Custom gas rangetops
Commercial-type cooking power
n Exclusive VSH™(Vari-Simmer-to-high) Pro Sealed
Burner System
n Front right burner equipped with PowerPlus™
18,500 BTU burner on select models
n Burners equipped with 15,000 BTUs
n Exclusive VariSimmer™setting for all burners
n Exclusive – all burners equipped with SureSpark
Ignition System for consistent and reliable ignition
n Automatic re-ignition; surface burners light at any
position on the knob and re-light if extinguished, even
on lowest setting
n Heavy-duty metal knobs with stainless steel finish
shipped standard
n Island trim ships standard with each rangetop
and already attached
Easy Operation and Cleanup
n
Exclusive one-piece tooled and porcelainized cooking
surface for easy clean up
n Burner caps are easily removable for quick cleaning
n Heavy-duty, porcelainized, cast-iron removable surface
grates provide continuous front-to-rear, left-to-right
surface for easy movement of large pots
n One-piece control panel assembly easily removable
for convenient front access
Griddle/Simmer Plate – 12" or 24" wide
n Commercial-grade, machined steel construction
with blanchard finish to retain cooking oils for stick-
resistant cooking
n Thermostatically controlled for precise temperatures
n Cast aluminum grease trough holds 2 1/2 cups of
liquid and can be easily removed from the front of
the griddle for cleaning
Char-Grill – 12" wide
n Automatic electric spark ignition/re-ignition
n Porcelainized, cast-iron one piece grate
n Porcelainized flavor generator-plates catch
dripping and circulate smoke around food for
outdoor-grilled flavor
n Exclusive – Two-piece porcelainized drip pan can
hold three quarts of liquid
n Drip tray located beneath the burner catches any
possible drippings not caught in the drip pan and is
easily removable for cleaning
Custom gas rangetops fit even more performance into your countertops. The VariSimmer-to-High™pro sealed burner system combines
the ultimate in power and cleanability. And heavy duty metal knobs keep everything under precise control. Select models also feature a
PowerPlus™18,500 BTU burner to conquer even the mightiest stock pots.
4
VGRT560 Gas 60"
Wide Sealed Burner
Rangetops
VGRT536 Gas 36"
Wide Sealed Burner
Rangetops
VGRT530 Gas 30"
Wide Sealed Burner
Rangetop
VGRT548 Gas 48"
Wide Sealed Burner
Rangetops

VGRT536 – Gas 36" wide
sealed burner rangetop
The exclusive one-piece cooking
surface features raised edges to
completely contain spills.
5

24" wide gas wok/cooker
Commercial-type cooking power
n 27,500 BTU burner for high heat/fast cooking
n Automatic electric spark ignition
n Two-piece heavy-duty, porcelainized, cast-iron
removable burner grate
n Exclusive agency-certified center trivet converts
burner grate for use with large stock pots
n 20" wide stainless steel wok with top (included
with product)
Easy operation and cleanup
n Large, easy-to-read knob with childproof,
push-to-turn safety feature
n Stainless steel landing ledge with solid, welded,
seamless finish
n Designed for built-in installation in standard-depth cabinets
n Removable, pull-out drip tray with roller-bearing glides,
full-length handle, and solid welded/finished end caps;
removable grease pan
VGWT240 Gas
24" Wide Wok/Cooker
The wok/cooker delivers extra capacity entertaining. The large 27,500 BTU burner conquers army-sized portions.
And the exclusive center trivet converts the burner grate for use with large stock pots – just the thing for a lobster boil.
6

VGWT240 – Gas 24" wide
wok/cooker
The removable center trivet
converts the wok into a high-
powered burner for use with
large stock pots.
7

