooting
1. When the reader is first powered on it will beep 4-times,
and the LED will shine red.
2. Presenting a supported access credential will result in the
reader beeping and the LED flashing once.
3. Mobile operation is optimized for smartphones supporting BLE
(Bluetooth LE) version 4.2 or newer. Further, for the downloading
of mobile access credentials, a stable, high-quality internet
connection is recommended.
NOTE: The access panel controls LED functionality, such as
switching the LED to green.
If the reader does not recognize the mobile credential or card or tag
(no beep, no LED flash) or exhibits short read range, please see the
table below for possible causes and solutions.
Possible Cause Corrective Action
Incorrect cabling Verify gauge, connections and
cabling length
Not enough power 12 VDC recommended
Incorrect credential used Verify if credential technology
is supported
Reader/access panel not
properly grounded
Earth ground needed—verify shield
and reader ground are tied at access
panel and connect to ground at
one point
Supply generating
interference
Linear power supply recommended,
verify switching power supply
before use
Should any of the corrective actions mentioned above not improve
performance, disconnect the reader from the access panel and power
it with a separate power supply or 9 VDC battery and re-test card
functionality. By powering the readers separately, most variables that
may lead to reduced performance can be eliminated. Should the
problem persist, please contact Vicon Technical Support.
Operating Temperature: –31° F to +150° F (–35° C to +66° C)
Operating Humidity: 0% to 90% Relative Humidity
IP Rating: IP67-rated for outdoor use
Access Control Performance Levels Conforming to UL STD 294:
Model
Destructive
Attack
Line
Security Endurance
Standby
Power
VAX-CR-35L Level I Level I Level IV Level I
VAX-CSR-6.2 Level II Level I Level IV Level I
Grade Classification Certified to CAN/ULC STD 60839-11-1:
Risk Level Application
Skill/
Knowledge
of Attackers
Typical
Examples
Grade 2 Grade 2 Grade 2 Grade 2
Many Vicon Readers carry the following certifications:
FCC Compliance Statement: This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by Farpointe Data could
void the user's authority to operate the equipment.
Product can be used without license conditions or restrictions in all European Union
countries, including Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Spain,
Sweden, United Kingdom, as well as other non-EU countries, including Iceland,
Norway, and Switzerland.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference that
may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2)
L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
For proper PIN security with keypad readers, please review
PIN Best Practices Reference Document.
QUICK START GUIDE
VAX-CR-35L AND VAX-CSR-6.2 MOBILE-READY
CONTACTLESS SMARTCARD READERS
©2021 Vicon Industries. All rights reserved. Vicon and its logo are registered
U.S. trademarks and VAX and its logo are trademarks of Vicon Industries Inc.
All other trademarks are the property of their respective owners.
www.vicon-security.com
P/N: 8009-8274-32-00
Vicon Industries Inc.
Tel: [phone]
Toll Free: 800-645-9116
Fax: [phone]
24-Hour Technical Support:
800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300
Product specifications are subject to
change without notice.
REV June 2021
