SAFETY INSTRUCTIONS
– It is important to read this entire manual before assembling and using the device. Safe and
effective use can only be achieved if the device is assembled, maintained and used properly.
It is your responsibility to ensure that all users of the device are informed of all warnings and
precautions.
– Before starting any exercise program, you should consult your doctor to determine if you have
any medical or physical conditions that could put your health and safety at risk, or prevent you
from using the device properly. Your doctor’s advice is essential if you are taking medication
that affects your heart rate, blood pressure or cholesterol level.
– Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, extreme shortness of breath, lightheadedness, dizziness or feelings of nausea. If you do
experience any of these conditions you should consult your doctor before continuing with your
exercise program.
– Keep children and pets away from the device. The device is designed for adult use only.
– Use the device on a solid, flat level surface with a protective cover for your floor or carpet. To
ensure safety, the device should have at least 0.5 metres of free space all around it.
– Before using the device, check that the nuts and bolts are securely tightened.
– The safety of the device can only be maintained if it is regularly examined for damage and/or
wear and tear.
ATTENTION
WARNING:
Before beginning any exercise program consult your physician. This is especially
important for people who are over 35 years old or who have pre-existing health
problems. Read all instructions before using any fitness equipment. Do not operate this
device without properly fitted guards, as the moving parts can present a risk of serious
injury if exposed.

EN Virtufit TR-100 Treadmill
4
SAFETY INSTRUCTIONS
– Always use the device as indicated. If you find any defective components while assembling or
checking the device, or if you hear any unusual noises coming from the device during use,
stop immediately. Do not use the device until the problem has been rectified.
– Wear suitable clothing while using the device. Avoid wearing loose clothing that may get caught
in the device or that may restrict or prevent movement.
– The max user weight is 136 KGS. Braking ability is independent of speed.
– The device is not suitable for therapeutic use.
– Care must be taken when lifting or moving the device so as not to injure your back. Always use
proper lifting techniques and/or seek assistance if necessary.
– Please keep the space at least 1 to 2 meter at the end of base frame to escape any accidents!
– Place the device on a clean and flat surface. Do not place the device on a thick carpet.
– The device is for indoor use and not for outdoor use to prevent damage. Keep the storage location
dry, clean and flat. It is forbidden to use the device for purposes other than training.
– Only use the machine in an environment with an ambient temperature between 10 °C and 35 °C.
Only store the device at an ambient temperature between 5 °C and 45 °C.
Warranty claim is excluded if the cause of the defect is the result of:
– Maintenance assembly and repair work not carried out by an official dealer.
– In the event of improper use, neglect and / or poor maintenance.
– Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed
manual).

EN
Virtufit TR-100 Treadmill 5
TOOLKIT
CHECKLIST
When you open the carton, and you will find the below parts in the carton:
#DESCRIPTION QTY
1Main frame 1
12 Allen key 5mm 1
51 Bold 4
64 Lock washer 6
71 Security key 1
72 Oil bottle 1
70 Bolt 2
85 MP3 cable 1
NOTE: Do not connect the appliance to the mains before it has been completely set up.

EN Virtufit TR-100 Treadmill
6
Missing parts: If you think you are missing certain parts in your package, carefully check the styrofoa and
the device. Some parts (bolts, screws, etc.) are already attached to/in the device.
Error message: Ensure that all cables are carefully attached. The aluminum legs are very sensitive and
must remain straight. Do you receive an error message after mounting your device? Then you have to
straighten these aluminum legs again, this may cause the error message to disappear.
Socket screws: The device contains socket screws, make sure that the allen key is firmly in the
bolt before you apply force to the key. In this way you prevent the head of the socket head screw from
being rotated.
STEP 1
• Open the carton, get out the above spare parts, put the Main Frame on the level ground.
ASSEMBLY INSTRUCTIONS

EN
Virtufit TR-100 Treadmill 7
STEP 2
• Hold the console frame, use the 5# Allen Wrench, lock the console frame onto left and right upright
tube with bolt M8*16(51)& lock washer (64) as the picture above.
NOTE: When folding, please don’t press the computer connecting wires.
ASSEMBLY INSTRUCTIONS