Gas cooktops
VGSU104 Gas 30"
Wide Cooktop
VGSU164 Gas 36"
Wide Cooktop
Commercial-type cooking power
n Updated styling incorporates refined detailing
n Sealed burners with brass flame ports and
porcelain/cast-iron caps
n 16,000 BTU burner for faster heat up
n Exclusive – all burners equipped with SureSpark™
ignition system for consistent and reliable ignition
n Automatic re-ignition; burners light at any position
on the knob and re-light if extinguished, even at
the lowest setting
n Gas 30" wide cooktop
• Left front – 16,000 BTU high/3,400 BTU low
• Left rear – 12,000 BTU high/1,700 BTU low
• Right front – 6,000 BTU high/950 BTU low
• Right rear – 8,000 BTU high/1,200 BTU low
n Gas 36" wide cooktop
• Left front – 16,000 BTU high/3,400 BTU low
• Left rear, center front, and center rear –
12,000 BTU high/1,700 BTU low
• Right front – 6,000 BTU high/950 BTU low
• Right rear – 8,000 BTU high/1,200 BTU low
Easy operation and cleanup
n Metal knobs with childproof, push-to-turn safety feature
n Heavy-duty, porcelainized, cast-iron, removable
burner grates provide virtually continuous front-to-rear,
left-to-right surface for easy movement of large pots
n Customer-removable knobs, grates, and burner
ports/caps
n Permanently sealed burners – spills cannot enter
burner box
n Large, separate spill-collection areas
• 30" wide cooktop – two 3 1/2-cup areas
• 36" wide cooktop – two 4 1/2-cup areas
Replaces most ordinary cooktops
n Overall burner box dimensions designed to fit
virtually all 30" and 36" wide cooktop cutouts
n Only “countertop cutout” six-burner cooktop
available in 36" width
Now the only thing complicated about transforming your kitchen into a professional kitchen is mastering that hollandaise sauce.
Viking gas cooktops fit into almost any existing cutout with little to no modifications. These models immediately empower your
countertop with 16,000 BTUs and precision controls. And the sealed burner system keeps everything nice and clean.
8

VGSU164 – Gas
36" wide cooktop
9

Electric cooktops
Different-sized elements make it possible to stir-fry
broccoli while simmering soup.
Commercial-type cooking power
n Updated styling reflects refined detailing
n QuickCook surface elements utilize ribbon
technology – elements reach full power in about
three seconds
n Wide range of surface element sizes and wattages
n Bridge element between left front and left rear
elements creates a continuous heated surface
n High infrared transmission for fast cooking, regardless
of the type of cookware used
n Electric 30" wide cooktop
• Left front – 7", 1,800-watt element; 800-watt bridge
• Left rear – 7", 1,800-watt element
•Right front – 6 1/2", 1,500-watt element
• Right rear – (dual element) – 9",2,500-watt/
6", 1,000-watt element
n Electric 36" wide cooktop
• Left front – (dual element) – 8 1/4", 2,200-watt/
4 3/4", 750-watt element
• Left rear – 6 1/2", 1,500-watt element
• Center front – 7", 1,800-watt element; 800-watt bridge
• Center rear – 7", 1,800-watt element
• Right front – 6", 1,200-watt element
• Right rear – (dual element) – 9", 2,500-watt/
6", 1,000 watt element
Easy operation and cleanup
n Glass ceramic top with stainless steel frame/control panel
• Extremely durable, wear-resistant surface
n Metal knobs with childproof, push-to-turn safety feature
n Smooth, wear-resistant glass ceramic surface for
excellent cleanability
n Customer-removable knobs
n Overall/burner box dimensions designed to fit the
majority of similarly sized cooktop cutouts
The only thing cleaner than the glass ceramic surface of Viking electric cooktops is the installation. Designed to fit virtually any
existing cutout, these cooktops offer a hassle-free kitchen upgrade. QuickCook™surface elements reach full power in three seconds–
and high infrared transmission allows for faster cooking with all types of cookware. A unique bridge element joins the left front
and left rear burners, creating one continuous cooking surface. Who knew versatility could be so easy?
10

VECU166 Electric 36"
Wide Cooktop
VECU106 Electric 30"
Wide Cooktop
VECU166 – Electric 36" wide
cooktop with optional 36" wide
VIPR162 downdraft
11

