VirtuFit Elite Smart Touch Treadmill 3
– It is important to read this entire manual before assembling and using the device. Safe and
effective use can only be achieved if the device is assembled, maintained and used properly.
It is your responsibility to ensure that all users of the device are informed of all warnings and
precautions.
– Before starting any exercise program, you should consult your doctor to determine if you have
any medical or physical conditions that could put your health and safety at risk, or prevent you
from using the device properly. Your doctor’s advice is essential if you are taking medication
that affects your heart rate, blood pressure or cholesterol level.
– Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, extreme shortness of breath, lightheadedness, dizziness or feelings of nausea. If you do
experience any of these conditions you should consult your doctor before continuing with your
exercise program.
– Keep children and pets away from the device. The device is designed for adult use only.
– Use the device on a solid, flat level surface with a protective cover for your floor or carpet. To
ensure safety, the device should have at least 0.5 metres of free space all around it.
– Before using the device, check that the nuts and bolts are securely tightened.
– The safety of the device can only be maintained if it is regularly examined for damage and/or
wear and tear.
ATTENTION
WARNING:
Before beginning any exercise program consult your physician. This is especially
important for people who are over 35 years old or who have pre-existing health
problems. Read all instructions before using any fitness equipment. Do not operate this
device without properly fitted guards, as the moving parts can present a risk of serious
injury if exposed.
SAFETY INSTRUCTIONS

EN VirtuFit Elite Smart Touch Treadmill
4
– Always use the device as indicated. If you find any defective components while assembling or
checking the device, or if you hear any unusual noises coming from the device during use,
stop immediately. Do not use the device until the problem has been rectified.
– Wear suitable clothing while using the device. Avoid wearing loose clothing that may get caught
in the device or that may restrict or prevent movement.
– The max user weight is 150 KGS. Braking ability is independent of speed.
– The device is not suitable for therapeutic use.
– Care must be taken when lifting or moving the device so as not to injure your back. Always use
proper lifting techniques and/or seek assistance if necessary.
– Please keep the space at least 1 to 2 meter at the end of base frame to escape any accidents!
– Place the device on a clean and flat surface. Do not place the device on a thick carpet.
– The device is for indoor use and not for outdoor use to prevent damage. Keep the storage location
dry, clean and flat. It is forbidden to use the device for purposes other than training.
– Only use the machine in an environment with an ambient temperature between 10 °C and 35 °C.
Only store the device at an ambient temperature between 5 °C and 45 °C.
Warranty claim is excluded if the cause of the defect is the result of:
– Maintenance assembly and repair work not carried out by an official dealer.
– In the event of improper use, neglect and / or poor maintenance.
– Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed
manual).
SAFETY INSTRUCTIONS

EN
VirtuFit Elite Smart Touch Treadmill 5
TOOLKIT
#DESCRIPTION QTY
AMainframe 1
BConsole support frame 1
CConsole 1
DSafety key 1
D14 Standard power cord 1
C05 Lower cover console 1
C08 Left column outer cover 1
C09 Right cover outer cover 1
#DESCRIPTION QTY
C10 Left column inner cover 1
C11 Right cover inner cover 1
C12 Foam armrest 2
C13 Screw hole plug 4
C14 Armrest tube plug 2
C36 Left bottom shield 1
C37 Right bottom shield 1
EOil bottle 1
CHECKLIST
When you open the carton, and you will find the below parts in the carton.

EN VirtuFit Elite Smart Touch Treadmill
6
ASSEMBLY TOOLS
Note: DO NOT plug in the power supply until the installation is complete.
Installation Steps
1. Unpacking
4
CHECKLIST

EN VirtuFit Elite Smart Touch Treadmill
7
Missing parts: If you think you are missing certain parts in your package, carefully check the styrofoa and
the device. Some parts (bolts, screws, etc.) are already attached to/in the device.
Error message: Ensure that all cables are carefully attached. The aluminum legs are very sensitive and
must remain straight. Do you receive an error message after mounting your device? Then you have to
straighten these aluminum legs again, this may cause the error message to disappear.
Socket screws: The device contains socket screws, make sure that the allen key is firmly in the
bolt before you apply force to the key. In this way you prevent the head of the socket head screw from
being rotated.
NOTE! Do not plug in the power cord until installation is complete.
STEP 1
• Open the packaging and place the main frame (A) on the floor.
ASSEMBLY INSTRUCTIONS

EN
VirtuFit Elite Smart Touch Treadmill 8
STEP 2
• Install the left and right uprights (A03, A04). Lift it upright as shown in the picture.
• Install the left and right uprights (A07, A08) to the main frame using the Allen key (B07) around the
M8 * 15 bolt (E15) and the lock washer (E32)
ASSEMBLY INSTRUCTIONS

EN VirtuFit Elite Smart Touch Treadmill
9
STEP 3
ASSEMBLY INSTRUCTIONS
• Now install the Display Support Frame (B).
• Connect the top cable (D09) to the bottom cable (D10). This runs out of the right upright (A04). It is
important that the bakels are attached carefully.
• Use Allen key 5 (B07) and the M8 * 15 bolts (E15) to attach the support frame to the frame.
• Use sealing plug (C14) to neatly close the bolts.