EN Virtufit TR-100 Treadmill
8
STEP 3
• Hold up the Upright.
NOTE: Please hold the L& R upright, avoid to have any hurt.
ASSEMBLY INSTRUCTIONS

EN
Virtufit TR-100 Treadmill 9
STEP 4
• Use the 5# Allen wrench, drill through the Bolt M8*45 (70) to Lock Washer (64), then lock the right
upright onto base frame.
• Use 5# Allen wrench, drill through M8*16 Bolt (51) to Lock Washer (64) then lock the right upright
tubes into the main frame. Reference the picture above.
NOTE: Hold the upright tube at when locking the upright tube to main frame.
ASSEMBLY INSTRUCTIONS

EN Virtufit TR-100 Treadmill
10
STEP 5
• Put on the safety key (71) on the computer.
ASSEMBLY INSTRUCTIONS

EN
Virtufit TR-100 Treadmill 11
FOLDING INSTRUCTIONS
NOTE: Store your machine in a dry area away from children and high trac areas as shown in the
illustration. Be sure it is secure and cannot fall onto small animals or children.
NOTE: Check if everything is assembled according to the instruction and that the bolts are tight. If
everything has been checked properly, please follow the following instructions. Before using the
treadmill, read the instructions carefully.
FOLDING
UNFOLDING
Hold the position A, pull up the machine, till
cylinder gets the position B.
Support the position A, kick the position B by
foot, and pull down the machine a little, the
machine will fall down automatically. Please
keep people and animal away to escape any
hurt.

EN Virtufit TR-100 Treadmill
12
GROUNDING AND ADJUSTMENT
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This product is equipped with a
cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into
an appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
NOTE:
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualied electrician or serviceman if you are in doubt as to whether the product is
properly grounded.
• Do not modify the plug provided with the product – if it will not t the outlet, have a proper outlet
installed by a qualied electrician.
• Make that the product is connected to an outlet having the same conguration as the plug. No
adapter should be used with this product.
GROUNDING METHOD
ADJUSTMENT GUIDE RUNNING BELT
01. Running belt deviates to left: Start the machine, set speed at 2-3 km/h without a load on the belt,
use Allen key to turn the screw 1/4 turn (see fig. 1). Then allow the machine to run without a load for 1-2
minutes. Repeat process until the belt becomes central.
02. Running belt deviate to right: Start the machine, set speed at 2-3 km/h without a load on the belt,
use Allen key to turn the screw 1/4 turn (see fig. 2). Then allow the machine to run without a load for 1-2
minutes. Repeat process until the belt becomes central.
03. Running belt jam: If the running belt is in dead condition, use the Allen key to turn the screw 1/2 a
turn both left and right until the jam solved (see fig 3).

EN
Virtufit TR-100 Treadmill 13
MAINTENANCE
SEMIANNUAL MAINTENANCE
ATTENTION
DAILY MAINTENANCE
• Clean and remove sweat after each use Do not use aggressive cleaning agents and ensure that
the device remains free of moisture.
• Check that the rail and the wheels under the seat are free from dust and dirt.
• Inspect all bolts and nuts in connection with moving parts of the device, tighten as required.
• Check the mobility of moving parts and components of the use equipment, silicone spray if
necessary.
Safeandeectiveusecanonlybeachievedifthedevicewillbeassembledandmaintained
well. It is your responsibility to ensure that the equipment is regularly maintained. Parts
that are already used and / or damaged must be replaced before continuing using. The
rower machine may only be used indoors and stored away, prolonged exposure to
weathering and changes in temperature / humidity can have a serious impact on the
electrical components and moving parts of the device.
Always unplug the treadmill power cord before cleaning or servicing the equipment.
Cleaning:General cleaning of the device will extend the life of the treadmill. Hold
clean the treadmill by dusting regularly. Be sure to clean the exposed area of the belt and the foot rails of
the treadmill on both sides.
In addition, wear clean shoes to reduce the risk of contamination of the treadmill. Remove the hood at least once
a year to vacuum underneath.