Viking cookware and most high-end stainless
steel, cast iron, and enamel cookware is
compatible with induction. To be sure, test yours
with a magnet. If it sticks, you’re cooking.
Induction cooktops
n Induction 36" wide cooktop
• Left front – 7", 1,800-watt element
• Left rear – 9", 2,700-watt element
• Center front – 9", 2,700-watt element
• Center rear – 7", 1,800-watt element
• Right front – 7", 1,200-watt element
• Right rear – 9", 3,300-watt element
Easy operation and cleanup
n Strong, wear-resistant glass ceramic surface with
stainless steel frame/control panel
n Metal knobs with childproof, push-to-turn safety feature
Commercial-type cooking power
n MagneQuick induction power generators utilize
magnetic energy for superior power, responsiveness,
and efficiency
n Induction 30" wide cooktop
• Left front – 9", 2,700-watt element
• Left rear – 7", 1,800-watt element
• Right front – 7", 1,200-watt element
• Right rear – 9", 3,300-watt element
Amaze your guests before the first course is even served. Induction cooking creates heat with magnetic power. MagneQuick™
induction power generators create a magnetic field, which reacts with iron in the base of the cookware – instantly transforming
the pot or pan into a very powerful and highly responsive heat source. The energy transfer stops just as quickly when the cookware
is removed – leaving the cooktop surface cool to the touch almost immediately.
12

VICU206 – Induction
30" wide cooktop
VICU266 Induction
36" Wide Cooktop
VICU206 Induction
30" Wide Cooktop
13
The energy transfer stops quickly when
the cookware is removed – leaving
the cooktop surface cool to the
touch almost immediately.

Accessories
Cooking accessories – rangetops and cooktops
n Wok grate (CWGT – rangetops)
• Porcelain/cast-iron grate to use in place of surface grate
• Available in Black (BK)
n Wok ring (PWRG6 – gas cooktops)
• Stainless steel fits securely on standard surface grate
n Portable griddle (SB-PGD – 12" wide; SB-PGD24 – 24" wide
rangetops; SU-PGD – gas cooktops)
• Cast-aluminum, non-stick finish on cooking surface
• Grease trough
• Fits over standard surface grates
• Can also be used to quickly defrost frozen foods
n Bamboo cover (CBC12QB – rangetops)
• Dense bamboo construction
• Fits over standard surface grates and 12" wide grill grate
• Can also be used as cutting board
n Hardwood cover (SU-CCH – gas cooktops)
• Maple hardwood “butcher block” construction
• Fits over standard surface grates, griddle, or grill
• Can also be used as cutting board
n Bamboo cutting board (CBC12G – rangetops)
• Maple hardwood “butcher block” construction
• Fits 12" wide griddle
n Stainless steel cover – for rangetops (CSC12U – 12" wide
griddle or grill cover)
• Stainless steel cover with Professional handle for use with
Professional gas rangetops with a 12" wide griddle/simmer
plate or char-grill
• Fits over griddle/simmer plate or over standard grill grates
• Grill cover can be used over surface burners to
prevent splatters when grilling
• Does not have to be removed when operating
adjacent surface burners (prevents spillage into
griddle or grill area when using burners)
n Griddle cleaning kit (GCK)
• Fast and easy commercial-grade cleaning system
• Contains enough for 25+ cleanings
• For use on steel griddles only
• Kit includes: 32 oz. quick clean griddle cleaner, one
pad holder, one pack of 10 griddle polishing pads,
one squeegee, and cleaning instruction sheet
n Black knob kits
• For use on all Custom rangetops
n White knob kits
• For use on all Custom rangetops
Installation accessories – rangetops and
indoor wok
n Stainless steel backguard
• 6" high – wok/cooker (T24BG6)
•
8" high – rangetops, (P30BG8, P36BG8, P48BG8, P601BG8)
n Stainless steel high shelf
• Wok/cooker (T24HS24)
• Rangetops (B30HS24, B36HS24, B48HS24, B60HS24)
n Stainless steel island trim
• Wok/cooker (T24TII)
• Rangetops (P30TII, P36TII, P48TII, P60TII)
n Stainless steel countertop side trim
• Wok/cooker (T24CST)
• Rangetops (P24CST)
14
Accessories are available separately to enhance professional performance
and appearance. A backguard, high-shelf, or island trim must be used for
all rangetop and wok/cooker installations.
Wok grate Wok ring Portable griddle Hardwood cover