EN
VirtuFit Elite Smart Touch Treadmill 10
STEP 4
ASSEMBLY INSTRUCTIONS
• Install the display (C)
• Connect the cables from the display (C) to the cables from the support frame (B).
6
4. Connect the instrument wiring .
P
A
C
5. Install the instrument and install the middle and lower covers of the electronic watch.
E15
#
( )
( )
( )
P
A
( )

EN VirtuFit Elite Smart Touch Treadmill
11
STEP 5
6
4. Connect the instrument wiring .
P
A
C
5. Install the instrument and install the middle and lower covers of the electronic watch.
E15
#
( )
( )
( )
P
A
( )
ASSEMBLY INSTRUCTIONS
• Place the protective cover (C05) under the support frame (B).
• Attach the display (C) to the support frame (B). To do this, use Allen key 5 (B07) and the and M8 * 15
bolts (E15) with the corresponding lock washers (E32).

EN
VirtuFit Elite Smart Touch Treadmill 12
STEP 6
ASSEMBLY INSTRUCTIONS
• Place the left and right hand rests (C12)
• Use Allen key 5 (B07) and the and M8 * 15 bolts (E15) to attach the palm rests to the support frame.
• Close the bolts with the corresponding blanking plugs (C15)
Install the left and right handles.

EN VirtuFit Elite Smart Touch Treadmill
13
STEP 7
ASSEMBLY INSTRUCTIONS
• Attach the upright cover (E24)
• Use the Phillips screwdriver (B08) and the screws (E24) to attach the cover.

EN
VirtuFit Elite Smart Touch Treadmill 14
STEP 8
ASSEMBLY INSTRUCTIONS
• Attach the left and right guards. (C36, C37).
Install the left and right bottom shields.

EN VirtuFit Elite Smart Touch Treadmill
15
STEP 9
ASSEMBLY INSTRUCTIONS
• Cut the packing strap (P).

EN
VirtuFit Elite Smart Touch Treadmill 16
STEP 10
ASSEMBLY INSTRUCTIONS
• Use the Allen key 5 (B07) and loosen the M8 * 15 bolt to remove the f-module (G).
ATTENTION
•When using the treadmill, always go before the treadmill rolls on the rails stand. Once the tire rolls,
you can stand on the walking platform. In this way, the engine least loaded.
•After using the treadmill, turn off the power switch (on / off). In addition, do not use the emergency
stop unnecessary, only in an emergency. In this way, the circuit board is least loaded.
Remove the running board safety device.

EN VirtuFit Elite Smart Touch Treadmill
17
SAFETY KEY
• Install the safety key in the console.
• When you start walking, attach the safety key to your clothing. Pull at one emergency on the key
safety lanyard and the treadmill will stop immediately.
ASSEMBLY INSTRUCTIONS

EN VirtuFit Elite Smart Touch Treadmill
18
NOTE! Store your machine in a dry area away from children and high trac areas as shown in the
illustration. Be sure it is secure and cannot fall onto small animals or children.
FOLDING
UNFOLDING
Hold the treadmill by the end. Push the
treadmill up until you hear a click of the gas
spring.
NOTE! Do not fold the treadmill while it is
in use.
Hold the treadmill by the end. Press against
the gas spring with your foot. Press down
on the walking platform and pull your foot
away. The walking platform will then lower
automatically.
FOLDING INSTRUCTIONS

EN
VirtuFit Elite Smart Touch Treadmill 19
MOVING THE TREADMILL
Before you can move the treadmill, it must
be folded.
Hold the walking platform rmly, step on
one of the wheels with your foot.
Push the walking platform down until the
transport wheels are both on the ground.
From this moment on, the treadmill can be
moved.
FOLDING INSTRUCTIONS

EN VirtuFit Elite Smart Touch Treadmill
20
The treadmill has passed the evenness test before leaving the factory. If the floor is uneven, please adjust
knob C30 in the figure.
ADJUSTMENTS GUIDE
LEVELING THE TREADMILL
RUNNING BELT ADJUSTMENT
01. Running belt deviates to left: Start the machine, set speed at 2-3 km/h without a load on the belt,
use Allen key to turn the screw 1/4 turn (see fig. 1). Then allow the machine to run without a load for 1-2
minutes. Repeat process until the belt becomes central.
02. Running belt deviate to right: Start the machine, set speed at 2-3 km/h without a load on the belt,
use Allen key to turn the screw 1/4 turn (see fig. 2). Then allow the machine to run without a load for 1-2
minutes. Repeat process until the belt becomes central.
03. Running belt jam: If the running belt is in dead condition, use the Allen key to turn the screw 1/2 a
turn both left and right until the jam solved (see fig 3).