EN Virtufit TR-100 Treadmill
14
This treadmill is equipped with a pre-lubricated, low maintenance deck system. The belt/ deck friction
may play a major role in the function and life of your treadmill, thus requiring periodic lubrication. We
recommend a periodic inspection of the deck. You need contact with our service center if you nd the
damage of the deck.
We recommend lubrication of the deck according to the following timetable:
•Light user (less than 3 hours/ week) annually
•Medium user (3-5 hours/ week) every six months
•Heavy user (more than 5 hours/ week) every three months
Best indicator is to lubricale when the walking platform feels dry. We recommend that you buy the
lubrication from our distributor or directly to our company.
NOTE: Any repair need the professional technician.
• We suggest that you should cut o the power for 10 minutes after keep running 2 hours, so that it’s
good for maintain the treadmill.
• For avoiding the slipping during running, the belt not too loose; for avoiding the more abrasion
between the roller and belt and maintain the machine’s good running ,the belt not too tight. You can
adjust the distance between plates and belt, the belt be away from the plates about 50-75 mm on
both sides, if the best not too tight and loose.
We strongly recommend that you do the following
• Switch o and remove the power cable from the wall after every use, especially if children are
present.
• Clean your treadmill after use.
• Use a dry cloth to clean the control panel and areas around the power switch. Use a soft clean cloth
and cleanser to remove stubborn stains and dirt o the running belt.
• Tighten the running belt once a month.
• Keep your treadmill in a safe dry place away from heat and water.
LUBRICATING THE BELT
MAINTENANCE

EN
Virtufit TR-100 Treadmill 15
MAINTENANCE
USAGE OF SILICONE OIL
Pull up tightly of the running belt. Then put the
silicone oil to running board. Then start the machine
to running 3 minutes without loading. It is better
to maintain like this every 30 hours working of the
machine. This can save lifetime of parts properly.
We recommend that you do the following:
• Disconnect the power cord after every use, especially when children are present.
• Clean the treadmill after use.
• Use a dry cloth to cover the control panel and areas around the on/o switch clean.
• Use a soft clean cloth and detergent to remove stubborn stains and dirt from the treadmill.
• Tighten the treadmill once a month.
• Keep your treadmill away from heat and water in a safe, dry place.
Regular maintenance prolongs the life of your treadmill and prevents injury!

EN Virtufit TR-100 Treadmill
16
TROUBLE SHOOTING
CODE SOLUTION
E01
Problem: Signal failed between computer and console.
Solution: Check if the wire is undamaged and properly connected, if so replace the circuit
board of the computer or console.
E02
Problem: The motor voltage is not recognized by the controller.
Solution: Check if the positive and negative cable of the motor is properly connected with
the terminal interface of the controller, if that is okay, check if the end tube that is on the
controller and peripheral equipment is damaged. Then consider replacing the console or
motor.
E03
Problem: Speed display is not recognized by the console when the engine is running.
Solution: First check if the engine is running when the machine is started and it shows E03,
then see if the light sensor is good, see if the wire of it is tight or if the transition between
the light sensor and the 4 white pins of the controller are well connected. If all of the above
is correct, see if the area around the 4 white pins on the peripherals are damaged, if not
consider replacing the console and circuit board. If the engine is not running when you
start the machine, and it shows E03, check if the engine is broken and consider replacing
the engine.
E05
Problem: When the motor is running, the voltage exceeds the protection value.
Solution: Check that the motor is in good condition and that there is something stuck
between the conveyor belt which increases the motor resistance. If all of the above is
correct, replace the console.
E07
Problem: Security key signal is not recognized by the computer, showing E07 or “--- --- ---”.
Solution: Check if the magnetic parts of the safety key are good plugged in.
ERROR CODES