Gas rangetop configurations
36" wide, six burners
VGRT536-6B
36" wide, four burners
12" wide griddle/simmer
plate
VGRT536-4G
36" wide, four burners
12" wide char-grill
VGRT536-4Q
48" wide, eight burners
VGRT548-8B
48" wide, six burners
12" wide griddle/simmer plate
VGRT548-6G
48" wide, six burners
12" wide char-grill
VGRT548-6Q
30" wide,
four burners
VGRT530-4B
24" wide,
wok/cooker
VGWT240
48" wide, four burners
12" wide griddle/simmer plate
12" wide char-grill
VGRT548-4GQ
48" wide, four burners
24" wide griddle/simmer plate
VGRT548-4G
60" wide, six burners
24" wide griddle/simmer plate
VGRT560-6G
60" wide, six burners
12" wide griddle/simmer plate
12" wide char-grill
VGRT560-6GQ
15
Stainless steel cover Griddle cleaning kit
Bamboo cover Bamboo cutting board

16
Design integrity
Consistency in both performance and design should be a major consideration when building or remodeling
a home. With the complete Viking indoor or outdoor kitchen, every single product works together in form and
function with the same level of excellence. It’s something Viking calls Design Integrity .
Viking offers complete ultra-premium kitchens and truly consistent design, while delivering the quality and
performance that makes Viking the true market leader. Across all product categories, the knobs, handles,
bezels, curves, angles, and lines all follow the same design cues – even the grain of stainless is the same from
product to product. This enables the designer to create a perfectly harmonious kitchen in one of three Viking
product offerings – Professional Indoor, Designer Indoor, or Professional Outdoor.
You wouldn’t install mismatched cabinets and drawers or countertops. Yet design differences are even more
dramatic between multiple appliance manufacturers. Traditional or contemporary. Stainless or color finish. No
matter the look you’re going for, no one can match the Viking kitchen and Viking Design Integrity.
™

n Rangetops are available in Stainless Steel (SS)
• May be ordered with Brass Accent Option (BR) for
nameplate and knob bezels
n Gas cooktops are available in Stainless Steel (SS), Black (BK),
and White (WH)
• May be ordered with Brass Accent Option (BR) for knob
bezels, control panel frame, and nameplate
n Electric and induction cooktops are available in Stainless
Steel/Black (SB), featuring black glass and knobs
• May be ordered with Brass Accent Option (BR) for knob
bezels, control panel frame, and nameplate
n Indoor wok/cooker, and outdoor wok/cooker are available
in Stainless Steel (SS)
• May be ordered with Brass Accent Option (BR) for
nameplate and knob bezels
17
Warranty highlights
n Three-year full covers complete unit
n Lifetime limited – stainless steel exterior
n Lifetime limited – rust through on all stainless steel
n Five-year limited – surface burners, griddle tubular
burner(s), grill tubular burner, and electric elements
components (VGWT outdoor model)
n Ninety-day limited – cosmetic parts such as glass,
painted items, and decorative items
Exclusive finishes

Basic specifications – Gas rangetops
GAS 30", 36", 48", AND 60" WIDE SEALED BURNER RANGETOPS
Overall Width
Overall Height
from Bottom
Overall Depth from Rear
Cutout Width
Cutout Height
Description
To end of side panel – 24 5/16" (61.8 cm), to end of landing ledge – 28 1/16" (71.3 cm), to end of knobs – 28 9/16" (72.6 cm)
Cutout Depth 24" (61.0 cm) minimum; 25 3/4" (65.4 cm) maximum
Gas Requirements
18
Electrical Requirements 120VAC/60Hz; 4 ft. (121.9 cm), 3-wire cord with grounded 3-prong plug attached to product
VGRT536
35 7/8" (91.1 cm)
36" (91.4 cm)
Accepts standard residential 1/2" (1.3 cm) ID gas service line. Order either natural gas or LP propane; to field convert from natural to LP propane, order optional LP conversion kit.
–15,000 BTU NAT./12,500 BTU LP
(4.4 kW NAT./3.7 kW LP)
Griddle Burner
Rating
–
Grill Burner Rating 18,000 BTU NAT./16,000 BTU LP
(5.3 kW NAT./4.7 kW LP)
To top of burner grate – 9 1/4" (23.5 cm), to top of island trim – 9 1/8" (23.2 cm), to top of 8" h. backguard – 16 1/8" (41.0 cm), to top of high-shelf – 31 5/8" (80.3 cm)
VGRT530
29 7/8" (75.9 cm)
30" (76.2 cm)
Maximum Amp Usage .5 amps
7 5/8" (19.4 cm) Top of side trim should be 3/8" (1.0 cm) above countertop
6B – 150 lb. (67.5 kg)
4G – 160 lb. (72.0 kg)
4Q – 155 lb. (69.8 kg)
Approximate Shipping
Weight
125 lb. (56.7 kg)
Surface Burner Rating Standard burners (each): 15,000 BTU NAT. (4.4 kW)/13,500 BTU LP (4.0 kW)
TruPower PlusTM burner (front right): 18,500 BTU NAT. (5.4 kW)/16,600 BTU LP (4.9 kW)

