Vividia VA-455 User manual

Vividia VA-455 Two-Way Articulating
Smartphone Borescope
Model: VA-455
Vividia Technologies
www.vividia-tech.com

Vividia VA-455 car borescope is an
important product for the global car
aftermarket. It is specially used to detect
narrow bending spaces that are difficult to
enter, such as car evaporator, combustion c h
a m b e r s , a n d t h r e e - w a y c a t a l y t i
c sensors. The product has a unique
temperature protection function and is
equipped with a two-way 180° steering
detection function, which allows users to take
small probes into a small space, and then
transmit vivid, clear and all-round video and
pictures to the mobile phone through the
cable and shown on the screen. Meet
your diverse inspection n e e d s w i t h a
d v a n c e d e x t e n d e d accessories and
real-time temperature display.
Warning: Please read this manual carefully before using this product, and follow the
instructions to avoid the damage caused by improper use.
Automobile Bores c ope VA-455 Introduct ion
1
2、弹性蛇管
NO.
Name
1
Mobile Phone Holder
2
Rotate Wheel
3
Handle
4
Snake Tube
5
Megapixel HD Probe
6
USB Inteface
7
Type-c Charging Interface
8
Working/Charging Indicator
9
Power On/Off,LED Adjust
10
Photo/Video Button
1
8
10
9
76
5
4
3
2
1 Appearance
2
Note: The probe temperature of this
product can not exceed 90 °C
Use the data cables in the package for connection btw phone and borescope.

1.Mobile phone Installation
Adjust the rotated knob of the mobile phone holder, insert the mobile phone into the holder(Support 3.5-inch -- 6.3-inch
screen mobile phone), Connect the phone and the handle with a data cable.
2.Power On/Off
Press on the handle 2 seconds for power on,Work indicator light green,Android mobile phone will open the APP
automatically(Apple mobile phone needs to be clicked to open the APP )，the snake tube LED is lighting on,the search
interface appears,presenting the image,press 2 seconds for power off.
3.Adjust LED
Power on and the LED is the brightest by default,press to adjust the brightness;brightness is divide into 3
gear,the 4th gear is LED turn off.
4.Photograph and video
Press on the handle to take photo,photo is saved in the Finder/CameraData directory of the mobile phone,the
format is JPG;Press on the handle 2 second to video,video is saved in the Finder/CameraData directory,the format is
Mp4.
5.PDF Generation
In APP click settings , click PDF to generate the setting footer,header,LOGO,click PDF Create to input
information,as fuel system test sheet can be generated.
6.Charging
Pls use the 5V adapter or mobile power to connect Type-c USB cable for charging.The charging voltage and current is
5V/1A,too high voltage may burn out the borescope.Notice:Fast charging is not supported.
7.Floating window setting
In APP click setting ,on “Floating window”click open.
安装指南：
1.Android mobile device: Search "Finder Borescope" in Google Play store, or Scan the QR code to
download and install APP. The app can be downloaded from apkpure.com
2.For iPhone device please search and install “Finder Borescope”in the App Store, or scan the QR code below to
download and install the APP.
AndroidiOS
/
/
/
3.For professional sevice personnel,this productscan be
used in the case of non-disassembleor damage the
instrument,used to detectthe blind zone.Can be applied to
instrument testing,engine maintenance,vehicle repair,pipe
inspection,building inspection and air conditioning
evaporator inspection and so on.
2: Mobile phone Download&installation guide 3: Operation instructions
34
/
/
Note: VA-455 is not compatible with Windows PC, Mac etc.

Camera lens diamerter
5.5mm
Battery Life
60-70 Minute
Snake Tube Length
1m
Interface
USB2.0
Snake Tube Material
Flexible Mental
Resolution
1280*720
DOF
15-45mm
Video resolution
MP4（1280*720）
FOV
100°
Photo resolution
JPG1280*720）
Manual LED Adjustment
Support
Lighting Source
4 pcs LED
Power source
Polymer Lithium Battery 1500mAh
Sensor
1/9"CMOS
Operating
Temp
Probe
In Air: -10 to 50°C
All Parts
In Air: -10 to 50°C
Input:DC5V
Humidity
All Parts
15 to 90％
Ingress
Protection
All Parts
Not operable in the rain
Not operable in water
For professional sevice personnel,this products can be used in the
case of non-disassemble or damage the instrument,used to detect
the blind zone.Can be applied to instrument testing,engine
maintenance,vehicle repair,pipe inspection,building inspection
and air conditioning evaporator inspection and so on.
4: VA-455 Parameter
5: Application Environment
5
ŸImportant safety matters
ŸPlease don't use our camera with other manufacturers monitor,even
same interface.
ŸDon't use the product in certain areas where it may be exposed to a wire
or charged area.The exposed metal parts can be electrically conductive
and may cause unexpected accidents.
ŸDon't allow children to operate the product separately,prohibit the use of
the product for medical or human testing.
ŸKeep the product clean,avoid exposure,or be in direct contact with
water,oil and corrosive liquids.
ŸIt is whole machine is not waterproof.
ŸConfirm that the dial is returned to the neutral position to pull out the
snake tube, forbid to rotate the dial roughly.
ŸForbid to twist and pull the curved body at the front of the snake tube.
ŸPlease take it lightly,don't overturn the tube,the Bending limit is one
circle.
ŸPlease use the original USB cable charge.
Ÿ1. T h an k yo u f o r ch oo si n g t h i s pr o d uc t, t hi s pr o d uc t is a w el l-
designed,durable video industrial endoscope.Under normal use and
maintenance should be able to play its superior performance.Within six
months from the purchase date,if there is any damage caused by the
manufacturing process or components,we will provide free maintenance
service for the licensee and replace the parts as appropriate.
Ÿ2.Within six months from the purchase date,you will receive a free
wa r rant y se rvic e if ou r profe s sion a l maint e nance pe r sone l ha ve
confirmed that damages caused by the manufacturing process or the bad
parts.
Ÿ3.Snake tube is a vulnerable part,since the purchase date,the warranty
for six months.Normal use caused by wear,not including part of the
warranty.The following conditions will not be available free of charge.
Below situation is unavailable in free serve:
ŸDamage caused by improper storage.
ŸThe customer is disassembling and causing damage.
ŸDamage caused by the customer's own modification.
ŸDamage caused by improper use.
ŸDamage caused by other irresistible factors.
Guarantee Card
Customer name:
Customer phone:
Purchase date:
Sending back date:
Unfavorable conditi:
Maintenance time:
Repair result:
Maintainer:
Customer address:
6
6: Precautions 7: Warranty regulations