EN
Virtufit TR-100 Treadmill 17
PROBLEM SOLUTION
Speed is not right Solution: Take E03 as an example.
No power
Solution:
• Check if the fuse is good.
• Check that the entire connection cable is properly connected to the
console.
Abnormal motor control
Solution:
• Check if the motor is normal or replace the motor.
• Confirm that the motor has no problems.
Engine burned out
Solution:
• Check if the console is also burnt out.
• Replace the motor.
• Replace the console.
Slope is not right
Solution: Check if the slope motor wire and 3 pin wire is properly
connected to the console, if that is okay, please do as follows:
1. Remove the computer cable installed on the console (security key), turn
on the device, press the small key the right corner of the controller for 2
seconds.
2. Release the button, the ramp motor will detect itself stating it the device
at the highest incline and after a while again will drop to the lowest
incline.
3. If the motor hits the ground after 3 seconds, it is automatic detection
process over.
4. After automatic detection, close the computer (or security key) on,
operate the computer function and test that the incline function works.
5. Or replace the console.
Power failure Solution: Check if the wire is connected properly.
No screen display
Solution:
• Check that the voltage is correct.
• Check if the power supply is 8V, change the console, if not, change the
computer.
LCD screen display
Solution:
• Check if the power is good.
• Check if the power supply is 8V, change the console, if not, change the
computer.
Sceen display is poor Solution: First turn off the device, restart the engine, see if the screen is
back to normal, if not, take out the computer and the fixed PCB.
TROUBLE SHOOTING

EN Virtufit TR-100 Treadmill
18
TROUBLE SHOOTING
PROBLEM SOLUTION
Screen display does not
work properly
Solution: First turn off the device, restart the engine, if the problem is still
not resolved, replace the computer.
Backlight is not bright
Solution:
• Turn off the device, restart the engine.
• Start the computer, see if the cable is properly connected, see if it
background light is damaged or not.
• Change the computer.
USB card does not play the
music
Solution: Test if the MP3 connection is normal, if it does not work normally,
open the computer to see if there is a good connection with the amplifier.
Connection is good, just like the MP3 connection, replace the USB to try
again or replace the computer.
Safety pin has no effect
Solution:
• Check that the safety pin is properly inserted.
• Take out the computer, make sure the switch and wire are in good
condition or replace the computer.
Button has no function
Solution:
• If it’s just one button that doesn’t work, open the computer program,see
if any key is damaged or replace the computer.
• If most buttons do not work, turn the computer back on see if the keys
still don’t work or replace the computer
Push button without
influence
Solution:
• Wash your hands and test again.
• Check that the cables of the handle, which measure the heart rate,
damaged and that they are properly connected to the connector.
• Change the circuit board or computer.
Button of handle has no
function
Solution:
• Check that the cables of the handle, which measure the heart rate,
damaged and that they are properly connected to the connector.
• Change the computer.
Hand sensors do not work
Solution:
• Wash your hands and hold the handle again.
• Check if the thread of the handle is good.
• If connection is good, change the computer.
Button on the handle does
not work
Solution:
• Check that the handle wire is good and the connection is good is
connected.
• Please replace the handle.

EN
Virtufit TR-100 Treadmill 19
CONSOLE
BUTTON FUNCTION
TIME Shows time.
DISTANCE Shows distance.
CALORIEN Shows calories.
PULSE Shows heart beat.
SPEED Shows speed.
INCLINE Shows incline.
CONTROL PANEL

EN Virtufit TR-100 Treadmill
20
FUNCTIONS
CONTROL PANEL
BUTTON FUNCTION
PROGRAM Press this button to select a program of manual mode: P1 --- P15 ---- “FAT”.
MODE When the machine is ready, press this button to choose the mode: time
mode countdown, distance mode countdown, calorie mode countdown.
START Press this button to start the machine, the machine will start at the lowest
speed or with the speed of the standard program after 3 seconds.
STOP Press this button to stop the machine, the machine will come to a slow stop.
SPEED ^^/v Sets the speed. Press this button to adjust the speed while running and
adjust it when you stop.
SPEED
3, 6, 9, 12 Adjusts the speed in quick steps.
INCLINE ^^/v Adjust the incline. Press the button to adjust incline section when run, and
adjust the data when stop.
INCLINE
3, 6, 9, 12 Adjust the incline quickly.
BUTTON
HANDLE R Speed button.