GAS 30", 36", 48", AND 60" WIDE SEALED BURNER RANGETOPS
To end of side panel – 24 5/16" (61.8 cm), to end of landing ledge – 28 1/16" (71.3 cm), to end of knobs – 28 9/16" (72.6 cm)
19
VGRT548 VGRT560
47 7/8" (121.6 cm) 60" (152.4 cm)
48" (121.9 cm) 60 1/4" (153.0 cm)
Accepts standard residential 1/2" (1.3 cm) ID gas service line. Order either natural gas or LP propane; to field convert from natural to LP propane, order optional LP conversion kit.
15,000 BTU NAT./12,500 BTU LP
(4.4 kW NAT./3.7 kW LP)
6G and 4GQ – 15,000 BTU NAT./12,500 BTU LP
(4.4 kW NAT./3.7 kW LP)
4G – Two at 15,000 BTU NAT./12,500 BTU LP
(4.4 kW NAT./3.7 kW LP)
6GQ – 15,000 BTU NAT./12,500 BTU LP
(4.4 kW NAT./3.7 kW LP)
6G – Two at 15,000 BTU NAT./12,500 BTU LP
(4.4 kW NAT./3.7 kW LP)
18,000 BTU NAT./16,000 BTU LP
(5.3 kW NAT./4.7 kW LP)
To top of burner grate – 9 1/4" (23.5 cm), to top of island trim – 9 1/8" (23.2 cm), to top of 8" h. backguard – 16 1/8" (41.0 cm), to top of high-shelf – 31 5/8" (80.3 cm)
6G – 203 lb. (91.4 kg)
6Q – 193 lb. (89.1 kg)
4GQ – 200 lb. (90.7 kg)
8B – 200 lb. (90.7 kg)
6G – 256 lb. (115.2 kg)
6Q – 251 lb. (113.0 kg)
Standard burners (each): 15,000 BTU NAT. (4.4 kW)/13,500 BTU LP (4.0 kW)
TruPower PlusTM burner (front right): 18,500 BTU NAT. (5.4 kW)/16,600 BTU LP (4.9 kW)

Basic specifications – Wok/cooker
Overall Width 23 7/8" (60.6 cm)
Overall Height
from Bottom
Description
To top of cooking surface – 7 7/8" (20.0 cm), to top of island trim – 8 7/8" (22.5 cm),
to top of 6" h. backguard – 13 7/8" (35.2 cm)
7 1/2" (19.1 cm) Top of grate support should be 3/8" (1.0 cm) above countertop
Cutout Height
24" (61.0 cm) minimum; 25 3/4" (65.4 cm) maximum
Cutout Depth
Electrical Requirements
120VAC/60Hz; 4 ft. (121.9 cm), 3-wire cord with grounded 3-prong plug attached to product
Gas Requirements Accepts standard residential 1/2" (1.3 cm) ID gas service line. Order either natural gas or LP propane;
to field convert from natural to LP propane, order optional LP conversion kit.
VGWT240
GAS 24" WIDE
WOK/COOKER
20
Overall Depth from Rear
Cutout Width 24" (61.0 cm)
Approximate Shipping
Weight
146 lb. (65.7 kg)
Maximum Amp Usage .08 amps
Surface Burner/
Element Rating
27,500 BTU NAT./27,500 BTU LP/Propane (8.1 kW NAT./8.1 kW LP)
To end of side panel – 24" (61.0 cm), to end of control panel – 25 3/4" (65.4 cm),
to end of knobs – 27 3/4" (70.5 cm)
